logika WL-ZSPWBPWBPW-PI11-04 User manual

© 2019 Logika Limited
Smart Retina Lock
WL-ZSPWBPWBPW-PI11-04
Product Manual
Version 1.0

1
Logika Limited
E
-Centre, Massey University, Gate 5, Oaklands Road
Albany, Auckland 0632, New Zealand
www.logika.nz
·[e-mail]
Introduction
Thank you for choosing Logika. Please take a moment to carefully read through the manual to
ensure safe and proper installation and use.
•Before use, the product must be properly installed as described in this manual by a qualified
technician.
•The product should be used with the supplied accessories.
•Do not disassemble or modify the product.
•Logika is not responsible for any loss due to improper installation or use of this product.
•Please visit our official website at www.logika.nz for more information.
•You can also contact us at the following email address: [e-mail].

2
Packing List
No. Item Name Quantity
1 Front Plate 1
2 Back Plate 1
3 Lock Body 1
4 Accessories Package 1
5 User Manual 1
6 Hole Drilling Template 1
7 Pencil 1
8 Warranty Card 1
9 Key 3
10 Magnetic Card 3
11 Door Frame Box 1
12 Strike Plate 1

3
Device Layout
Back Plate Front Plate
Bottom Profile
Keyhole
Emergency Power
Micro USB Port
LCD Screen
Touch Screen
Doorbell
NFC Sensor
Factory
Reset
Button
Fingerprint
Sensor
Leave
Home
Button
Double Lock Knob
PIR Motion
Sensor
Camera
Microphone

4
12
14
13
10
11
2
3
1
4
7
8
9
6
5
1. Front (outside facing) unit (1pc)
2. φ8 Connecting bolt (short) (1pc)
3. Key link strip (1pc)
4. Φ6 Connecting bolt (1pc)
5. Lock Body (1pc)
6. Lock body screw (4pcs)
7. Large square spindle (1pc)
8. Square spindle (Double Lock) (1pc)
9. Square spindle spring (1pc)
10. Link plate (1pc)
11. Countersink screw (2pcs)
12. Back (inside facing) unit (1pc)
13. Pan head crew (2pcs)
14. AA battery (8pcs)
15. Battery cover (1pc)
16. Screw cap (1pc)
17. φ8 Connecting bolt (long) (1pc)
15
16
17

5
Features
•Communication Mode: IEEE 802.15.4 Zigbee.
•Smart Doorbell to notify users of visitors.
•Smart night-vision camera with intercom, allows users to see who's at the door remotely
and communicate with them.
•When people approach and linger longer than a pre-set time the camera will take video
recording, and push warning message to the mobile app.
•One-button control to activate/deactivate household smart devices and enable home
security.
•Integrated with fingerprint and NFC door unlocking methods.
•Support different account permissions: Users can assign passwords to visitors remotely and
make restrictions on when and how many times it can be used.
Specifications
Product Name Smart Retina Lock
Colour Silver
Unlock Method Fingerprint/Passcode/Mobile App/Key
Fingerprint Identification Semiconductor capacitor scanning
False Rejection Rate < 0.1%
False Acceptance Rate < 0.001%
User Capacity 60
Each User 6 fingerprints, 1 passcode
Battery 8x AA – life expectancy 12 months (avg 10 access per day)
Emergency Power Micro USB
Standby Current < 40 μA
Working Current < 400 mA
Operating Temperature -20 ℃ ~50 ℃
Operating Humidity 15~90%RH
Plate Material Zinc Alloy + ABS Silver
Plate Craft Electric plating/Baking varnish
Body Material 304 Stainless steel
Body Craft Die-cast/Electric plating

6
Preparation Before Installation
Prior to installing the door lock, you need to determine the opening direction of the door, as there
are some adjustments that may need to be made to the lock body, door handle orientation and the
spindle rotation direction. Don’t worry if you get it wrong, as it’s easy enough to remove the lock
from the door and re-adjust, if necessary.
Determine Door Opening Direction
There are four possible opening directions of a door. In our case, we want to view the door from the
outside, looking in, and use this as our reference point for determining the opening direction.
The first two diagrams, then, are with the door with the hinge on the RIGHT side as we look inwards.
The opening directions are Right Outward and Right Inward, respectively.
RIGHT OUTWARD
RIGHT INWARD
The next two diagrams have the hinge on the LEFT side. The opening directions are Left Outward and
Left Inward, respectively.
LEFT OUTWARD
LEFT INWARD
Once you’ve determined which direction your door is opening, proceed to make adjustments to the
door mechanisms.

7
Fittings for the Different Door Opening Directions
The Smart Retina Lock components will need to have some adjustments made to cater for the
different opening directions of the door. The diagrams below illustrate the basics before we delve
into the details of the adjustments.
RIGHT OUTWARD OPENING
RIGHT INWARD OPENING
Bevel faces
towards
inside
Bevel faces
towards
outside
Triangle faces
towards outside
Right-handed
plate
Triangle faces
towards outside
Right-handed
plate

8
LEFT OUTWARD OPENING
LEFT INWARD OPENING
Bevel faces
towards
inside
Bevel faces
towards
outside
Triangle faces
towards outside
Left-handed
plate
Triangle faces
towards outside
Left-handed
plate

9
Door Latch Adjustment
Having determined the door opening direction and what needs to be adjusted, you may first need to
adjust the direction of the door latch on the lock body, so that it will engage correctly when the door
closes.
The rule of thumb here is quite simple. Simply rotate the door latch so that its bevel (curved bit)
points in the direction of the door frame, once it is fitted into the door. The following procedure
outlines how to do this.
1) Remove the screw by the door latch with a Philips screwdriver (Fig. 1).
2) Rotate the Cam Lock with a slotted screwdriver to open the deadbolt (Fig. 2).
3) Pull out the door latch and rotate it (Fig. 3).
4) Push the door latch back and tighten its screw.
5) Rotate the Cam Lock back to retract the deadbolt.

10
Lock Body Adjustment
Depending on the door opening direction, you may need to switch the direction of the Lock Body for
left and right swinging doors, by making adjustments to the spindle clutch.
1) Remove the screw for switching the clutch direction with a Philips screwdriver (Fig. 1).
2) Remove the Inside and Outside Handle Spindlesand swap them around (Fig. 2).
3) Check to see if the Inside Handle Spindle is installed in the right place (See the mark in Fig. 3).
4) Tighten the screw for switching the clutch direction.

11
Door Handle Orientation
Depending on the door opening direction, you may need to rotate the handles on the front and rear
plates of the door unit. The procedure below explains how to do this.
1) Using a Philips screwdriver, remove the
screw holding the handle in place, as
shown.
2) Rotate the handle 180 degrees clockwise
and tighten the screw again.
3) Rotate the handle to check it works
normally.
4) Repeat the above for the other side (inside
door unit).

12
Installing the Door Lock
Installing the Lock Body
1) Measure the point where you wish to
place the lock template – Typically,
1000mm to 1200mm from the bottom
and 60mm from the edge of the door.
2) Mark this point.
3) Place the supplied template to line up
the marker with the reference mark on
the template.
4) Mark out all the holes according to the
template. This is where you will be
drilling.
5) Remove the template, once everything
has been marked.
6) Drill the holes accordingly.

13
7) Insert the Lock Body and make sure all
the holes line up.
8) Screw the Lock Body in place. It’s now
ready for the attachment of the front
and rear door lock plates.

14
Installing the Front Plate
1) Install the connecting bolts, spindles and
key link strip.
2) Align the front plate to the holes in the
door.
3) Affix the front plate to the door making
sure the cables are pulled through the hole.
4) Turn the handle to make sure the rotate as
expected. Turn the key on the bottom to
make sure the door latch operates as
expected.

15
Installing the Back Plate
1) Connect the cables.
2) Install the square spindle (back plate).
Make sure this aligns with the double
lock knob which should be vertical.
3) Affix the back plate to the door with
the two screws as shown.
4) Rotate the handle to make sure the
door latch works as expected and
rotate the lock knob to check if the
double lock engages.

16
Adding the Device to the Smart Home Network
Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the
Logika Smart Mobile App user guide which will take you through the process of adding smart
devices to the system.
Refer to the information below to locate the device in the Device Add screen. Once selected, the app
will walk you through how to add the device to the system.
Device Category:
Smart Lock
Device Name:
Retina Lock
Note: The default admin passcode is 123456. Enter this on the keypad when requested, followed by
the #key.
If this code does not work, you may need to perform a factory reset. This can be done by pressing
the Factory Reset button, the hole for which is located below the battery compartment. You will
need a small pin or paperclip to reach the button and keep it pressed it for 10 seconds.

17
User Administration and Security
Entering Admin Mode
1) Tap the touchpad screen to wake it up.
2) Tap the *key twice in quick succession.
3) Enter the admin code (Default is 123456) followed by the #key.
4) The display will now show you some admin options that you can use.
Note: Don’t forget to change the Admin passcode from the default for complete security!
Set Time
Once the door lock is connected to the Smart Home system (as described previously), the time will
be synchronised with the Gateway automatically. However, you can adjust the time manually by
following the prompts below.
Smart Home Settings
The prompts below illustrate the options for adding to and removing from the Smart Home system.
Change Language

18
Add New User
1) Select Add User.
2) Select the type of user you wish to add.
3) Enter a username (up to 5 characters).
4) Type the passcode (6 digits) and/or start fingerprint recognition and/or NFC programming.
Delete User
Note: Delete All deletes all data relating to that user – passcode, fingerprint and NFC access.
Edit Users

19
Set Always-Open (Unlocked) Mode
This setting disables the security on the door lock, so that anyone can gain access without having to
type a passcode, use fingerprint identification or NFC card.
To disable this, after it’s been set, simply enter your passcode, fingerprint or NFC card.
Enable Double Authentication
This can be enabled to force each user to use two methods of authentication before they gain
access. For instance, they would need to enter a passcode and fingerprint, fingerprint + NFC card or
NFC card + passcode.
Enable Dual-User Authentication
In this mode, two users must authenticate before access is granted. Once the first user is
authenticated, the second user must do the same, with their passcode/fingerprint/NFC card within
10 seconds.
