LongCo Freeliner User manual

LongCo: User Manual V08 / 03. Mai 2019 Seite 1 von 56
USER Manual
Rev. V08: 03. Mai 2019

LongCo: User Manual V08 / 03. Mai 2019 Seite 2 von 56
Please read the following instructions carefully before the first drive. Note especially the
safety instructions in chapter 1.4. Not to pay attention to the safety instructions can cause
serious injury and / or death.
Welcome to the World of
LongCo!
The LongCo is a completely new kind of transportation.
Although keeping your balance on three wheels is easy, the risk of
injury from loss of control, collisions and falls will always be present. We
want you to enjoy riding your new LongCo and be safe at the same
time.
This User Manual is designed to help you learn and understand how to
properly drive, control, the road traffic laws to observe and enjoy your
LongCo while minimizing risks.
This manual was developed to help them.
Always Follow National
State and local Laws!
The LongCo comply with the homologation in Europe for mopeds and
motorcycle (Category L2e). There is also difference in individual
countries. Many other countries are based on this registration.
Therefore, always follow the applicable local legislation concerning
the use of the LongCo on public roads and public places. In some
countries, it is forbidden to use the LongCo in public areas.
If you are uncertain regarding the local legislation, contact your local
authorities for information or contact an authorized LongCo dealer.

LongCo: User Manual V08 / 03. Mai 2019 Seite 3 von 56
Table of Contents
1. Safe Riding ........................................................................................................................................................................................................................ 5
1.1. Basics.......................................................................................................................................................................................................................... 5
1.2. Where to Ride? ......................................................................................................................................................................................................... 6
1.3. Protective Gear ........................................................................................................................................................................................................ 7
1.4. Protective Measures................................................................................................................................................................................................ 8
1.5. Pre-Ride Inspection................................................................................................................................................................................................. 10
1.6. How to Ride ............................................................................................................................................................................................................. 10
1.6.1 Turn on ............................................................................................................................................................................................................... 11
1.6.2 Practice ............................................................................................................................................................................................................. 11
1.6.3 Riding Tips.......................................................................................................................................................................................................... 12
2. Preparation ..................................................................................................................................................................................................................... 13
2.1. Unfold frame ........................................................................................................................................................................................................... 13
2.2. Unfold Rear Fender................................................................................................................................................................................................. 18
2.3. Fold Rear Fender..................................................................................................................................................................................................... 19
2.4. Install Rear Carrier................................................................................................................................................................................................... 20
2.5. Installation of heavy-duty rear carrier .................................................................................................................................................................. 23
2.6. Unfold the folding stem.......................................................................................................................................................................................... 24
2.7. Fold the folding stem.............................................................................................................................................................................................. 25
2.8. Insert/Remove the Batteries .................................................................................................................................................................................. 26
3. LongCo Features............................................................................................................................................................................................................ 27
3.1. Batteries ................................................................................................................................................................................................................... 27
3.2. Charging Batteries.................................................................................................................................................................................................. 28
3.3. Control Features: Handlebar and TFT-Display ..................................................................................................................................................... 31

LongCo: User Manual V08 / 03. Mai 2019 Seite 4 von 56
3.4. RFID-Key-Set............................................................................................................................................................................................................. 33
3.5. Turn On/Off.............................................................................................................................................................................................................. 33
3.6. TFT-Display................................................................................................................................................................................................................ 34
3.7. Read TFT-Display ..................................................................................................................................................................................................... 35
3.8. Switch buttons of the TFT-Display .......................................................................................................................................................................... 36
3.9. Setup-Menu TFT-Display ......................................................................................................................................................................................... 37
3.10. Speed levels and Power Mode........................................................................................................................................................................... 40
4. Consumer Information................................................................................................................................................................................................... 41
4.1. Maintenance .......................................................................................................................................................................................................... 41
4.2. Repairs ..................................................................................................................................................................................................................... 43
4.3. Warranty and Limited Liability............................................................................................................................................................................... 43
4.4. Transport .................................................................................................................................................................................................................. 45
4.5. Storage and Care Instructions .............................................................................................................................................................................. 46
4.6. Disposal .................................................................................................................................................................................................................... 47
4.7. Troubleshooting....................................................................................................................................................................................................... 48
5. Inspection-Plan............................................................................................................................................................................................................... 50
5.1. Maintenance Plan.................................................................................................................................................................................................. 51
6. Technical Data ............................................................................................................................................................................................................... 54
6.1. Dimension when folded......................................................................................................................................................................................... 55
7. Index ................................................................................................................................................................................................................................ 56

LongCo: User Manual V08 / 03. Mai 2019 Seite 5 von 56
1. Safe Riding
1.1. Basics
Driver's License /Restrictions
If required by law, you must carry a valid driver’s license that is locally accepted for
riding the LongCo
Who cannot safely operate the LongCo in the traffic due to physical or mental defects
is only allowed to ride if he himself has made provision that he does not endanger others.
In case of doubt on the ability to drive the LongCo, then order at the driver's license
office a professional medical opinion, a medical-psychological examination or a
technical expertise.
Before first ride
The owner must ensure that any operator of the LongCo fully reads, understands and
follows all instructions in this manual. A demonstration to ensure that the rider
understands the operation of the LongCo is strongly advised.
Maximum Total Weight
Payload Rear Carrier
Permissible max. laden Mass: 250kg/550lbs àBe aware, if the rider is more than
150kg/330lbs and want to use the seat system, the additional heavy-duty rear carrier
with two additional air rear shock must be installed (see chapter 2.2.).
The maximum allowed payload for the rear carrier is 50kg/110lbs. The optional heavy-
duty rear carrier has the maximum allowed payload of 100kg/220kbs.
No Stunts
The LongCo is not developed for any type of tricks, stunts, jumping, wheelies or racing.

LongCo: User Manual V08 / 03. Mai 2019 Seite 6 von 56
Take account of
Regardless of where you use the LongCo, operators should always show courtesy to others
and ride in a safe and suitable manner.
Insurance
Make sure you are covered with insurance for both you and your LongCo.
Modifications
Do not remove, modify or alter any components of the LongCo. Any modification can
cause malfunctions and the loss of road approval or warranty claims. Modifications can be
dangerous and lead to serious injuries. Do not open, disassemble or service the battery.
1.2. Where to Ride?
Legislation
Always pay attention to the locally applicable legislation about the use of the LongCo
on public roads and in public places. If you are uncertain regarding your local
legislation, contact your local authorities or your LongCo dealer for information.
Private property
To ride the LongCo on private property, always obtain permission from the owner to do
so.
Roads
Typical bicycle lanes and side roads with low traffic (if allowed) are suitable for riding
the LongCo.

LongCo: User Manual V08 / 03. Mai 2019 Seite 7 von 56
All Season Tires
The special for LongCo developed All Season Tires are designed for
• paved roads and places with an even surface, such as asphalt, concrete,
sports field pavement, etc.
• streets and on dirt roads which are in good condition for driving
• lawns (if allowed)
• beaches with compact sand ((if allowed)
• in winter on compact snow
Unsafe Conditions
• Do not ride when road and weather conditions do not allow safe use.
• Never ride on ice or greasy surfaces (i.e. oil), in heavy rainfall or with poor visibility
(i.e. fog). Wet and icy weather impairs traction, braking, and visibility.
• Do not use the LongCo in water or drive through standstill water under any
circumstances.
• Do not ride on stairs, escalators or through revolving doors.
• Do not ride off curbs
1.3. Protective Gear
Note!
Important!
LongCo Recommends
Always inform yourself about local regulations regarding the use and wearing of
protective gear on public roads and areas where you are riding. In some
countries/states, it is mandatory to wear a helmet at all times.
• Helmets with chin protection, (DOT or SNELL certified)
• Good, sturdy footwear - No heels, open-backed shoes, or flip-flop type shoes
• Arm, elbow, knee and shin guards, as well as chest protection

LongCo: User Manual V08 / 03. Mai 2019 Seite 8 von 56
1.4. Protective
Measures
For maximum safety when riding the LongCo, it is extremely important to take certain protective
measures.
Throttle
Never use the throttle unless you are standing with both feet on the LongCo platform and are
fully ready to ride.
Turning Components
Turning wheels are a high risk for injury. Hands, feet, body parts and clothes should under no
circumstances be close to turning wheels. To prevent injury, never touch any moving or turning
parts.
Collapsible Frame
Special precaution must be used with the collapsible frame, especially when folding up the
folding stem into the riding position, as well as when folding out the platform for the riding
position. You risk injuring fingers, hands or other parts of your body.
Beware of Hot Brake Discs
Do not touch brake discs during or immediately after use, as they can get very hot when used.
Be Prepared to Stop
At any point in time during the use of the LongCo, the rider must be alert and prepared to stop.
Special care must be taken as soon as other people or vehicles are close by.
Normal Operational
Environment
• Temperature: -15ºC/5ºF to +45ºC/113ºF
• Humidity: 5% to 85%

LongCo: User Manual V08 / 03. Mai 2019 Seite 9 von 56
Lithium Batteries
Lithium batteries pose a risk of injury when handled improperly. Therefore:
• Do not use or leave battery near a heat source such as fire or heater
• Use only LongCo’s authorized chargers
• Do not connect battery to an electrical outlet directly
• Refer to chapter 3.1. Batteries and chapter 4.5. Storage and Care Instructions for more
detailed information
Be Aware
Adjust your riding style to your ability as well as road, traffic and weather conditions. The LongCo
is to be operated in a safe and suitable manner.
Avoid Distractions
The rider should not use a cell phone, listen to headphones, or engage in any other activity that
might distract or interfere with the ability to monitor the surroundings while driving. The attention
of the rider must be directed toward operating the LongCo.
Both Hands and Feet
While driving the LongCo, both hands should be kept on the handlebar, and both feet should
be kept on the platform.
Luggage
Do not carry objects in your hands or on the platform while driving. Use the LongCo’s carrier
equipment, such as a top case, to transport objects/luggage.
Parking
Lock the LongCo and remove battery keys (also remove main key located at the throttle, if
installed) when parking it. Activate the parking brake. Secure with an adequate lock.

LongCo: User Manual V08 / 03. Mai 2019 Seite 10 von 56
1.5. Pre-Ride Inspection
• Check the functionality of the LongCo prior to each use.
• Make sure all fastening elements are tight (bolts, quick release clamps, folding mechanism
for stem and platform, etc.).
• Do not use the LongCo if any parts are loose or damaged
• Ensure that brakes work properly
• All batteries must be firmly locked onto frame and both keys must be taken off the battery
before riding the LongCo.
• Ensure that the air pressure of the tires (see Error! Reference source not found.) and of the air s
uspension system is correct and adjusted to the rider weight. (see Error! Reference source
not found.)
1.6. How to Ride
1.6.1 Turn on
1.6.2 Practice
1. Turn on the battery by push the right button next to OLED Display (if equipped with 2 or 3
batteries, the other batteries will turn on automatically after activating one). For use only one
battery, the other batteries can be turned off then by push the right button for 2s.
2. Activate the TFT-Display with the blue RFID-Key (Setup A) or the black RFID-Key (Setup B)
For this hold RFID-Key on Top of the Display left lower corner over the RFID Symbol.
(All details how to use can be found in chapter 3)
• Beginners must practice using the LongCo first. Training rides should be performed in a safe
place on an even and non-slippery surface, away from traffic or pedestrians.
• Always be alert and ready to use the brakes.

LongCo: User Manual V08 / 03. Mai 2019 Seite 11 von 56
1.6.3 Riding Tips
Four Speed Levels
Beginners should use speed level 1 (6 km/h) or speed level 2 (12 km/h). Speed level 3 (20 km/h)
and speed level 4 (max speed) only if you are an experienced LongCo user.
Braking
Use primarily the left brake lever , to slow down, which is for the rear wheels.
Reverse
This feature should only be used by experienced LongCo users. ,
Acceleration
Never accelerate in an uncontrolled fashion.
Terrain/Surface changes
Be aware that every terrain/surface change (i.e. from pavement to grass, a threshold or speed
bump) is a potential hazard and may require a change in driving style. Do not pull up the LongCo
handlebar when riding over obstacles.
Steep Slopes
When going downhill never exceed a speed of 20 km/h (or 45km/h for the faster LongCo Models).
Instead, use the brakes to slow down or push the LongCo. If driving across a slope the driver must
balance the inclination by leaning his/her body uphill.
Added Height
Because of the added height of the LongCo platform (and the driver’s helmet) special care must
be taken when driving indoors, as well as through doorways, archways, under tree branches,
signs, or other overhead obstacles.
Visibility
To ride safely, the rider must be able to see clearly and must be visible to others. Always switch
on the light , when riding the LongCo at night time or in conditions of low visibility. Follow local
legislation regarding regulations for using the LongCo at night.

LongCo: User Manual V08 / 03. Mai 2019 Seite 12 von 56
Curves
Always turn slowly and with caution - do not turn abruptly! Reduce the speed, so all 3 wheels
have always contact to the ground.
Lean into the turn to maintain balance. The body must be brought into an inclined position as on
a bicycle or motorbike. (see diagrams below)
Exceptions:
A) When driving alongside a steep hill, lean towards the hill
.
B) If you use a LongCo Skyliner or Freeliner Sport model, and you have enough
experience in riding, you can also lean into the curves, using following riding technic:
If there is a left curve, you push the standing platform to the left with your left leg.
Make sure, you push steady and smoothly, not with a sudden movement. If needed,
reduce the speed in order all 3 wheels having always contact to the ground.
Same for the right curve, just push down the platform to the right with your right leg.
Important: In order to keep your body balanced, never push down the handlebar in
either direction.

LongCo: User Manual V08 / 03. Mai 2019 Seite 13 von 56
2. Preparation
2.1. Unfold frame
CAUTION
Beware of Pinch point!
Keep your fingers, hands or other parts of your body away, when folding out the platform, you could
get seriously injured.
• Unfold the stem and turn the front wheel so it points forward and lock the handle of the folding
stem (Details see chapter 2.6)
1
2

LongCo: User Manual V08 / 03. Mai 2019 Seite 14 von 56
• With the rear wheel brake (brake handle on the left side), you can unfold the LongCo simply by
pulling the handlebar forward.
3
4

LongCo: User Manual V08 / 03. Mai 2019 Seite 15 von 56
• When unfolded the LongCo about 90°, change to the rear brake (handle on the right side) and
unfold it backwards.
5
6
Attention:
Rear/All-Wheel Drive have
many cables between front
and rear Frame. Before you
close all the way, check every
cable and make sure, that
none of the cable will be
squeezed or damaged.
In order to arrange the cables
when unfold, 2 persons are
needed. One take care for
the cables while the other
one slowly lower down the
vehicle to horizontal position.
(like on the picture right side).
Attention, don’t squeeze your
finger!
Therefore Rear/All-Wheel
Drive can only be fold for
special occasions, like
holidays. For daily use the
folding cannot be used,
otherwise the cable will be
damaged sooner or later.

LongCo: User Manual V08 / 03. Mai 2019 Seite 16 von 56
• If the LongCo is total unfolded, fold down the platform and close the quick release on both sides
of the frame. (Details see Picture 8a to 8d on next page). If the quick release is not tight after it is
locked, then adjust the M6 Nut.
7
8

LongCo: User Manual V08 / 03. Mai 2019 Seite 17 von 56
8a
8b
8c
8d

LongCo: User Manual V08 / 03. Mai 2019 Seite 18 von 56
2.2. Unfold Rear
Fender
• Next the rear fender can be unfolded. The rear fender can easily be pulled up, when one hand
pulls out the outer part and push up the inner part. Make sure the rear fender are locked in at
the end position over the tire.
9

LongCo: User Manual V08 / 03. Mai 2019 Seite 19 von 56
2.3. Fold Rear
Fender
• For transport the LongCo the rear fender can be fold back, so the frame can be folded easy by
just turn back over the wheel.
• Attention: The Rear Fender can only be folded, when the rear carrier is removed first.

LongCo: User Manual V08 / 03. Mai 2019 Seite 20 von 56
2.4. Install rear
carrier
• At the end the rear carrier will be installed, first the rear carrier must be pushed in the lead slot.
10
