Logitech Keyboard Folio User manual

Setup Guide | Guide d’installation
Keyboard Folio

Logitech Keyboard Folio
2
Contents
English. . . . . . . . . . . . . . . . . . 3 Français . . . . . . . . . . . . . . . . 12
www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Logitech Keyboard Folio
English 3
Know your product
1. iPad holder
2. Protective folio
3. Function keys
4. Keyboard
5. Bluetooth and battery
status light
6. Bluetooth
connect button
7. On/o switch
8. Micro-USB
charging port
9. Micro-USB
charging cable
10. Product documentation
Setup Guide | Guide d’installation
Keyboard Folio
5
1
2
4
3
6
7
8
9
10

Logitech Keyboard Folio
4 English
Setting up the keyboard folio
Getting started
1. Open the keyboard folio and insert
your iPad in the iPad holder:
2. Move the iPad holder into the typing
position (see “Using the keyboard folio”).
Establishing connection with your
iPad
The keyboard folio links to your iPad via
a Bluetooth connection. The first time
you use the keyboard folio, you must pair it
with your iPad:
1. Turn on the keyboard:
The status light blinks blue to indicate
that the keyboard is discoverable,
ready for pairing with your iPad.
The first time you turn on the keyboard
it remains discoverable for 15 minutes.
If the status light turns red, charge
the battery. For more information,
see “Charging the keyboard battery.”

Logitech Keyboard Folio
English 5
2. On your iPad:
•Make sure your iPad’s Bluetooth
feature is on. Select Settings >
Bluetooth > On.
•Select “Logitech Keyboard Folio”
from the Devices menu.
3. If your iPad requests a PIN, enter it using
the folio keyboard (not on your iPad).
When successful connection is made,
the status light turns solid blue for
a short time, and then turns o.
Connecting to another iPad
1. Make sure the keyboard is turned on.
2. Make sure your iPad’s Bluetooth feature
is on. Select Settings > Bluetooth > On.
3. Press the Bluetooth Connect button:
The keyboard is discoverable
for 3 minutes.
4. Select “Logitech Keyboard Folio”
on your iPad’s Devices menu.
5. If your iPad requests a PIN, enter it using
the folio keyboard (not on your iPad).
When successful connection is made,
the status light turns solid blue for
a short time, and then turns o.

Logitech Keyboard Folio
6 English
Storing your iPad for travel
1. Insert your iPad in the iPad holder.
2. Close the keyboard folio:
Using the keyboard folio
Two viewing positions
The keyboard folio provides two viewing
positions—one for typing and another
for browsing.
To type, move the iPad holder into the
typing position, aligning it with the built-in
magnet to secure it. Turn on the keyboard:
To browse, place the iPad holder in
the browsing position remembering
to switch o the keyboard to conserve
battery power:
If you don’t use the keyboard for a while
in the typing position, it enters sleep mode
automatically. Pressing any key wakes it.
Typing position
Browsing position

Logitech Keyboard Folio
English 7
Status light indicators
Bluetooth and battery status light
Light Description
Blinking green The battery is charging.
Green The battery is charged (more than 20%).
Red Battery power is low (less than 20%). Recharge the battery.
Blinking blue The keyboard is ready for pairing or is trying to reconnect
to your iPad.
Solid blue Bluetooth pairing or reconnection is successful.

Logitech Keyboard Folio
8 English
Function keys
Home = iPad Home screen
Fn + 1 = Lock screen
Locks or unlocks the iPad screen
Fn + 2 = Siri
Use your voice to send messages,
make calls, schedule meetings,
and more
Fn + 3 = Search
Launches the iPad search function
Fn + 4 = Switch language
Switches the keyboard language
Fn + 5 = Virtual keyboard
Shows/hides the virtual keyboard
Fn + 6 = Slide show
Fn + 7 = Previous track
Fn + 8 = Play/Pause
Fn + 9 = Next track
Fn + 0 = Mute
Fn + dash = Volume down
Fn + plus = Volume up
Fn + X = Cut
Fn + C = Copy
Fn + V = Paste
Fn + Left cursor = Select left
Selects text on the left,
word by word
Fn + Right cursor = Select right
Selects text on the right,
word by word
Fn + Spacebar =
Switch applications
Notes:
• To select a function key, press and hold the Fn key, and then press the key indicated above.
• Siri is not supported on iPad 2 or earlier versions.

Logitech Keyboard Folio
English 9
Charging the keyboard battery
If the status light is red the keyboard folio
battery needs to be charged.
1. Plug one end of the micro-USB cable
into the charging port, and the other end
into a USB port on your computer.
The status light blinks green as the
battery charges.
Note: Please note the power input max is 5V,
500mA, if you use an alternative charging
solution.
2. Charge the battery until the status light
turns solid green.
Battery information
•A fully charged battery provides about
three months of use when the keyboard
is used about two hours a day.
•Charge the battery if the status light
turns red briefly after the keyboard
turns on.
•When not in use, turn o the keyboard
to conserve battery power.
•The keyboard enters sleep mode
automatically if not used for a while
in the typing position. Press any key
to wake it.
USB

Logitech Keyboard Folio
10 English
Battery disposal at product
end of life
1. Pry o top cover of keyboard
with screwdriver.
2. Detach battery from circuit board
and remove battery.
3. Dispose of your product and its battery
according to local laws
Visit Product Central
There’s more information and support
online for your product. Take a moment
to visit Product Central to learn more about
your new keyboard folio.
www.logitech.com/support/keyboardfolio
Browse online articles for setup help,
usage tips, and information about
additional features.
Connect with other users in our Community
Forums to get advice, ask questions,
and share solutions.
Find a wide selection of content including:
•Tutorials
•Troubleshooting
•Support community
•Online documentation
•Warranty information
•Spare parts (when available)
