Logic LDS120 User manual

LDS120/120DS/240/360/700
OPERATORS MANUAL
WM1
-
LDS120
LDS – GROUND
DRIVE SPREADER

LD
S Serial Number:
Date of Purchase:
INDEX
Section: Description: Page
No:
1 Introduction 1
HSE Information Sheet 2
HSE Information Sheet 3
2 In the interest of safety: DO NOT 4
3 In the interest of safety: DO 5
4 Instruction & Warning Decals 6
5 Transporting and lifting the LDS 7
6 Operating instructions and adjustments
6.1 Before use check the following 8
6.2 Distribution 9
6.3 Vane regulation / adjustment 10
6.4 Calibration 10
6.5 Calibration charts LDS120/240/360/700 11
6.6 Calibration charts LDS120DS 12
7 Maintenance
7.1 Daily maintenance 14
7.2 Seasonal 15
8 Exploded Parts Diagram
8.1 Main frame LDS120/DS
16
8.2 Main frame Parts list LDS120/DS 17
8.3 Spinner and Hopper LDS120/DS
18
8.4 Main frame LDS240/360
19
8.5 Main frame Parts list LDS240/360 20
8.6 Spinner and Hopper LDS240/360
21
8.7 Drive Assembly LDS700
22
8.8 Main frame LDS700
22
8.9 Wheels & Tyres LDS700 23
8.10 Spinner & Agitator LDS700
23
8.11 Parts list LDS700 24
9 Owner Guarantee 25
Declaration of conformity 26

1
With the purchase of your LOGIC LDS – GROUND DRIVE SPREADER you have made an
excellent choice.
This machine should give first class service for a long time, if used correctly, and maintained as
described in this manual.
The Ground Drive Spreader range is capable of spreading fertiliser as well as salt depending on
which model you have, it is ideal for small holdings or similar smaller areas where a general
approach to spreading is required.
The hopper capacities range from, 120 - 700lt. being land driven it is essential to maintain a
constant forward speed if accurate spread patterns and accurate quantities are to be achieved,
therefore an accurate speedometer may be required.
The Ground Drive Spreader has a mild steel framework with a galvanised finish to add extra
protection from corrosion and harsh working environments.
If, after reading this manual there are any queries, please get in touch, we will be pleased to
help.
NORTH & EXPORT SOUTH
LOGIC MANUFACTURING LTD LOGIC MH LTD - New Whiteway Works,
Foundry Industrial Estate Fossecross Industrial Estate
Bridge End, Hexham Chedworth. Cheltenham
Northumberland NE46 4JL Gloucestershire GL54 4NW
Tel: [phone] Fax: [phone] Tel: [phone] Fax:[phone]
E-mail: [e-mail] E-mail: [e-mail]
www.logic.gb.com www.logic.gb.com
INTRODUCTION
1

2
Introduction
This information sheet gives advice to users on how
to use All Terrain Vehicles (ATVs) safely with towed
and mounted equipment.
Plan the use of an ATV carefully and take particular
note of ground conditions and slopes, as these may
vary considerably, depending on the terrain, weather
conditions, ground surface and the crop under the
wheels.
Towed equipment
Choose equipment which matches your ATV.
Stability of towed equipment is affected by:
Weight ratios
The safe ratio between the trailed laden maximum
weight and unladen weight of the ATV must be
assessed for each operation.
Always take note of information given in the
manufacturer’s handbook when making this
assessment.
As a guide research shows that on level ground, 4 x
unladen weight of the ATV for braked trailed
equipment and 2 x unladen weight of the ATV for
unbraked trailed equipment are the appropriate
maximum ratios.
Note: For work on slopes or uneven ground the ratio
will need to be reduced.
Braking
Fit:
Brakes to trailed equipment. This helps prevent jack-
knifing when braking or travelling downhill;
Over-run brakes which come into action whenever
the ATV brakes are applied;
Agriculture Sheet No 11
Centre of gravity
Stability of the ATV is improved if there is:
A low centre of gravity which is within the wheel
base;
A wide wheel base;
A long draw-bar;
Means for holding detachable equipment in position.
Hitching and loads
Stability is also improved if:
Some weight is transferred from the trailer onto the
ATV draw-bar;
The draw-bar has a swivel hitch and the ATV a ball
hitch having a large head to neck ratio. This makes it
easier for the draw-bar hitch to swivel and cope with
undulating ground;
The load is positioned as near to the centre of the
trailer as possible.
Tyres and wheels
Check tyre pressures regularly with a pressure
gauge capable of reading low pressures accurately;
Check tyre pressures regularly for damage and
wear;
Select equipment which has tyres and wheels that
can cope with speeds over 20 mph and occasional
higher speeds;
Use wheels with bead locks on the rims if the main
use is going to be on sloping ground. This prevents
tyre run-off on side slopes.
Maximum towed weight
Follow the advice given by manufacturers on the
maximum trailed weight. This will be found on the
equipment or in the instruction handbook.
Note: Universal road going trailers will normally have
the maximum gross weight stated on a separate
notice.
Selecting and using equipment for All
Terrain Vehicles (ATVs)
HSE information sheet

3
Mounted Equipment
ATVs using mounted equipment are safer if the
equipment has:
A low centre of gravity. This improves stability;
A gross weight within the limits the limits approved
by the ATV manufacturer;
No dangerous projections to enquire the operator or
bystanders;
No forward projections which stop head protection
being worn;
Controls which are easy to work and which do not
create a hazard to the operator;
Working speeds less than 16hp.
Instructions for the mounted and trailed
equipment
Take note of the manufacturers instructions on:
Operating on slopes;
Where to place loads so as to give fore/aft and
lateral stability;
The risks of using equipment with negative drawbar
nose weight, i.e. loss of traction;
The maximum operating speed;
The effect that equipment carried on front and/or
rear racks will have on longitudinal and lateral
stability;
Securing loads;
The use of ballast, if any to improve stability;
The need to select and use safe routes.
Using an ATV
Read the manufactures instruction book and take
note of the safety advice given;
Choose an ATV with enough power for the work you
want it to do. Four wheel drive will give better
traction and mobility and may provide a margin of
safety;
Choose a safe route;
Be aware that increased speed greatly increases the
risk of instability and the risk of an overturn.
Printed and published by HSE
Training
Train everyone who has to use an ATV whether with
mounted or trailed equipment or as a solo machine.
The training should emphasise the factors affecting
stability, the need for care and concentration, and
how to recognise the conditions, which may affect
the safety of operation. It is important for trainees to
familiarise themselves with the handling and control
of the machine on level open ground before tackling
rough hill terrain.
Suitable training courses are run by such bodies as
ATB Landbase and Forestry Authority.
Helmets
Wear head protection, which protects the head and
neck. Helmets to BS 6658:1985 (specification for
protective helmets for vehicle users) are suitable.
Some users find open faced helmets more suitable
than full face helmets.
Use of ATV’s for Spraying
A separate information sheet No 10 ATV’s fitted with
spray equipment is available from the Crop and
Pesticides National Interest Group (see address
below)to cover the use of mounted or trailed ATV
sprayers.
Further information
HSE Contract Research Report No52/1993 braking
and overturning stability of all terrain vehicles with
trailed or mounted loads and review of guidelines
1993 ISBN 011 882149 0
HSE safeguarding agricultural machinery: moving
parts HS (G) 89 1992 ISBN 011 882051 6. This
provides further information on the design of
machinery.
These publications are available from HSE books,
PO Box 1999, Sudbury, Suffolk, CO10 6FS
(Tel: [phone]; fax: [phone]).
If you need information please contact your local
HSE office.
Further copies of this information may be obtained
from the crop and pesticides national interest group,
HSE, Bareback house, Trinity Square, Nottingham
NG1 4AU: tel: [phone]
This publication may be freely reproduced, except for
advertising, endorsement or sale purposes. The
information it contains is current at 7/94. Please
acknowledge the source as HSE.
NIS/13/11 C100

4
1. DO NOT – Operate the LDS without all the correct guards fitted.
2. DO NOT – Touch any moving or rotating parts, during working conditions
3. DO NOT – Operate the LDS without suitable ear and eye protection
4. DO NOT – Allow passengers.
5. DO NOT – Operate the LDS on excessively steep slopes.
6. DO NOT– Operate the LDS unless all safety features are fitted, and are used
correctly
7. DO NOT – Operate the LDS until you have read and understood the entire operators
manual
8. DO NOT – Wear loose fitting clothing, to avoid catching on parts of the machine
9. DO NOT – Operate the LDS in Dark conditions unless suitable artificial light is used.
10. DO NOT –Climb on the LDS.
11. DO NOT – Travel at speeds in excess of 20 Mph (32Kph) when travelling to and from
the spreading area.
12. DO NOT – Exceed 10 Mph (16 Kph) in working conditions
13. DO NOT – Engage or disengage the disc drive whilst the machine is running.
14. DO NOT – Tow the LDS with an unsuitable vehicle, check vehicle-towing limits before
operation. Never overload the LDS.
15. DO NOT – Use the spreader for any other task other than the one it was designed
for.
16. DO NOT – Use the LDS120 for spreading salt, only use the LDS120DS model.
17. DO NOT – Use the spreaders on public roads. The spreaders are not road legal.
2
IN THE INTEREST OF SAFETY:
DO NOT
This symbol means WARNING or CAUTION Personal safety or damage will be
at risk if these instructions are ignored. Most accidents are caused by neglect
or carelessness; Avoid needless accidents by following the safety
precautions listed below.

5
1. DO – Follow all manufactures guidelines.
2. DO – Ensure all spectators are a min of 15 metres distance away when operating the
spreader. The operator must continually check the working area, to avoid harming such
third parties.
3. DO – Carry out regular servicing and checks before use.
4. DO – Clear spreading area from potential damaging or restricting components.
5. DO – Reduce speeds when turning corners, working on hillsides or rough terrain
6. DO – Be aware components can be hot after operation e.g.: Gearbox
7. DO – Follow any towing guidelines stated by ATV / Vehicle manufacturer.
8. DO – Follow suitable lifting regulations when filling the hopper.
9. DO – Ensure all safety decals are in good condition, replace any that are damaged.
10.DO – Keep hands and feet away from rotating parts
11.DO – Ensure LDS disc drive is disengaged before transporting from workplace.
12. DO - Ensure the spreader tow hitch is in good repair and fit for towing.
13. DO – Wear protective gloves and boots / facemask when handling fertiliser or salt.
14. DO – Ensure the hopper is empty and the machine is washed down after daily use.
3
IN THE INTEREST OF SAFETY:
DO
SAFETY ZONE 15 METRES MINIMUM

6
INSTRUCTION
/ WARNING DECALS
4
The above decals should be located on your LDS – Ground Drive Spreader. If any of
the above decals are not located on your LDS or are damaged in any way contact Logic for
some replacement decals before use.

7
1. Check to see if the vehicle transporting the spreader can legally carry its weight (See
manufactures plate on spreader for unladen weights)
2. Ensure the vehicle used to lift and transport the LDS has the necessary lifting and
loading capacity. Follow all vehicle manufactures guidelines for lifting.
2. When lifting the LDS for transporting / delivery purposes always ensure to locate lifting
straps where you see the lifting symbol as shown on the below diagram. Never lift the
spreaders with material in the hopper. And ensure pedestrians are clear from danger
3. Ensure all straps are the same length and comply with EN1492-1
4. All LDS unladen weights are clearly marked on the Manufacture’s plate attached to the
LDS framework. Check the lifting weight complies with the vehicle lifting limits.
LDS120/120DS: Only lift the LDS from the correct lifting points as shown below.
LDS240 / LDS700:
TRAN
SPORTING & LIFTING
5
The above decals
should be located on your
LDS – Ground Drive
Spreader. If any of the above
decals are not located on your
LDS or are damaged in any
way contact Logic for some
replacement decals.

8
6.1 – BEFORE USE CHECK THE FOLLOWING:
1. Ensure the tow ball on the vehicle is compatible with the spreader.
2. Check the operation of all controls (A).
3. Ensure the ride height is correctly set for the ATV towing the spreader (B). Remove the
fixing bolt and adjust the angle of the spreader to ensure the spreader disc is running
horizontal to the ground. Replace the fixing bolt in the nearest hole available. (The
spreader disc must run horizontally to the ground to ensure the correct spreading width
and overlap is achieved)
4. Check that the tyre pressure (C) 10psi minimum to 25psi maximum dependant on load
size. Check the condition of the tyres. Look for signs of wear, cuts and impact damage.
5. Check the free operation for the shutter aperture (D).
6. Check the condition of the hopper and lid (E, If fitted).
7. Check that all grease points have been greased, and are operating freely.
8. Check the gearbox for oil leaks, if an oil leak is evident do not use the spreader and carry
out repairs immediately.
Check that the agitator (G) is free from debris and well greased.
9. Before filling the hopper, set the flow from the hopper by moving the pointer (A) to the
setting required (B) and locking in place with the lock nut (C).See figure 11.1
OPERATING INS
TRUCTIONS AND ADJUSTMENTS
6

9
10. Place the flow lever (D) in the zero position and fill the hopper with the material to be
spread. Ensure that a suitable towing vehicle has been hooked up to the spreader before
filling and that the handbrake has been applied. Do not overfill the hopper; this could
result in fertilizer being spilt or component failure. Ensure there are no foreign bodies in
the hopper e.g. stones or rocks. Wear suitable protective clothing and face protection.
11. Drive to the area requiring the fertiliser, move the drive lever (E) to the IN position (F)
gently moving forward at the same time.
Figure 11.1
6.2 – DISTRIBUTION OF THE FERTILISER/SALT:
The operator must ensure that the towing vehicle travels at a constant speed in order to obtain
an even distribution of material, the operator should use the following overlap technique as
illustrated below:
Spread width is dependable on forward speed and the type of material being spread.
6 Mtr
6 Mtr
1.5 Mtr
Overlap
1.5 Mtr
Overlap
Diagram shows three bout marks and the
desired overlap.
1 2 3

10
6.3 – VANE REGULATION / ADJUSTMENT:
Should the distribution prove to be uneven, the operator can remedy this by regulating the angle
of all the vanes by adjusting the vanes to the different holes on the spreader disc.
6.4 – CALIBRATION (FERTILISER)
To precisely calibrate the spreader carefully read and perform the following instructions:
1. Place a measured amount of fertiliser in the hopper e.g. 10kg
2. Choose an aperture setting to suit the rate required for the type of fertiliser being used,
e.g. Setting 6
3. Obtain the desired travel speed (12 to 20kpH) and open the aperture to preset setting 6,
e.g. 200 metres. (NOTE: Maintain a constant speed)
4. Check the effective spread coverage width, e.g. 12 metres (D).
5. Measure the amount of fertiliser left in the hopper, e.g. 4kg (E).
Then perform the following calculations: -
Measured amount of fertiliser initially loaded in hopper (A): 10kg
Deduct any remaining fertiliser (e): 4kg
Balance used (B): 6kg
Multiply width of spread (D) by the metres travelled (C): 12 x 200 Mtr = 2400 Mtr²
Divide 10,000 (1hectare) by the answer (2,400): 10,000
2400 = 4.1
Multiply the sum (4.1) by the test quantity balance used (B, 6Kg): 4.1 x 6 = 24.6 kg/Ha
The figure achieved is the sowing rate per hectare at the constant speed selected for the test.
Due to the variations of seeds and fertiliser types, it is recommended the test be carried out for
each product being used. Adjust the machine accordingly until the desired application rate is
achieved.
Record all results to ensure accurate speed rates for future reference, use the chart provided on
page 13).
Vane adjusting holes
LDS120 / 240
LDS700

11
6.5 – CALIBRATION CHARTS
LDS120:
Calibrated at a speed of 15kpH (kg/ha)
Setting 1 2 3 4 5 6
Urea - 11.00 27.50 482.50 63.30 82.50
Super - 19.30 44.00 77.00 112.80 140.30
DAP - 19.30 35.80 57.80 79.80 104.50
Calibrated at a speed of 20kpH (kg/ha)
Setting 1 2 3 4 5 6
Urea - 7.50 20.00 32.50 50.00 62.50
Super - 20.00 42.50 62.50 82.50 102.50
DAP - 10.00 25.00 40.00 60.00 75.00
LDS240:
Calibrated at a speed of 15kpH (kg/ha)
Setting 1 2 3 4 5 6
Urea - 11.00 29.70 41.50 52.50 67.50
Super - 19.30 44.00 93.50 107.30 140.30
DAP - 11.00 33.00 55.00 74.50 99.00
Calibrated at a speed of 20kpH (kg/ha)
Setting 1 2 3 4 5 6
Urea - 7.50 17.50 30.00 47.50 67.50
Super - 15.00 30.00 55.00 87.50 102.50
DAP - 8.80 25.00 40.00 55.00 70.00
LDS700:
Calibrated at a speed of 15 KPH (kg/ha)
Setting
1 2 3 4 5 6 7 8 9 10 11
Urea - - 9.40 25.00
50.00
84.40
118.80
162.50
200.00
250.00
275.00
Super - - 15.60
53.10
103.10
143.80
200.00
268.70
337.50
412.50
425.00
DAP - - 12.50
37.50
62.50
100.00
162.50
193.80
250.00
325.00
337.50
Calibrated at a speed of 20KPH (kg/ha)
Setting
1 2 3 4 5 6 7 8 9 10 11
Urea - - 9.40 25.00
40.60
75.00
100.00
137.50
162.50
200.00
237.50
Super - - 15.60
43.80
81.30
131.30
167.50
225.00
262.50
300.00
312.50
DAP - - 9.40 28.10
50.00
81.30
125.00
156.30
200.00
250.00
275.00
NOTE The calibration charts above are a guide only and should be checked to confirm
accuracy.

12
6.6 - LDS120DS – CALIBRATION (SALT)
The Logic LDS120DS is capable of spreading dry white bagged de-icing salt only.
All materials will vary slightly, depending on density and moisture, etc, even in bags, the same
batch can vary.
The following steps are intended as a guide only, and it is highly recommended that simple test
runs are carried out in the filling area before setting out, to check that the spreading quantity
and pattern are satisfactory.
The main controlling factor is forward speed, which dictates the spreading width. The
application rate will then be controlled by the feed gate setting.
The recommended minimum working forward speed is 3 mph (5 kph). This would be used in
confined spaces, or where a minimum spreading width is required. At this speed the spreading
width will be approx. 8mtrs. Recommended maximum working speed is 12 mph (19 kph)
which will result in a spreading width of approx 12mtrs suitable for car parks and roads, etc.
The feed gate setting at the front of the hopper controls the material flow and therefore the
application rate (grams per sq metre). Our recommendation would be to use setting 6 for
spreading salt; the aperture needs to be open enough to prevent the salt bridging in the hopper.
For transporting max / min operating speeds see page 4.
CALIBRATION STAGES
1. Decide what spread width is required in relation to a safe working speed.
2. Select the feed gate setting to achieve the desired application rate.
This will depend on trials carried out with materials to be spread at the time.
3. Check the accuracy of the settings, try a few trial runs over a clean area of concrete or
road surface, at the correct forward speed. Check the spread width, which may vary due
to bouncing material if it is very dry.
Check the application rate by visually looking at your test run and ensure a suitable
amount of salt is spread evenly. To change the application rate alter the forward speed
or aperture setting accordingly to ensure the correct amount of salt you require is applied
4. Write down results for future reference in the table provided (See next page).

13
LDS -SPREADER SETTINGS CHART
MATERIAL TOWING VEHICLE
OPERATING
SPEED
(mph)
SPREAD
WIDTH (m)
FEED
GATE
SETTING

14
Always empty the hopper before any maintenance is carried out
7.1 - DAILY
1. Check the condition of the engagement mechanism and grease daily. Use the following
procedure, firstly engage the drive, and then pump grease into the nipple.
2. Check the condition of the spreader, if any parts need replacing this should be carried
out before operating the machine.
3. Check tyre pressures before use.
4. Check all nuts and bolts are secure before operating.
5. Check the condition of the swivel hitch bushes and replace if damaged or worn
excessively.
6. Check the tension on drive chain and lubricate when necessary (LDS700 Only)
7. Always wash the spreader thoroughly after use, spray a CORROSION INHIBITOR over
the spreader disc and axle components to prevent corrosion. (LDS120DS version, see parts
list)
MAINTENANCE
7

15
7.2 - SEASONAL
1. Check the condition of the drive engagement lever and the plastic tube liner.
2. Check the wheel bearings for play and pack with grease every six months
3. Open the aperture and clean around the aperture blades and holes.
4. Periodically remove the agitator by removing the retaining pin located under the hopper.
5. Lift the agitator, clear of the shaft and remove any residue. Grease and replace the
agitator. Ensure the retaining pin is re-fitted and held in place by the spring clip.
6. Check the oil level in the gearbox. To check, turn the spreader on its side, remove the
filler plug located in the base, check that the oil is level with the rim of the hole, top up if
necessary.
Change the gearbox oil (EP 90) every six months with normal use, or every three months
under extreme conditions. The quantity of oil required is 300ml.
Maintenance should be undertaken regularly, good maintenance extends the
life of the spreader.
Clean aperture and
aperture blades
Remove pin
Remove agitator and
remove residue

16
8.1 – MAIN FRAME AND PARTS
PARTS LIST: LDS120 / LDS120DS
8

17
8.2 - PARTS LIST MAIN FRAME: LDS120 / LDS120DS
Item Part Number Description Qty
1 LDS120-1001 FRAME 1
2 LDS120-1002 DRIVE AXLE 1
3 LDS120-1003 EASYLOCK HUB 1
4 LDS120-1004 DRIVE COUPLING 1
5 LDS120-1005 BEARING HOUSING 1
6 LDS120-1006 DRIVE AXLE BEARINGS 2
7 LDS120-1007 KEY 1
8 LDS120-1008 DRIVING WHEEL 1
9 LDS120-1009 NON DRIVING WHEEL 1
10 LDS120-1010 WHEEL BEARINGS 4
11 LDS120-1011 BEARING SPACER 2
12 LDS120-1012 WHEEL NUT 2
13 LDS120-1013 DUST CAP 2
14 LDS120-1014 TYRE 2
15 LDS120-1015 POINTER 1
16 LDS120-1016 STAR NUT 1
17 LDS120-1017 SHUTTER LEVER 1
18 LDS120-1018 DRIVE LEVER 1
19 LDS120-1019 DRIVE OPERATING LEVER 1
20 LDS120-1020 HAND GRIP 2
21 LDS120-1021 SHAFT GUARD 2
22 LDS120-1022 PLASTIC BUSH 1
23 LDS120-1023 TOW BAR 1
24 LDS120-1024 TOW BAR STAY 1
25 LDS120-1025 TOW BAR BOLT 1
26 LDS120-1026 SPINNER GUARD 1
27 LDS120-1027 GEARBOX 1

18
8.3 – SPINNER AND HOPPER DETAILS: LDS120 / LDS120DS
Item Part Number Description Qty
1 LDS120-1028 LID - LDS120 1
2 LDS120-1029 HOPPER – LDS120 1
3 LDS120-1030 AGITATOR 1
4 LDS120-1031 AGITATOR BUSH 1
5 LDS120-1032 LOWER SHUTTER PLATE 1
6 LDS120-1033 CIRCLIP 1
7 LDS120-1034 SPINNER PLATE 1
8 LDS120-1035 SPINNER FIN 4
9 LDS120-1036 BLOWER FIN 4
10 LDS120-1027 GEARBOX 1
11 LDS120-1038 PIN 1
MLU-021 CORROSION INHIBITOR (LDS120DS) 1 (Can)
