LOFTNESS Timber Ax 63TA User manual

Model Number:
Serial Number:
Date of Purchase:
Timber Ax
Skid-Steer Mounted Tree Shredder
63TA 73TA 83TA
Owner’s Manual
(Originating w/Serial Number
01-862 thru 01-903)
N14867_L 03.21.17

LOFTNESS SPECIALIZED EQUIPMENT, INC.
WARRANTY POLICY
The warranty policy begins upon delivery of the unit to the original customer.
All Loftness products have a one (1) year warranty policy.
If any Loftness product is used as a rental unit, the warranty period extends for only 30 days from the delivery
date to the original customer.
Loftness Specialized Equipment, hereinafter referred to as LOFTNESS, a manufacturer of quality machinery since
1956, warrants new LOFTNESS machinery and/or attachments at the time of delivery to the original purchaser,
to be free from defects in material and workmanship when properly set up and operated in accordance with the
recommendations set forth in the LOFTNESS Operator’s Manual.
LOFTNESS’ liability for any defect with respect to accepted goods shall be limited to repairing the goods at an
authorized dealer or other LOFTNESS designated location, or replacing them as LOFTNESS shall elect. The above
shall be in accordance with LOFTNESS warranty adjustment policies. This warranty shall not apply to any machine
or attachment which shall have been repaired or altered outside the LOFTNESS factory or authorized LOFTNESS
dealership or in any way so as in LOFTNESS’ judgment, to affect its stability or reliability, nor which has been subject
to misuse, negligence or accident, nor to any machine or attachment which shall not have been operated in accordance
with LOFTNESS’ printed instructions or beyond the company recommended machine rated capacity.
WARRANTY REQUIREMENTS
Warranty registration form must be lled out and returned to Loftness Specialized Equipment to validate all
future warranty claims.
LIMITATIONS OF WARRANTY
All Products – LOFTNESS products are designed to provide years of dependable service when proper use and
maintenance is adhered to. The potential for misuse in many applications exists, therefore a limited warranty is provided
as follows:
All Shredders, Axes, Cutters & Mowers – Rotor Balance: Critical rotor balance can be affected by conditions beyond
LOFTNESS’ control, such as the operation of a shredder beyond the Company’s rated capacity, improper knife
replacement, missing knives, striking foreign objects, lack of lubrication, etc. Any failure resulting from running in as
“out-of-balance” condition, such as, but not limited to bearing and or drive-line failure, metal fatigue, cracks, etc. will
be considered abuse and will not be covered under warranty. LOFTNESS may elect to have an area representative
evaluate the condition of the machine before warranty is considered.
To receive a warranty claim, a return authorization from LOFTNESS must be obtained. The failed part may then be
returned in an untampered status. This warranty does not include freight or delivery charges incurred when returning
machinery for servicing. Dealer mileage, service calls and pick-up/delivery charges are the customer’s responsibility.
EXCLUSIONS OF WARRANTY
Except as otherwise expressly stated herein, LOFTNESS makes no representation or warranty of any kind, expressed
or implied, and makes no warranty of merchantability in respect to its machinery and/or attachments and makes no
warranty that its machinery and/or attachments are t for any particular purpose. LOFTNESS shall not be liable for
incidental or consequential damages for any breach of warranty, including but not limited to inconvenience, rental
or replacement equipment, loss of prots or other commercial loss. Upon purchase the buyer assumes all liability, all
personal injury and property damage resulting from the handling, possession or use of the goods by the buyer.
No agent, employee, or representative of LOFTNESS has any authority to bind LOFTNESS to any afrmation,
representation or warranty concerning its machinery and/or attachments except as specically set forth herein.
April 2009

Timber Ax
Table of Contents
Warranty
Table of Contents
Introduction
Owner Information ............................................................1
Warranty Policy ..............................................................1
Serial Number Location ........................................................2
Manual Storage ..............................................................2
Timber Ax Features ...........................................................3
Ordering Code ...............................................................4
Timber Ax (Example) .......................................................4
Safety Instructions
Safety First..................................................................5
Owner’s Responsibility ........................................................5
Mandatory Shut-Down Procedure .............................................6
Safety Rules.................................................................6
Safety Instructions for Operation and Maintenance ...............................6
Operation Safety ..........................................................8
Hydraulic Safety...........................................................9
Timber Ax Identification.......................................................10
Safety Decal Locations .......................................................11
Set-up Instructions
Installing the Timber Ax to the Skid Loader........................................15
Hydraulic Connections .......................................................15
Checking Rotor Rotation ......................................................16
Checking Rotor Speed .......................................................16
Pusher Bar Adjustment .......................................................17
Skid Adjustment ............................................................17
Rotor Locking Pin Installation ..................................................18
Operating Instructions
Getting Started .............................................................19
Operation ..................................................................19
Maintenance
General Maintenance.........................................................21
Lubrication.................................................................22
Grease Point Location .....................................................22
Overhung Load Adapter....................................................23
Belt Cover Removal..........................................................24
Belt Adjustment .............................................................24

Timber Ax
Table of Contents
Maintenance (Cont’d)
Knife Replacement ..........................................................25
Knife Sharpening ............................................................25
Knife Support Replacement ...................................................26
Storage ...................................................................27
End of Season ...........................................................27
Beginning of the Season ...................................................27
Motor and Sheave Selection Chart ..............................................28
Troubleshooting .............................................................29
Parts Identification
Timber Ax, Body Assembly ....................................................32
Body, Right Side ............................................................34
Body, Left Side .............................................................36
Pusher Bar .................................................................37
Rotor, with Knives ...........................................................38
Belt Tensioner (N32030).......................................................39
Motor and Sheave Options ....................................................40
Motor, Muncie ..............................................................42
Overhung Load Adapter (N16416)...............................................44
Shield, AXH Motor w/o Gauges (N32062) .........................................45
Gauge ....................................................................46
Holder, Hose Stick and Chain (N20403) ..........................................47
Machine Decals and Signs ....................................................48
Appendix
Specifications ..............................................................51
Dimensions ................................................................52
Torque Specifications ........................................................53
Inches Hardware and Lock Nuts .............................................53
Metric Hardware and Lock Nuts .............................................54

1Timber Ax
Owner Information
Thank you for your decision to purchase a Timber Ax
Skid-steer Mounted Tree Shredder from Loftness. It
has been designed to provided years of profitable and
dependable service. To ensure maximum performance of
your machine, it is mandatory that you thoroughly study
the owner’s manual and follow its recommendations.
Proper operation and maintenance are essential to
prevent injury or damage and to maximize machine life.
The Loftness Timber Ax is an effective, reliable machine
used for maintaining grass, weeds, brush and trees.
It efficiently cuts and mulches up to 6" diameter
material with as little as 38 hydraulic horsepower, and
intermittently cuts larger diameter material. The blades
cut and pulverize the grass, weeds and brush. The
shredder deposits cut material over the entire width-of-
cut, which eliminates bunching or windrowing behind the
machine.
The shredder rotor is equipped with two rows of stationary
cutting knives, plus an adjustable cutter bar that restricts
the feed rate of the material being shredded. The more
powerful systems can use a wider opening to increase
the feed rate.
The Timber Ax can be attached to any skid-steer with an
auxiliary hydraulic system of 21-54 GPM, which has a
standard universal skid-steer hitch
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws, and in compliance with
on-product labeling and these instructions.
Make sure that all personnel have read this owner’s
manual and thoroughly understand safe and correct
operating, installation and maintenance procedures.
Continuous improvement and advancement of Loftness
products may result in changes to your equipment
that may not be reflected in this publication. Loftness
reserves the right to make product improvements to the
machine at any time. Although great care has been taken
to ensure the accuracy of this publication, Loftness does
not assume any liability for errors or omissions.
Warranty Policy
Be sure to read and understand the Warranty Policy at
the beginning of this manual. It is also important that you
fill out the Warranty Registration form(s) completely with
your dealer.
Introduction

2Timber Ax
Serial Number Location
The arrow above indicates the location of the serial
number tag.
The serial number is also stamped into the frame, on top
of the hitch support.
Always use your model and serial number when requesting
information or when ordering parts. Refer to the Ordering
Code chart on page 4 to find your model number.
Manual Storage
Keep the owner’s manual and the entire documentation
packet in the storage compartment (1) provided on your
Timber Ax. The owner’s manual must be available for all
operators.
Introduction
1

3Timber Ax
Introduction
Timber Ax Features
• Standard Front Skid-Steer Mount
• Motors Sized for 22-40 GPM
• High-Efficiency Gear-type Motor
• Dual Cross-over Relief Valve Protection
• Upward Rotor And Knife Rotation;
Ridged, Pocket-style Knife Mounts
• Premium Strength Steel Body & Rotor
• Bearing Anti-wrap Protection
• 2-3/16 Inch Rotor Bearings
• External HD Bearing Block
• 4-Groove Banded Belt
• Single Belt Drive
• Automatic Tension System
• Manual Adjust Pusher Bar
• Claw Hooks on Pusher for Positioning Material
• Adjustable Shear Bar
• Skid Shoes - Adjustable 1 to 3 inches
• Steel Deflector Chains
• Rubber-Mounted Pressure Gauge
• Hydraulic Hose Holder
• Knife Sharpening without Detachment

4Timber Ax
SIZE
63 = 63" Cut
73 = 73" Cut
83 = 83" Cut
TYPE
TA = Timber Ax
MOTOR
M = Muncie
SHEAVES/BELT COMBO
P = 10.30 / 8.00 63" – 22-25 GPM
Q = 9.25 / 8.50 63" – 26-30 GPM
R = 8.50 / 9.25 63" – 31-36 GPM
S = 8.00 / 9.75 63" – 37-40 GPM
Ordering Code
Timber Ax (Example)
The ordering code will consist of two numbers (machine size), two letters (body type), one letter (motor type), and one
letter (sheaves/belt combo). An example for a Timber Ax of this type would be shown below.
63TAMP
Introduction

5Timber Ax
Safety First
In the owner’s manual and on decals used on the
machine the words DANGER, WARNING, CAUTION,
IMPORTANT, and NOTE are used to indicate the
following:
DANGER: This word warns of immediate hazards which,
if not avoided, will result in severe personal injury or
death. The color associated with Danger is RED.
WARNING: This word refers to a potentially hazardous
situation which, if not avoided, could result in severe
personal injury or death. The color associated with
Warning is ORANGE.
CAUTION: This word refers to a potentially hazardous or
unsafe situation that, if not avoided, may result in minor
or moderate injury. It may also be used to alert against
unsafe practices. The color associated with Caution is
YELLOW.
IMPORTANT: Highlights information that must be
heeded.
NOTE: A reminder of other related information that needs
to be considered.
If Safety Decals on this machine are ISO two panel
pictorial, decals are defined as follows:
• The first panel indicates the nature of the hazard.
• The second panel indicates the appropriate
avoidance of the hazard.
• Background color is YELLOW.
• Prohibition symbols such as and STOP if used,
are RED.
Be certain all machine operators are aware of the
dangers indicated by safety decals applied to the
machine, and be certain they follow all safety decal
instructions. Contact Loftness for safety decal
replacement.
Loftness cannot anticipate every possible
circumstance that may involve a potential hazard. The
warnings in this owner’s manual are not all inclusive.
Owner’s Responsibility
Because of the potential safety hazard to eyes
from hydraulic leaks and/or flying debris, “USE
OF PROTECTIVE EYEWEAR IS ABSOLUTELY
MANDATORY” for operator and others in the work area.
Due to the possible danger of flying debris, it is
“ABSOLUTELY MANDATORY that IMPACT-
RESISTANT SHIELDING” be provided on the power
unit to protect the operator. The owner is responsible for
providing the operator protection devices on the power
unit.
Flying debris can gather on the skid-steer and needs
to be cleaned off, especially around the radiator and oil
cooler screens, engine compartment and exhaust areas.
Periodic cleaning will help prevent the possibility of fire.
Make sure that all personnel have read this owner’s
manual, and thoroughly understand safe and correct
installation, operation, and maintenance procedures.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws; and in compliance with
on-product labeling and this owner’s manual instructions.
Make sure that all personnel know how to stop the
machine and attachment by disengaging all controls.
See “Mandatory Shut-Down Procedure” on page 6.
Safety Alert Symbol
This message alert symbol identifies
important safety messages on the machine
and in the owner’s manual. When you see this
symbol, be alert to the possibility of personal
injury and carefully read the message that
follows.
Safety Instructions
WARNING: IMPROPER OPERATION OF
THIS MACHINE CAN CAUSE DEATH OR
SERIOUS INJURY. BEFORE USING THIS
MACHINE, MAKE CERTAIN THAT EVERY
OPERATOR:
• Is instructed in safe and proper use of
the machine.
• Reads and understands the Manual(s)
pertaining to the machine.
• Reads and understands ALL Safety
Decals on the machine.
• Clears the area of other persons.
• Learns and practices safe use of machine
controls in a safe, clear area before
operating this machine on a job site.

6Timber Ax
Owner’s Responsibility (Cont’d)
Make sure the attachment is installed on the machine
correctly before being placed in service. At regular
intervals thereafter, the attachment should be serviced
in accordance with procedures outlined in this owner’s
manual.
Mandatory Shut-Down Procedure
• Stop the machine and attachment on a level surface
and lower the attachment to the ground.
• Move throttle to idle position.
• Disengage all power to the attachment.
• Shut off engine and remove the key.
Wait until the rotor has stopped completely before
inspecting the attachment.
Safety Rules
These are general safety considerations. Additional
precautions may be necessary to operate your
machine in a safe manner. Be certain you are operating
your machine in accordance with all safety codes,
OSHA rules and regulations, insurance requirements
and local, state, and federal laws.
• Read this manual carefully. Become thoroughly
familiar with the controls and proper use of the
machine. Insure that all operators know how to stop
the unit by disengagement of the controls using the
“Mandatory Shut-Down Procedure” on page 6.
• It is the owner’s responsibility for communicating all
information on the safe use and proper maintenance
of this machine.
• Never allow children to operate equipment. Allow
adults to operate the equipment only after receiving
the proper instructions. Keep the area of operation
clear of all unauthorized persons.
• Remove from area of operation all foreign objects
such as sticks, wire, rocks, etc., that might become
tangled in the rotor, causing damage to the machine
or thrown from the attachment striking other objects.
• Never attempt to make any adjustments while the
engine is running or the key is in the “ON” position of
the skid-steer loader. Before leaving the operator’s
position, disengage power to the attachment and
remove ignition key.
• Disengage hydraulic valve and place skid-steer
controls in neutral or park before starting engine.
Safety Instructions for Operation and
Maintenance
The following safety warnings are used here and on the
Timber Ax. Become familiar with them before operating
this machine.
CAUTION:
• Failure to follow safety, operating, and maintenance
instructions could result in death or serious injury to
the operator or bystanders, poor operation, or costly
breakdown.
• Become familiar with and know how to use all safety
devices and controls on the attachment before
attempting to operate the unit. Know how to stop
the unit before starting it.
• Do not start, operate, or work on this machine until
you have carefully read and thoroughly understand
the contents of this manual and the operator’s
manual for your loader.
• Keep children, spectators and other workers off
and away from the machine while it is operating or
engine is running. Do not carry passengers.
• Before inspecting, cleaning, lubricating, adjusting
or servicing any part of the attachment, always
exercise the “Mandatory Shut-Down Procedure” on
page 6. After service has been performed, be
sure to restore all guards, shields and covers to their
original position.
• Read and observe all warnings decals on the machine
before attempting to operate the attachment. Do not
attempt to operate this machine unless all factory
devices and decals are in place. Keep safety decals
clean of dirt and grime. Keep all guards, shields and
decals in place.
Safety Instructions

7Timber Ax
Safety Rules (Cont’d)
Safety Instructions for Operation and
Maintenance (Cont’d)
• The operator must not use drugs or alcoholic drinks
which would impair his alertness or coordination
while working. An operator who is taking prescription
drugs must get medical advice to determine if he
can safely operate a machine.
• Before using the attachment on a new job site,
check the rules and regulations at the location.
The rules may include an employer’s work safety
requirements.
• Make sure all controls, (levers, pedals and switches),
are in NEUTRAL position before starting the loader
engine.
• To prevent serious personal injury from escaping
high pressure fluid, never attempt to inspect, service
or disassemble any part of the hydraulic system until
all pressure has been relieved from the system. Do
not use your hands to check for hydraulic leaks.
WARNING:
• Keep all guards, shields and decals in place.
• Always repair or replace any damaged front guard
chains.
• Keep hands, feet and clothing away from moving
components.
• Do not wear loose or baggy clothing around rotating
machinery. Machine must be clear of people, tools,
and other objects before engaging hydraulic valve.
• Before working under any hydraulically controlled
implement, be certain it is securely blocked!
• Because of the potential safety hazard to eyes
from hydraulic leaks and/or flying debris, “USE
OF PROTECTIVE EYEWEAR IS ABSOLUTELY
MANDATORY” for operator and others in the work
area.
• Always use an approved roll bar and seatbelt for safe
operation. Overturning a loader without a roll bar and
seatbelt can result in injury or death.
• Use the handholds and step plates when getting on
and off the loader to prevent falls. Keep steps and
platform cleared of mud and debris.
• Operate the attachment only from the operator’s
seat.
• Keep your feet on the pedals, (floor plates) seat belt
fastened snuggly and seat bar lowered, (if equipped),
when operating the attachment.
• Never operate the attachment in a lifted position.
Work only on the surface that the loader is standing
on.
• Do not operate the attachment above the rated
RPM.
DANGER:
• DANGER: Before leaving the operator’s position for
ANY reason or allowing anyone near the attachment,
always exercise the following “Mandatory Shut-
Down Procedure” on page 6.
Safety Instructions

8Timber Ax
Safety Rules (Cont’d)
Operation Safety
Because this machine will be operated in a potentially
hazardous environment, it is ABSOLUTELY MANDATORY
that you read and follow these safety precautions.
WARNING:
• Due to the possible danger of flying debris, it is
“ABSOLUTELY MANDATORY that IMPACT-
RESISTANT SHIELDING” be provided on the power
unit to protect the operator. The owner is responsible
for providing the operator protection devices on the
power unit.
• The adjustable push bar could contact the power
unit in some positions. Before starting the power
unit, set the push bar in the most forward position,
then slowly rotate the Timber Ax back while an
assistant checks for clearance. Repeat this process
in the other settings to determine which positions
are usable with your power unit.
• Stay alert for hidden hazards or traffic. Do not carry
passengers.
• Never operate the attachment without good light or
visibility.
• After striking a foreign object, be sure to exercise the
“Mandatory Shut-Down Procedure” on page 6.
Thoroughly inspect the attachment for any damage
before restarting and operating the machine.
• Repeated impact of knives with ground or hard
objects can cause excessive wear and damage to
the skid-steer or attachment. Be sure to maintain
recommended ground clearance as specified in this
manual.
• Should excessive vibration occur, disengage
hydraulic valve immediately. Do not continue
operation of the attachment until the problem has
been detected and corrected. Be sure to exercise
the “Mandatory Shut-Down Procedure” on page
6.
• Disengage power to the attachment when
transporting or not in use.
• When transporting the attachment on the road at day
or night, provide adequate warning to the operators
of other vehicles.
• Never park on a steep incline.
• Do not leave equipment in raised position.
• DO NOT allow ANY people or animals within 300
feet of the work area while operating this machine.
• THOROUGHLY clear the work area of ALL foreign
objects such as bottles, rocks, wire, etc. before
starting the machine.
• ALWAYS operate the attachment level with the
ground (front to rear).
• NEVER operate the attachment over 2 feet above
the ground.
WARNING:
• Never operate the attachment without guards,
shields, plates or other safety precaution devices in
place. Shields are for your protection, please keep
all shields in place.
• Always cut in an up and down direction on slopes.
To avoid loss of control and to prevent overturn,
never cut across the slope.
• Reduce speed when turning.
• Do not operate on extremely steep slopes.
• Before servicing or adjusting the attachment, or
removing material from it, be sure to exercise the
“Mandatory Shut-Down Procedure” on page 6.
• Be sure the rotor has stopped completely before
checking knives.
• Be especially careful not to touch attachment parts
which might be hot from operation. Allow such parts
to cool before attempting to maintain, adjust, or
service.
DANGER:
• Never get off skid-steer while it is in motion!
• Keep hands and feet out! Do not step on or climb
over the unit while machine is in operation, or engine
is running. Do not carry passengers.
Safety Instructions

9Timber Ax
Safety Rules (Cont’d)
Hydraulic Safety
• The hydraulic system is under high pressure. Make
sure all lines and fittings are tight and in good
condition. These fluids escaping under high pressure
can have sufficient force to penetrate skin and cause
serious injury.
• Never check for leaks by using any part of your body
to feel for escaping fluid.
• When high pressure fluid escapes, it can be almost
invisible, yet have enough pressure to penetrate the
skin and enter the blood stream. Never attempt to
use hands to search for suspected oil leak. If injured
by escaping fluid, consult a doctor at once! Serious
reaction or infection can occur if proper medical
treatment is not obtained immediately.
Safety Instructions

10 Timber Ax
Safety Instructions
Pusher Bar
Rotor and Knives
Hydraulic Hoses
Hydraulic Hose Support
Drive Belt and
Belt Shield
Rotor Locking Pin
(Storage Location)
Mounting Plate
Deflector Chain
Hydraulic Motor and
Motor Shield
Pressure Gauge
Skid
Skid
Rotor Bearing
Guard
Timber Ax Identification

11Timber Ax
Safety Instructions
Safety Decal Locations
Check and replace any worn, torn, hard to read or
missing safety decals on your machine.
1
4
5
2
2
1
2
3
Part No. N17013
Part No. N20661
Part No. N17014
WARNING
Due to the possible danger of flying debris,
it is absolutely MANDATORY that impact-resistant
shielding be provided on the power unit to
protect the operator.
The owner is responsible for providing the
operator protection devices on the power unit.
WARNING
Flying Debris can gather on the skid-loader and needs to
be cleaned off, especially around the radiator and oil cooler
screens, engine compartment and exhaust areas. Periodic
cleaning will help prevent the possibility of fire.
The adjustable push bar could contact the power
unit in some positions.
Before starting the power unit, set the push bar in the
most forward position, then slowly rotate the cutter
head back while an assistant checks for clearance.
Repeat this process in the other settings to determine
which positions are usable with your power unit.
WARNING
4
Part No. N28385
WARNING
IMPROPER CONNECTION TO THE POWER UNIT'S HYDRAULIC SYSTEM
COULD CAUSE SERIOUS COMPONENT DAMAGE AND PERSONAL INJURY.
This attachment can be configured with different components to operate on a variety
of power units, with or without case drain connections.
It is absolutely MANDATORY that you refer to your OPERATOR'S MANUAL for Set-up
Instructions and Pressure Ratings that apply to the components used on this unit.
The dealer/owner will be responsible for any damage caused by improper connection
to the power unit.
For technical assistance call Loftness/US Attachments at 800-828-7624
International: 320-848-6266 www.loftness.com
5
Part No. N13863

12 Timber Ax
Safety Instructions
Safety Decal Locations (Cont’d)
6
7
7
6
6
Part No. N28386
STAY BACK
KEEP HANDS AND FEET
AWAY FROM ROTATING
KNIVES UNDER MACHINE
DO NOT LEAVE
OPERATORS POSITION
WHILE POWER UNIT IS
RUNNING
DANGER
7
Part No. 4334
8
8
Part No. N16759
WARNING
Rotor must be stabilized with the rotor locking pin
to prevent accidental rotation any time the rotor is
exposed for service work.
Do Not Remove the locking pin for any reason
when one or more knives are missing from the
rotor assembly. The imbalance could cause the
rotor to turn without warning, causing serious
personal injury.

13Timber Ax
Safety Instructions
Safety Decal Locations (Cont’d)
10
9
10
9
Part No. 4189
Part No. 4256
WARNING
Rotating parts hazard.
Can cause serious
injuries or death.
Do not operate machine
without shields attached.
PN 4189
DO NOT START, OPERATE, OR WORK ON THIS
MACHINE UNTIL YOU HAVE CAREFULLY READ
AND THOROUGHLY UNDERSTAND THE
CONTENTS OF THE OPERATOR'S MANUAL.
NOTE: IF YOU DO NOT HAVE AN OPERATOR'S
MANUAL, CONTACT YOUR DEALER OR
LOFTNESS SPECIALIZED EQUIPMENT
650 SOUTH MAIN
HECTOR, MN 55342
1-800-828-7624
FAILURE TO FOLLOW SAFETY, OPERATING, AND
MAINTENANCE INSTRUCTIONS COULD RESULT
IN DEATH OR SERIOUS INJURY TO THE
OPERATOR OR BYSTANDERS, POOR
OPERATION, AND COSTLY BREAKDOWN.
CAUTION

14 Timber Ax
