Logik L32SBIN16 User manual

2.1CH Soundbar with
Built-in Subwoofer
Instruction Manual
L32SBIN16
L32SBIN16_IB_Final191216V8.indd 1 17/12/2019 11:08

L32SBIN16_IB_Final191216V8.indd 2 17/12/2019 11:08

Contents
Safety Warnings.....................................................................................................................................4
Unpacking..............................................................................................................................................6
Product Overview..................................................................................................................................7
Front View.............................................................................................................................................................................7
Top View................................................................................................................................................................................7
Rear View ..............................................................................................................................................................................7
Remote Control...................................................................................................................................... 8
Remove the Plastic Strip from the Remote Control ............................................................................8
Battery Replacement for the Remote Control..................................................................................... 9
Remote Control Operation Range......................................................................................................10
Wall Mounting .....................................................................................................................................10
Connections .........................................................................................................................................12
Method 1: Optical / Coaxial Connection ................................................................................................................12
Method 2: Using the AUX Connection....................................................................................................................13
Method 3: Connecting to an external device.......................................................................................................14
Connecting to the Mains Supply...............................................................................................................................14
General Operation...............................................................................................................................15
Selecting Modes..............................................................................................................................................................15
Adjusting the Volume....................................................................................................................................................15
Selecting the Equaliser .................................................................................................................................................15
Adjusting the Bass/Treble Level in CUSTOM EQ mode ..................................................................................... 16
Bluetooth® Operation ..........................................................................................................................16
Listen to Music from Bluetooth® Device................................................................................................................17
Maintenance ........................................................................................................................................17
Hints and Tips ......................................................................................................................................18
Specications.......................................................................................................................................19
L32SBIN16_IB_Final191216V8.indd 3 17/12/2019 11:08

4
• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit
onto a third party make sure to include this
manual.
• Check that the voltage marked on the
rating label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about it working normally,
or if it is damaged in any way - switch o,
withdraw the mains plug and consult your
dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
• This unit is designed for indoor use only.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases,
should be placed on the unit. Do not
operate the unit with wet hands, near water
or other liquid.
• If you spill any liquid into the unit, it can
cause serious damage. Switch it o at the
mains immediately. Withdraw the mains
plug and consult your dealer.
Safety Warnings
Ventilation
• To prevent the risk of electric shock or
re hazard due to overheating, ensure
that curtains and other materials do not
obstruct the ventilation vents.
• A minimum distance of 5cm around the
unit should be maintained to allow for
sucient ventilation.
• Do not install or place this unit in a
bookcase, built-in cabinet or in another
conned space. Ensure the unit is well
ventilated.
Safety
• Always disconnect the unit from the mains
supply before connecting/ disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
during a lightning storm.
Mains Cable
• Make sure the unit or unit stand is not
resting on top of the mains cable, as the
weight of the unit may damage the mains
cable and create a safety hazard.
• If the mains cable is damaged it must be
replaced by the manufacturer, its service
agent, or similarly qualied persons in order
to avoid a hazard.
The mains plug is used as
disconnect device, the disconnect
device shall remain readily
operable.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely
aect the working of the unit, and cause a
distorted sound.
Batteries
• Batteries used in the unit are easily
swallowed by young children and this is
dangerous.
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the unit. Seek
medical advice if you believe a cell has been
swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
L32SBIN16_IB_Final191216V8.indd 4 17/12/2019 11:08

5
• Do not expose the battery to direct sunlight
or sources of excessive heat.
• Do not ingest the battery, Chemical Burn
Hazard.
• The remote control supplied with this
product contains a coin/button cell battery.
If the coin/button cell battery is swallowed,
it can cause severe internal burns in just 2
hours and can lead to death.
• Keep new and used battery away from
children.
• If the battery compartment does not close
securely, stop using the product and keep it
away from children.
• If you think batteries might have been
swallowed or placed inside any part of the
body, seek immediate medical attention.
Supervision
• Children should be supervised to ensure
that they do not play with the unit.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a
fatal electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated“dangerous
voltage” within the unit’s enclosure that
may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
Maintenance
• Ensure to unplug the unit from the power
supply before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.
~ AC voltage: This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage: This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
• This equipment is a Class II
or double insulated electrical
appliance. It has been designed in
such a way that it does not require a
safety connection to electrical earth.
L32SBIN16_IB_Final191216V8.indd 5 17/12/2019 11:08

6
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Remote Control
Coaxial Cable 3.5 mm to 3.5 mm
Audio Cable
Mains Cable
Main Unit
Instruction Manual
Instruction
Manual
Wall Bracket x 2
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features
it oers. You will also nd some hints and tips to help you resolve any
issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Screw × 2 Dowel × 2
L32SBIN16_IB_Final191216V8.indd 6 17/12/2019 11:08

7
Product Overview
Front View
Top View
Rear View
1. POWER Indicator
Light up in Standby mode.
2. AUX Indicator
Light up green in AUX mode.
Light up once while selecting CUSTOM EQ
eect.
3. Bluetooth® Indicator
Light up blue in Bluetooth® mode.
Light up once while selecting MUSIC EQ eect.
1. Button
Switch the unit between On and
Standby mode.
2. SRC Button
Press repeatedly to select between
AUX , Bluetooth®, Optical or Coaxial
mode
1. AC~ Socket
2. SERVICE ONLY Socket
The USB socket is for service only. It is
not designed to charge smartphones,
tablets or similar devices.
4. Optical Indicator
Light up orange in Optical mode.
Light up once while selecting
MOVIE EQ eect.
5. Coaxial Indicator
Flash orange in Coaxial mode.
2 3 4 51
AC~
SERVICE ONLY
AUX
COAXIAL
OPTICAL
1
3
4
5
2
3. AUX Socket
4. COAXIAL Socket
5. OPTICAL Socket
1 2 3 4
3. EQ Button
Press repeatedly to select between
CUSTOM / MOVIE / MUSIC EQ eect.
4. VOL +/– Button
Press to increase/decrease volume.
L32SBIN16_IB_Final191216V8.indd 7 17/12/2019 11:08

8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Remote Control
1. Button
Switch the unit between On and
Standby mode.
2. OPTICAL Button
Press to select OPTICAL mode.
3. COAXIAL Button
Press to select COAXIAL mode.
4. AUX Button
Press to select AUX mode.
5. Button
Skip to previous track/Skip to next track
in Bluetooth® mode.
6. Button
Play/pause/resume playback in
Bluetooth® mode.
7. MOVIE Button
Press to switch to MOVIE EQ eect.
8. BASS +/– Button
Press to increase/decrease the bass
level in default EQ mode.
Remove the Plastic Strip from the Remote
Control
Remove the plastic strip from the battery if the
battery is being used for the rst time. It is located
at the bottom rear of the remote control.
9. CUSTOM Button
Press to select the default EQ setting.
10. MUTE Button
Silence the unit or restore the sound.
11. BT Button
Press to select Bluetooth® mode.
12. PAIR Button
Press to activate the pairing function in
Bluetooth® mode and disconnect the
existing paired Bluetooth® device.
13. VOL +/– Button
Press to increase/decrease volume.
14. MUSIC Button
Press to switch to MUSIC EQ eect.
15. TREBLE +/– Button
Press to increase/decrease the treble
level in default EQ mode.
L32SBIN16_IB_Final191216V8.indd 8 17/12/2019 11:08

9
Battery Replacement for the Remote Control
The remote control requires a CR2025, 3V Lithium
battery.
1. Slide and hold the battery release tab in the
direction of the arrow.
2. Pull out the battery holder and remove the old
battery.
3. Replace with a new battery.
4. Insert the battery holder back into the remote
control.
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage,
which could cause re, personal injury or damage to property.
• Install the battery correctly in the battery compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in
accordance with local regulations.
• Small button cell batteries such as the one used in the remote control are
easily swallowed by young children and this is dangerous. Keep loose button
cells away from young children and make sure that the battery is secure in
the remote control. Seek medical advice if you believe a battery cell has been
swallowed.
Handling the Remote Control
• Take care of your ngernails when you slide and pull the battery release tab.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or liquid on the remote control.
• Do not place the remote control on a wet object.
• Remove the battery from the remote control when not in use for a long period
of time, as corrosion or battery leakage may occur and result in physical injury,
and/or property damage, and/or re.
L32SBIN16_IB_Final191216V8.indd 9 17/12/2019 11:08

10
Remote Control Operation Range
• The remote control sensor at the front unit is
sensitive to the remote control’s commands up
to a maximum of 6 metres away and within a
maximum of a 60° arc.
• Please note that the operating distance may
vary depending on the brightness of the room.
30° 30°
Max. 6 m
Wall Mounting
1. Remove the screws from the main unit.
2. Attach the wall brackets to the main unit with the screws removed from the main unit.
Wall bracket
Screw
• Installation must be carried out by qualied personnel only. Incorrect assembly
can result in severe personal injury and property damage (if you intend to
install this product yourself, you must check for installations such as electrical
wiring and plumbing that may be buried inside the wall). It is the installer’s
responsibility to verify that the wall will safely support the total load of the
soundbar.
• Additional tools (not included) are required for the installation.
• Do not overtighten screws.
• Keep this instruction manual for future reference.
• Use an electronic stud nder to check the wall type before drilling and mounting.
L32SBIN16_IB_Final191216V8.indd 10 17/12/2019 11:08

11
3. Drill 2 parallel holes (Ø ~6 mm each according to wall type) in the wall. Fix two screws
onto the wall. They should be parallel to each other. The distance between the two
screws should be 657 mm.
ø2.5~3mm
ø ~6mm
657 mm
657 mm
5 mm
25-30 mm
4. Leave a 5 mm gap between the wall and the screw’s head. Lift the unit with the attached
wall brackets over the heads of the screws and slot into place.
Wall mounting with dowels and screws
Wall mounting with screws only
Make sure that the mounting screws are in the centre of the timer stud.
L32SBIN16_IB_Final191216V8.indd 11 17/12/2019 11:08

12
Connections
This section involves various methods of connecting the product to other
external components. Ensure all audio connections of the unit are connected
before connecting to the mains power socket.
After the unit is connected to an external device, audio will only be heard from
the soundbar while the connected device is used as a source output.
Method 1: Optical / Coaxial Connection
Use an optical cable (not included) / coaxial cable (included) to connect the soundbar’s
OPTICAL / COAXIAL socket to the OPTICAL OUT / COAXIAL OUT socket of the external
device. The simplest option is to connect your soundbar directly to your TV. If you connect
the soundbar to another external device (e.g. Blu-Ray player), you will hear the sound from
that device through the soundbar.
After the connection is complete,
1. Press button on the unit or remote control to switch on the unit.
2. Press SRC button on the unit repeatedly or press OPTICAL or COAXIAL button on the
remote control to select Optical or Coaxial mode.
AC~
SERVICE ONLY
AUX
COAXIAL
OPTICAL
1
2
Optical cable
(not included)
Coaxial cable
(included)
TV
Rear view of the unit
DO NOT connect the soundbar to the TV through its Yellow/Red/White sockets.
The unit may not be able to decode all digital audio formats from the input
source. In this case, the Optical/Coaxial indicator will ash quickly, and the unit
will prompt “Unsupported format, please refer to the Instruction Book”. This
is NOT a defect. Ensure that the audio setting of the input source (e.g. TV, game
console, DVD player, etc.) is set to PCM (Refer to the user manual of the input
source device for its audio setting details) with Optical/Coaxial input.
L32SBIN16_IB_Final191216V8.indd 12 17/12/2019 11:08

13
Method 2: Using the AUX Connection
Use the 3.5 mm to 3.5 mm stereo audio cable (included) to connect the AUDIO OUT /
HEADPHONE socket of the external device (e.g. TV, DVD player, etc.)to the unit’s AUX
socket. Please ensure that the output volume is turned up in order for the soundbar to
operate.
After the connection is complete,
1. Press button on the unit or remote control to switch on the unit.
2. Press SRC button on the unit repeatedly or press AUX button on the remote control to
select AUX mode.
AC~
SERVICE ONLY
AUX
COAXIAL
OPTICAL
Please refer to the user manual of your TV to change the functionality of your
headphone socket to a line out if possible.
3.5 mm to 3.5 mm Stereo
Audio Cable (included)
AUDIO OUT /
HEADPHONE
Socket
Set-top Box
TV
Rear view of the unit
Blu-ray Player /
DVD Player
Satellite
Receiver
L32SBIN16_IB_Final191216V8.indd 13 17/12/2019 11:08

14
Connecting to the Mains Supply
• Ensure that the power supply voltage
corresponds to the voltage printed on the back
or the underside of the unit.
• The soundbar is designed to operate with the
supplied mains cable.
• Connecting the main unit to any other power
source may cause damage to the unit. Unwind
the mains cable to its full length.
• Connect the mains plug of the main unit to a
mains socket. Make sure the mains plug is fully
inserted into the mains socket. The soundbar is
now connected and ready to use.
• To switch o the soundbar completely, remove
the mains plugs from the mains sockets.
Ensure all audio connections of the unit are
connected before connecting to the mains
power socket.
AC~
SERVICEONLY
AUX
COAXIAL
OPTICAL
AC~
SERVICE ONLY
AUX
COAXIAL
OPTICAL
Method 3: Connecting to an external device
Use the 3.5 mm to RCA stereo audio cable (not included) to connect the AUDIO OUT
sockets (L/R) of an external device to the unit’s AUX socket.
1. Press button on the unit or remote control to switch on the unit.
2. Press SRC button on the unit repeatedly or press AUX button on the remote control to
select AUX mode.
3.5 mm to RCA stereo
audio cable (not included)
Rear view of the unit
TV Blu-ray Player /
DVD Player
Set-top Box
Satellite
Receive
Game
Console
To the mains
socket
red (R)
white (L)
L32SBIN16_IB_Final191216V8.indd 14 17/12/2019 11:08

15
General Operation
When you rst connect the main unit to the mains socket, the main unit will be in Standby
mode. The POWER indicator will light up red.
• Press the button on the main unit or remote control to switch the main unit on. The
status indicator of the last used mode will light up.
• Press the button on the main unit or remote control to switch the main unit back to
Standby mode. The POWER indicator will light up red.
• Disconnect the mains plug from the mains socket if you want to switch the unit o
completely.
The eco-friendly technology will switch this device to Standby mode
automatically when the input volume is too low or muted for 15 minutes.
Selecting Modes
Press the SRC button on the main unit repeatedly to switch between AUX, Bluetooth®,
Optical or Coaxial mode, or press AUX, BT, OPTICAL or COAXIAL button on the remote
control to select your desired mode.
Adjusting the Volume
• Press the VOL +/– button to adjust the volume.
• If you wish to turn the sound o, press the MUTE button on the remote control. Press
the MUTE button again or press the VOL +/–button to resume normal listening.
• While adjusting the volume, the status indicator ashes quickly.
• While the volume level reaches its maximum level, if you press the VOL + button again,
the status indicator ashes once. While the volume level reaches its minimum level, if
you press the VOL – button again, the status indicator ashes once.
If the unit is connected with an external device, you may also adjust the volume
of the input source for volume control.
Selecting the Equaliser
While playing, press EQ button on the unit repeatedly, or press CUSTOM / MOVIE / MUSIC
button on the remote control to select between preset equalisers: CUSTOM (default EQ
mode), MOVIE (recommended for viewing movies) and MUSIC (recommended for listening
to music).
• When Coaxial or Optical mode is selected, the unit will automatically switch
into MOVIE EQ eect.
• When AUX or Bluetooth® mode is selected, the unit will automatically switch
into MUSIC EQ eect.
L32SBIN16_IB_Final191216V8.indd 15 17/12/2019 11:08

16
Bluetooth® Operation
You can listen to tracks from a media device if it is connected to the unit via Bluetooth®.
• The operational range between the main unit and a Bluetooth® device is
approximately 8 metres.
• Before you connect a Bluetooth® device to this unit, familiarize yourself with the
Bluetooth® capabilities of the device.
• Compatibility with all Bluetooth® devices is not guaranteed.
• Any obstacle between this unit and a Bluetooth® device can reduce the
operational range.
• Keep this unit away from other electronic devices that may cause interference.
To connect your device to the unit via Bluetooth®, follow the steps below:
1. Switch the unit on. Press the SRC button on the main unit repeatedly or the BT button
on the remote control to select Bluetooth® mode, the Bluetooth® indicator will ash
slowly. The unit is now in pairing mode.
2. Activate your Bluetooth® device and select the search mode.
3. “L32SBIN16” will appear on your Bluetooth® device. Select “L32SBIN16” and enter
“0000” for password if necessary.
4. On successful pairing, you will hear “Paired“ from the unit, and the Bluetooth® indicator
will light up steadily.
To disconnect the Bluetooth® function, switch to another function on the unit or disable the
function from your Bluetooth® device, or press the PAIR button on the remote control. After
the Bluetooth® device is disconnected from the soundbar, you will hear “DISCONNECT” from
the unit.
Adjusting the Bass/Treble Level in CUSTOM EQ mode
1. Press EQ button on the unit repeatedly, or press CUSTOM button on the remote control
to select default EQ mode. The AUX indicator (Green) will light up once.
2. Press BASS +/– or TREBLE +/– button on the remote control to adjust the bass/treble
level.
• While adjusting the bass/treble level, the status indicator ashes quickly.
• While the BASS/TREBLE reaches its maximum or minimum level, the status
will ash once if you press BASS +/– or TREBLE +/– button again.
The table below also shows the EQ mode supporting bass/treble adjustment.
EQ Mode Adjusting Bass Level? Adjusting Treble Level?
Custom 3 3
Movie N/A N/A
Music N/A N/A
L32SBIN16_IB_Final191216V8.indd 16 17/12/2019 11:08

17
• If there is an existing connection, press PAIR button on the remote control to
re-activate the pairing mode, the existing connection will be interrupted.
• If no other Bluetooth® device pairs with this player within two minutes, the
player will recover its previous connection.
• The player will also be disconnected when your device is moved beyond the
operational range.
• If you want to reconnect your device to this player, place it within the
operational range.
• If the device is moved beyond the operational range, when it is brought back,
please check if the device is still connected to the player.
– If the connection is lost, follow the instructions above to pair your device to
the player again.
Listen to Music from Bluetooth® Device
• If the connected Bluetooth® device supports Advanced Audio Distribution Prole (A2DP),
you can listen to the music stored on the device through the player.
• If the device also supports Audio Video Remote Control Prole (AVRCP), you can use the
player’s remote control to play music stored on the device.
1. Pair your device with the player.
2. Play music via your device (if it supports A2DP)
3. Use supplied remote control to control play (if it supports AVRCP)
• To pause/resume play, press the button.
• To skip to a track, press the button.
Maintenance
Ensure the unit is fully unplugged from the mains socket before cleaning.
• To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray aerosol at or near the unit.
L32SBIN16_IB_Final191216V8.indd 17 17/12/2019 11:08

18
Hints and Tips
If a problem occurs, it may often be due to something very minor. The following table
contains various tips.
Problem Solution
No power. • Ensure the mains cable is connected securely.
• Make sure that the unit is switched on.
Loud hum or noise
is heard.
The plugs and sockets are dirty. Wipe them with a cloth slightly
moistened with an appropriate non-abrasive cleaning solution.
The remote control
does not work.
• Use the remote control near the unit.
• Point the remote control at the remote control sensor on the
main unit.
• Replace the battery in the remote control with a new one.
• Remove any obstacles between the remote control and the unit.
The unit does not
respond when
pressing any
buttons.
The unit may freeze up during use. Switch the unit off and then on
again at the mains socket to reset the unit.
No sound output
from the main unit
• Make sure that the unit is not muted. Press the MUTE Button or
the VOL + Button to resume normal listening.
• Ensure the audio setting of the input source (e.g. TV, game
console, DVD player, etc.) is set to PCM mode while using optical
or coaxial connection.
The sound output
effect sounds
unfamiliar
Press the EQ Button on the unit repeatedly or press CUSTOM /
MOVIE / MUSIC button on the remote control for the optimal
sound output effect.
I cannot find
“L32SBIN16” on
my Bluetooth®
device
• Ensure that the unit is switched on.
• Ensure that the Bluetooth® function is activated on your
Bluetooth® device.
• The unit has a Bluetooth® function that can receive a signal within
8 metres. Keep a distance within 8 metres between the unit and
your Bluetooth® device.
The unit will
sometimes
switch back to
standby mode
automatically.
The eco-friendly technology will switch this device to Standby
mode automatically when the input volume is too low or muted for
15 minutes. Press the button on the main unit or remote control
to switch the main unit on again.
If any functional abnormality is encountered, unplug the unit from the mains
socket and reconnect it again.
L32SBIN16_IB_Final191216V8.indd 18 17/12/2019 11:08

19
Specications
Model L32SBIN16
Main Unit
Power Supply AC 220 – 240V ~50/60 Hz
Main Unit Power Consumption 30 W
USB Service Port 5 V 500 mA (for service use
only)
Do NOT use for other purpose
Amplifier Output Power 15 W rms × 2 + 30 W rms
Bluetooth® Bluetooth® Version Bluetooth® 3.0
Maximum transmitted power 7 dBm
Frequency bands 2402 MHz ~ 2480 MHz
Ecodesign Information
Information
on Power
Consumption
Power Consumption of Another
Condition (Sound bar was
connected to AC mains via
detachable power cordset, and
without status display, and
the USB port with 5V output
and all network ports are
deactivated)
< 0.5 W
Network Standby Power
Consumption
< 2.0 W
Time interval for power management function
switches the unit automatically into Another
Condition (Sound bar was connected to AC
mains via detachable power cordset, and
without status display, and the USB port
with 5V output and all network ports are
deactivated)
Switch to another condition
within 15 minutes after intended
use
Power consumption in network standby if all
wireless network ports are activated
1.0 W
How to activate wireless network port:
• Switch to wireless mode (e.g. Bluetooth®, etc)
• Connect the unit with power
How to deactivate wireless network port:
• Press the Standby button
Net Weight 2.1 kg
Dimension (W x H x D) 815 × 58 × 85 mm
Features and specications are subject to change without prior notice.
L32SBIN16_IB_Final191216V8.indd 19 17/12/2019 11:08

All trademarks are the property of their respective owners and all rights are acknowledged.
The symbol on the product or its packaging indicates that this product must not
be disposed of with your other household waste. Instead, it is your responsibility
to dispose of your waste equipment by handing it over to a designated collection
point for the recycling of waste electrical and electronic equipment. The separate
collection and recycling of your waste equipment at the time of disposal will help
conserve natural resources and ensure that it is recycled in a manner that protects
human health and the environment.
For more information about where you can drop o your waste for recycling, please
contact your local authority, or where you purchased your product.
Notes for battery disposal
The batteries used with this product contain chemicals that are harmful to the environment. To
preserve our environment, dispose of used batteries according to your local laws or regulations.
Do not dispose of batteries with normal household waste.
For more information, please contact the local authority or your retailer where you purchased the
product.
In the unlikely event of a problem developing, please contact the store where you purchased
your equipment.
We continually strive to improve our products; specications may change without prior notice.
For advice on where to purchase accessories, please contact the store where you purchased your
equipment.
Visit Partmaster.co.uk today for the easiest way to buy electrical
spares and accessories. With over 1 million spares and accessories
available we can deliver direct to your door the very next day. Visit
www.partmaster.co.uk or call 0344 800 3456 (UK customers only) Calls charged at National Rate.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by DSG Retail Limited is under license. Other trademarks and trade names
are those of their respective owners.
IB-L32SBIN16-191211V8
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
EU Representative
DSG Retail Ireland Ltd (259460)
3rd Floor Oce Suite,
Omni Park SC, Santry, Dublin 9, Republic of Ireland
L32SBIN16_IB_Final191216V8.indd 20 17/12/2019 11:08
