LIVARNO LUX LSHB 150 A1 User manual

IAN 85950
HALOGEN FLOODLIGHT LSHB 150 A1
HALOGEN FLOODLIGHT
Operating instructions REFLECTOR CU HALOGEN
Instrucţiuni de utilizare
ΠΡΟΒΟΛΕΑΣ ΑΛΟГΟΝΟΥ
Οδηүίες χρήσης
HALOGENSTRAHLER
Bedienungsanleitung

GB/CY Operating instructions Page 1
RO Instrucţiuni de utilizare Pagina 13
GR/CY Οδηүίες χρήσης Σελίδα 25
DE/AT/CH Bedienungsanleitung Seite 37
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţiile aparatului.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

1
LSHB 150 A1
GB
CY
Index
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Information for these operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Limited liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Risks from electrical current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Appliance description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly / Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Selecting the installation location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Adjustment of the motion detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Changing the bulb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Notes on the Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
IB_85950_LSHB150A1_LB7.indb 1IB_85950_LSHB150A1_LB7.indb 1 10.01.13 13:5210.01.13 13:52

2LSHB 150 A1
GB
CY
Introduction
Information for these operating instructions
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating instruc-
tions are a part of this product. They contain important information in regard to
safety, use and disposal. Before using the product, familiarise yourself with all of
these operating and safety instructions. Use the product only as described and
only for the specified areas of application. Retain these instructions for future reference.
In addition, pass these documents on, together with the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction of it, including as extracts, as well as the reproduction
of images, also in an altered state, is only permitted with the written authorisation
of the manufacturer.
Limited liability
All technical information, data and instructions for the installation, connection and
operation contained in these operating instructions correspond to the latest avail-
able at the time of printing and, to the best of our knowledge, take into account
our previous experience and know-how.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to
observe these instructions, improper use, incompetent repairs, making unauthorised
modifications or for using unapproved replacement parts.
Intended use
This appliance is intended for use as a lighting system in indoor and covered
outdoor areas.
This appliance is not intended for any other use or for uses beyond those mentioned.
Claims of any kind for damage resulting from unintended use will not be accepted.
The operator alone bears liability.
IB_85950_LSHB150A1_LB7.indb 2IB_85950_LSHB150A1_LB7.indb 2 10.01.13 13:5210.01.13 13:52

3
LSHB 150 A1
GB
CY
Warnings
In the existing operation instructions the following warnings are used:
DANGER
A warning of this danger level indicates a threateningly
dangerous situation
If the dangerous situation is not avoided, it could lead to death or serious
physical injury.
► Pay heed to the instructions in this warning to avoid the death of or serious
physical injury to people.
WARNING
A warning of this danger level signifies a possible dangerous
situation.
If the dangerous situation is not avoided it can lead to physical injuries.
► Pay heed to the instructions in this warning to avoid personal injuries.
IMPORTANT
A warning of this danger level signifies possible property
damage.
If the situation is not avoided it could lead to property damage.
► Pay heed to the instructions in this warning to avoid property damage.
NOTICE
► A notice signifies additional information that assists in the handling of the
appliance.
IB_85950_LSHB150A1_LB7.indb 3IB_85950_LSHB150A1_LB7.indb 3 10.01.13 13:5210.01.13 13:52

4LSHB 150 A1
GB
CY
Safety
In this chapter you will receive important safety information regarding the handling
of the appliance. This appliance complies with the statutory safety regulations.
Incorrect usage can lead to personal injury and property damage.
Risks from electrical current
DANGER
Risk of potentially fatal electrical current!
Contact with wires or components that are under voltage could
be potentially fatal!
Pay heed to the following safety instructions to avoid risks from electrical current:
► The electrical installation may only be carried out by an accredited electrician.
► The appropriate standards are to be applied during assembly.
► Switch the electrical circuit off prior to assembly / installation.
Basic Safety Instructions
For safe handling of the appliance observe the following safety information:
■ Before use check the appliance for visible external damage. Do not put into
operation an appliance that is damaged. There will be the risk of a fatal
electrical shock.
■ A broken protective screen must be replaced before
further use. There is a risk of personal injury.
■ Repairs should only be carried out by authorised specialist companies or by
the Customer Service Department. Incompetent repairs can result in significant
risks for the user. In addition, warranty claims become void.
■ To avoid possible risks, arrange for damaged cables or connectors to be
exchanged by an authorised specialist or the Customer Service Department.
■ Maintain a sufficient distance from the illuminated area (at least
1 m), otherwise there is a risk of fire from the generated heat.
■ This appliance is suitable for mounting on ordinary flammable
surfaces.
IB_85950_LSHB150A1_LB7.indb 4IB_85950_LSHB150A1_LB7.indb 4 10.01.13 13:5210.01.13 13:52

5
LSHB 150 A1
GB
CY
■ Defective components may only be replaced with original replacement parts.
Only by using original replacement parts can it be guaranteed that the
safety requirements are being complied with.
■ The electrical circuit must be switched off before the replacement of a bulb
and before cleaning it. Otherwise, there will be the risk of a fatal electrical
shock.
■ Only bulbs complying with the technical specifications may be used. Unsuit-
able bulbs may cause a short circuit and thereby damage the appliance
permanently.
■ Replace defective bulbs immediately. Defective bulbs may cause a short
circuit and thereby damage the appliance permanently.
■ NEVER use the light with a damaged cable. There will be the risk of a fatal
electrical shock.
■ This appliance is not intended for use by individuals (including children)
with restricted physical, physiological or intellectual abilities or deficiences
in experience and/or knowledge unless they are supervised by a person
responsible for their safety or receive from this person instruction in how the
appliance is to be used.
■ Children should be supervised to ensure that they do not play with the appliance.
Items supplied
The appliance is delivered with the following components as standard:
▯ Halogen floodlight
▯ R7s/J78/120 W bulb
▯ Assembly material
▯ This operating manual
NOTICE
► Check the contents to ensure everything is available and for signs of visible
damage.
► If the delivery is not complete or is damaged due to defective packaging or
through transportation contact the Service Hotline (see chapter Service).
► The bulb is enclosed with the halogen floodlight in the as-delivered condi-
tion (separately packaged). For correct use of the bulb, please refer to the
chapter entitled Changing the bulb.
IB_85950_LSHB150A1_LB7.indb 5IB_85950_LSHB150A1_LB7.indb 5 10.01.13 13:5210.01.13 13:52

6LSHB 150 A1
GB
CY
Appliance description
Rotary switch LUX
2Rotary switch TIME
3Rotary switch SENS
4Motion Detector
5Bracket
6Protective screen
7Screw
8Bulb
9Cable entry
10 Locking screw
Assembly / Electrical connection
Selecting the installation location
The appliance can be mounted indoors or in a covered outdoor area.
DANGER
► Maintain a sufficient distance from the illuminated area (at least 1 m),
otherwise there is a risk of fire from the generated heat.
The motion detector 4may be oriented at about 170° horizontally and about
180° vertically and has a detection range of max. 120°.
The range is adjustable from about 5 - 12 m.
When selecting the installation location ensure there will be no adverse incidents
registered in the coverage range, such as from roads or lights.
IB_85950_LSHB150A1_LB7.indb 6IB_85950_LSHB150A1_LB7.indb 6 10.01.13 13:5210.01.13 13:52

7
LSHB 150 A1
GB
CY
Assembly
DANGER
Risk of electrocution from electrical current!
► The electrical installation may only be carried out by an accredited electrician.
► The appropriate standards must be applied during fitting.
► Switch the electrical circuit off prior to assembly / installation.
WARNING
► When drilling, take care not to damage any pipes/cables in the wall or
ceiling.
► The supplied plugs are only suitable for a mounting on concrete or stone.
Before starting the installation, please check your installation location care-
fully for its suitability for the plugs. If in doubt, call a professional.
NOTICE
► For easier installation the bracket 5can be unscrewed from the appliance.
♦ Drill two holes with a diameter of 6 mm and a depth of 30 mm at a spacing
of 52 mm.
♦ Insert a plug into each of the holes and screw the appliance with the
bracket 5to the ceiling or wall (see Fig Ceiling mounting/Wall mounting).
Fig. Wall assembly
Fig. Ceiling assembly
IB_85950_LSHB150A1_LB7.indb 7IB_85950_LSHB150A1_LB7.indb 7 10.01.13 13:5210.01.13 13:52

8LSHB 150 A1
GB
CY
Electrical connection
WARNING
This appliance falls under Protection Class I.
► The earth wire (green/yellow wire) must be connected to the point
marked .
♦ Switch the electrical circuit off and secure it against unintentional reactivation.
♦ Unscrew the four screws at the rear of the connection box and remove the
cover.
♦ First, pull a cable through the cable entry 9into the connection box and
secure it to the available cable strain relief.
♦ Connect the cable to the terminals, as shown in the connection diagram.
♦ Replace the cover of the connection box and screw it down firmly.
♦ Now switch the power supply back on.
N L
X
Brown or black wire (L)
Blue wire (N)
Green/yellow wire ( )
Fig. Terminal diagram
IB_85950_LSHB150A1_LB7.indb 8IB_85950_LSHB150A1_LB7.indb 8 10.01.13 13:5210.01.13 13:52

9
LSHB 150 A1
GB
CY
Adjustment of the motion detector
The adjustment of the range, the twilight level, and the illumination time is made
with the rotary switches on the motion detector 4.
Twilight level (LUX )
Adjustment of the brightness level below which the motion detector 4will activate.
The brightness sensor is adjustable from 5 Lux to 2000 Lux .
Illumination time (TIME 2)
Adjustment of the illumination time from 7 seconds to 12 minutes. If the appliance
is switched on and it registers a new movement, the illumination time is extended
by the set value.
NOTICE
► We recommend setting the illumination time to the maximum, so as to
achieve the longest service life for the bulb 8.
Range (SENS 3)
Setting the range of motion detector 4to between 5 - 12 m.
♦ Finally, set the motion detector 4according to your requirement.
♦ Fix the position of the motion detector 4with the locking screw 10 .
Changing the bulb
The supplied bulb 8is excluded from the warranty. Please use only bulbs 8
as specified in the Technical Data.
♦ Switch the electrical circuit off and secure it against being inadvertently
switched back on.
♦ Loosen the screw 7on the front panel.
♦ Fold the front panel with the protective screen 6to the front.
♦ Change the bulb 8. Do not touch the bulb with your bare hands, use a
dust-free soft cloth.
♦ Close the front panel, ensuring that the sealing gasket is properly seated
and clean.
♦ Firmly screw the front panel back down.
♦ Switch the electrical circuit back on and check the functioning.
IB_85950_LSHB150A1_LB7.indb 9IB_85950_LSHB150A1_LB7.indb 9 10.01.13 13:5210.01.13 13:52

10 LSHB 150 A1
GB
CY
Cleaning
DANGER
Risk of potentially fatal electrical shock!
► Replace the bulb only when the mains voltage is switched off.
TAKE NOTE
Possible damage to the appliance.
► Ensure that moisture cannot permeate into the appliance during cleaning.
► Do not use aggressive or abrasive cleaning agents, as these can damage
the upper surfaces.
♦ Clean the housing exclusively with a soft damp cloth and a mild dishwashing
liquid.
Disposal
DO NOT dispose of the appliance and/or the bulb in your normal
domestic waste. This product is subject to the European Directive
2002/96/EC (Waste Electrical and Electronic Equipment).
Dispose of the appliance and/or the bulb via an approved waste disposal com-
pany or your communal waste disposal centre. Observe the currently applicable
regulations. In case of doubt, please contact your waste disposal centre.
IB_85950_LSHB150A1_LB7.indb 10IB_85950_LSHB150A1_LB7.indb 10 10.01.13 13:5310.01.13 13:53

11
LSHB 150 A1
GB
CY
Appendix
Technical data
Halogen floodlight
Operating voltage 220-240 V ∼, 50Hz
Power consumption approx. 120W
Protection class I
Protection type IP44
Bulb R7s/J78/120 W
(max. 150 W permitted)
Motion Detector
Coverage max. 120°
Range approx. 5-12 m
Brightness sensor approx. 5-2000 Lux
Illumination time approx. 7 s-12 min
Notes on the Declaration of Conformity
With regard to conformity with essential requirements and
other relevant provisions, this appliance complies with the
guidelines of the Electromagnetic Compatibility Directive
2004/108/EC as well as the Directive for Low Voltage
Devices 2006/95/EC.
The complete original declaration of conformity can be
obtained from the importer.
IB_85950_LSHB150A1_LB7.indb 11IB_85950_LSHB150A1_LB7.indb 11 10.01.13 13:5310.01.13 13:53

12 LSHB 150 A1
GB
CY
Warranty
You receive a 3-year warranty for this appliance as of the purchase date. This
appliance has been manufactured with care and meticulously examined before
delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim,
please make contact by telephone with our service department. Only in this way
can a post-free despatch for your goods be assured.
NOTICE
► The warranty covers only claims for material and manufacturing defects,
but not for transport damages, wearing parts or for damage to fragile
components, e.g. bulbs or switches.
This product is for private use only and is not intended for commercial applications.
In the event of misuse and improper handling, use of force and interference not
carried out by our authorized service branch, the warranty will become void.
Your statutory rights are not restricted in any way by this warranty.
The warranty period is not extended by repairs effected under warranty. This
applies also to replaced and repaired parts.
Damages or defects discovered after purchase are to be reported directly after
unpacking, at the latest two days after the purchase date.
Repairs carried out after lapse of the warranty period are subject to charge.
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
IAN 85950
CY Service Cyprus
Tel.: [phone]
E-Mail: k[email protected]
IAN 85950
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
IB_85950_LSHB150A1_LB7.indb 12IB_85950_LSHB150A1_LB7.indb 12 10.01.13 13:5310.01.13 13:53

13
LSHB 150 A1
RO
Cuprins
Introducere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Informaţii despre aceste instrucţiuni de utilizare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Dreptul de autor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Limitarea responsabilităţii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Utilizarea conform destinaţiei . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Indicaţii de avertizare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Siguranţa. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pericol de electrocutare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Indicaţii fundamentale de siguranţă. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Furnitura . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Descrierea aparatului. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Montarea/conexiunea electrică . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Selectarea locului de instalare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Montajul . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Conectarea electrică . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setarea senzorului de mişcare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Înlocuirea corpurilor de iluminat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Curăţarea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Eliminarea aparatelor uzate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Anexă . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Date tehnice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Indicaţii privind declaraţia de conformitate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Garanţia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Service-ul . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Importator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
IB_85950_LSHB150A1_LB7.indb 13IB_85950_LSHB150A1_LB7.indb 13 10.01.13 13:5310.01.13 13:53

14 LSHB 150 A1
RO
Introducere
Informaţii despre aceste instrucţiuni de utilizare
Felicitări pentru cumpărarea noului dumneavoastră aparat!
Acum deţineţi un produs de calitate excepţională. Instrucţiunile de utilizare sunt
parte integrantă a produsului. Acestea conţin indicaţii importante privind sigu-
ranţa, modul de utilizare şi de eliminare a aparatelor uzate. Înainte de a utiliza
produsul, familiarizaţi-vă cu toate indicaţiile de operare şi de siguranţă. Utilizaţi
acest produs numai în modul descris şi doar pentru domeniile de utilizare speci-
ficate. Păstraţi bine aceste instrucţiuni. Dacă înmânaţi produsul altor persoane,
predaţi, de asemenea, şi documentele aferente.
Dreptul de autor
Această documentaţie este protejată de legea privind drepturile de autor.
Multiplicarea, retipărirea, chiar şi în extras, precum şi reproducerea imaginilor,
chiar şi modificate, sunt permise numai cu acordul scris primit din partea produ-
cătorului.
Limitarea responsabilităţii
Toate informaţiile tehnice, datele şi indicaţiile de conectare şi operare din aceste
instrucţiuni de utilizare corespund stadiului tehnic din momentul tipăririi, fiind
concepute pe baza experienţei şi cunoştinţelor noastre de până acum.
Din specificaţiile, imaginile şi descrierile din acest manual nu pot fi derivate
niciun fel de pretenţii.
Producătorul nu răspunde pentru pagubele rezultate în urma nerespectării instruc-
ţiunilor, a utilizării neconforme, a reparaţiilor necorespunzătoare, a modificărilor
operate neautorizate sau a utilizării pieselor de schimb neaprobate.
Utilizarea conform destinaţiei
Acest aparat este conceput pentru iluminarea zonelor din interiorul clădirilor,
precum şi pentru spaţiile acoperite de afară.
Un alt mod de utilizare este considerat în neconformitate cu destinaţia de utilizare
pentru care a fost conceput. Sunt excluse orice fel de pretenţii pentru pagubele
rezultate în urma utilizării neconforme cu destinaţia.
Riscul este suportat în exclusivitate de către beneficiar.
IB_85950_LSHB150A1_LB7.indb 14IB_85950_LSHB150A1_LB7.indb 14 10.01.13 13:5310.01.13 13:53

15
LSHB 150 A1
RO
Indicaţii de avertizare
În prezentele instrucţiuni sunt utilizate următoarele indicaţii de avertizare:
PERICOL
Avertizările pentru acest grad de pericol marchează o situaţie
periculoasă iminentă.
Dacă situaţia periculoasă nu este evitată, aceasta poate conduce la deces sau
răniri grave.
► Pentru a evita pericolul de moarte şi rănirile grave ale persoanelor, respectaţi
instrucţiunile oferite prin această indicaţie de avertizare.
AVERTIZARE
Indicaţiile de avertizare pentru acest grad de pericol marchează
o situaţie posibil periculoasă.
Dacă situaţia periculoasă nu este evitată, aceasta poate provoca răniri.
► Urmaţi indicaţiile oferite prin această avertizare pentru a evita rănirea
persoanelor.
ATENŢIE
Indicaţiile de avertizare pentru acest grad de pericol marchează
posibile pagube materiale.
Dacă situaţia periculoasă nu este evitată, aceasta poate provoca daune
materiale.
► Urmaţi indicaţiile oferite prin această avertizare pentru a evita daunele
materiale.
INDICAŢIE
► Indicaţiile vă oferă informaţii suplimentare cu scopul de a facilita utilizarea
aparatului.
IB_85950_LSHB150A1_LB7.indb 15IB_85950_LSHB150A1_LB7.indb 15 10.01.13 13:5310.01.13 13:53

16 LSHB 150 A1
RO
Siguranţa
În acest capitol sunt oferite indicaţii importante de siguranţă în vederea manipu-
lării aparatului. Acest aparat corespunde dispoziţiilor de siguranţă prescrise.
Utilizarea necorespunzătoare a aparatului poate provoca fatalităţi umane şi
pagube materiale.
Pericol de electrocutare
PERICOL
Pericol de moarte prin electrocutare!
Pericol de moarte la atingerea conductorilor electrici sau a
componentelor sub tensiune!
Respectaţi următoarele indicaţii de siguranţă, pentru a evita periclitările prin
electrocutare:
► instalarea electrică trebuie realizată exclusiv de către un electrician autorizat;
► la montaj, trebuie aplicate normele corespunzătoare;
► Înaintea montării / instalării decuplaţi circuitul de curent.
Indicaţii fundamentale de siguranţă
Pentru utilizarea în siguranţă a aparatului, respectaţi următoarele indicaţii de
siguranţă:
■ Înainte de utilizare, verificaţi aparatul în privinţa deteriorărilor exterioare vizibile.
Nu puneţi niciodată aparatul în funcţiune, dacă este deteriorat. Pericol de
electrocutare;
■ Dacă sticla de protecţie este spartă, aceasta trebuie
înlocuită înainte de a utiliza aparatul în continuare.
Pericol de rănire.
■ Reparaţia aparatului este permisă numai firmelor autorizate sau serviciului
pentru clienţi. În cazul reparaţiilor necorespunzătoare pot apărea pericole
considerabile pentru utilizator. În plus, se pierde dreptul la garanţie.
■ Dacă este deteriorat cablul sau conexiunile, acestea trebuie înlocuite de
către electricieni autorizaţi sau de către serviciul clienţi, pentru a evita
periclitările.
■ Menţineţi o distanţă suficient de mare faţă de suprafaţa iluminată
(min. 1 m), deoarece, din cauza formării de căldură există
pericol de incendiu.
■ În vederea montării, aparatul trebuie aşezat pe suprafeţe cu risc
normal de inflamare.
IB_85950_LSHB150A1_LB7.indb 16IB_85950_LSHB150A1_LB7.indb 16 10.01.13 13:5310.01.13 13:53

17
LSHB 150 A1
RO
■ Componentele defecte ale aparatului pot fi înlocuite numai cu piese de schimb
originale. Numai prin utilizarea acestor piese este garantată îndeplinirea
cerinţelor de siguranţă.
■ Înainte de înlocuirea unui corp de iluminat şi înainte de curăţare, circuitul de
curent trebuie decuplat. Pericol de electrocutare.
■ Trebuie să se utilizeze numai corpuri de iluminat corespunzătoare cu datele
tehnice. Corpurile de iluminat necorespunzătoare pot provoca scurtcircuite
şi astfel pot deteriora permanent aparatul.
■ Înlocuiţi imediat corpurile de iluminat defecte. Corpurile de iluminat defecte
pot provoca scurtcircuite şi astfel pot deteriora permanent aparatul.
■ Nu utilizaţi niciodată aparatul în cazul în care cablul de alimentare este
defect. Pericol de electrocutare.
■ Acest aparat nu este destinat utilizării de către persoane (inclusiv copii) cu
capacităţi fizice, senzoriale sau mentale limitate sau cu o experienţă şi/sau
cunoştinţe limitate, cu excepţia cazului în care sunt supravegheate de către
o persoană responsabilă cu siguranţa lor sau au primit instrucţiuni de la
aceasta privind modul de utilizare a aparatului.
■ Copiii trebuie supravegheaţi, pentru a împiedica utilizarea aparatului ca jucărie.
Furnitura
Standard, aparatul este livrat împreună cu următoarele componente:
▯ Reflector cu halogen
▯ Corp de iluminat R7s/J78/120 W
▯ Material de montaj
▯ Instrucţiuni de utilizare
INDICAŢIE
► Verificaţi dacă furnitura este completă şi dacă prezintă deteriorări vizibile.
► Dacă furnitura nu este completă sau dacă există defecte rezultate în urma
transportului sau a ambalajului precar, luaţi legătura telefonică cu linia
directă de service (a se vedea capitolul Service-ul).
► Corpul de iluminat este livrat într-un ambalaj separat în cadrul reflectorului
cu halogen. Pentru montarea corectă a corpului de iluminat se va consulta
capitolul Înlocuirea corpurilor de iluminat.
IB_85950_LSHB150A1_LB7.indb 17IB_85950_LSHB150A1_LB7.indb 17 10.01.13 13:5310.01.13 13:53
