LOGICDATA DYNAMIC MOTION User guide

SYSTEM manual
DYNAMIC MOTION system
DOCUMENT VERSION 3.0 | JANUARY 2020

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 2
DYNAMIC MOTION System - System Manual
Document Version 3.0/January 2020
This document was originally published in English.
LOGICDATA Electronic & Software Entwicklungs GmbH
Wirtschaftspark 18
8530 Deutschlandsberg
Austria
Phone: [phone]
Fax: [phone]
Internet: http://www.logicdata.net
Email: o[email protected]
INFO This manual is valid for all congurations of the DYNAMIC MOTION system

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 3
CONTENTS
1 General information 5
1.1 Other applicable documents 5
1.2 Copyright 5
1.3 Royalty-free use of images and text 5
1.4 Trademarks 5
2Safety 6
2.1 General safety regulations and obligations 6
2.2 Intended use 6
2.3 Reasonably foreseeable misuse 6
2.4 Explanation of symbols and signal words 6
2.5 Liability 7
2.6 Residual risks 7
2.7 Notes for Resellers 8
3 Scope of delivery 9
4Assembly 9
4.1 Performing a Position Reset Procedure 9
5Operation 10
5.1 Notes for EASY2move 10
5.2 Standard functions 11
5.2.1 Adjusting the table top height 11
5.3 Advanced functions 11
5.3.1 Saving Memory Positions 11
5.3.2 Adjusting the table top to a saved position 12
6 Software dependent functions 13
6.1 Standard functions 13
6.1.1 Low speed area 13
6.1.2 Safety area 13
6.1.3 Container Stop and Self Stop Positions 13
6.1.4 Factory Reset 14
6.2 Advanced functions 15
6.2.1 Key Lock 15
6.2.2 Correcting the height display 15
6.2.3 Changing the displayed Unit of Measurement 15

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 4
7 Collision Protection 16
7.1 Drive Back Function 16
8Troubleshooting 16
8.1 Possible Problems and their solutions 16
8.2 System Information 17
8.2.1 DMUI-TOUCH-B-UD/DMUI-EASY2move 17
8.2.2 DMUI-TOUCH-C-FX 17
10 Additional Information 19
10.1 Disassembly 19
10.2 Maintenance 19
10.2.1 Cleaning 19
10.3 Disposal 19

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 5
1 GENERAL INFORMATION
Documentation for the DYNAMIC MOTION System consists of this Manual and several other documents.
Read all documentation before assembling or operating the table system. Keep all documentation for as long
as the products are in your possession. Ensure that all documentation is provided to subsequent owners. Go
to www.logicdata.net for more information and support. This Manual may change without notice. The most
recent version is available on our website.
1.1 OTHER APPLICABLE DOCUMENTS
This Operating Manual assumes that the reader has assembled the products in the Table System, connected
the system according to the Conguration Handbook, and has read the following documents:
• DYNAMIC MOTION Conguration Handbook
• Datasheet and Operating Manual for the installed DYNAMIC MOTION Actuator
• Datasheet and Operating Manual for the installed User Interface (Handset or other)
• Datasheet and Operating Manual for the installed Power Hub (DYNAMIC MOTION Power Hub or
LOGICDATA-approved external Power Supply)
1.2 COPYRIGHT
© January 2020 by LOGICDATA Electronic und Software Entwicklungs GmbH. All rights reserved, except for
those listed in Chapter 1.3 Royalty-free use of images and text on page 5 .
1.3 ROYALTYFREE USE OF IMAGES AND TEXT
After purchase and full payment of the product, all text and images in Chapter 2, “Safety”, may be used free
of charge by the customer for 10 years after delivery. They should be used to prepare end user documentation
for height-adjustable table systems. The license does not include logos, designs, and page layout elements
belonging to LOGICDATA. The customer may make any necessary changes to the text and images to adapt
them for the purpose of end user documentation. No part of the text and no image may be used without the
prior written consent of LOGICDATA. Texts and images may not be sold in their current state, and may not
be published or sublicensed digitally. The transfer of this license to third parties without permission from
LOGICDATA is excluded. Full ownership and copyright of the text and graphics remain with LOGICDATA.
Texts and graphics are oered in their current state without warranty or promise of any kind. Contact
LOGICDATA to obtain text or images in an editable format ([email protected]).
1.4 TRADEMARKS
Documentation may include the representation of registered trademarks of goods or services, as well
as information about copyright or other proprietary expertise of LOGICDATA or third parties. In all cas-
es, all rights remain exclusively with the respective copyright holder. LOGICDATA® is a registered trade-
mark of LOGICDATA Electronic & Software GmbH in the USA, the European Union, and other countries.
Unauthorized use or duplication of this or any trademark is strictly prohibited by law.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 6
2 SAFETY
2.1 GENERAL SAFETY REGULATIONS
In general, the following safety regulations and obligations apply when handling the product:
• Do not operate the DYNAMIC MOTION system unless it is in a clean and perfect condition
• Do not remove, change, bridge, or bypass any protection, safety, or monitoring equipment
• Do not convert or modify any components without written approval from LOGICDATA
• In the event of malfunction or damage, any faulty components must be replaced immediately
• Unauthorized repairs are prohibited
• Do not attempt to replace hardware unless the system is in a de-energized state
• Only skilled persons are allowed to work on the Table System
• Ensure that national worker protection conditions and national safety and accident prevention reg-
ulations are observed during operation of the system
2.2 INTENDED USE
The DYNAMIC MOTION system is a group of products intended to operate electrically Height-Adjustable
Tables. It is intended for indoor use only. The system may only be installed in compatible Height-Adjustable
Tables and with LOGICDATA-approved accessories. Contact LOGICDATA for further details. Use beyond or
outside the intended use will void the product’s warranty. Please refer to the Operating Manual of each prod-
uct in the DYNAMIC MOTION system to determine its individual intended use.
2.3 REASONABLY FORESEEABLE MISUSE
Usage outside of the intended use for each product could lead to minor injuries, serious injuries, or even
death. Reasonably foreseeable misuse of the system includes, but does not extend to:
• Using the system as a climbing or lifting aid for people or animals
• Connecting unauthorized products to the Table System. If you are unsure as to whether a product
can be used with the system, contact LOGICDATA for further information
• Overloading the Table System
2.4 EXPLANATION OF SYMBOLS AND SIGNAL WORDS
Safety notices contain both symbols and signal words. The signal word indicates the severity of the hazard.
DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moder-
ate injury.
NOTICE Indicates a situation which, if not avoided, could result in damage to the product
through electrostatic discharge (ESD).
NOTICE Indicates a situation that will not lead to personal injury, but could lead to damage to
the device or the environment.
INFO Indicates the protection class of a device: Protection Class III.
Protection Class III devices may only be connected to SELV or PELV power sources.
INFO Indicates important tips for handling the product.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 7
2.5 LIABILITY
LOGICDATA products comply with all relevant industry standards, which are listed in the product's data-
sheet. However, risk can result from incorrect operation or misuse. LOGICDATA is in particular not liable for
damage or injury caused by:
•Improper product use
•Accidental usage
•Clear misuse/abuse of the Table System
•Disregard of the documentation
•Unauthorized product alterations
•Improper work on and with the Table System
•Operation of damaged products
•Normal wear and tear of the Table System or its components
•Wear parts
•Improperly performed repairs
•Unauthorized changes to the operating parameters
•Disasters, external inuence, and force majeure
The information in this documentation describes the characteristics of the system without assurances.
Resellers assume responsibility for the LOGICDATA products installed in their applications. They must en-
sure their product complies with all relevant directives, standards, and laws. LOGICDATA shall not be held
liable for any damage that is directly or indirectly caused by the delivery or use of this document. Resellers
must observe the relevant safety standards and guidelines for each product in the Table System.
2.6 RESIDUAL RISKS
Residual risks are the risks that remain after all relevant safety standards have been complied with. These
have been evaluated in the form of a risk assessment. Residual risks associated with the operation of the sys-
tem are listed here and throughout this Operating Manual. The risks associated with mounting each product
to the Table System are detailed in the respective product’s Operating Manual. The risks associated with con-
necting the products in the Table System are detailed in the DYNAMIC MOTION Conguration Handbook.
See also page 5. The symbols and signal words used in this Operating Manual are listed in Chapter 2.5 on
page 6.
WARNING Risk of death or serious injury in explosive atmospheres
Operating the system in potentially explosive atmospheres may lead to death or serious
injury through explosions.
• Read the relevant directives to determine if an atmosphere is potentially explosive
• Do not operate the system in potentially explosive atmospheres
WARNING Moderate risk of serious injury through electric shocks
While cleaning or using the system, liquid intrusion may lead to serious injury through
electric shocks.
• Do not allow any components to become wet during cleaning
• Ensure components are placed away from areas where spillages are likely to occur
• Take care not to spill liquids onto or around the system
CAUTION Risk of injury through exposure to harmful gases
Operating the system using damaged cables may lead to overheating and the release
of harmful gases. Inhaling these gases may lead to minor or moderate injury.
• Do not use damaged Cable
• Ensure that Cables are not clamped during assembly
CAUTION Risk of minor or moderate injury through crushing
If any Handset Key becomes stuck while the system is in motion, the system may not
stop properly. This may lead to minor or moderate injury through crushing.
• Disconnect the system immediately if any Handset Key becomes stuck

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 8
CAUTION Risk of minor or moderate injury through crushing
Self-retention (i.e. the ability of the Table System to maintain its position while station-
ary and in movement) is a safety issue that must be considered by all resellers. Although
the DYNAMIC MOTION system was designed with measures to help prevent the Table
System from slipping, the risk of uncontrolled movement is dependent on the design of
the Height-Adjustable Columns and – if applicable – the installed 3rd party spindles them-
selves. Resultantly, LOGICDATA cannot assume responsibility for this risk. Failure to en-
sure self-retention may lead to minor or moderate injury through crushing between parts
or by falling objects, which may be caused by unexpected movement of the Table System.
• Ensure that Height-Adjustable columns are designed with sucient friction to
prevent uncontrolled movement
• Contact LOGICDATA for further advice and design specications
CAUTION This appliance can be used by children from 8 years and above and people with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning the use of the appliance in a safe
way and understand the hazards involved. Children must not play with the appliance.
Cleaning and maintenance by the user must not be performed by children, unless they
are over 8 years old and supervised.
2.7 NOTES FOR RESELLERS
Resellers are companies that purchase LOGICDATA products for installation in their own products.
INFO For reasons of EU conformity and product safety, Resellers should provide end users
with an Operating Manual in their native EU ocial language.
INFO Resellers must perform a risk assessment on their product that covers residual hazards.
It must include measures to mitigate risk, or reference the product's Operating Manual.
INFO
The Charter of the French Language (La charte de la langue française) or Bill 101
(Loi 101) guarantees the right of the population of Quebec to conduct business and
commercial activities in French. The bill applies to all products sold and used in Quebec.
For table systems that will be sold or used in Quebec, Resellers must provide all product-
relevant texts in French. These include, but are not limited to:
• Operating Manuals
• All other product documentation, including datasheets
• Inscriptions on the product (such as labels), including those on product packaging
• Warranty certicates
The French inscription may be accompanied with a translation or translations, but no
inscription in another language may be given greater prominence than that in French.
INFO
Operating Manuals must include all the safety instructions that end users require to
handle the product safely. They must also include an instruction to always keep the
Operating Manual in the immediate vicinity of the product.
INFO No unauthorized persons (young children, persons under the inuence of medications,
etc.) should be allowed to handle the product.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 9
3 SCOPE OF DELIVERY
Scope of delivery depends on which Table System is to be assembled, and which accessories have been cho-
sen. Read the DYNAMIC MOTION Conguration Handbook to see the components required for your system.
4 ASSEMBLY
Aseembly for the DYNAMIC MOTION system is split into two parts:
• Mounting the DYNAMIC MOTION products onto/into the Table System (see Product Manual)
• Connecting the products (see Conguration Handbook)
Always ensure assembly has been completed safely and correctly before attempting to operate the DYNAMIC
MOTION system.
4.1 PERFORMING A POSITION RESET PROCEDURE
CAUTION Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive during start-up and reset processes. This may lead
to minor or moderate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
A Position Reset Procedure is required to complete Assembly, as well as to remedy certain malfunctions. It is
possible to perform a Position Reset Procedure with all types of compatible User Interface. However, this sec-
tion describes performing a Position Reset Procedure for Table Systems controlled by a Handset with an UP Key
and DOWN Key (Comfort or Basic Handsets). If your DYNAMIC MOTION system is operated by a dierent User
Interface, consult that product’s operating Manual for instructions on performing a Position Reset Procedure.
1. Press and hold the DOWN Key until the table stops at the lower position limit
2. Release the DOWN Key
3. Press and hold the DOWN Key again
 The table will move down slightly, then up again
4. Release the DOWN Key
 The Position Reset Procedure is complete.
INFO If your DYNAMIC MOTION system has been parameterized with additional stop-
ping points (e.g. a Safety Area or Container Stop Position), repeat Step 3 until the
table has moved upwards again.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 10
5 OPERATION
WARNING Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
While the table moves up and down, unsecured objects may fall o the table and onto
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
This section of the System Manual contains instructions for operating the DYNAMIC MOTION system. All
instructions assume the reader has assembled a Table System that will be controlled by a Handset with an UP
Key and DOWN Key. If your DYNAMIC MOTION system is operated by a dierent User Interface, consult that
product’s operating Manual for instructions on operating the DYNAMIC MOTION system.
The availability of some functions depends on the Handset used. This section describes two variants:
• Comfort Handsets - These products have a digital display, a SAVE Key and Memory Position Keys
• Basic Handsets - These products have only an UP and DOWN Key
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE SAVE Key (Comfort Handsets only)
1Memory Position Keys (Comfort Handsets only)
5.1 NOTES FOR DMUIEASY2MOVE
The DMUI-EASY2move is a Paddle Handset that can be used to control the DYNAMIC MOTION system. It
works by lifting the paddle upwards to move the table up, and by pressing it downwards to move the table
down.
In the interests of clarity, specic instructions for this Handset are not included in this manual. However, in
most cases, instructions for Basic Handsets can be used to operate the DYNAMIC MOTION system with the
DMUI-EASY2move. To do so, you will need to make the following equivalencies.
UP Key - Gently lift the Paddle upwards
DOWN Key - Gently push the Paddle downwards
UP and DOWN Keys simultaneously - Press the SAVE Key (on the bottom of the DMUI-EASY2move).
If you have installed the DMUI-EASY2move alongside the DYNAMIC MOTION system, you are obliged to
read the product's operating manual, including all relevant safety information, in full.
24
3

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 11
5.2 STANDARD FUNCTIONS
This section describes functions that can be performed using both Comfort and Basic User Handsets along-
side the DYNAMIC MOTION system. If your DYNAMIC MOTION system will be controlled by a dierent User
Interface, consult that product's Operating Manual for instructions and safety advice.
5.2.1 ADJUSTING THE TABLE TOP HEIGHT
CAUTION Risk of minor or moderate injury through crushing
Your ngers may be crushed when you attempt to change the height of the table
• Keep ngers away from moving parts
• Ensure that no persons or objects are in the table's range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-
ned stopping point has been reached.
To move the Table Top UP:
Press and hold the UP Key until the desired height has been reached
To move the Table Top DOWN:
Press and hold the DOWN Key until the desired height has been reached
5.3 ADVANCED FUNCTIONS
This section describes functions that can only be performed using Comfort User Handsets alongside
the DYNAMIC MOTION system. If your DYNAMIC MOTION system will be controlled by a dierent User
Interface, consult that product's Operating Manual for instructions and safety advice.
5.3.1 SAVING A MEMORY POSITION
This function saves a set Table Top position. One Memory Position can be saved per Memory Position Key.
1. Move the table to the desired height (Chapter 5.1.1, Adjusting the Table Top height)
 The display shows the Table Top height (e.g. 73 cm)
2. Press the SAVE Key.
3. Press the Memory Position Key (e.g. 2)
 The display shows S 2
 After about two seconds, the Table Top height is displayed again
SAVE
2

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 12
5.3.2 ADJUSTING THE TABLE TO A MEMORY POSITION
Version A (without double-click function):
2Press and hold the required Memory Position Key (e.g. 2).
The Table Top will move until the saved Table Top height has been reached. If you re-
lease the Key before the Memory Position is reached, the table will stop.
2Release the Memory Position Key
7 The display shows the Table Top height (e.g. 73 cm)
Version B (Auto-Movement with double-click function):
INFO The double-click function is available only for DYNAMIC MOTION systems sold in US
markets. It is not activated as standard.
INFO If you press any Key while the table moves to a Memory Position, the Table Top will stop
moving immediately. To continue, you must select the Memory Position again.
CAUTION Risk of minor or moderate injury through unauthorized modications
The rmware is delivered with a deactivated double-click function. If you activate this
function, the gradings of the safety functions according to EN ISO 13849-1 PL b, Category
B, are no longer valid, as the legal requirements in the standard are no longer met.
• If you activate the function, perform a new risk new assessment to meet the higher
safety requirements (EN 60335-1). These cannot be met by the DYNAMIC MOTION
system
• LOGICDATA is not liable for injuries or damage caused by activating the dou-
ble-click function
2Double-click the required Memory Position Key (e.g. 2)
 The table will move to the Memory Position. You do not have to hold the Key
 The display shows the Table Top height (e.g. 73 cm)

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 13
6 SOFTWAREDEPENDENT
FUNCTIONS
6.1 STANDARD FUNCTIONS
This section describes the software-dependent functions that can be performed by Comfort and Basic User
Handsets alongside the DYNAMIC MOTION system. If your DYNAMIC MOTION system will be controlled by
a dierent User Interface, consult that product's Operating Manual for instructions and safety advice.
6.1.1 LOW SPEED AREA
During movement, this function causes a reduction in speed before the following positions are reached:
•Maximum and minimum Table Top height
•All saved positions (e.g. Memory Positions, Container Stop Position, etc.)
CAUTION
Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive in the Low Speed Area. This may lead to minor or
moderate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
6.1.2 SAFETY AREA
This function causes a safety stop at a dened Table Top height, which is set through the product's software.
INFO You cannot save table positions that fall within the safety area.
CAUTION
Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive in the Safety Area. This may lead to minor or mod-
erate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
You can move the table into the safety area as follows:
1. Press and hold the DOWN Key
 The Table Top is adjusted to the start of the safety area
 The Table Top stops moving when the safety area is reached
2. Press the DOWN Key again to move into the safety area
6.1.3 CONTAINER STOP AND SHELF STOP POSITIONS
These features can limit the movement area of the Table Top (e.g. if a container is below the table or a shelf
is above it). Container Stop Positions become the new lowest end position, Shelf Stop Positions the highest.
INFO Container Stop Positions can only be saved in the lower half of the movement area, Shelf
Stop Positions in the upper half. You must set each position separately.
Proceed as follows to save a Container Stop / Shelf Stop Position with a Comfort Handset:
1. Press the UP or DOWN Key to move the Table Top to the desired position
2. Press and hold the SAVE Key for 10 seconds
 The Container Stop / Shelf Stop Position is saved
Proceed as follows to save a Container Stop / Shelf Stop Position with a Basic Handset:
1. Press the UP or DOWN Key to move the Table Top to the desired position
2. Press and hold the UP Key and DOWN Key for 10 seconds.
 The Container Stop / Shelf Stop Position is saved
Proceed as follows to delete a Container Stop / Shelf Stop Position with a Comfort Handset:
SAVE

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 14
1. Press the UP or DOWN Key to move the Table Top to the top half (to delete a Shelf
Stop Position) or bottom half (Container Stop Position) of the movement area.
2. Press and hold the SAVE Key for 10 seconds
 The Container Stop / Shelf Stop Position is deleted
Proceed as follows to delete a Container Stop / Shelf Stop Position with a Basic Handset:
1. Press the UP or DOWN Key to move the Table Top to the top half (to delete a Shelf
Stop Position) or bottom half (Container Stop Position) of the movement area.
2. Press and hold the UP Key and DOWN Key for 10 seconds.
 The Container Stop / Shelf Stop Position is deleted
6.1.4 FACTORY RESET
To reset the DYNAMIC MOTION System to its Factor Settings with a Basic Handset:
Press the UP and DOWN Keys simultaneously, then release
Press and hold the UP and DOWN Keys for 10 seconds
 The LED will light up in Red
When the LED light begins to blink, release the UP and DOWN Keys
The DYNAMIC MOTION system has now been reset to its factory settings.
To reset the DYNAMIC MOTION System to its Factor Settings with a Comfort Handset:
1 2 Press and hold the following Keys for 3 seconds:
• Memory Position Keys 1 and 2
• UP Key
The display shows S and a number (e.g. S 4)
Press the DOWN Key until the display shows S 0.
The display shows S 0.
SAVE Press the SAVE Key.
The DYNAMIC MOTION system has now been reset to its factory settings.
SAVE

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 15
6.2 ADVANCED FUNCTIONS
This section describes functions that can only be performed by certain Comfort Handsets alongside the
DYNAMIC MOTION system. Consult your User Interface's Manual for instructions and safety advice.
6.2.1 KEY LOCK
CAUTION Risk of minor or moderate injury through uncontrolled movement
When attempting to activate the Key Lock, pressing the Handset too forcefully may
cause the table to move unexpectedly. Failure to anticipate the table's movements may
lead to minor or moderate injury through crushing.
• Do not press the Handset too forcefully while activating the Key Lock
INFO The Handset must be turned on for the Key Lock to be activated. To activate a locked
Handset, press any key.
INFO Key Lock is only available as standard on certain models. If your Handset supports Key
Lock, the feature can be activated during parameterization.
Activating the Key Lock prevents you from moving the table if you accidentally press a Key. The Key Lock
can be activated and deactivated by swiping across the bottom edge of the Handset. Alternatively, swipe
horizontally across the left or right-hand side of the Handset (Fig.1). The display must be active for you to
activate the Key Lock. To activate an inactive display, press any Key. After you have activated the Key Lock, a
key is displayed on the screen (Fig.2).
Fig. 1: Activating the Key Lock Fig. 2: Locked Handset
6.2.2 CHANGING THE DISPLAYED UNIT OF MEASUREMENT CM / "
Most Comfort Handsets can display the height of the Table Top in both centimeters and inches. To change
the displayed unit of measurement:
1 2 Press and hold the following Keys for 3 seconds:
• Memory Position Keys 1 and 2
• UP Key
 The display shows S and a number, e.g. S 7.
2. Press the button UP Key until the display shows S 5.
 The display shows S 5.
3. Press the SAVE Key
 If the display was previously set to cm, it is now set to inches.
 If the display was previously set to inches, it is now set to cm.
SAVE

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 16
7 COLLISION DETECTION
Intelligent System Protection (ISP) is LOGICDATA’s collision detection system. It aims to reduce the risk of
system damage when using LOGICDATA products. If there is an obstacle in the operating range of a table,
and the obstacle and table collide, a load change aects the DYNAMIC MOTION system. When the load
change is detected, all Actuators stop immediately and move back in the opposite direction for a few seconds
(see 9.2 Drive Back Function). There are two types of ISP:
Integrated
ISP Sensor
Some DYNAMIC MOTION Actuators are tted with integrated ISP Sensors as standard. No
additional Sensor can be connected.
External
ISP Sensor
Other DYNAMIC MOTION Actuators are not tted with integrated ISP Sensors as standard. An
additional LOGICDATA (or LOGICDATA-approved) Sensor can be connected to the Actuator.
NOTICE If your DYNAMIC MOTION Actuator supports the use of an External Collision Sensor,
assembly and connection instructions can be found in its Operating Manual.
7.1 DRIVE BACK FUNCTION
After ISP is triggered, the Table Top automatically moves a dened distance in the opposite direction.
8 TROUBLESHOOTING
8.1 POSSIBLE PROBLEMS AND THEIR SOLUTIONS
Problem Possible cause Solution
The table does not
move
The system is not plugged
in
Ensure that the system has been connected to the
Power Hub correctly
The Actuator is not con-
nected properly
Ensure that the Actuator is properly connected to
all components of the system
Poor plug connection Ensure that all plugs have been connected properly
The Actuator is defective Replace the Actuator. Contact LOGICDATA if the
problem persists
The User Interface is
defective
Replace the User Interface. Contact LOGICDATA if
the problem persists
The table only moves
slowly downwards
There was power failure
while the table was in
motion
Perform a Position Reset Procedure (see Chapter 4.7
Performing a Position Reset Procedure)
The Power Hub was
disconnected while the
device was in motion
Reset required
The Actuator is defective Replace the Actuator. Contact LOGICDATA if the
problem persists
The User Interface
does not work
The User Interface is
defective
Replace the User Interface. Contact LOGICDATA if
the problem persists
For further information, or if you are experiencing problems that are not covered in this chapter, refer to the
Operating Manual of each individual product in the DYNAMIC MOTION system.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 17
8.2 SYSTEM INFORMATION
8.2.1 DMUITOUCHB-UD / DMUIEASY2MOVE
When a DMUI-TOUCH-B-UD or DMUI-EASY2move Handset is installed alongside the DYNAMIC MOTION sys-
tem, system information is communicated via ashes of the LED Signal Light. Possible signals are as follows:
Signal Message Required Actions
No Light System operating normally Operate the DM System as normal.
System not connected See Conguration Handbook for instructions.
Red Light Blinking System Error Warning
Release all Keys and wait for 5 seconds. Then, try
to repeat the action again.
Disconnect all components from the Power Hub.
Disconnect the Power Hub from the Mains.
Check the Power Hub for overheating. Let cool if
necessary.
Check all connections and reconnect the system.
If problem persists: Perform a Position Reset
Procedure (Chapter 4.7). Contact LOGICDATA
Green Light Blinking System Start-up Wait until the LED has stopped blinking to
continue.
Do not press any buttons.
Reset in Progress
Duty Cycle Exceeded
Collision Detected (ISP) Remove the obstruction from the Table System.
Remove unnecessary loads from the Table Top
Operate the DM System as normal.
Green Light Flashing
Rapidly
Position Reset Required. Perform a Position Reset Procedure (Chapter
4.7).
NOTICE Do not operate the DYNAMIC MOTION system if problems persist. Contact LOGICDATA
for further information.
8.2.2 DMUITOUCHCFX
When a DMUI-TOUCH-C-FX Handset is installed alongside the DYNAMIC MOTION system, error messages
are displayed on the digital display panel. These are as follows:
Signal Message Required Actions
The display shows "Hot".
Overheating protection has
been activated.
Wait for the overheated components to
cool.
The display shows "ISP".
The system has recognized a
collision.
Release all Keys and wait for the Drive
Back function to be completed.
The display shows "Con",
then "Err".
The system has recognized a
connection error.
Release all Keys and wait for 5 seconds.
Then, try again.
Disconnect the Power Hub from the
Mains. Then, disconnect System from the
Power Hub. Reconnect the system again,
then operate the DM System as normal.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 18
The display shows "Err",
then an error number.
An internal error has occur-
red.
Read the table below to nd the correct
response to the error code shown.
Code Message Required Actions
1 Firmware Error
Disconnect the Power Hub from the Mains. Then, disconnect
System from the Power Hub. Reconnect the system again,
then operate the DM System as normal.
2 Motor Over Current Release all Keys and wait for 5 seconds. Then, try again.
3 DC Over Voltage Release all Keys and wait for 5 seconds. Then, try again.
8 Impulse Detection Timeout Perform a Position Reset Procedure (see System Manual)
11 Speed cannot be achieved Release all Keys and wait for 5 seconds. Then, try again.
12 Power Stage Overcurrent Release all Keys and wait for 5 seconds. Then, try again.
13 DC Under Voltage Release all Keys and wait for 5 seconds. Then, try again.
14 Critical DC Over Voltage Release all Keys and wait for 5 seconds. Then, try again.
15 Strain Gauge is defective
Release all Keys and wait for 5 seconds. Then, try again.
Contact LOGICDATA if the problem persists. Do not operate
the DM System if components are broken.
17 Error during pairing sequence
Disconnect the Power Hub from the Mains. Then, disconnect
System from the Power Hub. Reconnect the system again,
then operate the DM System as normal.
If this fails, perform a factory reset (see DM System Manual).
18
Parameterization or rmware of
dierent Actuators in the Table
System are incompatible.
Re-paramaterize the Actuators. Contact LOGICDATA for
further information.
19 Too many / too few Actuators
connected
Connect the correct number of Actuators (as specied in
setup).
20 Motor short circuit and/or open
load Contact LOGICDATA.
21 Firmware Error
Disconnect the Power Hub from the Mains. Then, disconnect
System from the Power Hub. Reconnect the system again,
then operate the DM System as normal.
22 Power Hub overload Release all Keys and wait for 5 seconds. Then, try again.
23 Motor Under Voltage Release all Keys and wait for 5 seconds. Then, try again.
NOTICE Do not operate the DYNAMIC MOTION system if problems persist. Contact LOGICDATA
for further information.

DYNAMIC MOTION SYSTEM  SYSTEM MANUAL // PAGE 19
9 ADDITIONAL INFORMATION
9.1 DISASSEMBLY
To disassemble the DYNAMIC MOTION system, unplug the Power Hub at the mains, then disconnect all
cables from the Power Hub. Then, follow the assembly instructions for your chosen product in reverse order.
9.2 MAINTENANCE
All DYNAMIC MOTION system Products are maintenance-free.
WARNING Risk of death or serious injury through electric shocks and other hazards
Using the DYNAMIC MOTION system alongside unauthorized spare or accessory parts
may lead to death or serious injury through electric shocks and other hazards.
• Only use accessory parts produced or approved by LOGICDATA
• Only use replacement parts produced or approved by LOGICDATA
• Only allow Skilled Persons to perform repairs or install accessory parts
• Contact customer services immediately if the system malfunctions
The use of unauthorized spare or accessory parts may cause system damage. Warranty
claims are void in this scenario.
9.2.1 CLEANING
WARNING Moderate risk of serious injury through electric shocks
While cleaning the system, liquid intrusion may lead to serious injury through electric
shocks.
• Do not allow any components to become wet during cleaning
• Ensure components are placed away from areas where spillages are likely to occur
• Take care not to spill liquids onto or around the system
1. Disconnect the system from the mains
2. Wait 30 seconds for residual voltage to dissipate.
3. Wipe the surface of the components with a dry, soft cloth. Never immerse components into liquid
4. Wait for all components to dry completely
5. Reconnect the Power Hub to the mains
9.3 DISPOSAL
All products in the DM System are subject to the WEEE Directive2012/19/EU.
• Dispose of all components separately from household waste. Use designated collection
points or disposal companies authorized for this purpose

www.logicdata.net
LOGICDATA
Electronic & Software Entwicklungs GmbH
Wirtschaftspark 18
8530 Deutschlandsberg
Austria
Phone: [phone]
Fax: [phone]
Email: o[email protected]
Internet: http://www.logicdata.net
LOGICDATA North America, Inc.
Broadmoor Ave SE
Suite D
Grand Rapids
MI, USA,
Phone: [phone]
Email: o[email protected]
