LOOKEE® BabyO2™ Sleep Monitor
User Manual
7/24 Customer Support:
[e-mail]
Chat with us: www.LookeeTech.com
Download App
App name: ViHealth
iOS: App Store
Android: Google Play
If you have installed the App before, please update it to the latest
version.
NOTICE
The Monitor is not a medical device. It should not be used to
diagnose or treat any medical condition.
1 Tips for Safe Sleep
Room-share instead of co-sleeping
Place your baby alone and on their back to sleep.
Use a firm sleep surface. Keep soft objects out of crib.
Use a crib that meets safety standards. Do not use cradle
for sleep.
Do not use BabyO2 as an excuse for unsafe sleep.
2 Warnings and Cautions
DO NOT twist the sensor and the wrap or apply excessive
force on them.
Do not use this device during MRI examination.
Do not store the device in the following locations: locations in

which the device is exposed to direct sunlight, high
temperatures or levels of moisture, or heavy contamination;
locations near to sources of water or fire; or locations that are
subject to strong electromagnetic influences.
Do not use the device in a combustible environment.
Never submerge the device in water or other liquids.
Do not clean the device with acetone or other volatile solutions.
Do not drop this device or subject it to strong impact.
The device and accessories are provided non-sterile.
Do not place this device in pressure vessels or gas
sterilization device.
Do not dismantle the device, as this could cause damage or
malfunctions or impede the operation of the device.
Consult your doctor immediately if you experience symptoms
that could indicate acute disease.
Do not self-diagnose or self-medicate based on this device
without consulting your doctor. In particular, do not start taking
any new medication or change the type and/or dosage of any
existing medication without prior approval.
Use only cables, sensors and other accessories specified in
this manual.
Prolonged continuous monitoring may increase the risk of
undesirable changes in skin characteristics, such as irritation,
reddening, blistering or burns.
Do not open the device cover without authorization. The cover
should only be opened by a qualified service personnel.
3 Unpacking
Device (main unit)
Sensor cable
2 soft wraps, different size
User Manual
Data/Charging Cable

4 Using the device and App
4.1 Download App
App name: ViHealth
iOS: App Store
Android: Google Play
Notice: if you have installed the App before, please
update it to the latest version.
4.2 Charging
Charge the battery before using.
Connect the device to USB of computer or USB charging
adapter with the supplied cable.
After fully charged, the device will power off automatically.
4.3 POWER ON/OFF
POWER ON:
Press the side button for 2 seconds.

POWER OFF:
3 ways:
Press the side button for 2 seconds.
Unplug the sensor cable, it will power
off automatically if not connected to
phone for 2 minutes.
Even with sensor cable connected, it
will power off automatically if no
working for 10 minutes.
4.4 Placement Guide before working
1) Choose the wrap with appropriate size
0~3 Months, choose the smaller (for reference only)
2) Place the sensor into the wrap as shown
3) Position and secure the sensor
a. Place the wrap with the sensor on the foot (either

foot works), with the sensor part running on the
outside edge of the foot.
b. The sensor cable should be oriented to the baby’s
leg.
c. The light emitter and the light detector should be
opposite to each other on the two sides of the foot.

For the right foot, the Light Emitter should be on the top; for the left foot, the
Light Emitter should be on the bottom.
d. Attach the wrap velcro securely with no gap
between the sensor and the baby’s skin
4) Plug the sensor cable into the device

5) Put the device around the leg, attach the velcro
to secure the device.
4.5 Start working
After the placement, press the side button for 2 seconds
to power on. There should be red light inside the soft
wrap.
After displaying time and battery, you can change the
reminder settings with side button (usually you can do
nothing). You can also change the settings in App
(illustrated later). It is easier to set in App.

After a few seconds, readings will be displayed on the
screen.
If the screen display “poor signal”, please check if the
sensor has been positioned and secured properly.
When the above symbol displays on device screen, it
indicates the readings is unavailable right now.
When at rest, there will be readings in a few seconds. If
you cannot get readings for a long time, it may be
caused by:
Improper sensor placement
Frequent movement
Foot is too cold
Run App to connect the device, you can check the real-
time readings in App Dashboard. (The detail of using App
will be illustrated later)
Notice:

If the working time is less than 2 minutes, the data
will not be saved.
Motion may cause readings unavailable. Readings
recover very soon at rest.
Please avoid strong ambient light condition.
4.6 Stop working & sync data
Unplug the sensor cable, the
countdown on the screen will begin.
During the countdown, if you plug the
sensor cable again, the record will be resumed.
After the countdown, the data will be ready for sync.
Notice:
If the working time is less than 2 minutes, there will
be no data saved
If the device power off during working, the data
should have been saved.
Sync data:
After the countdown, run App to sync data; If app
has already opened, go to History page to sync data.
You can also sync data later. The built-in memory
can store 4 sessions. The oldest will be overwritten
by the 5th. Please sync data to your phone in time.
Notice: The built-in memory can store 4 sessions, up to
10 hours for each. It will start the next session
automatically after 10 hours monitoring.
4.7 Screen wake up / change display
During measurement, the screen will go off automatically

for saving power; you can press the side button to wake
up the screen or change display.
4.8 Bluetooth Connection
The device Bluetooth will be enabled automatically after
it’s turned on.
To establish a Bluetooth connection,
1) Power on the device.
2) Make sure the phone Bluetooth is enabled.
3) Run the App.
4) Allow the App to use Bluetooth.
Notice:
DO NOT PAIR in the settings of your smartphone.
4.9 Add a new device
For the initial use, you need to add a new device.
1) Turn on device, run App, select <BabyO2>.
2) Follow the App instruction to add the new device.
4.10 App Dashboard
In App Dashboard, you can view:
Real-time oxygen Level, heart rate.
Near term trends of oxygen level, heart rate and
motion.
PI (Perfusion Index). If too weak (being red), please
check if the sensor has been positioned and
secured properly.
Bluetooth signal. If too weak, place phone closer to
the device.
Device battery level
Reminder info
Help info

4.11 Audio reminder in Device
You can configure it in App-Settings when your device is connected
to App.
•You can switch on or off the reminder.
•You can adjust the volume of the reminder.
•You can adjust the Threshold.
The reminder will stop when oxygen level recover, or you
can press the side button to stop it.
4.12 Audio reminder in App
You can configure it in App-Settings.
•You can switch on or off the reminder.
•You can adjust the Threshold.
The volume is same as your phone’s volume.
The Reminder works only when your phone stayed in Dashboard and
not locked.
The Reminder in Dashboard will be activated when the
oxygen level fall below the pre-set value (Threshold).
The Reminder will stop when the oxygen level recover. You
can press the Mute icon on Dashboard to mute.
4.13 View Report
In App->History,
Tap an item in the list, you can check the detailed
report, which includes analysis results and
diagrams.
Slide an item to left, you can delete it.

4.14 App Offline Mode | Multiple Devices
If you enter App Offline Mode, you can view history data, in App
Settings->Select Device, you can select device if you have multiple devices.
In this Mode, device is not connected so you cannot sync data or set device.
5 PC software
PC Software: O2 Insight Pro
Download from:
https://www.lookeetech.com/pages/downloads
Install the software on windows PC. If you are using Mac,
please go to App store to download “O2 Insight Pro” there.
To use the software,
1) Turn on device, connect the device to PC USB port
with the supplied Cable. Do not connect device to
App when you want to connect to PC Software.
2) Run the PC software, click the Download button to
download data from the device
With the PC software, you can view and print report,
which can also be exported as PDF or CSV files.
6 Maintenance
6.1 Time & Date
After connection with App, device time will sync from your
phone time automatically.
6.2 Cleaning
Clear the wrap with water. Water temperature should be
lower than 104℉(40℃)

Use a soft cloth moistened with water or alcohol to clean
the device surface.
7 Troubleshooting
Problem
Possible Cause
Possible
Solution
No
readings
on
screen
the sensor is not
positioned and
secured properly
check if the
sensor has been
positioned and
secured properly
Baby is moving
frequently
It will recover
when at rest
Device
does not
turn on
or no
response
Battery may be low.
Charge battery
and try again.
Device might be
damaged.
Please contact
your local
distributor.
The app
cannot
find the
device
The Bluetooth of
your phone is off.
Turn on the
Bluetooth in the
phone.
The device
Bluetooth is off.
Turn on device
The App is not
allowed to use
Bluetooth
Allow the App to
use Bluetooth
For Android,
Bluetooth cannot
work without
location permission
Allow location
access
8 Specifications
Environmental
Operating
Storage
Temperature
5 to 40°C
-25 to 70°C
Relative humidity
(noncondensing)
10% to 95% 10% to 95%
Barometric
700 to 1060hPa
700 to 1060hPa

Protection against
electric shock Internally powered equipment
Degree protection
against electrical
shock
Type BF
Electro-magnetic
compatibility
Group I, Class B
Degree of dust &
water resistance
IP22
Weight
31g
(main unit with band and sensor)
Size
49×27×14 mm (main unit)
Battery
3.7Vdc, Rechargeable Lithium-
polymer
Charge time
2-3 hours
Battery life
16 hours for typical use
Wireless
Bluetooth 4.0 BLE
Oxygen level range
70% to 99%
Oxygen level
Accuracy (Arms)
80-99%: ±2%, 70-79%: ±3%
Heart Rate range
30 to 250 bpm
Heart Rate accuracy
±2 bpm or ±2%, whichever is greater
Reminder
Triggered by low oxygen level
Recorded
parameters Oxygen level, Heart Rate, motion
Data storage
4 sessions, up to 10 hours for each
Mobile App for iOS
iOS 9.0 or above,
iPhone 4s/ iPad 3 or above
Mobile App for
android
Android 5.0 or above,
with Bluetooth 4.0 BLE
Manufacturer: Shenzhen Viatom Technology Co., Ltd
Address: 4E, Building 3, Tingwei Industrial Park No. 6 Liufang
Road, Block 67 Xin’an Street, Baoan District
Shenzhen 518101 Guangdong China
Model: BabyO2
Version: A
