1. Introduction
The LM-SD is a laser based distance measurement tool used to measure distances from
0.2m to more than 100m with pinpoint accuracy. A given target can be clearly identified
with the help of a red laser sighting point. The usable range of the sensor is dependent
upon target physical properties.
The range finder is based on comparative phase measurement. It emits high-frequency
modulated light which is diffusely reflected from the target and returns to the instrument
with a certain phase shift compared with the emitted signal. The distance can then be
determined with millimeter accuracy from the amount of this phase shift
Special performance features are:
- Provides high accuracy over long distances under extreme outdoor temperatures.
- Works in a wide range of operating voltages from 10 VDC to 30 VDC
- Features consistently low power consumption of <1.5 W (without IAlarm).
- Up to 30m range for distance measurement, with the potential for more than 100m
if additional reflectors are mounted onto the target (depending on reflectance and
environmental conditions).
- Visible laser beam for easier sighting.
- Switching output and analog output are separately programmed.
- Switching output tied to adjustable limits, indicating positive and negative over-range of
pre-selectable distance range window.
- Measured values can be displayed in meters, decimeters, centimeters, feet or inches.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 3
2. Description
2.1 Model Nomenclature
Record your Laser Meter’s complete Model Number here:
LM-SD - ___________
Base Model
Power Input
24: 24VDC
110: 110VAC
Serial Number _________________
Figure 2.1: Model Number
2.2 Specifications
Accuracy
±3mm within 30m
Resolution
0.1 mm
Laser
650nm Visible red, <1mW Class II, 0.6 mrad scattering
Detect Range
0.2-100m Reflector needed between 30m and 100m
Response
Relay < 320 ms, PNP < 300ms
Operating Temp
-10˚C to +50˚C (14˚F to +122˚F). With water cooling: +110˚C (230˚F)
Storage Temp
-10˚C to +70˚C
Output
Relay NO/NC 125VAC @ 0.3A, PNP type output 24VDC @300mA,
Analog Output
4-20mA @ ≤500Ω Accuracy: ±0.15%
Temp Drift
<50ppm/˚C
Power Input
24VDC ±10% <1.5W
Cable
Insulation 20MΩ, 500VDC, ≥500˚C (930˚F)
Housing
Hermetically sealed cast aluminum enclosure rated IP65, includes cooling
water connections and air purge.
Size
Enclosure; 280 mm L x 89 mm D x 300 mm H (with mounting bracket)
Weight
6kg (13.3 lbs)

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 4
2.3 Operating Principle
The Laser Meter operates on a time-of flight-principal, comparing the phase shift of the
returned signal with respect to that of the emitted laser. Careful measurement of this
phase shift indicates the time taken between sending the light signal and receiving the
reflection back. This is directly proportional to the distance travelled.
3. Location and Mounting
3.1 Sensor Location
The LM-SD Sensor should be installed so as to give a direct view of the target, unobstructed
by dust, steam, hoses or passers-by. The mounting should be vibration free, as any motion
of the sensor is magnified many times at the laser spot. This is a Class II laser, it should
mounted not to shine directly into the eyes of plant personnel. Direct sunlight into the
detector may cause erroneous readings.
It is best to try to have the target surface normal to the laser beam

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 5
Figure 3.1 shows the zero point on the LM-SD for calibration purposes. There is a
parameter “OF” that allows the Zero Point to be changed to some other meaningful point in
space.
Figure 3.1: Zero Point on the LM-SD
Mounting Distance- The sensor is rated at 30m operating distance without a reflector.
Operation at the end of this range should be tested before final installation. For distances
greater than 30m, a diffuse reflector is recommended.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 6
3.2 Sensor Mounting
Mounting Bracket- The LM-SD has an adjustable mounting foot designed to allow easy
rotation through horizontal and vertical axes. The sensor is fixed to the support with a
single 18 mm bolt through the LM-SD’s base mounting stand. The altitude angle may be
changed by slightly loosening the three cap screws in the base with a 4mm Allen key,
adjusting to the correct angle and retightening the same three screws. The support must be
sufficiently rigid to absorb any excessive site vibrations that could affect the precision
output of the detector.
Air, Cooling Water Fittings- The LM-SD has a water-cooling jacket to keep the electronics
within their operating temperature range, and an air-purged hood for protection of the
window glass. These sensors can thus be used in harsh environments with high
temperatures, steam, dust, and smoke. Please see Section 4.2 Plumbing Connection and
Section 4.3 Air-Purge Connection for further details on installing these protections for your
sensor.
Caution- For installation in environments that may include excessive water vapor or smoke,
it is recommended that additional ventilation such as air curtains or fans be used to clear
the area so the sensor can “see” the target.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 7
4. Utility Connections
4.1 Electrical Connections
Electrical Overview- All electrical connections (power and signal) to the LM-SD are made via
a 15-pin Harting style connector with ground. The sensor is supplied with a mating
connector at the back of its enclosure and a standard 2-meter cable with the quick-connect
assembly mating to the sensor and bare wire terminals for the junction box connections.
Other cable lengths are available from Logika Technologies upon request.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 8
Figure 4.1 Connections to LM-SD Harting Connector
Cable Specification-
Multi-lead cables of 10 x 20 gauge (10 x 0.6 mm²) shielded Teflon insulation for high
temperature applications.
Outer metallic braid for mechanical protection.
Overall diameter of 9 mm.
Minimum bending radius of 30 mm.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 9
Each lead is color-coded.
Junction Box Wiring- Please see Figure 4.1 for the sensor wiring diagram. The supplied
cable should be connected directly to the terminals of a junction box. All cables must be
shielded all the way to the console with the shield connected to ground to eliminate
electrical noise, which may trigger false detection. Any unused output wires must have
insulation protection or be connected to free terminals in the junction box.
Power Connections- Power Input (please specify power input at time of order).
Currently, this instrument is available in the 24VDC format only.
Current Output- 4-20mA Current Loop proportional to measured position
Relay Output- Single-pole double throw contacts, contact capacity rating is 125VAC/0.3A,
30VDC/1A. Relay operating time ≤ 320 ms.
PNP Output –Maximum current 300 mA. Response ≤300 ms
Note: PNP output and Relay output are isolated; these may wired to separate circuits
PNP output and Relay output change state together.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 10
4.2 Plumbing Connection
Description- Water cooling is required when the ambient temperature at the sensor’s
location is higher than 50oC (120oF). Temperatures above this level require protection for
the electronics. A standard cooling water fitting is available at the sensor enclosure and
copper heat exchanger tubing is embedded in the sensor housing to facilitate efficient heat
removal from the sensor using circulating cooling water.
Cooling Water Requirements
Clean industrial water
Maximum water inlet temperature of 25oC (75oF).
Maximum water pressure of 4 bars (60 psi)
Water flow rate of 1 to 2 L/min (0.035 to 0.071 ft3/min)
Connection- Use ¼” flexible tube to connect the plant’s cool water supply to the sensor
cooling water fitting and secure with a hose clamp. Use Figure 4.2, Ambient Temperature
vs Water Flow Rate Graph, to determine the cooling water flow rate for the ambient
conditions around the sensor.
Figure 4.2: Ambient Temperature vs. Water Flow Rate
4.3 Air Purge Connection
Description- Compressed plant air can be used to prevent dust and vapor from entering the
protective shroud around the lens of the sensor. Using plant air with the sensor will reduce
lens cleaning maintenance and prolong sensor life where dust or corrosive vapors are
present.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 11
Compressed Air Requirements
Must be clean, dry air free of contaminants. Poor purge air quality will lead to dirty glass
which may decrease sensor performance and increase sensor maintenance. Air filtration
prior to the sensor purge inlet fitting is recommended for purge air of questionable quality.
Air Pressure range of 50 to 200 g/cm2(0.71 to 2.84psi)
Air Flow rate of 4 to 16 L/min (0.14 to 0.56 ft3/Min)
Connection- Connect the plant purge air pipe to the air purge fitting on the sensor’s lens
shroud using a 10mm hose. The purge air flows out of the sensor shroud and dissipates into
the ambient environment.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 12
5 Operation
5.1 Controls
The LM-SD Sensor’s Control Panel is located under the protective cover plate on the back of
the sensor. The following functions are available at the Control Panel.
Figure 5.1: Control Panel
The five digit display shows the current reading in RUN mode and parameter information in
SETUP mode. See Section 5.3
BUTTONS
SET –Takes the unit into parameters or back to the menu
ADD –Increments the displayed parameter or value. Holding the button increases
the speed.
RED –Reduces the displayed parameter or value. Holding the button increases the
speed.
OK –Saves parameter values and exits
LEDs
Power –The unit is powered on
Com –Flickers to indicate communications to the processor are active
Alarm –Alarm threshold has been tripped.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 13
5.2 Setting Parameters
1. Press and hold the REDUCE button for two seconds until SEL-0 is
displayed.
2. Press ADD or RED to select the desired menu (See Section 5.3). In this
example we will use SEL-3, Alarm Center.
3. Press SET to go into setting mode. The screen in this case will display AC
for one second, then switch to the current value of the parameter.
06.300 means the alarm value is set at 6.3m.
4. Press ADD or RED to adjust this value up or down. Holding one of these
buttons will increase the rate the numbers change.
5. When the value is correct, press SET to return to the menu, in this
example SEL-3.
6. After all of the parameters have been set, press OK to save the changes.
The sensor will return to normal detect mode.
5.3 Parameter Menus
SEL0 –No parameter
SEL1 –rb –Range Beginning: The distance reading that will correspond to 4mA output
Minimum Value: 00.000m
Maximum Value: 99.999m
Default Value: 00.200m
SEL2 –rE –Range End: The distance reading that will correspond to 20mA output.
Minimum Value: 00.000m
Maximum Value: 99.999m
Default Value: 00.200m
SEL3 –AC- Alarm Center: The distance reading at which the alarm outputs change state.
Minimum Value: 00.000m
Maximum Value: 99.999m

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 14
Default Value: 02.500m
SEL4 –AH –Alarm Hysteresis: Width of the deadband on either side of the Alarm Center.
This prevents flicker of the Alarm Outputs.
Minimum Value: 00.000m
Maximum Value: 99.999m
Default Value: 00.200m

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 15
6. Maintenance
6.1 Regular Maintenance
Normally, the LM-SD does not require major periodic maintenance. Regular attention to
the following will ensure steady operation of the sensor:
Lens Cleaning- Routinely check the LM-SD sensor’s glass for dust or oil residue. Open the
lens shield board at the front of the sensor by unscrewing the fastening hardware on the
shield and clean the glass with alcohol and lens paper or soft cloth.
6.2 Returns of the LM-SD
Contact us with the Serial Number of your sensor before you return our product. If we are
unable to solve the problem by phone or email, we will then provide you with a return
authorization number.
Do not return the LM-SD without an authorization number.
If the product is out of warranty, we will provide a repair estimate and then complete the
repairs after your approval.

Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: [phone] Fax: [phone] Email: [email protected]
P a g e | 16
7. LM-SD Enclosure Dimensions
Figure 7.1: LM-SD Enclosure and Mounting Bracket Dimensions
