Industrial Computer - LC6000
Connector Assignment
USB Port
Serial Port
Keyboard/MouseInput
Video Output
Industrial Computer - LC6000
Front View
Back View
MECHANICAL
Weight 2.3 lbs
Dimension (in inches)
Housing
6.3W x 1.0H x 5.1D
zinc die cast
ELECTRICAL
(External Switching Power Adapter - included)
Input 100 to 240VAC, 25W
Frequency 47 to 63 Hz
Output 5.0VDC at 1A
2.5VDC at 2A
Output Ripple < 150 mVPP
Operating Temperature 5°C to 40°C
Relative Humidity 8 to 80%, non-condensing
Storage Temperature 0°C to 60°C
Relative Humidity 5 to 80%, non-condensing
LOGIC CONTROLS, INC., NY, USA
An Innovative Manufacturer Since 1982
www.logiccontrols.com
LC6000 TECHNICAL SPECIFICATIONS
Standard, DB15 female connector
PS/2 mini-DIN6 female connector
Standard DB9 male connector
Standard USB type-B connector
RJ45 8 pin female connector
Shielded snap lock mini-DIN with
EMI/RFI suppression, female
connector
LC6000
Power Adapter Input
Ethernet Port
SVGA
Keyboard & Mouse
RS232
USB
Ethernet
DC Power
SYSTEM
Intel Compatible 133MHz 486DX2
32MB to 64MB SDRAM
Internal Compact Flash, 16MB to more than 4GB
Resolution: 1280 x 1024 pixels max.
Color: up to 16 million colors (True Color)
10/100 Base-T Ethernet
USB 1-1
COM1
COM2 (internal connection)
PS/2 Compatible
LPT1 (internal connection)
Primary IDE (internal connection)
Windows CE/98, DOS, Red Hat Linux 7.3
Processor
Memory
Hard Drive
Video
Network Interface
USB Port
Serial Port
Keyboard/Mouse
Parallel Port
IDE Port
Supported Operating
Systems
ENVIRONMENT
CONNECTORS
