LONCIN LC2500-J User manual

Thank you forpurchasingour generatorset(hereinafterreferredtoasagenerator).
The copyrightoftheManual isreservedtoourcompany.
Nopartofthis publication maybereproduced,transmitted,distributedorstoredwithout
priorwritten permission ofour company.
Ourcompanys EnglishnameanditsChinesetranslation are thebrandorregistered
trademarkofour company.
Ourcompanyadheres toastrategyof sustainabledevelopment, sowereservethe
righttomakechanges orimprovements withoutnoticetoanyproduct describedinthis
publication.
This manualshouldbeconsideredapermanentpartofthegeneratorandshould
remainwithitifitisresold.
This manualcontainstheinformation abouthowtousethegeneratorcorrectly,please
read it carefullybefore operating the generator.Safeandcorrect operationofthe
generatorwill giveyou thebestresults.

SafetyWarnings
Personalsafetyand propertysafetyof youandothersarevery
important. Wehaveprovidedthreekinds of safetymessagesinthis
manual andon thegeneratorlabels.Eachsafetymessageisprecededbyasymbol .
Pleasereadthesemessagescarefully.
You WILLbeSERIOUSLYHURT ifyoudont followinstructions.
YouCANbe SERIOUSLYHURTifyou don tfollowinstructions.
You CANbe HURT ifyou dontfollowinstructions.
Your generatororotherpropertycouldbedamagedifyou don tfollow
instructions.

CONTENTS
1.SAFETYINSTRUCTIONS................................................... ..................................................1
2.COMPONENTIDENTIFICATION...........................................................................................3
3.CONTROLS......................................................................................................................4
1) EngineSwitch...........................................................................................................…….4
2) RecoilStarter........................................................................................................……..4
3)FuelCock........................................................................................................................4
4) Choke Lever..................................................................................................................... 5
5) OvercurrentProtector....................................................................................................... 5
6)Ground Terminal..............................................................................................................6
7) OilAlertSystem.....................................................................................................…6
4.GENERATORUSE...............................................................................................................7
1)ConnectionstoaHomePower Supply...........................................................................7
2)GeneratorGroundCircuit................................................................................................8
3)ACApplications..............................................................................................................8
4) DC Applications..............................................................................................................9
5) High AltitudeOperation.................................................................................................. 10
5.PREOPERATIONCHECK................................................................................................... 11
1) EngineOil.................................................................................................................11
2)Fuel............................................................................................................................11
6.STARTING THE ENGINE.....................................................................................................13
7. STOPPING THE ENGINE....................................................................................................13
8.MAINTENANCE................................................................................................................... 14
1) Engine Oil Change..................................................................................................15
2) AirFilterService......................................................................................................15
3)FuelSedimentCup.....................................................................................16
4)SparkPlug....................................................................................................................16
9.STORAGE..........................................................................................................................18
10.TROUBLESHOOTING.......................................................................................................19
11.WIRING DIAGRAM...........................................................................................................20
12.Parameters.......................................................................................................................22

SAFETYINSTRUCTIONS
1
1.SAFETYINSTRUCTIONS
Read andunderstand thisowners manual beforeoperating your generator. Itwill help
youavoidaccidents ifyouget familiarwithyourgenerator s safeoperationprocedures.
Neveruse itindoorsNever useitinawetcondition
Never directlyconnectitto ahome
power system
Keepitatleast1m away from
Inflammables

SAFETYINSTRUCTIONS
2
Neversmoke whenfueling
Don’tspill whenfueling
Stop theenginebeforefueling

COMPONENTIDENTIFICATION
- 3-
2. COMPONENT IDENTIFICATION
Modelandserial
number
Oildipstick
Fueltankcap ACreceptacle
Fueltank
Startergrip
Flameout
switch
DC
overcurrent
protector DC output
terminals
Overcurrent
protector
Voltage
meter
Airfilter
Muffler

CONTROLS
-4-
3CONTROLS
1) EngineSwitch
2) RecoilStarter
Gentlypullupthestartergripandpullitoutbrisklywhen aresistanceisfelt.
Don tletthestartergripspring backabruptlyafterstarting;the starter
grip shouldbeletbackgently.
3) Fuel Cock
Fuel cockisforcontrollingfuelflowfromfueltanktothecarburetor.Ensure fuelvalveis
in the OFF position after stoppinghe engine.
Engineswitch
OFF
ON
Fuelvalve
ON
OFF
Startergrip
LC2500-J Start switch LC6500-J Start switch
ON
OFF
Engine switch

CONTROLS
- 5-
4) ChokeLever
The chokeisusedtoprovideanenriched fuel mixturewhen startingacoldengine.Put
chokelever intheONposition whenthe engine haswarmed up.
5) ACOvercurrentProtector
Whenthereis aprobleminthe loador awrongconnection, theAC circuit willbe
overloaded,andthe ACovercurrentprotectorwill automaticallydisconnect the circuitto
protectit.
Whentheindicatorinside ACovercurrentprotectorpopsup,itmeansACovercurrent
protectorisinthe OFF position. Afterseveralminutes, pushthe protectorsbuttontolet
theprotectorback tothe ONposition.
ON
OFF
Chokelever
OFF
ON

CONTROLS
-6-
6) Ground Terminal
The ground terminalisadedicatedterminal forreliablygroundingthe wholegenerator.
7) Oil AlertSystem
The oilalert systemisdesignedtoprevent enginedamage causedbyan insufficient
amountofoil inthe crankcase.Before theoillevel inthecrankcasecan fallbelowa
safelimit, theoil alertsystemwill automaticallyshutdowntheengine(theengine
switchwillremaininthe ON position)toavoiddamagetotheengine.
Ground
terminal

GENERATORUSE
- 7-
4. GENERATOR USE
Requirements of generatoruseconcerningtheenvironment
Applicableambienttemperaturerange:-15°C~40°C.
Applicablehumiditylevel:below95%.
Applicablealtitude:under3,300feet(1,000m)abovesealevel;foraltitudes over
3,300 feet(1,000m)abovesea level,lower power ratingisneededforoperation).
1) Connectionsto aHome PowerSupply
Ifthegenerator istobeconnected toahomepowersupplyas a
standby, connection shall beperformedbyaprofessional
electricianorbyanotherperson withproficientelectricalskill.
Whentheloadsareconnectedtothegenerator, please carefullycheck whether
electricalconnectionsaresafeand reliable. Anyimproperconnection maycause
damagetothegenerator,or cause afire.
Good Prohibite
Good

GENERATORUSE
-8-
2) Generator Ground Circuit
Inordertoprevent electric shock duetoshoddyelectricalappliances orwronguseof
electricity,the generatormust be grounded withagood-qualityinsulated conductor.
3) ACApplications
Beforestartingthe generator,itmust be confirmedthatthetotal ofallloads power
valuesdoesntexceedthegenerators ratedpower.
Overloadusewill remarkablyshortenthegenerator’sservice
life.
If thegeneratorisconnectedtomultipleloads or electricity consumers, please
remembertofirstconnecttheonewiththehighest starting current, thenthe onewith
thesecondhighest startingcurrent... and lastconnecttheonewiththe lowest starting
current.
Groundterminal

GENERATORUSE
- 9-
Generally,capacitiveand inductiveloads, especially motor driven deviceswill generate
averyhighstartingcurrent. Thefollowingtableservesasareferenceforyour
connectingthegeneratortotheelectricityconsumersasshownin thetable.
4) DCApplications
DCterminals
DCterminalsare for supplyingpower tolow-power DC loads,orchargingother
batteries.PositiveDCterminalsare coloredred,and negativeonesarecolored black.
Connecting loads:Connectthe load spositivepole topositiveDCterminal;connect the
loadsnegativepoletonegativeDC terminal.
ON
OFF
Wattage Example
Type Starting
Rating
Typicaldevice Device Starting
Rating
●
Incandescent
lamp
●Heating
device
X1 X1 Incandescentlamp
TVset
Incandescent
lamp
100W
100VA
(W) 100VA (W)
●Fluorescent
tube X2 X1.5
Fluorescenttube
40W
Fluorescenttube
80VA
(W) 60VA (W)
●Motor
driven device
X3～5
X2
Refrigerator
Electric
fan
Refrigerator
150W
450～
750VA
(W）
300VA
(W)
DCovercurrent
protector
Positive(red) Negative(black)

GENERATORUSE
- 10-
DCovercurrentprotector
Whenthereisaproblemintheloadorawrong connection,theDCcircuit willbe
overloaded,andtheDC overcurrentprotectorwill automaticlydisconnectthecircuitto
protect it.
WhentheindicatorinsideDC overcurrentprotectorpopsup,it meansDC overcurrent
protectorisin theOFF position. Afterseveralminutes, pushtheDC protectorsbutton
toletit back tothe ONposition.
5) High AltitudeOperation
Athighaltitudes,thestandardcarburetorair-fuelmixturewillbe excessivelyrich.
Power outputwill decrease,andfuelconsumptionwillincrease.High altitude
performancecan beimproved byinstalling asmaller diametermainfueljet in the
carburetorandreadjustingthepilotscrew. Ifyoualways operatethegeneratorat
altitudeshigherthan 3,300feet(1,000meters)abovesealevel,haveagenerator
dealerauthorizedbyour companyperformthiscarburetor modification;orthe
generatorshouldbeusedwithlowered powerrating.
Even withsuitablecarburetorjetting, enginepower will decreaseapproximately3.5%
foreach1,000 feet(300meter)increasein altitude.The effect ofaltitude onpower will
be greaterthanthisifnocarburetor modificationismade.
Ifanenginejetted for high altitudeisusedataloweraltitude, the
leanair fuelmixturewill reduce performanceand mayover-heat
and seriouslydamagetheengine.

GENERATORUSE
- 11-
5. PREOPERATIONCHECK
1) EngineOil ChecktheoillevelBEFOREEACHUSE withthegenerator on a
levelsurfaceand withtheenginestopped.
Engineoilisamajor factoraffectingengineperformance and servicelife.
Non-detergentand2-stroke engineoils
willdamagetheengineand arenot
recommended.
Recommendedengineoil
Four-strokegasolineengineoil
SE orSFgradeunder APIclassification,or
SAE10W-30thatisequivalenttoSGgrade.
Oilchecksteps:
Removetheoil dipstick from the oilfiller
holeandwipeitclean; Insertthedipstickwithoutscrewing itintighttocheckthe engine
oil level.
If the engineoillevelistoolow, addrecommendedengine oiluntil oil level reachesthe
upperlimit;
After addingoil,remembertorescrewin
and tighten theoildipstick.
2) Fuel
○1.Loosenfueltankcaptocheckfuellevel.
○2.Iffuellevel istoolow, addfueluntil fuel
Level reachesthe red markonthetopof
fuelfilter.
○3.Reinstallandtightenfueltank capafter fueling.
Oilupper
limit
Oildipstick
Oillowerlimit
Loosen Tighten
Fueltankcap
Fuelupperlimit

GENERATORUSE
- 12-
·Fuelling must beperformedinaplacewithgood ventilation whentheengine
has stopped. Remember:neversmokeorlightafire.
·Never spillthefuel outwhenfueling
·Avoidlong or frequentcontactwithfuelor inhalation offuelvapor.
Never letchildrencontactfuel.
Never use oil-fuel mixtureor gasolinewith impurities.
The gasolinesoctane valueshould be90orhigher.
Unleadedgasolineis recommendedbyus becauseitproducesless carbon depositon
theengineand spark plug,andcanprolong servicelifeofthe exhaust system.
Never uselong aged gasoline,contaminatedgasoline orgasolinemixed withengineoil.
Never letdustor waterintothefueltank.

STARTING/STOPPING THEENGINE
-13-
6. STARTING THEENGINE
1) Manualstarting
○
1.Cutoffallloads from theoutputend.
○
2. Turnthe fuelcock totheONposition.
○
3. Put thechokelever in theOFF position.
Donot shutoffthechokeif theengine isstarted whenitis warm.
○
4. Put theengineswitchintheONposition.
○
5.Gentlypullupthestartergripand pullitoutbrisklywhen aresistanceisfelt.
○
6.Whentheengine has warmedup,put thechokelever intheONposition.
7. STOPPING THEENGINE
○
1. Turnoffengineswitch.
○
2. Turnofffuelcock.
Ifanemergencystop ofthe engineis needed, theengineswitch
shouldbeputintheOFF position。

MAINTENANCE
- 14-
8.MAINTENANCE
Good maintenanceisthe bestassuranceforsafe,economicalandzero-malfunction
runningof thegenerator,and itis alsogoodfor environmentprotection.
Engineexhaustgas containspoisonouscarbon monoxide.
Maintenancecanonlybeperformedaftertheengineisstopped.If
maintenancemustbeperformed whiletheengineisrunning, theworking area
must bewell ventilated.
Periodic maintenanceandadjustmentarenecessaryforkeeping thegeneratorina
goodoperatingcondition.Maintenancescheduleisas follows:
MAINTENANCESCHEDULE
Each
use Firsmonthor20
Hrs (3)
Every3
months or
50Hrs
(3)
Every6
months or
100Hrs
(3)
Everyyear
or
300Hrs
(3)
Checkoil
level ○
Engineoil Change ○○
Check ○
Airfilter Clean ○(1)
Fuel sediment
cup Clean ○
Batteryelectrolyte
level Check ○
Spark plug Clean ○Replace
Valveclearance Readjust ○(2)
Cylinderhead Clean Every300Hrs. (2)
Fuel tankand
strainer Clean Everytwoyears(2)
Fuel line Replace Everytwoyears(2)
(1) Maintainmorefrequentlywhen the generatorisusedindustyareas.
(2) Theseitemsshouldbemaintainedbyanauthorizeddealerof ourcompany.
(3) Ifthe generatoristobeusedfrequently,maintenanceshallbe performedasperthe
scheduleabovetoensure long-timenormaloperation.

MAINTENANCE
-15-
Impropermaintenance,or failuretocorrectaproblembefore
operation,can cause amalfunction bywhichyou can behurtor
killed.
Alwaysfollowtheinspectionand maintenancerecommendationsand schedules
inthisowner’smanual.
1) Engineoilchange
Drain the engine oilwhen theenginehasbeenwarmedtoensurecompleteandrapid
draining.
○
1.Removetheoil dipstick andscrewoffthedrainplugtodrain theengineoil
○
2. Reinstalltheoildrainplug andtightenit.
○
3. Refillwiththerecommendedengineoil
and checkoillevel.
Engine oilvolume:
168F-II:0.6L
188F: 1.1L
Engineoilmaycause skincancerifrepeatedlyleft in contact
withtheskinforprolongedperiods.Although theskin cancerdoesnot
necessarilyhappen,itisstill advisabletothoroughlywash theskinthathas
contactedengineoilwith soapand water afterhandling engineoil.
For the sakeofenvironment protection,pleasetreattheused engineoil inan
appropriateway. Westronglyadviseyou tostoretheused engine oilinasealed
containerand takeittothelocalservicestationorrecyclingcenter forusedoil
reclamation.Never throwitinthetrashorpouritonthegroundorintothe ditch.
2) Air filtermaintenance
Adirtyairfilterwill restrict airflowintothecarburetor.Topreventcarburetor
malfunction,maintain theairfilterregularly.Maintainitmore frequentlywhen operating
thegeneratorinextremelydustyareas.
Using gasolineor inflammablesolventtocleanthefilterelement
cancauseafireor explosion. Useonlysoapywateror nonflammablesolvent.
Neverrun thegenerator withouttheairfilter,orrapidenginewear
will result.
Drainplug Oildipstick
Highest oil
level

MAINTENANCE
- 16-
○
1. Unsnaptheairfilter coverclips, removetheair filter coverand check the filter
elementtoconfirmitis completeandclean.
○
2. Ifthefoamelementis dirty,clean itfollowing the methodbelow:
Washthe element in asolutionofhouseholddetergentandwarm water,or ina
nonflammable(orhighflashpoint)detergent, detergent;thoroughlysqueezefluid
outofit. Dripsomedropsofengineoil intoit.
If thepaperelementis dirty, gentlyknock it severaltimes; then usecompressed air
(withapressurenothigherthan207KPa) toblowit fromtheinsidetotheoutside.
Never useabrushtocleanthe paper element,oritsairporeswill beclogged.Ifthe
paperelementisdamaged, replaceitwithanewone
○
3. Reinstall theairfilterelement andthecover.
3) Cleanthefuel sedimentcup
○
1. Turnthefuel valvetothe OFF position,
removethefuel sedimentcup,and takeout
theOringandstrainer.
○
2. Cleanthesediment cup,O-ring, andstrainer
in anonflammableor highflashpointsolvent.
○
3. Reinstall O-ring and strainer,and thefuel
sediment cupandtightenthecup.
过滤网
O-ring
Sediment cup
Fuel valve
Sediment cup
Foamelement
Airfiltercover
Air Filter
element
