Logic DLC NET Series User manual

LOGIC S.r.l.
Via Del Tovo 5/3
I-27020 Travacò Sicc. PV
Italy
T.+39.0382.482657
F.+39.0382.1850248
www.logic-pavia.it
[email protected]
LOGIC S.r.l. codice fiscale / partita I.V.A. IT00842600181
Tribunale di PAVIA n. ORD. 31473 n. SOC. 4719 n. FASC. 6024 - CCIAA 154531
Pagina 1 di 78
Mod. L0006A01 del 30/05/2016
Doc. n.: M0145Db.docx
DLCNET SERIES
Load cells digital interface with indicator
USE AND MAINTENANCE MANUAL
This manual consists of 78 pages, annexes excluded.
INSTRUMENT DATA
Manufacturer
LOGIC S.r.l.
Via del Tovo 5/3
I-27020 Travacò Siccomario (PV)
Italy
Series
DLCNET
Typology
Load cells digital interface with indicator

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 2 of 78
INTENTIONALLY BLANK PAGE

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 3 of 78
DOCUMENT DESCRIPTION
Document title
Use and maintenance Manual, DLCNET Series
Document date
01/03/2017
Version
D
Document description
Instrument manual of installation, use and maintenance.
SW release: J0130 3.0
Language
Italian (original).
REVIEW
Rewiev
Date
Description
1.0
10/10/2015
Initial release.
1.1
08/04/2016
General bugs correction
1.2
02/05/2016
Printer connections described.
Beka (RS232) - Printer (RS485) connection removed.
A
15/07/2016
New indexing review
B
02/08/2016
Description of printing configuration in Batch mode and watchdog behavior
description added. Connection of start / stop button added.
C
03/10/2016
Configuration password added. Wall mounting drawings added. Declaration of
conformity directives updated.
D
01/03/2017
Updated device name of DLC-NET-DIN (former DTR-NET-WM)

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 4 of 78
BLANK PAGE

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 5 of 78
1 INDEX
1INDEX....................................................................................................................................................................5
2General information ............................................................................................................................................9
2.1 Introduction...................................................................................................................................................9
2.2 Use and conservation of the manual............................................................................................................9
2.3 Warranty .....................................................................................................................................................10
2.4 Symbology..................................................................................................................................................10
2.5 Unauthorized use........................................................................................................................................11
2.6 Instrument identification..............................................................................................................................11
2.6.1 Manufacturer data...................................................................................................................................11
2.6.2 Marking ...................................................................................................................................................11
2.6.3 Declaration of conformity........................................................................................................................12
2.7 Technical specifications..............................................................................................................................13
2.7.1 General specifications ............................................................................................................................13
2.7.2 Principle of operation..............................................................................................................................13
2.7.3 Technical details.....................................................................................................................................14
2.7.4 Operating environment ...........................................................................................................................14
2.7.5 Electromagnetic compatibility .................................................................................................................14
3Installation..........................................................................................................................................................15
3.1 Preliminary checks......................................................................................................................................15
3.2 Mechanical installation................................................................................................................................15
3.3 Board connections......................................................................................................................................17
3.3.1 Power supply ..........................................................................................................................................17
3.3.2 Load cell..................................................................................................................................................17
3.3.3 Ground connections................................................................................................................................17
3.3.4 Data connection......................................................................................................................................18
3.4 Power supply connection............................................................................................................................18
3.4.1 Layout of the terminal blocks..................................................................................................................18
3.4.2 Power supply connection........................................................................................................................20
3.5 Load cells connection .................................................................................................................................21
3.5.1 Load cells connection in safe area .........................................................................................................21
3.5.2 Load cells connection in ATEX Zone 1 (Zener barrier) ..........................................................................22
3.5.3 Load cells connection in ATEX Zone 1 (active barrier) ..........................................................................22
3.5.4 Connection to the junction box ...............................................................................................................23

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 6 of 78
3.6 Connecting of remote display via RS-485 ................................................................................................. 25
3.6.1 Introduction ............................................................................................................................................ 25
3.6.2 RS-485 connection with Logic display DLC3-RD .................................................................................. 25
3.6.3 RS-485 connection with display BEKA®BA488C.................................................................................. 26
3.7 Fieldbus connection................................................................................................................................... 28
3.7.1 Profibus-DP®.......................................................................................................................................... 28
3.7.2 Profinet®................................................................................................................................................. 29
3.8 Input and output connections..................................................................................................................... 30
3.8.1 Inputs from potential-free contacts......................................................................................................... 30
3.8.2 Inputs from active source....................................................................................................................... 30
3.8.3 Connection to setpoint output................................................................................................................ 31
3.8.4 I/O connections in Batch mode.............................................................................................................. 32
3.8.5 Analog ouput connection 0-20 mA or 4-20 mA...................................................................................... 32
3.9 RS-232 connection for printer.................................................................................................................... 34
3.10 Parallel interface connection...................................................................................................................... 35
3.10.1 Operating mode ..................................................................................................................................... 35
3.10.2 Connection for parallel interface type PNP............................................................................................ 36
3.10.3 Connection for parallel interface type NPN............................................................................................ 36
4Settings...............................................................................................................................................................39
4.1 Preliminary operations ............................................................................................................................... 39
4.1.1 Introduction ............................................................................................................................................ 39
4.1.2 Setting speed ADC ................................................................................................................................ 39
4.1.3 Setting termination resistance................................................................................................................ 39
4.2 Fieldbus communication............................................................................................................................ 40
4.2.1 PLC hardware setting ............................................................................................................................ 40
4.2.2 Data structure......................................................................................................................................... 40
4.2.3 Diagnostics............................................................................................................................................. 42
5Use as interface with indicator.........................................................................................................................43
5.1 Introduction ................................................................................................................................................ 43
5.1.1 User interface......................................................................................................................................... 43
5.2 Electrical calibration................................................................................................................................... 45
5.3 Main screen................................................................................................................................................ 45
5.3.1 Weight displaying................................................................................................................................... 45
5.3.2 Menu browsing....................................................................................................................................... 45
5.3.3 Net / gross weight displaying................................................................................................................. 46
5.4 Calibration menu........................................................................................................................................ 47
5.4.1 Calibration mode with weight................................................................................................................. 47
5.4.2 Access to the calibration menu ( )................................................................................................ 47

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 7 of 78
5.4.3 Calibration with sample weights or simulator ( ).......................................................................48
5.4.4 Automatic calibration ( )............................................................................................................49
5.4.5 Sensitivity correction ( ).............................................................................................................50
5.4.6 Zero scale calibration ( )................................................................................................................50
5.4.7 Analog output calibration ( )......................................................................................................51
5.5 Parameterization of the instrument.............................................................................................................53
5.5.1 Access to the configuration menu ( ) ..........................................................................................53
5.5.2 Output configuration ( ).............................................................................................................53
5.5.3 Configuration of setpoint modality intervention ( ) ....................................................................53
5.5.4 Filter configuration ( )..................................................................................................................53
5.5.5 Serial port configuration ( )........................................................................................................54
5.5.6 Configuration of the instrument identifier ( )................................................................................55
5.5.7 Minimum increase configuration ( )...........................................................................................55
5.5.8 Profibus-DP®address configuration ( ).......................................................................................56
5.5.9 Real-time clock configuration ( ) ...............................................................................................56
5.6 Setpoint use and configuration...................................................................................................................57
5.6.1 Setpoint intervention mode ( )...................................................................................................57
5.6.2 Setpoint operating value ( ).......................................................................................................58
6Use as a batcher................................................................................................................................................61
6.1 Working specification..................................................................................................................................61
6.1.1 General functionality...............................................................................................................................61
6.1.2 Dosing control.........................................................................................................................................61
6.2 Batcher configuration ( )................................................................................................................63
6.2.1 Scale zero configuration ( ).......................................................................................................63
6.2.2 Maximum capacity configuration ( ) ..............................................................................................64
6.2.3 Auto-correction of the amount in flight ( )..................................................................................64
6.2.4 Configuration of the expected amount in flight time ( ).............................................................65
6.2.5 Print mode configuration ( ).......................................................................................................66
6.3 Components configuration ( )........................................................................................................67
6.3.1 Configurations of the in flight amounts ( ) .......................................................................................67
6.3.2 Pre-actions configuration ( )..............................................................................................................67
6.4 Dosing management...................................................................................................................................69
6.4.1 Introduction.............................................................................................................................................69
6.4.2 Dosing of automatic components ( ) ...............................................................................................69
6.4.3 Dosing of manual components ( ).....................................................................................................70
6.4.4 End of recipe ( ).........................................................................................................................71
6.4.5 Recipe printing ( )............................................................................................................................71
6.4.6 Abort of recipe ( )...........................................................................................................................72

USE AND MAINTENANCE MANUAL –DLCNET Series
INDEX
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 8 of 78
7Decommissioning and dismantling.................................................................................................................73
7.1 General indications .................................................................................................................................... 73
7.2 Procedure................................................................................................................................................... 73
8FIGURES.............................................................................................................................................................75
9TABLES ..............................................................................................................................................................77

USE AND MAINTENANCE MANUAL –DLCNET Series
General information
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 9 of 78
2 General information
2.1 Introduction
This manual includes instructions for use and maintenance of the instrument. Its
content is directed to operators previously instructed on the precautions to be
taken.
For a correct use of the instrument in question, read and follow the instructions
contained in this manual. Our technical support is always available to provide any
clarifications that were necessary to your staff responsible of commissioning of
equipment LOGIC S.r.l..
The microprocessor conditioners for load cells series DLCNET are designed to meet
the needs required by the weighing systems.
An easy installation together to a simple operating mode, allow to this tool an
immediate and correct use.
The reliability and accuracy characteristics allow its use in harsh environmental
conditions and therefore suitable for use in an industrial environment.
2.2 Use and conservation of the manual
The purpose of this manual is to provide the directions to use the instrument safely
and perform the installation procedures and routine maintenance. Any calibration,
adjustment and extraordinary maintenance operations are not covered in this text,
being the exclusive competence of the technical assistance, which must assist on
the instrument in accordance with the technical specifications and project for which
it was manufactured.
The reading of this manual is essential, but it cannot replace the competence of
the technical personnel who must have obtain a preliminary training.
The manual must be kept intact and in good condition throughout the life of the
instrument. After use, store in a safe and secure place, together with the CE
certification.
If the documentation is lost or damaged you can obtain a copy from the
manufacturer, mention the order number and the serial number of the instrument.
The instruments of DLCNET series are made in accordance with the applicable
directives in the European Community and the technical standards that include
their requirements, as certified by the Declaration of Conformity issued by the
manufacturer and attached to the manual.

USE AND MAINTENANCE MANUAL –DLCNET Series
General information
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 10 of 78
The information contained in this manual cannot be disclosed to third parties. Any
duplication unauthorized in writing by LOGIC S.r.l., partial or total, obtained by
photocopying, duplication or other systems, including electronic acquisition,
violates the copyright conditions and is punishable by law.
2.3 Warranty
The warranty starts from the date of the test report, has duration of 12 months and
is subject to the use of the instrument in the operating conditions, operating and
maintenance fixed by the manufacturer in the documentation and technical
descriptions provided. The warranty covers all parts of which it is established the
construction defect; this excludes all parts so it is expected wear caused by the
use of the instrument.
In no event LOGIC S.r.l. shall bear the cost of charges for failure of production.
LOGIC S.r.l. is liable for defects resulting from normal use of the machine and not
those resulting from:
↘Incorrect installation
↘Lack of maintenance or calibration
↘Improper use of the instrument
↘Manumission, modification, maintenance by the customer without the
written permission of LOGIC S.r.l.
↘Inappropriate power supply
The warranty does not cover damage caused by improper or different use from the
one described here and by failure to follow instructions in this manual.
2.4 Symbology
In this manual, some operations are highlighted by graphical symbols that recall
the reader's attention on the importance and danger of such transactions:
Table 1. Symbology
Symbol
Description
Warning or general safety requirement
Danger or warning of electrical origin
Danger of explosion or inhalation of hazardous substances within a classified area
Important information for the user

USE AND MAINTENANCE MANUAL –DLCNET Series
General information
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 11 of 78
2.5 Unauthorized use
It is expressly forbidden use the instrument for applications other that
described above or shown in this manual.
2.6 Instrument identification
2.6.1 Manufacturer data
LOGIC S.r.l.
Via del Tovo 5/3
I-27020 Travacò Siccomario (PV)
Italy
2.6.2 Marking
The instrument shows the following screen-printed marking on the case:
Figure 1. Equipment back serigraphy
On the chassis the serial number is indicated. Please communicate it to LOGIC
S.r.l. in case of malfunctioning or replacement of the instrument.

USE AND MAINTENANCE MANUAL –DLCNET Series
General information
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 12 of 78
2.6.3 Declaration of
conformity
DICHIARAZIONE DI CONFORMITA’
Ai sensi dell’all. II-A della Direttiva 2006/42/CE
(originale in lingua italiana)
LOGIC S.r.l.
Via del Tovo 5/3
I-27020 Travacò Siccomario (PV)
Italy
Il Costruttore LOGIC S.r.l.. dichiara sotto la propria responsabilità che la macchina:
The Manufacturer LOGIC S.r.l. declares under its responsibility that the machine:
Costruttore
Manufacturer
LOGIC S.r.l.
Via del Tovo 5/3
Travacò Siccomario, PV
Italy
Modello
Model
Serie DLCNET
DLCNET Series
Descrizione
Description
Condizionatore digitale per celle di carico per installazione in quadri elettrici industriali
Load cells digital conditioner for industrial electrical cabinet installations
Soddisfa le disposizioni della Direttiva 2014/30/UE del 29 Marzo 2014 e successive modifiche.
Meets the requirements of 2014/30/EU Directive, March 29th, 2014 and subsequent modifications.
L’apparato elettronico in oggetto è conforme agli standard armonizzati di seguito elencati:
This electronic apparatus meets the requirements of the following harmonized standard:
EN 61000-4-2 Compatibilità elettromagnetica –Prove di immunità a carica elettrostatica
Electromagnetic Compatibity - Electrostatic Discharge Immunity Test
EN 61000-4-3 Compatibilità elettromagnetica –Prove di immunità su campi irradiati a radiofrequenza
Electromagnetic Compatibity - Radiated, radio-frequency, electromagnetic field immunity
test
EN 61000-4-4 Compatibilità elettromagnetica –Prove di immunità a transitori/treni elettrici veloci
Electromagnetic Compatibity - Electrical Fast Transient / Burst Immunity Test
EN 61000-4-6 Compatibilità elettromagnetica –Prove di immunità ai disturbi condotti, indotti da campi a
radiofrequenza
Electromagnetic Compatibity - Electrical Fast Transient / Burst Immunity Test
EN 61000-4-8 Compatibilità elettromagnetica –Prove di immunità ai campi magnetici
Electromagnetic Compatibity - Testing and Measurement Techniques Power Frequency
Magnetic Field Immunity Test
Travacò Siccomario, xx/xx/xxxx
Lucio Mantovani
Presidente

USE AND MAINTENANCE MANUAL –DLCNET Series
General information
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 13 of 78
2.7 Technical specifications
2.7.1 General
specifications
The conditioner and digital weight transmitter DLCNET is designed for interfacing to
strain gauge transducers with collecting data or industrial automation systems via
Profibus-DP®or Profinet®interface.
The board is calibrated in factory in the range of 0 ÷ 4 mV/V and does not
require no further adjustment by the customer.
The board is available in aluminum case for DIN rail mounting.
The instrument allows the transmission of data weight and diagnostics via fieldbus.
The maximum number of DLCNET Profibus-DP®is 128. The maximum number of
Profinet®nodes is limited by application.
In addition to these functionality, the board can be interfaced with a remote display
as a weight repeater (to be installed in safe or hazardous area) through a serial
port RS-485 (in addition to the fieldbus connection).
2.7.2 Principle of operation
The DLCNET module is a load cells signal amplifier. The supply voltage of the
transducer is 5 Vdc with the possibility of 4 or 6 wire connection. With six-wire
connection, you make a correct voltage drop compensation on the connecting
cables, for greater accuracy.
The fieldbus and power supply of the load cell are galvanically isolated via DC /
DC converter, among the 24 Vdc power supply. This allows the connection of
several weighing systems to a data collection system (PLC or PC) with the use of
the same power supply (+24 Vdc) common to other devices without any kind of
problem.
Figure 2. Diagram of operation and power supplies

USE AND MAINTENANCE MANUAL –DLCNET Series
General information
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 14 of 78
2.7.3 Technical details
Table 2 shows the technical characteristics of the instrument.
Table 2. Technical data instruments of the series DLCNET
Data
Value
Supply
24 Vdc ±10 %, with galvanic isolation between 24 Vdc, power supply of load cells
and Fieldbus
Power
3 W max
Maximum current
150 mA (max 4 load cells of 350 ohm)
Temperature range
from 0 °C to + 45 °C
Load cells power supply
5 Vdc
Input signal
from - 4 mV/V to + 4 mV/V
Weight resolution
19 bit + sign (524.288 divisions to 4 mV/V)
Maximum sensitivity
40 nV/div
Fieldbus
Profibus-DP®, Profinet®
Linearity
0.01 % F.S.
Conversions
10 or 80 sample/s configurable (default 10)
Digital filter
8, 16, 32, 64 averaged values
Protection
IP20
Digital outputs (EB-board)
n. 8 output, 24Vdc 100mA total with all outputs on
Serial outputs
RS-485 and RS-232 (on EB-board)
Analog output (EB-board)
0-20mA –4-20mA configurable
Dimensions
30 x 135 x 107 mm (W x H x D)
2.7.4 Operating
environment
The environmental license plate requirements for the correct functioning of the
instrument are:
↘Operating temperature: 045°C
↘Storage temperature: 050°C
↘Humidity: 85% non-condensing
2.7.5 Electromagnetic
compatibility
The boards of DLCNET series are equipped with appropriate filtration in order to
meet the EMC requirements that the Directive 2014/34/EU requires.
To improve immunity to radiated interference, emitted by a radio transmitter,
it is important to:
↘Use shielded cables with shielding connected to earth at 100% for
connections to the card.
↘In the presence of earth resistance values low, connect to ground
both sides of the screen to improve the effectiveness of the
shielding.

USE AND MAINTENANCE MANUAL –DLCNET Series
Installation
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 15 of 78
3 Installation
3.1 Preliminary checks
Verify the status of the instrument through a visual inspection, inside and outside
of it. Any deformation indicate shocks experienced during transport, it could
compromise the normal operation.
Check if the instrument received is intact and complete with all accessories
essential for mechanical and electrical installation.
3.2 Mechanical installation
The instrument in question is supplied in nickel-plated aluminum case for DIN rail
mounting.
Figure 3 shows the mechanical drawing of the instrument.
Figure 3. Mechanical drawing of DLCNET
The instrument must be installed in a safe area in accordance with ATEX
Directive.
The instrument includes a case with IP20 protection. It will be the customer
care to adequately protect the instrument in the installation environment.
In Figure 4 DLCNET-WM mounting is depicted. DLCNET-WM can be installed on DIN
rail.

USE AND MAINTENANCE MANUAL –DLCNET Series
Installation
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 16 of 78
Figure 4. DLCNET-WM mechanical drawing
DLCNET-DIN has a 20 poles connector for an external keyboard (DLC-NET-KB)
and can be installed vertically on a DIN rail as well (Figure 5).
Figure 5. DLCNET-DIN mechanical drawing

USE AND MAINTENANCE MANUAL –DLCNET Series
Installation
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 17 of 78
3.3 Board connections
This instrument is an electrical apparatus: it must therefore be installed by
trained personnel. Start-up, maintenance and the following tests must be
carried out by qualified personnel.
3.3.1 Power supply
Use a power supply cable, with suitable protection to the environment in which
they are installed, with a maximum diameter of 1,5 mm2.
3.3.2 Load cell
The load cell provides a low-level signal (a few millivolts); it is therefore essential
for a correct application, use good quality shielded cables. For single-cell
applications with distance equal to or less than 8 meters is enough the 4-wire
connection.
The connection to the load cells must be done with high quality shielded
cable. The cable CAB-TS6 Logic model is recommended for all industrial
applications including areas with risk of explosion.
In applications with more load cells (platforms, tanks, silos, etc.), It is
recommended the use of junction boxes that minimize differences in impedance or
compensation on the signal branches. The junction boxes JBOX series have been
designed for this purpose and properly solve the problem.
The maximum cable length between the junction box and the instrument, depends
on the specific situation of electrical noise in the plant, which potentially can induce
noise on the signal cable. In normal situations cable lengths up to 300 meters can
be used without problems.
The shielded cable must be positioned preferably in metal conduit grounded and in
any case away from any other power supply cable or power cable.
Verify, before and during the installation of the cable cells, which do not occur
entry of moisture in the same cable, causing loss of insulation and consequent
malfunction.
3.3.3 Ground connections
The ground connection is very important for compliance with electromagnetic
compatibility and therefore for the reliability of the apparatus.
Respect and carefully check ground connections indicated on the attached
diagrams in order to prevent possible malfunctions. Connect the shielded cable to
the GND terminal of the terminal blocks; the other end of the screen normally is
isolated.
In presence of strong interferences (inverter etc.), connect to ground both
heads of the screen. In this case it is important to have low values of ground
resistance.

USE AND MAINTENANCE MANUAL –DLCNET Series
Installation
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 18 of 78
3.3.4 Data connection
The data transmission takes place through the RS485 serial interface, if you use
the Profibus-DP® protocol and ethernet interface if you purchase the version with
Profinet® protocol. Also in this case it is important to use shielded cables
especially if long or coupled with cables that can induce electrical noise (cables
connected to the actuators, motors, etc.).
3.4 Power supply connection
3.4.1 Layout of the terminal
blocks
The instruments of DLCNET series have three terminal blocks connection, with the
Fieldbus connector, which can be a D-SUB 9-pin connector for the Profibus-DP®
protocol or double RJ45 Ethernet port with integrated switch in the case of
connection in Profinet®(Figure 6, Figure 7).
Figure 6. Layout of the terminal blocks, Profibus-DP®
Figure 7. Layout of the terminal blocks, Profinet®
The terminal blocks have the following nomenclature:
↘TB1: load cells connection
↘TB2: Fieldbus
↘TB3: serial connection for remote display
↘TB4: power supply connection

USE AND MAINTENANCE MANUAL –DLCNET Series
Installation
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 19 of 78
On the front panel it is also present the led F, which indicates a possible fault of
the Fieldbus communication.
Concerning DIN rail mounting inside a control panel, board terminals are set as
follows:
Figure 8. DLCNET-WM terminals (model with on-board keyboard)
Figure 9. DTRNET-WM terminals (model with external keyboard)
Where TB7 is a 20 poles connector reserved for keyboard connection.

USE AND MAINTENANCE MANUAL –DLCNET Series
Installation
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
Page 20 of 78
3.4.2 Power supply
connection
Make connections to TB4 terminal to supply power to the instrument according to
the following table:
Table 3. Power supply connection
Terminal
Connection
TB4-1
GND / Shld
TB4-2
0 Vdc
TB4-3
+24 Vdc
Use cables with maximum cross-section 1,5mm2.
It recommends the use of power supplies with standard current limitation
(eg.: 24V / 1A with Icc 1,2 A). With power supplies provided with intervention
at short circuit type “Fold Back" or similar are possible problems. The
instrument in question, in fact, absorb a strong current at power for a limited
time (about 4 A for 10 ms).
Figure 10. Power supply connection
If the instrument outputs are connected to the dosage of components by
solenoid valves and pumps, it is always necessary to unpower the
instrument in case long times without supervision from operators, in order
to prevent possible uncontrolled spills.
