Logik LBMFMX14 User manual

BI Oven:
LBMFMX14
LBFANX14
LBFANW14
LBFANB14
SERVICE MANUAL

2

3
Door assembly
Removing the door assembly
1. Lift the lock of the left and right door hinge.
2. Position the door at an angle of 45° relative to the front of the appliance, lift and
pull out toward yourself.
3. Place the door on a at surface with the handle facing downward. Using a at
screwdriver, pry the cap of the prole on one side to remove it.

4
4. Pull out the inner glass panel and carefully lift it. Do the same with the middle
glass panel(s).
Door assembly
5. Remove the screw that fastens the hinge to the inner glass prole. Pull the hinge
out of the prole.
6. Use the screwdriver to pry and remove the glass panel bracket.
Refer to the Annex to the SBI_001 service manual.

5
Door assembly
7. Remove the door handle by undoing the screws.
8. To reassemble the components follow the above steps in reverse order.

6
Front panel
Remove the front panel
1. Remove the front panel top cover and lift it up. On both sides undo the screws
that fasten the front panel to the body of the appliance.

7
Convection fan assembly
1. Remove the rear wall according to relevant instructions in the manual. Remove
the fan guard by removing the screws. Remove the fan propeller by holding the
fastening nut with the pliers and rotating propeller.
Remove the fan
3. To reassemble the components follow the above steps in reverse order.
2. Remove the fan drive by bending the locking tab. Then turn counter-clockwise
and pull the fan drive toward you. Disconnect the fan drive wiring harness.

8
Temperature sensor
1. Remove the rear wall according to relevant instructions in the manual. Remove
the screw securing the temperature sensor. Remove the temperature sensor em-
bedded in the socket. Disconnect the temperature sensor wiring harness.
Remove the temperature probe
2. To reassemble the components follow the above steps in reverse order.

9
Heating elements
1. Remove the rear wall according to relevant instructions in the manual. Discon-
nect the wiring harness of the top heater. Remove the nuts securing the heater to
the oven chamber. After unscrewing, remove the heater from the oven chamber.
Remove the top heating element
2. To reassemble the components follow the above steps in reverse order.

10
Heating elements
1. Remove the rear wall and the fan guard according to relevant instructions in the
manual. Disconnect the wiring harness from the convection fan heater. Using a
socket head wrench undo and remove the nut securing the heater assembly.
Remove the convection heater
3. To reassemble the components follow the above steps in reverse order.
2. Inside the oven chamber, remove the screw securing the heater and pull the
heater toward yourself.

11
Heating elements
1. Remove the rear guard according to relevant instructions in the manual. Discon-
nect the wiring harness from the bottom the heater. Move the oven chamber insu-
lation out of the way to allow access to the heater mounting. Deect the catches
securing the heater.
Remove the bottom heater

12
Front wall
1. Remove the door assembly, side walls and front panel according to relevant in-
structions in the manual. To replace the front wall it is not necessary to remove
the oven insulation. Undo the screws securing the front wall to the oven cham-
ber.
Remove the front wall
2. To reassemble the components follow the above steps in reverse order.

13
Oven door seal
1. Unhook the seal holders after removing the front wall according to relevant in-
structions in the manual.
Remove the oven door seal
2. To reassemble the components follow the above steps in reverse order.

14
Oven chamber insulation
1. Remove the top cover, side walls, bottom cover and fan guard according to rel-
evant instructions in the manual. Remove the rear insulation cover (previously
disconnecting all wire harnesses) by removing the two screws.
Replace the oven insulation
3. To reassemble the components follow the above steps in reverse order.
2. Replace the oven insulation

15

IS-002.1_EN
(05.2014)
