LOFTNESS FS 800 User manual

Model Number:
Serial Number:
Date of Purchase:
FS 800 Fertilizer Spreader
Owner’s Manual and Parts Book
(Originating w/Serial Number
76-001 thru 76-145)
12.28.17N62775 Rev. B

LOFTNESS SPECIALIZED EQUIPMENT, INC.
LIMITED WARRANTY POLICY
The limited warranty policy begins upon delivery of the unit to the original customers.
All Loftness products have a one (1) year limited warranty. The XLB10 Grain Bag Loader has a two (2) year limited warranty.
If any Loftness product is used as rental equipment, or in a commercial application, the limited warranty period is for only 30 days
from the delivery date to the original customers.
Loftness Specialized Equipment, hereinafter referred to as LOFTNESS, a manufacturer of quality machinery since 1956, warrants
new LOFTNESS machinery and/or attachments at the time of delivery to the original purchaser, to be free from defects in material and
workmanship when properly set up and operated in accordance with the recommendations set forth in the LOFTNESS Operator’s
Manual.
LOFTNESS’ liability for any defect with respect to accepted goods shall be limited to repairing the goods at an authorized dealer or
other LOFTNESS designated location, or replacing them as LOFTNESS shall elect. The above shall be in accordance with
LOFTNESS warranty adjustment policies.
WARRANTY REQUIREMENTS
.smialcytnarrawllaetadilavottnempiuqEdezilaicepSssentfoLotdenruterdnatuodellifebtsummrofnoitartsigerytnarraW
To receive a warranty claim, a return authorization from LOFTNESS must be obtained. The failed part may then be returned in an
.gnicivresrofyrenihcamgninruternehwderrucnisegrahcyreviledrothgierfedulcnitonseodytnarrawsihT.sutatsderepmatnu
Dealer mileage, service calls and pick-up/delivery charges are the customer’s responsibility.
LIMITATIONS OF WARRANTY
LOFTNESS products are designed to provide years of dependable service when proper use and maintenance is adhered to. The
potential for misuse in many applications exists; therefore, a limited warranty is provided as follows.
This warranty shall not apply to any machine or attachment which shall have been repaired or altered outside the LOFTNESS factory
or authorized LOFTNESS dealership or in any way so as in LOFTNESS’ judgment, to affect its stability or reliability, nor which has
been subject to misuse, negligence or accident, nor to any machine or attachment which shall not have been operated in accordance
with LOFTNESS’ printed instructions or beyond the company recommended machine rated capacity. LOFTNESS may elect to have
an area representative evaluate the condition of the machine before warranty is considered.
In addition, this limited warranty provides no coverage for general wear or maintenance items, misuse, environmental conditions and/
or contamination for which they were not designed or not intended, including but not limited to the following items:
•Use of machine beyond its rated capacity;
•Improper knife replacement;
•Missing knives;
•Striking foreign objects
•Lack of lubrication
•Failures caused by running in an “out-of-balance” condition;
•Tires;
•Conveyors;
•Auger wear;
•Saw blades; and
•Brakes and brake pads.
EXCLUSIONS OF WARRANTY
Except as otherwise expressly stated herein, LOFTNESS makes no representation or warranty of any kind, expressed or implied. The
implied warranty of merchantability and fitness for a particular purpose are excluded from this limited warranty. The
remedies set forth in this warranty are the only remedies available to any person under this warranty. LOFTNESS shall have no
liability to any person for incidental, consequential or special damages of any description, whether arising out of express or implied
warranty or any other contract, negligence, or other tort or otherwise. This exclusion of consequential, incidental and special damages
is independent from and shall survive any finding that the exclusive remedy failed of its essential purpose. Upon purchase, the buyer
assumes all liability, all personal injury and property damage resulting from the handling, possession or use of the goods by the buyer.
No agent, employee or representative of LOFTNESS has any authority to bind LOFTNESS to any affirmation, representation or
warranty concerning its machinery and/or attachments except as specifically set forth herein.
April 2017

Fertilizer Spreader OM
Table of Contents
Warranty
Table of Contents
Introduction
Owner Information ............................................................1
Warranty Policy ..............................................................1
Serial Number Location ........................................................1
Manual Storage ..............................................................1
Features ....................................................................2
Options ....................................................................2
Safety Instructions
Safety First..................................................................3
Owner’s Responsibility ........................................................3
Safety Rules.................................................................4
Operating Safety ..........................................................4
Transporting Safety ........................................................4
Maintenance Safety ........................................................5
Hydraulic Safety...........................................................5
PTO Safety...............................................................5
Chemical Fertilizer Safety ...................................................6
Fertilizer Spreader Identification .................................................7
Safety Decal Locations ........................................................8
Operation
Preparation for Use ...........................................................9
Connecting to Tractor .........................................................9
For PTO Drive Models ......................................................9
Attaching PTO ...........................................................10
Connect Hydraulics and Wiring ..............................................10
Connecting to Truck (Transporting) ..............................................10
Setting the Metering Gate Opening..............................................10
Adjusting for High or Low Range................................................11
Engaging the Conveyor Ground Drive............................................11
Spreading Speed and Interval ..................................................12
Speed..................................................................12
Driving Interval ...........................................................12
Application Rate Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Fertilizer Spreader OM
Table of Contents
Set-up Instructions
Spread Pattern Test ..........................................................14
Machine Preparation ......................................................14
Course Set-up ...........................................................14
Spread Procedure ........................................................15
Spread Pattern Recording ..................................................17
Graphing the Test Results ..................................................17
Spread Pattern Adjustments ...................................................19
Spinner Blade Positions....................................................19
Rear Deflector Adjustment..................................................19
Spinner RPM ............................................................19
Maintenance
General Maintenance.........................................................21
Maintenance Schedule .......................................................21
Fluids And Lubricants ........................................................21
Lubrication.................................................................22
Grease Points............................................................22
Wheel Bearing Maintenance ...................................................25
Roller Chains ...............................................................25
Slip Clutch Adjustment .......................................................25
Ground Drive Train Adjustment .................................................26
Hydraulic Surge Brakes (Optional)...............................................26
Operation ...............................................................26
Bleeding Brakes ..........................................................26
Brake Adjustment.........................................................26
Removing the Rear End.......................................................27
Rear Belt Alignment..........................................................27
Optional 540/1000 RPM Dual Drive..............................................27
Adjusting Belt Tension .....................................................27
Alignment of HTD (High Torque Drive) Belts ....................................27
Tightening Conveyor .........................................................28
Replacing Metering Shaft .....................................................28
Cleaning...................................................................28
Storage ...................................................................28
Troubleshooting .............................................................29

Fertilizer Spreader OM
Parts Identification
Spreader Frame .............................................................32
Conveyor ..................................................................33
Wheels, Brakes, and Suspension ...............................................34
Brakes and Suspension.......................................................35
Driveline, 540/1000 ..........................................................36
Drive, Hydraulic .............................................................38
Drive, Hydraulic (Cont’d) ......................................................40
Drive, PTO .................................................................42
Drive, Ground...............................................................44
Drive, Ground (Cont’d)........................................................46
Disconnect, Hydraulic ........................................................48
Electrical ..................................................................49
Window ...................................................................50
Manual Holder ..............................................................50
Machine Decals and Signs ....................................................51
Appendix
Specifications ..............................................................53
Dimensions ................................................................54
Torque Specifications ........................................................55
Inches Hardware and Lock Nuts .............................................55
Metric Hardware and Lock Nuts .............................................56
Table of Contents

1Fertilizer Spreader OM
Owner Information
Thank you for your decision to purchase a Fertilizer
Spreader from Loftness. To ensure maximum performance
of this product, it is mandatory that you thoroughly study
the owner’s manual and follow its recommendations.
Proper operation and maintenance are essential to
prevent injury or damage and to maximize machine life.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and / or laws, and in compliance with
on-product labeling and these instructions.
Make sure that all personnel have read this owner’s
manual and thoroughly understand safe and correct
operating, installation and maintenance procedures.
Continuous improvement and advancement of Loftness
products may result in changes to your equipment
that may not be reflected in this publication. Loftness
reserves the right to make product improvements to the
machine at any time. Although great care has been taken
to ensure the accuracy of this publication, Loftness does
not assume any liability for errors or omissions.
Loftness is not responsible for costs or damages
caused by misapplication of fertilizers. It is the
responsibility of the operator to assure that the
fertilizer is applied uniformly and correctly over the
application area.
Warranty Policy
Be sure to read and understand the Warranty Policy at
the beginning of this manual. It is also important that you
fill out the Warranty Registration form(s) completely and
return to Loftness so as not to void the warranty.
Serial Number Location
Always use your serial number when requesting
information or when ordering parts. The machine’s serial
number is stamped in this area (1).
Manual Storage
Keep the owner’s manual and the entire documentation
packet in the storage compartment provided with your
fertilizer spreader. The owner’s manual must be available
for all operators.
The manual holder is located on the inside of the spreader
tongue.
Introduction
1

2Fertilizer Spreader OM
Features
Spread Pattern
• Dual (50 ft.) stainless steel spinners deliver a
total spread pattern of 100 feet using a 100%
overlapping triangular pattern.
Wider Leaf Springs
• Heavy duty 2.5 in. wide leaf springs.
• Walking suspension.
Adjustable Height Hitch
• Moveable clevis accommodates wide range of
drawbar heights.
• Allows for leveling of spreader.
Integral Hitch
• Hitch is integral to frame.
• Suspension pulls from hitch.
Mechanical Apron Drive
• Positive mechanically driven from wheel.
Split sprocket design
• Allows for easy in-field replacement of worn
sprockets without removal of wheel.
Integral Lights
• Sealed and rubber isolated lights tucked neatly and
cleanly inside frame.
• Compliant with ASABE standard (S279.14)
Obstruction Free Interior
• No internal gussets/plates to catch fertilizer.
Introductions
Options
Conveyor Drive
• Mechanical Drive (Standard)
Two speed axle driven transmission.
Hydraulic engage/disengage from cab.
Stainless steel chains.
• Hydraulic Drive (Optional)
Spinner Drive
• 540 rpm PTO (Standard)
• 540/1000 rpm dual-drive PTO (Optional)
• Hydraulic drive (Optional)
Brakes
• None (Standard)
• 2 wheel (Optional)
• 4 wheel (Optional)
Roll Tarp
• Optional (Contact your dealer for a hopper roll tarp.)

3Fertilizer Spreader OM
Safety First
Accidents can be prevented by recognizing the causes or
hazards before an accident occurs and doing something
about them. Regardless of the care used in the design
and construction of this machine, there are some areas
that cannot be safeguarded without interfering with
accessibility and efficient operation.
In the owner’s manual and on decals used on the
machine the words DANGER, WARNING, CAUTION,
IMPORTANT, and NOTE are used to indicate the
following:
DANGER: This word warns of immediate hazards which,
if not avoided, will result in severe personal injury or
death. The color associated with Danger is RED.
WARNING: This word refers to a potentially hazardous
situation which, if not avoided, could result in severe
personal injury or death. The color associated with
Warning is ORANGE.
CAUTION: This word refers to a potentially hazardous or
unsafe situation that, if not avoided, may result in minor
or moderate injury. It may also be used to alert against
unsafe practices. The color associated with Caution is
YELLOW.
IMPORTANT: Highlights information that must be
heeded.
NOTE: A reminder of other related information that needs
to be considered.
Safety Alert Symbol
This message alert symbol identifies
important safety messages on the machine
and in the owner’s manual. When you see this
symbol, be alert to the possibility of personal
injury and carefully read the message that
follows.
If Safety Decals on this machine are ISO two panel
pictorial, decals are defined as follows:
• The first panel indicates the nature of the hazard.
• The second panel indicates the appropriate
avoidance of the hazard.
• Background color is YELLOW.
• Prohibition symbols such as and STOP if used,
are RED.
Be certain all machine operators are aware of the
dangers indicated by safety decals applied to the
machine, and be certain they follow all safety decal
instructions. Contact Loftness for safety decal
replacement.
Loftness cannot anticipate every possible
circumstance that may involve a potential hazard. The
warnings in this owner’s manual are not all inclusive.
Owner’s Responsibility
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws and in compliance with
on-product labeling and this owner’s manual instructions.
Make sure that all personnel have read this owner’s
manual, and thoroughly understand safe and correct
installation, operation and maintenance procedures.
Make sure the machine is assembled and installed
correctly before being placed in service. At regular
intervals thereafter, the machine should be serviced in
accordance with procedures outlined in this owner’s
manual.
Fulfill all warranty obligations so as not to void the
warranties. The warranty policy included in this manual
outlines the warranty policy of Loftness.
Safety Instructions

4Fertilizer Spreader OM
Safety Rules
These are general safety considerations. Additional
precautions may be necessary to operate your
machine in a safe manner. Be certain you are operating
your machine in accordance with all safety codes,
OSHA rules and regulations, insurance requirements
and local, state, and federal laws.
Operating Safety
• Do not allow anyone to operate the machine until he
or she has read the owner’s manual and is completely
familiar with all safety precautions.
• Do not allow inexperienced persons unfamiliar with
the machine, or unfamiliar with safe operating and
maintenance procedures, to operate or maintain the
machine.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment
or cause drowsiness to operate or maintain the
machine.
• Keep children, bystanders and other workers away
from the machine while it is operating. No riders
allowed.
• The machine requires an operator at all times. Never
leave the machine running and unattended.
• Do not wear loose hanging clothes, neckties or
jewelry. Long hair is to be placed under a cap
or hat. These precautions will help prevent you
from becoming caught in any moving parts on the
machine.
• Do wear safety glasses, ear protection, respirators,
gloves, hard hats, safety shoes and other protective
clothing when required.
• The fertilizer spreader should not be used to handle
materials other than those which were specified as
part of its design. It is the operator’s responsibility
to be aware of the specifications and operate the
spreader accordingly.
• It is the operator’s responsibility to be aware of
machine operation and work area hazards at all
times.
• Operators are responsible to know the location and
function of all guards and shields including but not
limited to PTO drivelines, chain drives, conveyors,
spinners and are responsible to make certain that all
guards are in place when operating the machine.
• Operators are responsible to be aware of safety
hazard areas and follow instructions on warning,
caution, or danger decals applied to the machine.
• Know the area before operating the machine. Be
aware of power lines or other equipment. Watch for
adequate overhead clearance.
• Always have an operator in the tractor while the
machine is in operation.
• Disengage PTO, clutch hydraulic valve and shift
tractor into neutral or park before starting engine.
Transporting Safety
• Be sure the machine is in the transport position
before transporting on a roadway.
• Do not exceed speed rating (20 mph) on the factory
provided tires.
• Disengage PTO, clutch hydraulic valve and shift
tractor into neutral or park before starting engine.
Safety Instructions

5Fertilizer Spreader OM
Maintenance Safety
• Do not allow inexperienced persons unfamiliar with
the machine, or unfamiliar with safe operating and
maintenance procedures, to operate or maintain the
machine.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment or
cause drowsiness to operate or maintain the machine.
• Make sure the operator’s area is clear of any
distracting objects. Keep work areas clean and free
of grease and oil to avoid slipping or falling.
• Periodically check all guards, shields and structural
members. Replace or repair anything that could
cause a potential hazard.
• Periodically check all hoses, hose connections and
electrical wiring. Replace or repair anything that
could cause a potential hazard.
• Do not replace components or parts with other than
factory-recommended service parts. To do so may
decrease the effectiveness of the machine.
• Do not lubricate parts while the machine is running.
• Do not smoke while servicing the machine.
• Never attempt to make any adjustments while the
tractor engine is running or the key is in the “ON”
position in the tractor. Before leaving the operator’s
position, disengage power to the machine and
remove ignition key.
Hydraulic Safety
• The hydraulic system is under high pressure. Make
sure all lines and fittings are tight and in good
condition. These fluids escaping under high pressure
can have sufficient force to penetrate skin and cause
serious injury.
• Never check for leaks by using any part of your body
to feel for escaping fluid.
• Always use a piece of wood to check for leaks.
WARNING: Contact with high pressure
fluids may cause fluid penetration and burn
hazards. Fluid that is under pressure can
penetrate body tissue. Fluid penetration can
cause serious injury and possible death. If
fluid is injected into the skin, seek medical
attention immediately!
Safety Instructions
PTO Safety
• Keep all guards and shields in place when operating
the PTO. Replace any damaged or missing guards
and shields before operating the PTO.
• Keep children, bystanders and other workers away
from the machine while it is operating or while the
PTO is engaged. No riders allowed.
• Do not wear loose hanging clothes, neckties or
jewelry. Long hair is to be placed under a cap
or hat. These precautions will help prevent you
from becoming caught in any moving parts on the
machine.
• Read and understand the tractor operation and
maintenance manual regarding safe and proper
operation for PTO driven equipment.
• Never step over or crawl around the equipment while
the PTO is engaged; entanglement could occur.
• Do not exceed rated PTO speed.
• Disengage PTO driveline and place in the stored
position when the machine is transported.
• Never use a steel hammer when connecting or
disconnecting a PTO shaft.
• Engage the PTO slowly at idle speed to prevent
unnecessary stress to the driveline.
• DO NOT USE PTO ADAPTERS OF ANY KIND.
• Use only recommended shear-bolts.
• Maintain proper hitching dimensions
1 - 3/8" - 21 Spline - PTO end to pin of draw bar 16".
1 - 3/8" - 6 Spline - PTO end to pin of draw bar 14".

6Fertilizer Spreader OM
Chemical Fertilizer Safety
• Always read the label before using chemical
fertilizers. Follow manufacturer’s instructions for
use and handling. Also follow label directions and
recommendations on keeping fertilizer residue on
edible parts of plants within limits permitted by law.
• Wear personal protective equipment (PPE) when
handling chemical fertilizers, such as safety glasses
or face shield, respirators, proper clothing, and
rubber gloves.
• Wash hands, face, and clothing after handling and
spreading.
• Do not spill chemical fertilizers on skin or clothing.
In case of a spill, remove contaminated clothing and
wash skin and clothing thoroughly with soap and
water.
• Avoid inhaling chemical fertilizers.
• Do not smoke when handling chemical fertilizers.
• Cover food and water containers when spreading
around livestock or pet areas.
• Keep bystanders away while spreading fertilizer.
• The spreader should be completely emptied of
chemical fertilizer, all residue removed, and washed
with clean water before servicing.
• If symptoms of illness occur during or after handling
and/or spreading chemical fertilizers, contact a
physician immediately.
• Store chemical fertilizer in a locked, secure space
away from food and animal feed. Do not store inside
of the home.
• Keep chemical fertilizers away from children, pets,
and unauthorized personnel.
• Store chemical fertilizers in their original containers
and securely closed. Be sure to read fertilizer
manufacturers storage recommendations.
• Dispose of empty fertilizer containers according to
manufacturer’s instructions.
Safety Instructions

7Fertilizer Spreader OM
Fertilizer Spreader Identification
Safety Instructions
19L-16.1 12 Ply Tires
Jack
PTO Drive model shown.
* Only on PTO Drive model.
Safety Chain
Adjustable
Height Hitch
540/1000 RPM
PTO
Spinner
Driveline
Hydraulic
Brake
Actuator
**PTO
Storage
Cradle
Hopper
Conveyor Ground
Drive Lever
Spinners
*Rear V-Belt
(Covered)
Rear Gate
Lever
Conveyor
Window

8Fertilizer Spreader OM
Safety Instructions
Safety Decal Locations
Check and replace any worn, torn, hard to read or
missing safety decals on your machine.
1
2
3
Part No. N35391
Part No. N35383
Part No. N35380
WARNING
N35391
Disengage all
power before
servicing
or adjusting.
CAUTION
N35383
WITH BRAKES
NO BRAKES
20 MPH
MAX
25 MPH
MAX
IMPLEMENT TOWING REQUIREMENTS
WEIGHT RATIO
1# TO 1
1/2 # MAX
1 1/2 # MAX
1#
1#
4
1/2 # MAX
WEIGHT RATIO
1# TO 4
1/2 # MAX
WARNING
N35380
Stay clear.
Wear eye
protection.
1
3
2

9Fertilizer Spreader OM
Operation
Preparation for Use
Before putting the spreader into operation make sure
the machine has been properly adjusted and the spread
pattern has been determined.
IMPORTANT: Read and thoroughly understand the
contents of the operator’s manual before
operating.
• Visually inspect the spreader for damage or missing
parts. Contact your Loftness dealer if any parts need
replacing.
• Check the v-belts and chains for tension and
alignment.
• Check the machine for loose bolts. Check bearing,
sheave, and sprocket set screws.
• For PTO drive models, check the rear belt wrap. The
spinners should rotate in opposite directions.
• Check wheel lugs for tightness.
• Check tire pressure.
• Turn conveyor chain by hand to ensure it moves
freely without obstruction(s).
• Check conveyor chain for tension. There should be a
2-3 in. (5.08 - 7.62 cm) sag underneath.
• Perform a test pattern.
IMPORTANT: Before placing the fertilizer spreader into
operation, a spread pattern test MUST
be performed. Refer to “Spread Pattern
Test” on page 14 for instructions.
Connecting to Tractor
For PTO Drive Models
Adjust the spreader hitch so the spreader is as level as
possible. Connect to the tractor and install an approved
hitch pin for the load, securing hitch pin with a safety
locking pin. Connect the safety chains to the tractor.
Connect surge breakaway chain to tractor.
The tractor draw bar and PTO must conform to ASAE
specifications shown in illustration below for proper PTO
operation.
PTO Shaft
Drawbar
A
B
C
CAUTION: Lock the draw bar securely in
both the horizontal and the vertical positions
to avoid damage to the PTO.
A- 6-12 in. (15.24-30.48 cm)
B- 13-17 in. (33.02-43.18 cm); 15 in. (38.1 cm preferred.
(Higher draw bars disrupt spread pattern.)
C- 540 RPM - 14 in. (35.56 cm);
1,000 RPM - 16 in. (40.64 cm)
CAUTION: Always work with the PTO
driveline as straight as possible to guard
against damage to the PTO, spreader, or
tractor.

10 Fertilizer Spreader OM
Attaching PTO
1
2
1,000 RPM Input Shaft
Connect the PTO to the top shaft (1) on the spreader for
1,000 RPM input.
540 RPM Input Shaft
Connect the PTO to the bottom shaft (2) on the spreader
for 540 RPM input.
Connect Hydraulics and Wiring
Connect the hydraulic hoses used for the cylinder to the
tractors hydraulic system.
Connect the spreader wiring connector to the tractor
using the provided 7-pin round to 4 wire flat connector.
See Loftness part number N62721.
Connecting to Truck (Transporting)
CAUTION: Tow only with a truck or vehicle
capable of pulling the weight of the spreader
and its contents.
Adjust the spreader hitch so the spreader is as level
as possible. Connect to the truck hitch and install an
approved hitch pin for the load, securing hitch pin with
a safety locking pin. Connect the safety chains to the
truck. Connect surge breakaway chain to the truck
Connect the spreader’s running light wiring harness to
the truck.
IMPORTANT: Make sure PTO is locked in the storage
cradle and hydraulic hoses are secure
before transport.
Setting the Metering Gate Opening
The application rate is determined by the metering gate
opening and the speed of the conveyor chain.
To determine the gate opening:
1. Determine the fertilizer density. Weigh 1 gallon (3.78
Liters) of the fertilizer and then multiply that by 7.5.
2. Select the column with the value closest to your
outcome in the “Product Density” row of the
application rate chart found on page 13. Follow
this column down to the desired application rate.
3. Follow this row to the left of the chart to the proper
gate opening size.
2
1
3
Loosen knob (1). Move the gate control lever (2) until
the indicator (3) is at the proper setting. Lock gate by
retightening the knob (1).
Operation

11Fertilizer Spreader OM
Adjusting for High or Low Range
1
Determine if the application will be spread in high range
or low range.
High range - the chain must be on the inside sprockets.
Low range - the chain must be on the outside sprockets.
If adjustment is needed, loosen the conveyor drive chain
tensioner (1) and move the chain to the appropriate set
of sprockets. Reposition the drive chain tensioner and
retighten. Chain tensioner should be oriented such that it
does not touch sprockets.
IMPORTANT: Read the application rate chart for
operating in high range. To avoid undue
stress on the conveyor mechanism, it is
recommended to use the largest practical
gate opening in low range before
changing to high range.
To assure a uniform application rate around field edges,
make a border application with these adjustments.
Reduce to 1/2 fan speed, gate opening, and travel
interval.
CAUTION: Do not use a gate setting of
1.5 in. (3.81 cm) in high range. This could
cause undue stress on the hopper from a high
conveyor speed.
Operation
Engaging the Conveyor Ground Drive
1
2
Raise the lever (1) to the upper position as shown to
engage the ground drive. Secure with retaining pin (2).
To disengage the drive, move the lever to the lower
position and secure with the retaining pin.
During transport, always have the ground drive
disengaged.
IMPORTANT: Be sure the chain engages the hub
sprocket properly. If it slips to one
side, raise the chain and realign before
lowering.

12 Fertilizer Spreader OM
Spreading Speed and Interval
Speed
When spreading for a test pattern and for the final field
application, maintain a speed of 3-8 mph.
Driving Interval
Test Pattern Interval: Driving interval is 50 ft. (15.24 m)
to maintain accurate application rate and spread pattern.
Field Application Interval: Determine optimum driving
interval by following the steps below.
NOTE: The spreader is designed to spread the material
50 ft. (15.24 m) to each side of center, giving a
double coverage for a uniform application. The
application chart is based on 50 ft. (15.24 m)
driving intervals, not the actual spread width.
However, a slight change in driving distance may
be beneficial for optimum coverage.
1. Make sure all adjustments and a spread pattern has
been produced following the “Spread Pattern Test”
and “Spread Pattern Adjustments” section in this
manual.
2. From the Spread Pattern Test Results Sheet found
on page 16, determine the maximum (cc) volume
value of material in center of pattern.
3. Divide this value by two.
4. Locate the distance from the zero foot mark
(centerline of driving path) where the graph intersects
this (cc) value.
5. Multiply this distance by two to determine the
optimum driving interval.
Even if the pattern has an acceptable shape, optimum
driving interval may be too small for practical field
use. If this is the case, the spreader must be adjusted
to produce the best possible pattern shape with an
acceptable driving interval.
CAUTION: Do not exceed the rated gross
weight of the spreader.
Operation
