Logic Supply Karbon 300 User manual

Karbon 300 Manual
Version 3.0
US Offi ce
Phone: [phone]
Email: [e-mail]
www.logicsupply.com
EU Offi ce
Phone: [phone]
Email: [e-mail]
www.logicsupply.com

2
Karbon 300 Rugged Computer
Karbon 300 Manual
1 - System Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.1 - What’s In The Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1.1 - Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2 - Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.3 - Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4 - Exterior Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.5 - Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.6 - Motherboard Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.6.1 - System Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.6.2 - Memory Specifi cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.6.3 - Motherboard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2 - Pin Defi nitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.1 - External I/O Defi nitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.1.1 - Audio Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.1.2 - CAN Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.1.3 - DIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.1.4 - LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1.5 - LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.1.6 - Automotive Ignition Power Sensing (IGN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.1.7 - Serial Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2 - On-Board I/O Defi nitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.2.1 - M.2 2230 E-key Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.2.2 - M.2 2280 M-key Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.2.3 - mPCIe Expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3 - Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.1 - Pre-Installation Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.2 - M.2 or mPCIe Expansion Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.3 - Mounting Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.3.1 - Wall Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.3.2 - DIN Rail Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.3.3 - Wall (Shock and Vibration) Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.3.4 - VESA Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4 - BIOS Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.1 - UEFI Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.2 - Main Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.3 - Advanced Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.3.1 - Driver Health . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.3.2 - NCT5524D Super IO Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.3.3 - Hardware Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.3.4 - S5 RTC Wake Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.3.5 - CPU Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.3.6 - AMI Graphic Output Protocol Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4.3.7 - Network Stack Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
4.3.8 - USB Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.3.9 - Platform Trust Technology (PTT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4.3.10 - Thermal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.3.11 - System Component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4.3.12 - RC ACPI Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
4.4 - Chipset Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4.4.1 - PCI Express Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.4.2 - USB Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.5 - Security Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
4.5.1 - Secure Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
4.5.2 - HDD Security Confi guration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4.6 - Boot Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
4.6.1 - UEFI Hard Disk Drive BBS Priorities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
4.7 - Save & Exit Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

3
Karbon 300 Rugged Computer
5 - Logic Supply Microcontroller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5.1 - Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5.2 - Using the Serial Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5.2.1 - Method 1 - Serial Terminal Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5.2.2 - Method 2 - Pykarbon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5.3 - Serial Interface Technical Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5.3.1 - Connection Specs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5.3.2 - Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
6 - Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
6.1 - Wake-Up Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
6.2 - Protection Circuitry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Karbon 300 Rugged Computer
4
Contact nformation
Logic Supply Global
35 Thompson Street
South Burlington, VT 05403
USA
[phone]
[email protected]m
Logic Supply Europe
De Boedingen 39
4906 BA Oosterhout
The Netherlands
[phone]
[email protected]
Preface
About Loic Supply
Logic Supply is powering innovation with highly confi gurable embedded and IoT computers engineered for
reliability. Businesses worldwide depend on our solutions to operate in the toughest environments while
tapping into the evolving Industrial Internet of Things.
This guide will introduce you to the Karbon 300 (K300) rugged computer and walk you through hardware
installation, BIOS setup, and the Logic Supply Microcontroller (LS MCU) setup. For technical questions or
support, please reach out via our contact information below.
You have a lot of choices when choosing computer hardware. The Logic Supply Team wants to thank you for
trusting our hardware to meet your application needs. Karbon 300 is the result of input from partners like
you. We’ve worked hard to create a system that meets the varied needs of industrial and IoT computing and
we’ve manufactured this system under our strict quality assurance and immunity standards to serve you
best. If you have any concerns about the quality or performance of this product, please contact us directly
or visit our support pages at US: https://www.logicsupply.com/company/support/ or EU: https://www.
logicsupply.com/eu-en/company/support/.

Karbon 300 Rugged Computer
5
Revision History
Revision Date Notes
1.0 05/15/2019 Initial Karbon 300 manual release
2.0 07/29/2019 Updated DIO Circuit Diagram
3.0 08/20/2019 Updated part number for 3-pin CAN bus terminal block connector

Karbon 300 Rugged Computer
6
Legal Disclaimer
Intellectual Property Notice: All material including but not limited to, text, design specifi cations, graphics,
logos, reference, images, drawings, and software including this document and the product itself (together
and separately) is owned, controlled by, licensed to, or used with permission by Logic Supply, Inc., Logic
Supply BV, Interlogic, Inc. or the authorized agents and representatives (Collectively “Logic Supply”) and is
protected by copyright, trademark, and other intellectual property rights. No part of this manual may be
reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except
duplication of documentation by the purchaser for backup purpose, without the written consent of Logic
Supply. Products and corporate names appearing in this manual may or may not be registered trademarks
or copyrights of their respective companies, and are used only for identifi cation or explanation and to the
owners’ benefi t, without intent to infringe. Information in this document is subject to change without notice.
Legal Disclaimer: Specifi cations and information contained in this manual are furnished for informational
use only and subject to change without notice, and should not be constructed as a commitment by Logic
Supply. Logic Supply assumes no responsibility for any errors or omissions that may appear in this manual.
With respect to the contents of this manual, all is provided “as is” and Logic Supply does not provide
warranty of any kind, either expressed or implied, statutory or otherwise and expressly disclaims all implied
warranties of noninfringement, merchantability, and fi tness for a particular purpose. IN NO EVENT SHALL
LOGIC SUPPLY, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY
TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
IN PARTICULAR, LOGIC SUPPLY SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA
STORED OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARD- WARE, SOFTWARE, OR DATA. Unless otherwise expressly agreed
to in writing, the sale, use, etc. of any and all Logic Supply products is governed exclusively by the terms and
conditions of purchase (www.logicsupply.com/company/support/terms-conditions) and/or other written
agreements executed by Logic Supply. Unless other- wise expressly agreed to in writing, any and all disputes
arising between Logic Supply and the customer shall be governed by the laws of the State of Vermont, USA
and the State of Vermont shall be the exclusive venue for the resolution of any such disputes.
Regulatory Compliance: This digital device is designed to comply with all applicable FCC Rules Part 15
and CE compliance requirements for electronic equipment. For more detailed or additional regulatory
compliance information, please see the relevant product page at www.logicsupply.com or contact Logic
Supply directly at [e-mail].
Copyright © 2018 by Logic Supply, Inc. All rights reserved.

Karbon 300 Rugged Computer
7
Reulatory Compliance and Safety nformation
This document provides international regulatory and safety compliance information for the Logic
Supply Rugged Fanless PC model K300 computer system. This information also covers models
xxxxxK300xxxxxxxxxxxxxxx (where x is any alphanumeric character, “-” or blank designating confi guration
diff erences).
Safe use and installation instructions
1. Do not open or modify the device. This device uses components that comply with FCC and CE
regulations. Modifi cation of the device may void these certifi cations.
2. Install the device securely. Be careful handling the device to prevent injury and do not drop.
3. Wall or ceiling mounting device requires use of a mounting plate or bracket. Plate or bracket must be of
metal construction and have a minimum thickness of 1mm.
4. Use M3x0.5mm Flat Head screws to attach mounting plate or mounting brackets to threaded holes on
bottom or rear of chassis. Screws should be minimum length of 4mm. Add 1mm of screw length for
every millimeter of additional thickness of plate or bracket beyond 1.5mm.
5. Ambient operating temperature must be between -25°C to 70°C with a non-condensing relative
humidity of 10-90%. Operational temperature is dependent on component selection including power
adapter. See Table 1 below for derating.
6. The device can be stored at temperatures between -40°C to 85°C.
7. Keep the device away from liquids and fl ammable materials.
8. Do not clean the device with liquids. The chassis can be cleaned with a cloth.
9. Allow at least 2 inches of space around all sides of the device for proper cooling. If device is mounted
to vertical surface then recommended device orientation is so that heatsink fi ns allow air to rise
unobstructed. Alternative orientations may result in reduced operational temperature range.
10. This device is intended for indoor operation only.
11. Use UL Listed external power supply with rated output 9-36V DC.
12. Install the device only with shielded network cables.
13. Service and repair of the device must be done by qualifi ed service personnel. This includes, but is not
limited to, replacement of the CMOS battery. Replacement CMOS battery must be of the same type as
original.
14. Proper disposal of CMOS battery must comply with local governance.
WARNING: There is danger of explosion if the CMOS battery is replaced incorrectly. Disposal of
battery into fi re or a hot oven, or mechanically crushing or cutting of a battery can result in an
explosion.

Karbon 300 Rugged Computer
8
Précautions et guide d’installation
1. Ne pas ouvrir ou modifi er l’appareil. L’appareil utilise des composants conformes aux réglementations
FCC et EC. La modifi cation de l’appareil peut annuler ces certifi cations.
2. Installez l’appareil en toute sécurité. Soyez prudent lors de la manipulation de l’appareil pour éviter les
blessures et ne pas faire tomber.
3. Le montage au mur ou au plafond nécessite l’utilisation d’une plaque de montage ou d’un support. La
plaque ou le support doit être en métal et doit avoir une épaisseur minimale de 1 mm.
4. Utilisez des vis à tête plate M3x0,5mm pour fi xer la plaque de montage ou les supports aux trous fi letés
situés au bas ou à l’arrière du châssis. Les vis doivent avoir une longueur minimale de 4 mm. Ajoutez
1 mm de longueur de vis pour chaque mm d’épaisseur supplémentaire de plaque ou de support
dépassant 1,5 mm.
5. La plage de températures de fonctionnement doit être de -25 °C à 70 °C avec une humidité relative de
10 à 90% sans condensation. La température de fonctionnement dépend du choix du composant, y
compris de l’adaptateur d’alimentation. Voir le tableau 1 ci-dessous pour le déclassement.
6. La plage de températures de stockage doit être de -40 °C à 85 °C.
7. Gardez l’appareil à l’écart des liquides et des matières infl ammables.
8. Ne nettoyez pas l’appareil avec des liquides. Le châssis peut être nettoyé avec un chiff on.
9. Laissez au moins 5 cm d’espace autour de tous les côtés de l’appareil pour un refroidissement correct.
Si l’appareil est monté sur une surface verticale, l’orientation recommandée est telle que les ailettes
du dissipateur de chaleur permettent à l’air de monter sans obstruction. Les orientations alternatives
peuvent entraîner une réduction de la plage de température de fonctionnement.
10. Cet appareil est conçu uniquement pour une utilisation en intérieur.
11. Utilisez une alimentation externe listée UL avec une sortie nominale de 9-36V DC.
12. Installez l’appareil uniquement avec des câbles réseau blindés.
13. L’entretien et la réparation de l’appareil doivent être eff ectués par du personnel qualifi é. Cela inclut,
sans toutefois s’y limiter, le remplacement de la batterie CMOS. La batterie CMOS de remplacement doit
être du même type que l’originale.
14. La mise au rebut des batteries usagées doit être réalisée conformément aux réglementations
environnementales.

Karbon 300 Rugged Computer
9
Table 1 - Operational temperature rating by included power adapter
Power Adapter Model
(Modèle d’adaptteur
d’alimentation )
Description
(Description)
Operating Temperature
(Plage de températures de
fonctionnement)
GST60A12
60W AC-DC SWITCHING ADAPTOR;
Input: 100-240Vac, 50/60Hz, 1.4A;
Output: 12Vdc, 5.0A
-25°C - 50°C
GST90A24
90W AC-DC SWITCHING ADAPTOR;
Input: 100-240Vac, 50/60Hz, 1.3A;
Output: 24Vdc, 3.75A
-25°C - 40°C
GST120A24
120W AC-DC SWITCHING ADAPTOR;
Input: 100-240Vac, 50/60Hz, 1.4A;
Output: 24Vdc, 5.0A
-25°C - 40°C
FSP090-AAAN3
90W AC-DC SWITCHING ADAPTOR;
Input: 100-240Vac, 50/60Hz, 1.2A;
Output: 24Vdc, 3.75A
0°C - 40°C
FSP120-AAAN3
120W AC-DC SWITCHING ADAPTOR;
Input:100-240Vac, 50/60Hz, 1.2A;
Output: 24Vdc,5.0A
0°C - 40°C
No Adapter
(Sans adaptateur) -- -25°C - 70°C
Interchangeable Adapter
(Adaptateur interchangeable)
UL Listed;
Output: 9-36Vdc, 60W minimum;
-25°C - 70°C ambient operating
temperature (-25°C - 70°C plage de
températures de fonctionnement)
-25°C - 70°C

Karbon 300 Rugged Computer
10
Declaration of Conformity
FCC
This device complies with part 15 of the FCC rules as a Class A device. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that might cause undesired operation.
ISED (Innovation, Science and Economic Development Canada)
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire
de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
CE
This equipment complies with all application European Union (CE) directives if it has a CE marking. For this
device to remain CE compliant, only CE compliant parts can be installed and proper cables and cabling
techniques are required.

Karbon 300 Rugged Computer
11
We of:
Logic Supply, Inc. Logic Supply BV
35 Thompson Street De Boedingen 39
South Burlington, VT 05403 4906 BA Oosterhout
USA The Netherlands
In accordance with the following Directive(s):
Electromagnetic Compatibility (2014/30/EU)
Low-Voltage (2014/35/EU)
RoHS 2 (2011/65/EU)
Radio Equipment (2014/53/EU) - Only applicable for confi gurations with wireless transmitters
Hereby declare that:
Equipment: Logic Supply model(s): xxxxxK300xxxxxxxxxxxxxxx
Is in conformity with the applicable requirements of the following documents:
EN 55032:2015/AC:2016 Class A
EN 55035:2017
EN 61000-3-2:2014 Class D
EN 61000-3-3:2013
EN 61000-4-2:2009
EN 61000-4-3:2006+A1:2008+A2:2010
EN 61000-4-4:2012
EN 61000-4-5:2014+A1:2017
EN 61000-4-6:2014+AC:2015
EN 61000-4-8:2010
EN 61000-4-11:2004+A1:2017
EN 62368-1:2014
EN 301 489-1 V2.2.0 (2017-03) Draft
EN 301 489-17 V3.2.0 (2017-03) Draft
Reports: BTL-EMC-1-1901T106, BTL-EMC-2-1906T106, BTL-ETSE-1-1901T106
Hereby declare the equipment named above has been designed and/or tested to comply with the relevant
sections of the above referenced specifi cations. The unit complies with all applicable Essential Requirements
of the Directives.

1 - System Overview

Karbon 300 Rugged Computer
13
1.1 - What’s In The Box
1.1.1 - Accessories
• 3-pin Power Terminal Block Connector (Dinkle 2ESDVM-03P)
• 3-pin CAN bus Terminal Block Connector (Dinkle EC350V-03P)
• 10-pin DIO Terminal Block Connector (Dinkle EC350V-10P)
• M.2 and mPCIe expansion card screws
If you purchased additional items such as specifi c mounting brackets, power supplies or antennas, they will
be located in the system box or within the outer shipping carton.
All drivers and product guides can be found on the corresponding product page. For more information on
accessories and additional features, visit the Karbon 300 page at US: https://www.logicsupply.com/k300/
or EU: https://www.logicsupply.com/eu-en/k300/.

Karbon 300 Rugged Computer
14
1.2 - Highlights
Karbon 300 is designed for use as an industrial or mobile gateway, automation PC, workstation or digital
media device, Karbon 300’s all-metal chassis measures just 154 x 56 x 119 mm and can be wall, VESA or DIN
rail mounted. The system is powered by either an Intel® Apollo Lake Atom E3930 Dual-Core, or E3950 Quad-
Core processor. Connectivity includes 3x LAN with optional Power over Ethernet (PoE+), dual DisplayPorts,
dual RS-232/422/485 COM ports, 4x USB 3.0, integrated CAN bus and DIO. Available wireless options include
Wi-Fi/Bluetooth, 4G LTE and LTE Cat M1. Expansion and storage can be confi gured via two M.2 slots and
one mPCIe slot. The system is available with 4 or 8 GB of onboard high-speed LPDDR4 memory. OS options
include multiple versions of Windows 10 and Ubuntu Linux.
Karbon 300 can be confi gured with an Intel Movidius Vision Processing Unit (VPU) to accelerate machine
vision algorithms and enable AI and machine learning applications. Integrated hardware TPM provides Root
of Trust data security to help protect sensitive information and integrated Consumer Electronics Control
allows Karbon 300 to control connected displays in digital signage, kiosk or entertainment installations.
To meet the demands of extreme computing environments, Karbon 300 is tested according to IEC 60068-
2-27 and IEC 60068-2-64 procedures for shock and vibration. EMC, shock and vibration performance also
meets the in-vehicle UNECE Reg.10 E-mark and rolling stock EN50155 standards. The system is CE and
FCC compliant. A wide input voltage rating, operating temperature range of -25~70°C (-13~158°F) and
automotive ignition power sensing capability make the system well-suited to in-vehicle and other mobile
installations.
The Karbon 300 rugged fanless computer has been engineered to help innovators overcome the limitations
of deploying reliable computer hardware in challenging environments.

Karbon 300 Rugged Computer
15
1.3 - Key Features
Karbon 300 Series
K300-E3930-4-P K300-E3930-4P-P K300-E3950-8-P K300-E3950-8P-P
Processor Intel Atom x5-E3930 Dual-core Intel Atom x7-E3950 Quad-core
System Memory 4GB Onboard LPDDR4 8GB Onboard LPDDR4
Integrated Graphics Intel HD Graphics 500 Intel HD Graphics 505
Bottom I/O 3x GbE LAN 1x GbE LAN
2x PoE LAN 3x GbE LAN 1x GbE LAN 2x PoE LAN
2x Full-size DisplayPort
Top I/O
2x Serial RS-232/422/485
3-pin Power input
4x Antenna holes
Front I/O
Power button
1x 3.5 mm Audio jack (mic-in, line-out)
8-bit Isolated DIO
4x USB 3.0 Type A
8x Status LEDs
3-pin CAN bus 2.0B
Nano-SIM slot (4FF)
Storage M.2 2280 M-key (PCIe x2, SATA)
Expansion Full-length mPCIe slot (PCIe, USB)
M.2 2230 E-key (PCIe, USB)
Special Features
Logic Supply Microcontroller (LS MCU)
Onboard TPM 2.0 (Nuvoton NPCT750)
Automotive Ignition Power Sensing
SuperCap backup for RTC battery
Operating Systems Windows 10, Ubuntu 18.04
LAN Controller Intel Ethernet Controller I210-IT
Voltage Input 9~36 VDC
Dimensions 56 x 154 x 119 mm
Mounting
Wall mount (edge and bottom)
DIN Rail mount (edge and bottom)
VESA mount (bottom)
Environment
Operating Temperature : -25°C ~ 70°C
Operating Humidity: 0~90%
Storage Temperature: -40°C ~ 85°C
Storage Humidity: 0~95%
Certifi cation
2011/65/EU (RoHS 2 Directive)
CE
EN 55024
EN 55032
EN 62368-1
FCC 47 CFR Part 15
IEC 60068-2-27
IEC 60068-2-64

Karbon 300 Rugged Computer
16
1.4 - Exterior Features
DIO CAN bus USB 3.0 Audio Jack Power Button
COMGbE LAN DisplayPort Power Input
Nano-SIM
Grounding Nut
Antenna
(Optional)
2x GbE LAN
(Optional PoE)

Karbon 300 Rugged Computer
17
1.5 - Dimensional Drawings
TOP
56 mm
119 mm 119 mm
BOTTOM
56 mm
FRONT
56 mm
154 mm
SIDE
71.12 mm
35.56 mm
119 mm
154 mm

Karbon 300 Rugged Computer
18
1.6 - Motherboard Overview
1.6.1 - System Block Diagram
Apollo Lake-I
Atom E3930 or E3950
LPDDR4 LPDDR4
PCIe x1
GbE LAN
I210-IT
GbE LAN
I210-IT
GbE LAN
I210-IT
RJ45
2x RJ45
Optional PoE 30W
Full-size mPCIe Nano-SIM
USB 2.0
M.2 2280 M-key
PCIe x2
SATA
MCU
MK22FN1M0AVMC12
User Mode
Switch
USB 2.0
PoE Controller
CAN bus
8-bit DIO
Power
Button
BIOS TPM
NPCT750
COM 1
RS-232/422/485
COM 2
RS-232/422/485
Super I/O
2x USB 3.0
2x USB 3.0
2x USB 2.0
2x USB 3.0
2x USB 3.0
2x USB 2.0
Audio
ALC233-VB2
Audio Jack
Mic-in; Line-out
M.2 2230 E-key
PCIe x1
USB 2.0
DisplayPort 2
DisplayPort 1

Karbon 300 Rugged Computer
19
1.6.2 - Memory Specifi cation
Karbon 300 system memory is soldered on the motherboard. Onboard memory for all K300 models is dual-
channel LPDDR4. Manufacturer and part numbers are subject to change, so please check the system pages
for updates.
System Memory Manufacturer Part Number Quantity Total Capacity
K300-E3930-4-P LPDDR4 Samsung K4F6E304HBMGCJ 2 4 GB
K300-E3930-4P-P LPDDR4 Samsung K4F6E304HBMGCJ 2 4 GB
K300-E3950-8-P LPDDR4 Samsung K4FBE3D4HMMGCJ 2 8 GB
K300-E3950-8P-P LPDDR4 Samsung K4FBE3D4HMMGCJ 2 8 GB

Karbon 300 Rugged Computer
20
1.6.3 - Motherboard Features
Back
Front
Item Function Description
A1 Power button
A2 3.5 mm Audio jack
A3 4 x USB 3.0 Type A ports
A4 3-pin CAN bus
A5 8-bit isolated DIO (10-pin)
A6 2 x Full-size DisplayPort
A7 1 x RJ45 GbE LAN port
2 x RJ45 GbE LAN ports with optional PoE (30W total)
A8 3-pin power input (9~36 VDC)
A9 2 x Serial RS-232/422/485 ports
A10 Full-size mPCIe
A11 M.2 2280 M-key for NVMe or SATA storage
A12 M.2 2230 E-key for Wi-Fi or WAN card
