Living Spaces 4249/4250 User manual

CORNER BED FRAME HARDWARE
QTY: DESCRIPTION:
92" X 3" ANGLE BRACKETS
10
36 6X 1 1/4" PHIL FLAT SLAT SCREW
7030-01120 KIT
8 x 3/4" PHIL PAN ZINC SCREWS

7030-01120
MATEO / COTTAGE
COLLECTION
CORNER BED
PARTS LIST
A) 9-Angle brackets
B) 1 - 76" Side Bookcase End
C) 1 - Twin or Full Bookcase End
D) 1 - 9" x 74 3/4" Mattress Rail w/Support Cleats.
E) 1 - Twin or Full x 9" Support Rail
F) 3 - 3 1/2” x 38 3/4”(Twin) or 3 1/2" x 53 3/4”(Full) Mattress Supports
G) 10 - 1 ¼” Slat Screws
H) 36 - 3/4" Pan head screws for corner brackets
TOOLS REQUIRED:
1) Phillips Head Screwdriver - preferably with power drill
Make sure you have all parts before beginning assembly. If you need a part, contact Living Spaces.
1) Attach side bookcase end (B) to twin/full bookcase end (C), 9" x 74 3/4" mattress rail (D), and twin/full 9"
support rail with two angle brackets (A) in each corner (8 total), placing one bracket below the cleat and one
above it, as pictured. ** USE ONLY THE OUTER 4 HOLES OF EACH CORNER BRACKET **
2) Install the ninth angle bracket (A) to hold the bookcases together in the back, as pictured above.
** Again, use only the outer 4 holes on the bracket **
3) Place Slat Roll across bed, to span from Head to Foot of bed, on top of mattress support cleats. Place the
loose (3) slats (F) on mattress rail support cleats in the built in gaps, in accordance with diagram 2 on the
next page.
4) IF you do not use the Slat Roll, be sure to place 3 loose slats in accordance with diagram 1 on the next page.
** 9" Mattress supports are attached to the back of the twin/full bookcase end (C) **
4) Secure 4 corners of Slat Roll, as well as the 3 loose slats at each side, to mattress supports with the 10 wood
screws as shown in diagram 2, next page.
5) Add mattress.
TWIN - 4249/4250
FULL - 4249/4251
BC
D
E
A
A

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
Diagram 2
Diagram 1
