Livoo DOM444 User manual

Instruction Manual
WWW.LIVOO.FR
Reference: DOM444
Version: 1.4
Language: English
Portable air cooler

Instruction Manual
1
ou have purchased a LIVOO brand product and we thank you for it. We give great attention to the design,
ergonomics and ease of use of our products. We hope that this product will give you complete satisfaction.
This instruction manual is available too on our website www.livoo.fr
SAFET INSTRUCTIONS
PLEASE, TAKE TIME TO READ WELL THE INSTRUCTIONS FOR USE
PARTICULARL BEFORE THE FIRST USE.
A misuse of the appliance can damage it or hurt the user. Assure
that you use the appliance for the use for which it is designed, we
refuse any responsibilities as for the damages by an incorrect use
or a bad manipulation.
1. Before connecting your appliance, verify that the supply
voltage indicated on the indicator plate of the appliance
corresponds properly to that of your electrical
installation.
2. No responsibility may be assumed in case of damages
caused by non-compliance of this manual by the user or
by faulty use or handling.
3. This appliance is meant for ONL DOMESTIC USE and
FOR INTERNAL USE.
4. Use this appliance only as indicated in the instruction
manual.
5. Completely assemble the air cooler before starting it.
6. Before each use, ensue that the supply cord is in good
condition.
7. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified

Instruction Manual
2
persons (*) in order to avoid a hazard.
8.Never plunge the appliance, its supply cord or the plug
in water or any other liquid.
9. Do not handle the plug on the appliance with wet
hands.
10.This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities, or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
11. When you disconnect the supply cord, always remove
it from the plug. Do not pull on the cord itself.
12. Unplug the appliance during filling and cleaning.
13. Ensure that the fan is switched off from the supply
mains before removing the guard.
14. Never insert your fingers, pencils or any other object
across the ventilation grills.
15. Ensure that the air cooler is always placed on a flat
surface, dry and stable.
16. Do not use your air cooler close to a window. Rain may
cause risks of electric shocks.
17. Do not use chemical products or abrasive detergents
for cleaning, which may easily damage or deform your
appliance.
18. Do not place either the air cooler or its parts near an

Instruction Manual
3
over, a cooking appliance or any other source of heat.
19. Do not use the appliance in the presence of explosive
or inflammable vapours.
20. Never try to disassemble or repair your appliance
yourself. In case of repair by an unqualified person, the
guarantee is cancelled.
21. For reducing the risk of electric shock, never use this
product with wet hands, never spill a liquid on the
product or submerge it in water.
22. Do not place the appliance on or near a hot gas or in a
heated oven.
23. Do not use outside (For internal use only). This
appliance is not suitable for industrial or open air use.
24. Never leave the appliance working without
surveillance.
25. Avoid overheating the device by preventing the
blocking of entry and exit of air. Clean all the entries
and exits from time to time to remove the accumulated
dust.
26. This appliance is not designed to be used with an
external timer or a separate remote control system.
27. Do not try to remove the parts and do not insert a
metallic object inside the appliance.
28. This appliance is intended to be used in household and
similar applications such as:
•staff kitchen areas in shops, offices and other
working environments
•farm houses
•by clients in hotels, motels and other

Instruction Manual
4
residential type environments
•bed and breakfast type environments
(*)
Authorised qualified electrician: after-sales department of the manufacturer or the importer or any
other qualified person, approved and authorised for carrying out this kind of repair for avoiding any
danger. In any case, you must send the appliance to this electrician.
SPECIAL SAFET INSTRUCTIONS
Information:
NEVER COVER THE APPLIANCE , even temporarily, because it
may overheat and generate a risk of fire.
Do not use the air cooler near a shower, bathtub or a swimming
pool.
TECHNICAL SPECIFICATIONS
Voltage : 220-240V~50Hz
Puissance : 80W
3 speeds
Water tank capacity: 3,2L
Remote control: 1 battery X CR2025
DOM444
Description Symbol alue Unit
Maximum fan flow rate F 5,0 m
3
/min
FAN power input P 80 W
Service value SV 0,06 (m
3
/min)/W
Standby power consumption P
SB
/ W
Fan sound power level L
WA
60 dB(A)
Maximum air velocity C 8,0 meters/sec
Service Value measurement standard IEC 60879: 1986 (corr.1992) Performance and construction of
electric circulating fans and regulators.
Contact details for further information
DELTA | 1 rue Foch – 67450 Mundolsheim – France

Instruction Manual
5
DESCRIPTION
Control Panel:
Remote control:
FROID=COOLER
OSC=SWING
TEMPS=TIMER
MODE=WIND
VITESSE=SPEED
ION=ION

Instruction Manual
6
USE
Insert plug to the electrical outlet, the LED indicator shows power on.
The function of the unit can be controlled via on board control panel or by remote.
ON/OFF button
•Press the button the first time, the indicator "LOW" of control panel is working air cooler is working
with low speed.
•Press the button the second time, the air cooler stop working.
Speed button ( ITESSE): Press this button to change the fan speed: low-medium-high speed.
Wind button (MODE): Normal Nature Sleep
•Normal mode: wind blow based on low/med/high
•Natural mode: the wind imitates blow of natural strong and soft wind
•Sleep mode: the sleep function operates at natural fan speed and slowly lowers the speed before
turning it off together.
Cooler button (FROID): Press the button one time: air cooler is working; indicator of control panel
lights up. Press the button second time to stop it.
Caution: Please pay attention to the water level in the tank before activating the air cooler function.
Water should stay between Min and Max level. It is recommended to replace water in the tank at least
once in a week.
Swing button (OSC): Press swing button to change the wind direction. The swing icon will appear
on the screen when the function is activated. Press the button again to stop the oscillation.
Timer button (TEMPS): Set the operating time from 0.5H to 7,5 hours. Each pressure represents
30 minutes. Indicators on the control panel indicate the selected run time.
Ioniser (ION): Press “Ion” button to activate the ionizer function. Indicator light will signify that
the ionizer is on as the negative ions releases. Ions attract harmful particles in the air such as dust,
pollen, mold, spores etc. to eliminate them and clean the air.
Remote
•The remote control is supplied with 1 battery CR2025. Do not use other types of batteries.
•In case of prolonged non-operation, remove the battery from the remote control.

Instruction Manual
7
Frozen ice box
Use frozen ice box to get colder air
First put them in the freezer, after well frozen, pull the water tank out, fill the ice box with water and put
the frozen ice boxes into it.
The ice box contains powder which helps to keep ice in the box longer.
ou can also use the ice box without powder.
Attention, do not leave the ice box with the powder within reach of children.
Be careful, do not ingest the powder in the box.
Warning: The water level of water tank must be less than “MAX” level (with or without ice
boxes use)
CLEANING AND MAINTENANCE
Cut off the power and unplug appliance before cleaning
1. Clean dust filter :
Pull the holder of air filter, then clean air filter with soft brush or water.
2. Clean the cooling pad:
After removing the dust filter you can see the cooling pad. Press the lock of 2 sides and gently pull
out the pad. Use a clean cloth or soft brush to remove dust and dirt from the pad. Rinse with clean
water if needed and leave open air dry. Never use any harmful chemical solution for may cause
damage to the pad. our cooler takes water from narrow section of the tank and pumps it on the
cooling pad. The water flowing through the cooling pad goes down to the large section of the tank.
The cycle results to absorption of dust and dirt in the air which makes the air safer and fresher to
breathe. The filter that is located at the middle portion of the tank cleanses the water that passes
through it and should be attached to its place upon use of the unit.
3. Clean water tank :
Take the water tank out and wipe it or clean it with water.
4. Clean the housing:
Wipe off the housing by neutral cleaner and soft cloth.

Instruction Manual
8
Correct disposal of the unit
(Electrical and Electronic Equipment)
(Applicable in the European Union and the rest of Europe that have adopted separate collection systems
countries)
The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old
household electrical appliances must not be disposed of in the normal household waste stream.
Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain and
reduce the impact on human health and the environment.
The symbol of the crossed out dustbin is marked on all products to remind the obligations of separate collection.
Consumers should contact their local authority or retailer for information concerning the correct disposal of their product.
•Photo no contractual
• Worried about the quality of his products the manufacturer reserves the right to make modifications without advance
