Lombardi LS1000P User manual

AMPLIFICAZIONI
LS1000P
www.amplificazionilombardi.it
manual

AMPLIFICAZIONI
Potentially dangerous situations can occur and cause
personal injuries.
Potentially dangerous situations can occur and cause
damage to the equipment.
Potentially dangerous situations can occur and cause
the equipment malfunction.
manual references
www.amplificazionilombardi.it
WARNING !
symbols
WARNING !
electric voltage equipment
LS1000 P manual
Version 1.2, 18/05/2017
© by Lombardi Amplificazioni all right reserved.
The data in this manual were precisely controlled, however their accuracy
cannot be guaranteed. Lombardi Amplificazioni takes no responsibility for any
errors or imprecisions in this manual or about the products to which it refers.
As a manufacturer we reserve the right to modify the products under the law
provisions in order to improve the quality.
Amplificazioni Lombardi
via G.Mengozzi 21/b, cap.47011 Castrocaro Terme (FC) ITALY
Telephone - fax [phone]
E-mail: [email protected]
general information
LS1000P

AMPLIFICAZIONI
Please read the manual carefully and observe the
precautions to prevent and to avoid damages to the
equipment, before using the products of Lombardi
Amplification.
Please keep this manual for future references.
precautions for use
www.amplificazionilombardi.it
WARNINIG !
information on the usage of the speakers
Do not stand nearby speakers with the volume turned
up. The loudspeakers system can cause a sound
pressure level damaging to health, especially in case of
long lasting exposures. WARNING! The speakers exert
a static magnetic field even when they are connected
or in use. Therefore make sure during assembly and
transport, that they are not nearby things or devices that
can be damaged by an external magnetic field.
Use the proper fasteners and accessorizes (hook, eyelet,
snap-hook, small chains) and follow the instructions to
avoid potential personal injury or property damage.
All the screw, the fasteners and the accessorizes must
be checked periodically.
LS1000P

AMPLIFICAZIONI
Passive Subwoofer with bass reflex system and 4 speakers 12", in isobaric
configuration. The subwoofer is an high quality and compact product with a
good power for dimensions, our advice is to pilot it with an amplifier of at least
1000 / 1200 W RMS on 2 Ohm. The warm sound and the high sound pressure
makes this subwoofer unique. The subwoofer is ideal for enclosed spaces
and small open-air places, when combined with the satellites LV100P,
LV250PB, LV250A, LVR600BP, LVR1200BP.
subwoofer cinema / surround system
subwoofer front stage
subwoofer pub / club / squares
subwoofer nightclub
subwoofer live music
rated impedance
maximum power (dB)
power 1W with 1mt (dB)
speakers
dimensions (DxHxW)
weight (kg)
Use
2 Ohm – passive subwoofer
138 dB SPL 1mt in free field
2 Ohm: 93,1 dBA
4 woofer 320mm 12" in isobaric configuration
54x76x62 cm
47
characteristics
www.amplificazionilombardi.it
LS1000P

AMPLIFICAZIONI
frequency response
resonant frequency
maximum power
maximum power (dB)
power 1W with 1mt (dB)
speakers
cut-off frequency
input
technical specifications
pagina 5 di 8
www.amplificazionilombardi.it
25 - 145 Hz
30 Hz
1200W RMS / 1400W peak
138 dB SPL 1mt in free field
2 Ohm: 93,1 dBA
4 suspended woofer made with canvas with nomex
and cellulose membrane 8 Ohm – 320mm 12" -
450W RMS – parallel wired – in isobaric
configuration – bob. 64
adviced 113 Hz 12 dB/oct
panel speakon
cabinet
material
finish
description
handles
support feet
poplar plywood
black scratch proof spray coating waterproof
metal protection with grille and open cell acoustic
foam
2 side handles
rubber feet
LS1000P

AMPLIFICAZIONI
www.amplificazionilombardi.it
pagina 6 di 8
in the rear panel of the passive loudspeaker LS1000P
there is a SPEAKON.
input:
female SPEAKON connector for panel
1+ +
1- -
2+ nc
2- nc
inputs and connections
LS1000P
SPK 1+
1-
2+
2-
IN
+
-
+
-+
-
+
-+
-

AMPLIFICAZIONI
cabinet dimension in mm [inch]
www.amplificazionilombardi.it
front unde
pagina 7 di 8
side
LS1000P
760 [29,92]
540 [21,26]
handles
540 [21,26]
540 [21,26]
540 [21,26]
760 [29,92]

AMPLIFICAZIONI
This device is in conformity with the requirements of the relevant
European Community directives with regard to the European
Electromagnetic Compatibility Directive (EMC) 89/336/EC as
amended by Directives 92/31/EC and 93/68/EC and the Low
Voltage Directive (LVD) 73/23/EC as amended by Directive
93/68/EC.
This device is in conformity with the European directive 2002/95/EC
as amended on the restriction of the use of certain hazardous
substances in electrical and electronic equipment.
Under Directive WEEE 2002/96/EC as amended by Directive
2003/108/EC this device is marked with a crossed-out wheeled
bin, as shown below. “INFORMATION TO USERS: In accordance
with article 13 of the Legislative Decree No 151 of 25 July 2005,
2002/95/EC and 2002/96/EC on the restriction of the use of certain
hazardous substances in electrical and electronic equipment and
of the waste disposal.
The symbol of the crossed-out wheeled bin indicates that the
product at the end of its useful live should be collected separately
from all other waste. The user should bring the end-of-life
equipment to the appropriate waste collection center of electrical
and electronic equipment, or deliver it
to the retailer when they buy a new equivalent equipment, at the
ratio of one to one. Separate collection of waste followed by its
proper treatment and proper waste disposal can greatly improve
environmental
and health protection and promote the recovery and recycling of
the materials of the equipment.
Illegal waste dumping shall lead to the application of the
administrative penalties provided for in Legislative Decree No
22 /1997”.
European Community directives
www.amplificazionilombardi.it
LS1000P
made in Italy
