Lobos Tech LB-FEA800M User manual

User Guide
LB-FEA800M
Rev.1.0
2005/1/27

1. Introduction
The LB-FEA800M is compact desktop size switches that are ideal solutions
for SOHO (Small Office or Home Office) network user. It provides wire-speed,
Fast Ethernet switching function that allows high-performance, low-cost
connection. The Switches feature a store-and-forward switching and it can
auto-learn and store source address on an 8K-entry MAC address table.
The Switches provides 8 switched auto-sensing 10/100 Mbps RJ-45 Ethernet
ports and features Auto MDI/MDIX function for each port. [In general, MDI
means connecting to another Hub or Switch while MDIX means connecting to
a workstation or PC. Therefore, Auto MDI/MDIX means that you can connect
to another Switch or workstation without changing non-crossover or crossover
cabling. ]
With there build-in Web-based Management, managing and configuring the
LB-FEA800M becomes easier. From cabinet management to port-level control
and monitoring, you can visually configure and manage your network via Web
Browser. Just click your mouse instead of typing command strings. However,
the LB-FEA800M can also be managed via Telnet, Console, or SNMP
Management.
Features
n8 10/100BASE-TX intelligent switch
nSwitch fabric up to 3.8Gbps
nFully software feature for Layer 2 management switch
nIGMP support for Multi-media application
nPort Mirror supported
nSpanning Tree, SNMP, RMON supported
nSupport Port-based VLAN

2
nIEEE802 .1Q VLAN, GVRP supported
nSupport Class of Service
nBroadcast Storm filter supported
nSupport Port Security
nIEEE802.3ad Port trunk with LACP supported
Software Feature
SNMP
RFC 1157 SNMP, RFC 1213 MIB II, Bridge MIB,
RFC
1643 Ethernet Like, RFC 1493 Bridge MIB
, RFC 1757
RMON1, LANTECH Enterprise MIB, RFC 1215 Trap,
RFC 2674VLAN MIB
Management
Web management (IE)
RS-232 console management (Rear side)
Telnet
Trunk
IEEE 802.3ad Trunk with LACP for
load distribution
control and fail over recover
Up to 4 ports per group, max 4 Groups
Class of Service Global system supports 2 queues for Hi and Low priority
QoS
Global System support 8 levels of priority and mapping
to Hi/Low priority queue for Class of Service
VLAN
Port based VLAN, 802.1Q Tag VLAN, Protocol Type
VLAN, GVRP support
VLAN ID up to 4094, VLANs up to 256 groups
IP Multicast
Support IGMP Snooping, supports 256 groups.
Support 2 types of Query mode for Enable/Disable or
Auto Query

Filter Database Support port s
tatic MAC address lock, MAC Filter, Port
Security
Port Mirror
Use this feature to analysis port traffic for this switch. It
supports max 8 ports.
Broadcast
Control None, 5%, 10%, 15%, 20%, 25%
Spanning Tree IEEE802.1d support
RFC Standard
RFC 768 UDP, RFC 783 TFTP, RFC 791 IP, RFC792
ICMP, RF
C 854 TELNET Server/Client, RFC 1112
IGMP, RFC 2068 HTTP,
Package Contents
Unpack the contents of the LB-FEA800M and verify them against the checklist
below.
nLB-FEA800M
nPower Cord
nFour Rubber Feet
nRS-232 cable
nUser Guide
LB-FEA800MPower Cord

4
Rubber Feet RS-232 cable User Guide
Figure 1-2. Package Contents
Compare the contents of your LB-FEA800M package with the checklist above.
IF any item is missing or damaged, please contact your local dealer for
service.
Ethernet Switching Technology
Ethernet Switching Technology dramatically boosted the total bandwidth of a
network, eliminated congestion problems inherent with Carrier Sense multiple
access with Collision Detection (CSMA/CD) protocol, and greatly reduced
unnecessary transmissions.
This revolutionized networking. First, by allowing two-way, simultaneous
transmissions over the same port (Full-duplex), which essentially doubled the
bandwidth. Second, by reducing the collision domain to a single switch-port,
which eliminated the need for carrier sensing. Third, by using the
store-and-forward technology’s approach of inspecting each packet to
intercept corrupt or redundant data, switching eliminated unnecessary
transmission that slow the network. By employing address learning, which
replaced the inefficient receiving port.
Auto-negotiation regulates the speed and duplex of each port, based on the
capability of both devices. Flow-control allows transmission from a 100Mbps
node to a 10Mbps node without loss of data. Auto-negotiation and flow-control
may require disablement for some networking operations involves legacy
equipment. Disabling the auto-negotiation is accomplished by fixing the speed
or duplex of a port.

Ethernet Switching Technology supplied higher performance at costs lower
than other solutions. Wider bandwidth, no congestion, and the reduction in
traffic is why switching is replacing expensive routers and inefficient hubs as
the ultimate networking solution. Switching brought a whole new way of
thinking to networking.

6
Management Methods
The LB-FEA800M series supports following management methods:
nConsole and Telnet Management
nWeb-based Management
nSNMP Network Management
Console and Telnet Management
Console Management is done through the RS-232 Console Port. Managing
the LB-FEA800M in this method requires a direct connection between PC and
the 8TP+1Fiber Management Switch. While Telnet management is done over
the network. Once the LB-FEA800M is on the network, you can use Telnet to
Log in and change the configuration.
Web-based Management
The Switch provides an embedded HTML web site residing in flash memory. It
offers advanced management features and allow users to manage the
LB-FEA800M from anywhere on the network through a standard browser such
as Microsoft Internet Explorer.
SNMP Network Management
SNMP (Simple Network Management Protocol) provides a means to monitor
and control network device, and to manage configurations, statistic collection,
performance, and security.

2. Hardware Description
This section mainly describes the hardware of the LB-FEA800M.
Physical dimensions
The physical dimensions of the LB-FEA800M is 250mm x 133mm x 37mm (L
x W x H)
Front Panel
The Front Panel of the LB-FEA800M consist of 8x auto-sensing 10/100Mbps
Ethernet RJ-45 ports (automatic MDI/MDIX) and the LED indicators are also
located on the frond panel of the switch.
Figure 2-1. The Front Panel of theLB-FEA800M
nRJ-45 Ports (Auto MDI/MDIX): 8x 10/100 auto-sensing for 10Base-T or
100Base-TX connections.
[In general, MDI means connecting to another Hub or Switch while MDIX
means connecting to a workstation or PC. Therefore, Auto MDI/MDIX
means that you can connect to another Switch or workstation without
changing non-crossover or crossover cabling. ]

8
LED Indicators
There are three LED-Indicators (100M, LNK/ACT, FDX/COL) for each UTP
port. The following table provides descriptions of the LED statuses and
meaning. They provide a real-time indication of systematic operation status.
Figure 2-2. LED Indicators
LED Status Color Description
Power On Green Power On
On Green The port is operating at the
speed of 100Mbps.
100M
Off In 10Mbps mode or no
device attached
On Green The port is successfully
connecting with the device.
Blinks Green The port is receiving or
transmitting data.
LNK /ACT
Off No device attached.
On Orange The port is operating in
Full-duplex mode.
FDX /COL
Blinks Orange Collision of Packets occurs
in the port.
