logika Wulian WL-ZSSWBPW-TH-01 User manual

© 2019 Logika Limited
Smart Gas Detector
WL-ZSSWBPW-TH-01
Product Manual
Version 1.0

1
Logika Limited
E
-Centre, Massey University, Gate 5, Oaklands Road
Albany, Auckland 0632, New Zealand
www.logika.nz
·[e-mail]
Introduction
Thank you for choosing Logika. Please take a moment to carefully read through the manual to
ensure safe and proper installation and use.
•Before use, the product must be properly installed as described in this manual by a qualified
technician.
•The product should be used with the supplied accessories.
•Do not disassemble or modify the product.
•Logika is not responsible for any loss due to improper installation or use of this product.
•Please visit our official website at www.logika.nz for more information.
•You can also contact us at the following email address: [e-mail].

2
Device Layout
Arrow Label
System
Indicator Light
Mains Power
Connectors
Multi-Function Button
Main Body Front
Main Body Back

3
Features
•Communication Mode: IEEE802.15.4 Zigbee.
•Can be linked to the other devices, like the Smart Automatic Manipulator and Sound
Warner.
•Strong anti-interference ability, low false alarm rate.
•Automatic adjustment of sensitivity.
Specifications
Communication Method IEEE 802.15.4 ZigBee
Antenna Type PCB Antenna
Power 100-240V AC, 50/60Hz
Max Power Consumption <5W
Standby Power Consumption <3W
Alarm Decibel >80dB @ 1m
Communication Distance 300m (depend on specific environment)
Alarm Concentration 9% LEL ±1%
Detecting Gas Type Natural Gas, Liquefied Gas
Detecting Method Catalyst Contact Combustion Type Sensor
Overall Size (Diameter x Thickness) 98×45 (mm)
Material & Colour PC, White
Working Temperature -10°C to +45°C
Working Humidity ≤95% RH (Noncondensing)
Installation Method Sidewall Type
Flame Retardant Rating UL94V-0
Net Weight 115g
Storage Temperature -20°C to +60°C

4
Installation Steps
Hardware Installation
Due to the way this Gas Detector works, it is recommended that you install the device on a wall
(wall-mounted method). In this vertical orientation it is more efficient at detecting the movement of
the airflow/gases. The Smart Gas Detector requires a mains supply to operate, so please make sure
that the cables are in place at the location you wish to mount the device.
Some things to bear in mind, prior to installation:
•The Smart Gas Detector must be installed in a room where there’s a possibility of a gas leak
to be most effective.
•Do not install too close to the stove, due to any steam from cooking.
•Do not install near an extractor fan, as this will affect detection efficiency.
•Do not install anywhere damp, like the bathroom.
•Vibrations can cause issues, so keep away from fridges and washing machines.
Install Option 1
1) Turn of the main supply before you begin!
2) Mark out the two screw locations using the supplied template, then drill the holes with a
5mm drill bit.
Screw Locations

5
3) Insert the wall plugs and attach the Wall-Mounted base using the supplied screws. Feed the
mains cables through the hole in the base.
4) Connect the main cables to the Smart Gas Detector connection points and attach the device
to the base by lining up the slots on the Smart Gas Detector to the hooks on the base. Turn
clockwise to lock them together. Make sure the arrow label on the front of the device is
pointing upwards.
5) Switch on the main supply. Installation is now complete.
Connect Mains
Supply

6
Install Option 2
This install option is similar to Install Option 1 but for situations where the cable can only be fed in
from the side. However, rather than using the Wall-Mounted Base, we will be using the Ceiling-
Mounted Base with the spring mounts removed.
1) Remove the spring mounts from the Ceiling-Mounted Base and place on the wall to mark off
the drill holes.
2) Drill the holes (5mm) and insert the wall plugs.
3) Screw in the base to the wall, feeding the mains cable through the side, as shown.
4) Connect the main cables to the Smart Gas Detector connection points and attach the device
to the base by lining up the slots on the Smart Gas Detector to the hooks on the base. Turn
clockwise to lock them together. Make sure the arrow label on the front of the device is
pointing upwards.
5) Switch on the main supply. Installation is now complete.
Once the hardware installation is complete, you will need to follow the instructions in Adding the
Device to the Smart Home Network along with the Logika Smart Mobile App user manual to add
the device to the system.
You can then set up a Housekeeper (Linkage) Task to listen for an alarm condition and either sound a
Smart Sound Warner device and/or turn off the gas using a Smart Valve Manipulator.
Torsion Spring Location

7
Adding the Device to the Smart Home Network
Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the
Logika Smart Mobile App user guide which will take you through the process of adding smart
devices to the system.
Refer to the information below to locate the device in the Device Add screen. Once selected, the app
will walk you through how to add the device to the system.
Device Category:
Security
Device Name:
Flammable Gas Detector

8
Device Functions
When the device is first powered on, it will normally automatically attempt to connect to the Zigbee
Smart Home network. The System Indicator light will flash as it’s searching for the network. If it
connects, the light will remain on for 2 seconds and then go out.
If this does not happen, you can manually connect via the mobile app and follow the instructions
below.
Join the Zigbee Network
Press the Multi-Function Button 4 times in quick succession. The System Indicator light will start
flashing, signifying it’s searching for the network.
When it successfully connects, the System Indicator light will stay solid for 2 seconds then go out.
Quit the Zigbee Network
Long press the Multi-Function Button for 6 seconds. The System Indicator light will flash 4 times and
go out. The device has now been successfully removed from the network and been reset to the
factory defaults.

9
Safety Precautions
• Disable any power prior to connecting the device to the main supply.
• The device must be installed by a qualified electrician.
• Do not disassemble or refit this product or its accessories.
• The device should be mounted in a dry environment. It is not designed to be used
outdoors.
• Do not use any household sprays near the device as this could give a false alarm.
• Do not smoke near the device as the smoke can set the alarm off.
• Do not install while decorating or make sure it is off when you do! The paint odour can
set off the alarm.
• When cleaning, do not use any detergent or spray. Just wipe with a damp cloth.

10
Troubleshooting
The device cannot be added to the Zigbee network.
The device may be registered to another network. In rare occasions this can happen if the device
was not removed from the test network at the factory.
Perform the Quit the Zigbee Network procedure mentioned in Device Functions section to clear this
setting. You should now be free to add the device to the local smart network.
The issue you are experiencing is not mentioned here.
Please contact us at [e-mail] with your issue and we will do our utmost to help!
