LIVARNO LUX 434404-2304 User manual

IAN 434404_2304
FERNBEDIENUNG
DES LED-BANDS
Bedienungs- und Sicherheitshinweise
LED STRIP LIGHT REMOTE CONTROL
LED STRIP LIGHT
REMOTE CONTROL
Operation and safety notes
ΤΗΛΕΧΕΙΡΙΣΜΌΣ ΤΗΣ
ΤΑΙΝΙΑΣ LED
Υποδείξεις χειρισμού και ασφαλείας
Auto
w/ww
IC Set
CS
C3
C7
C16
Flash
Jump
Meteor

GB/IE/NI/CY Operation and safety notes Page 5
GR/CY Υποδείξεις χειρισμού και ασφαλείας Σελίδα 23
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 45
Before reading, unfold the page containing the illustration and familiarise yourself with all
functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με την εικόνα και εξοικειωθείτε με όλες τις
λειτουργίες της συσκευής.
Kl appen Sie vor dem Lesen die Seite mit der Abbildung aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

Auto
w/ww
IC Set
CS
C3
C7
C16
Flash
Jump
Meteor

5GB/IE/NI/CY
LED strip light remote control
Switching the LED strip on /
off using the remote control
Be sure there are no obstacles between the transmitter and receiver.
Press the button on the remote control to switch the LED strip on
or off.
Controlling lighting effects
using the remote control
The remote control has 24 buttons. The functions of these buttons are:
Determining the lighting area of the LED strip:
w/ww
IC Set After pressing this button, repeated press the or button
to switch groups of three lights of the LED strip on or off,
starting from the end.
Static color selection buttons:
White light
w/ww After pressing this button all LEDs light up in white. Press the
button again to switch between white and warm white.

6 GB/IE/NI/CY
Dim the lamp / set speed:
Use the two arrow keys / to dim the lamp in 6 increments or to
set the speed.
The LED strip has a memory function.
After switching off, it will start in the last selected setting.
Modes But-
ton 1
But-
ton 2
Function
1
CS
Single color of Red
2 Single color of Green
3 Single color of Blue
4 Single color of Yellow
5 Single color of Purple
6 Single color of Cyan
7 Single color white
8 Single color warm white
9C3 3 colors simultaneously (RGB)
10 C7 7 colors simultaneously
11 C16 16 colors simultaneously

7GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
12
CS
Chaser, Single color of Red.
Starting from the centre to both ends.
13 Chaser, Single color of Green.
Starting from the centre to both ends.
14 Chaser, Single color of Blue.
Starting from the centre to both ends.
15 Chaser, Single color of Yellow.
Starting from the centre to both ends.
16 Chaser, Single color of Purple.
Starting from the centre to both ends.
17 Chaser, Single color of Cyan.
Starting from the centre to both ends.
18 Chaser light, White.
Running from the centre to both ends.
19 Chaser light, Warm White.
Running from the centre to both ends.
20 C3 Chaser, multi-color (RGB).
Starting from the centre to the ends.
21 C7 Chaser, multi-color (7 colors).
Starting from the centre to the ends.
22 C16 Chaser, multi-color (16 colors).
Starting from the centre to the ends.

8 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
23
CS
Chaser, Single color of Red.
Starting from the ends to the centre.
24 Chaser, Single color of Green.
Starting from the ends to the centre.
25 Chaser, Single color of Blue.
Starting from the ends to the centre.
26 Chaser, Single color of Yellow.
Starting from the ends to the centre.
27 Chaser, Single color of Purple.
Starting from the ends to the centre.
28 Chaser, Single color of Cyan.
Starting from the ends to the centre.
29 Chaser light, White.
Running from the ends to the centre.
30 Chaser light, Warm White.
Running from the ends to the centre.
31 C3 Chaser, multi-color (RGB).
Starting from the ends to the centre.
32 C7 Chaser, multi-color (7 colors).
Starting from the ends to the centre.
33 C16 Chaser, multi-color (16 colors).
Starting from the ends to the centre.

9GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
34
CS
Waterfall effect chaser of Single color -
Red (illuminated, not illuminated).
Running from the end to the start.
35
Waterfall effect chaser of Single color -
Green (illuminated, not illuminated).
Running from the end to the start.
36
Waterfall effect chaser of Single color -
Blue (illuminated, not illuminated).
Running from the end to the start.
37
Waterfall effect chaser of Single color -
Yellow (illuminated, not illuminated).
Running from the end to the start.
38
Waterfall effect chaser of Single color -
Purple (illuminated, not illuminated).
Running from the end to the start.
39
Waterfall effect chaser of Single color -
Cyan (illuminated, not illuminated).
Running from the end to the start.
40
Waterfall effect chaser of Single color -
White (illuminated, not illuminated).
Running from the end to the beginning.
41
Waterfall effect chaser of Single color -
Warm White (illuminated, not illuminated).
Running from the end to the beginning.
42 C3
Waterfall effect chaser of multi-color
(RGB) (illuminated, not illuminated).
Running from the end to the start.
43 C7
Waterfall effect chaser of multi-color
(7 colors) (illuminated, not illuminated).
Running from the end to the start.

10 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
44 C16
Waterfall effect chaser of multi-color
(16 colors) (illuminated, not illuminated).
Running from the end to the start.
45
CS
Waterfall effect chaser of Single color -
Red (illuminated, not illuminated).
Running from the start to the end.
46
Waterfall effect chaser of Single color -
Green (illuminated, not illuminated).
Running from the start to the end.
47
Waterfall effect chaser of Single color -
Blue (illuminated, not illuminated).
Running from the start to the end.
48
Waterfall effect chaser of Single color -
Yellow (illuminated, not illuminated).
Running from the start to the end.
49
Waterfall effect chaser of Single color -
Purple (illuminated, not illuminated).
Running from the start to the end.
50
CS
Waterfall effect chaser of Single color -
Cyan (illuminated, not illuminated).
Running from the start to the end.
51
Waterfall effect chaser of Single color -
White (illuminated, not illuminated).
Running from the beginning to the end.
52
Waterfall effect chaser of Single color -
Warm White(illuminated, not illuminated).
Running from the beginning to the end.
53 C3
Waterfall effect chaser of multi-color
(RGB) (illuminated, not illuminated).
Running from the start to the end.

11GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
54 C7
Waterfall effect chaser of multi-color
(7 colors) (illuminated, not illuminated).
Running from the start to the end.
55 C16
Waterfall effect chaser of multi-color
(16 colors) (illuminated, not illuminated).
Running from the start to the end.
56
CS
Running light, alternating white light
& single color - Red.
Running from the end to the start.
57
Running light, alternating white light
& single color - Green.
Running from the end to the start.
58
CS
Running light, alternating white light
& single color - Blue.
Running from the end to the start.
59
Running light, alternating white light
& single color - Yellow.
Running from the end to the start.
60
Running light, alternating white light
& single color - Purple
Running from the end to the start.
61
Running light, alternating white light
& single color - Cyan
Running from the end to the start.
62
Running light, alternating white light
& single color - White
Running from the end to the start.
63
Running light, alternating white light
& single color - Warm White.
Running from the end to the start.

12 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
64 C3
Running light, alternating white light
& multi-color (RGB).
Running from the end to the start.
65 C7
Running light, alternating white light
& multi-color (7 colors)
Running from the end to the start.
66 C16
Running light, alternating white light
& multi-color (16 colors)
Running from the end to the start.

13GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
67
CS
Running light, alternating white light
& single color - Red.
Running from the start to the end.
68
Running light, alternating white light
& single color - Green.
Running from the start to the end.
69
Running light, alternating white light
& single color - Blue.
Running from the start to the end.
70
Running light, alternating white light
& single color - Yellow.
Running from the start to the end.
71
Running light, alternating white light
& single color - Purple
Running from the start to the end.
72
Running light, alternating white light
& single color - Cyan.
Running from the start to the end.
73
Running light, alternating white light
& single color - White.
Running from the start to the end.
74
Running light, alternating white light
& single color - Warm White.
Running from the start to the end.
75 C3
Running light, alternating white light
& multi-color (RGB).
Running from the start to the end.
76 C7
Running light, alternating white light
& multi-color (7 colors)
Running from the start to the end.

14 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
77 C16
Running light, alternating white light
& multi-color (16 colors)
Running from the start to the end.
78
CS
Dynamic light setup, Single color - Red.
Running from the end to the start.
79 D
ynamic light setup, Single color - Gr een.
Running from the end to the start.
80 Dynamic light setup, Single color - Blue.
Running from the end to the start.
81
Dynamic light setup, Single color - Yello w.
Running from the end to the start.
82 Dynamic light setup, Single color - Purple.
Running from the end to the start.
83
CS
Dynamic light setup, Single color - Cyan.
Running from the end to the start.
84
Dynamic lamp setting, Single color -
White.
Running from the end to the start.
85
Dynamic lamp setting, Single color -
Warm White.
Running from the end to the start.
86 C3 Dynamic light setup, multi-color (RGB).
Running from the end to the start.
87 C7
Dynamic light setup, multi-color
(7 colors)
Running from the end to the start.
88 C16
Dynamic light setup, multi-color
(16 colors)
Running from the end to the start.

15GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
89
CS
Dynamic light setup, Single color - Red.
Running from the start to the end.
90 Dynamic light setup, Single color - Green.
Running from the start to the end.
91 Dynamic light setup, Single color - Blue.
Running from the start to the end.
92
CS
D ynamic light setup, Single color - Yellow .
Running from the start to the end.
93 Dynamic light setup, Single color - Purple.
Running from the start to the end.
94 Dynamic light setup, Single color - Cyan
Running from the start to the end.
95
Dynamic lamp setting, Single color -
White.
Running from the start to the end.
96
Dynamic lamp setting, Single color -
Warm White.
Running from the start to the end.
97 C3 Dynamic light setup, multi-color (RGB).
Running from the start to the end.
98 C7 Dynamic light setup, multi-color (7 colors)
Running from the start to the end.
99 C16
Dynamic light setup, multi-color (16 color s)
Running from the start to the end.
100 CS
Falling star effect, Single color - Red
Dynamic light setup running from the
end to the start.

16 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
101
CS
Falling star effect, Single color - Green
Dynamic light setup running from the
end to the start.
102
Falling star effect, Single color - Blue
Dynamic light setup running from the
end to the start.
103
Falling star effect, Single color - Yellow
Dynamic light setup running from the
end to the start.
104
Falling star effect, Single color - Purple
Dynamic light setup running from the
end to the start.
105
Falling star effect, Single color - Cyan
Dynamic light setup running from the
end to the start.
106
Shooting star effect, Single color - White
Dynamic light setup running from the
end to the start.
107
Shooting star effect, Single color -
Warm White
Dynamic light setup running from the
end to the start.
108 C3
Falling star effect, multi-color (RGB)
Dynamic light setup running from the
end to the start.
109 C7
Falling star effect, multi-color (7 colors)
Dynamic light setup running from the
end to the start.

17GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
110 C16
Falling star effect, multi-color (16 colors)
Dynamic light setup running from the
end to the start.
111
CS
Falling star effect, Single color - Red
Dynamic light setup running from the
start to the end.
112
Falling star effect, Single color - Green
Dynamic light setup running from the
start to the end.
113
Falling star effect, Single color - Blue
Dynamic light setup running from the
start to the end.
114
Falling star effect, Single color - Yellow
Dynamic light setup running from the
start to the end.
115
CS
Falling star effect, Single color - Purple
Dynamic light setup running from the
start to the end.
116
Falling star effect, Single color - Cyan
Dynamic light setup running from the
start to the end.
117
Shooting star effect, Single color - White
Dynamic light setup running from the
start to the end.
118
Shooting star effect, Single color -
Warm White
Dynamic light setup running from the
start to the end.

18 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
119 C3
Falling star effect, multi-color (RGB)
Dynamic light setup running from the
start to the end.
120 C7
Falling star effect, multi-color (7 colors)
Dynamic light setup running from the
start to the end.
121 C16
Falling star effect, multi-color (16 colors)
Dynamic light setup running from the
start to the end.
122
CS
Water flow effect, altenating direction
of Single color - Red
123 Water flow effect, altenating direction
of Single color - Green
124 Water flow effect, altenating direction
of Single color - Blue
125 Water flow effect, altenating direction
of Single color - Yellow
126 Water flow effect, altenating direction
of Single color - Purple
127 Water flow effect, altenating direction
of Single color - Cyan
128 Water flow effect, altenating direction
of Single color - White
129 Water flow effect, altenating direction
of Single color - Warm White
130 C3 Water flow effect, altenating direction
of multi-color (RGB)
131 C7 Water flow effect, altenating direction
of multi-color (7 colors)

19GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
132 C16 Water flow effect, altenating direction
of multi-color (16 colors)
133
CS Flash
Indicator light effect with increasing
light intensity, Single color - Red
134 Indicator light effect with increasing
light intensity, Single color - Green
135 Indicator light effect with increasing
light intensity, Single color - Blue
136 Indicator light effect with increasing
light intensity, Single color - Yellow
137 Indicator light effect with increasing
light intensity, Single color - Purple
138 Indicator light effect with increasing
light intensity, Single color - Cyan
139 Indicator light effect with increasing
light intensity, Single color - White
140 Indicator light effect with increasing light
intensity, Single color - Warm White
141 C3 Flash Indicator light effect with increasing
light intensity, multi-color (RGB)
142 C7 Flash Indicator light effect with increasing
light intensity, multi-color (7 colors)
143 C16 Flash Indicator light effect with increasing
light intensity, multi-color (16 colors)

20 GB/IE/NI/CY
Modes But-
ton 1
But-
ton 2
Function
144
CS Jump
Indicator light effect of Single color -
Red, fast
145 Indicator light effect of Single color -
Green, fast
146 Indicator light effect of Single color -
Blue, fast
147 Indicator light effect of Single color -
Yellow, fast
148 Indicator light effect of Single color -
Purple, fast
149 Indicator light effect of Single color -
Cyan, fast
150 Indicator light effect of Single color -
White, fast
151 Indicator light effect of Single color -
Warm White, fast
152 C3 Jump Indicator light effect of multi-color
(RGB), fast
153 C7 Jump Indicator light effect of multi-color
(7 colors), fast
154 C16 Jump Indicator light effect of multi-color
(16 colors), fast
