Living Spaces 305-P253550 User manual

1Top Panel 1
AJCBC Bolt 6
B
Flat Washer 6
C
DAllen Key
Side panel (L)
1
1
6
2
3
4
Spring Washer
E Fitting-System 5
( 05656 + KT-9608 )
M6 x 30MM
M6
M6
4 x 65MM
-8
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS HEAD SCREWDRIVER
ITEM 305-P253550
DESK
ASSEMBLY INSTRUCTIONS
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small hardware which may have come loose inside the carton during shipment. Identify and count all
hardware and compare with the hardware list below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such
as an area rug or furniture pads. Area rugs and padding not included with purchase.
PARTS LIST
No. Description Quantity
Sketch
HARDWARE LIST
No. Description Sketch Quantity
Size
Page 1 of 4
Made In Malaysia Residential Use Only
Side panel (R)
Back Panel
1
1

STEP 1
Insert Fitting to the Side Panel (2) & (3) as shown.
ASSEMBLY INSTRUCTIONS
Page 2 of 4
Made In Malaysia Residential Use Only
E
E
4
3
4
E
STEP 2
Attach the Back Panel (4) to the Side Panel (R).
23
&
2
3
4
3

Top Facing Down
E
1
ASSEMBLY INSTRUCTIONS
Page 3 of 4
Made In Malaysia Residential Use Only
STEP 4
Turn the Desk upside down on the protective surface.
Firmly grab the drawer on each sides and slide
out until it stops. Proceed to pull outward until
the drawer track slips past the Stop.
Fasten fitting system (E) to the top panel.
STEP 3
Attach the Back Panel (4) to the Side Panel (L).
E
4
E
42
4
3
2
1

STEP 5
Fixed the side panel base to the Top Panel (1) as shown.
ASSEMBLY INSTRUCTIONS
Page 4 of 4
Made In Malaysia Residential Use Only
STEP 6
Align the side panel base to the Top Panel (1) and fasten it by using JCBC Bolt (M6) with Spring
Washer and Washer.
E
4
12
C
B
A
D
STEP 7
Insert the Drawer.
After completing all assembly part. Align
the drawer with the opening while making
sure that the drawer track guide is line up
with the stop and metal track. Press the
drawer inward. Continue to press the
drawer inward until it moves past the stop.
You should feel the drawer slide smoothly
on the track until it gets to the end.
1
4
2
3
3
2
1
