LM Technologies LM740 User manual

Stereo headset mode
User’s Guide
Rev 1.0
1. Overview
The LM740 is CSR ®BlueCore 5®MM based Bluetooth module and is suitable for A2DP, SPP, DUN, OPP, FTP,
PBAP and HID applications. It also allows to implement advanced functions such as noise cancellation and
multi-media streaming. The LM740 module board is de signed for using with the LM556 Bluetooth module
Evaluation Kit. This user’s guide will introduce the settings of LM556 with LM740 module board to implement
wireless stereo headset application.
2. The Settings
LM740 Stereo Loud speakers
Device name：LM740 RX-HIC
Profiles：A2DP-Sink, AVRCP, HFP/HSP
Pin code：0000
Image file: LM740-RX-HIC.zip
Description: These settings enable the LM556 with LM740 module board to receive A2DP streaming from
music audio source as well as answering phone call with HFP/HSP. That is, to implement the wireless stereo
headset application.
When receiving or making a call, the music playback will be automatically paused. The music playback can be
resumes when the call is ended.
Each time the LM740 - RX - HIC is switched on, it will intend to connect to the Bluetooth device that the last it had
connected with.
The LM740 -RX-HIC has battery low detection and protection. When battery low occurred, it will worn by
flashing red LED. If the battery is exhausted, the firmware will switch off the system to protect the Li-ion battery.
LM740
Running
A2DP, AVRCP
profiles
A2DP Streaming
LM556 Development Board

LM556- Blue LED (LED1) & Red LED (LED0) Indicators
Operating State Blue LED (LED1) & Red LED (LED0) controlled by LM740
Standby The system is standby but not connected to any Bluetooth device yet.
Blue LED: (repeat cycles) 2 seconds on, 1 second off.
Pairing mode Flashing Blue and red LEDs alternatively.
Connecting state Try to connect with paired Bluetooth device.
Blue LED is flashing rapidly (in blue).
Both A2DP and HFP are
connected Flashing Blue LED twice by every 2 sec.
Only A2DP is connected Flashing Blue LED once by every 2 sec.
Only HFP is connected Flashing Blue LED once by every 4 sec.
Battery Low Flashing Red LED once by every 5 sec
Charging the battery Red LED steady on
LM556 Jumper Settings
snoitpircseD.oNrepmuJ
J1 Ø3.5mm phone jack for audio output
JP3, JP4
Battery charger settings. Please refer to the “ LM556 Evaluation Kit General Guide” for
details.
Warning: To use the internal charger of LM740, the Li-ion re-chargeable battery shall
be installed permanently.
JP6 Short circuit to pin1 & pin2.
Set the voltage level of SPI interface to LM740 module board.
JP14, JP17 Short circuit to pin2 & pin3 to each of these jumpers.
These will wire the MIC1 to the audio input of LM740.

J15Short circuit.
Select 3.3V for system power
JP20, JP22, JP25,
JP26
Short circuit to pin1 & pin2 to each of these jumpers.
These will wire the audio outputs (L & R channels) of LM740 to headphone amplifier.
and then output to J1 phone jack.
JP24 Short circuit to pin2 & pin3.
Select 3.3V for power supply to LM740 module board
JP27 Short circuit to pin2 & pin3.
Select active low Reset for LM740 module board
JP28 Short circuit to pin2 & pin3.
Select 3.3V for the signal level of PIOs of LM740 module board
JP29 Short circuit.
Seelect 3.3V for headphone power supply.
JP30 Short circuit to pin2 & pin3.
Enable the self sustain powering scheme
JP31 Short circuit
Enable 3.3V power supply to the driver ICs of printer port (SPI) and serial port.
On/Off/Pairing Control 1. Pressed and held for more than 2 seconds can turn on/off the module board.
2. Short pressed will set the module board to Pairing mode.
MFB (PIO6) This is multi-function button for A2DP and HFP modes. Please refer to firmware guide of
LM740 RX-HIC version.
Rewind (PIO7) Rewind the music playback (A2DP) of the audio source by AVRCP.
Fast Forward (PIO8) Fast Forward the music playback (A2DP) of the audio source by AVRCP.
Volume Up (PIO11) Turn volume up of the audio source.
Volume Down (PIO12) Turn volume down of the audio source.
