Living Spaces Summit 7030-01165 User manual

PARTS LIST
BOX 1: 4658 Summit Bookcase Bed Full Headboard
Part # Description Quantity
4658 Summit Bookcase Bed Full Headboard
1
BOX 2: 4659 Summit Bookcase Bed Full Footboard
Part # Description Quantity
S0179END Summit Bookcase Bed Full Footboard
1
BOX 3: 4655 Summit Panel Bed Full Frame Rails
Part # Description Quantity
S1001SRL 5/4 x 6x 75 Mattress Rail
2
140533/40 Full Individual Slat
3
5040-43183 7MM x 100MM Decorative Lag Bolt 8
5040-35410 #6 x 1 1/4 Phil Flat Slat Scew 10
ALNWR 4MM Allen Wrench 1
PWRDD 4MM Power Drill Driver 1
COMPLETED ASSEMBLY
7030-01165KIT
4655 Frame Rails/4658 Heaboard/4659 Footboard
Summit Collection: Full Bookcase Bed
(Scan code for
instructional
video)

ASSEMBLY INSTRUCTIONS
4658
S0179END
S1001SRL
5040-43183

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
Diagram 1 Diagram 2
Scan Code for Instructional video

Mateo/Summit Collections: Knob and Pull Installation
7030-01195 KIT
1. Locate the box containing your knobs and/or pulls in the bottom drawer of your case
good.
2. Identify which of the screw sizes is correct for your drawers/doors. The screw should
protrude no more than 1/4" when pushed through the pre-drilled holes on your
drawers/doors.
3. Push the screw through the back of the pre-drilled hole on the drawer/door and line it
up with the thread on the back of the knob/pull.
4. Tighten the screw into the back of the knob/pull until the knob/pull is tight against the
front of your drawer/door.
**You can tighten your screws with either a phillips screwrdiver,
a drill with a phillips bit, or your hand**
(Scan code for
instructional
video)
