Dear customer:
Thank you for buying this upright freezer. To ensure that you get the best results from
your new freezer, please take time to read through the simple instructions in this
booklet.
Please ensure that the packing material is disposed of in accordance with the current
environmental requirements.
When disposing of any Freezer equipment please contact your local waste disposal
department for advice on safe disposal.
This appliance must be only used for its intended purpose. This appliance is intended
to be used in household.

3
SAFETY WARNINGS.......................................................................................................4
WARNING................................................................................................................................................... 4
MEANING OF SAFETY WARNING SYMBOLS ................................................................................ 7
ELECTRICITY RELATED WARNINGS.................................................................................................. 8
WARNINGS FOR USING ........................................................................................................................ 8
WARNINGS FOR PLACEMENT............................................................................................................ 9
WARNINGS FOR ENERGY...................................................................................................................10
WARNINGS FOR DISPOSAL...............................................................................................................10
PROPER USE OF REFRIGERATORS.............................................................................12
PLACEMENT............................................................................................................................................12
LEVELING FEET ......................................................................................................................................13
DOOR RIGHTLEFT CHANGE............................................................................................................13
CHANGING THE LIGHT .......................................................................................................................17
STARTING.................................................................................................................................................17
ENERGY SAVING TIPS..........................................................................................................................17
STRUCTURE AND FUNCTIONS...................................................................................18
KEY COMPONENTS..............................................................................................................................18
FUNCTIONS.............................................................................................................................................19
MODE SETTING .....................................................................................................................................20
MAINTENANCE AND CARE OF THE APPLIANCE ......................................................22
OVERALL CLEANING ...........................................................................................................................22
CLEANING THE GLASS SHELF..........................................................................................................23
DEFROSTING ..........................................................................................................................................23
OUT OF OPERATION............................................................................................................................23
TROUBLESHOOTING...................................................................................................24
PRODUCT INFORMATION SHEET ..............................................................................26
CONTENT

4
SAFETY WARNINGS
Warning
Warning: risk of re / ammable materials
• Thisapplianceisintendedtobeusedinhouseholdandsimilar
applications such as sta kitchen areas in shops, oces and
other working environments; farm houses and by clients in
hotels, motels and other residential type environments; bed
and breakfast type environments; catering and similar nonretail
applications.
• Thisapplianceisnotintendedforusebypersons(including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.)
• Childrenshouldbesupervisedtoensurethattheydonotplay
with the appliance.
• Ifthesupplycordisdamaged,itmustbereplacedbythe
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
• Donotstoreexplosivesubstancessuchasaerosolcanswitha
ammable propellant in this appliance.
• Theappliancehastobeunpluggedafteruseandbefore
carrying out user maintenance on the appliance.
• Warning:Keepventilationopenings,intheapplianceenclosure
or in the built-in structure, clear of obstruction.

5
• Warning:Donotusemechanicaldevicesorothermeans
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning:Donotdamagetherefrigerantcircuit.
• Warning:Donotuseelectricalappliancesinsidethefood
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
• Warning:Pleaseabandontherefrigeratoraccordingtolocal
regulators for it use ammable blowing gas and refrigerant.
• Warning:Whenpositioningtheappliance,ensurethesupply
cord is not trapped or damaged.
• Warning:Donotlocatemultipleportablesocket-outletsor
portable power supplies at the rear of the appliance.
• Donotuseextensioncordsorungrounded(twoprong)
adapters.
• Danger:Riskofchildentrapment.Beforeyouthrowawayyour
old refrigerator or freezer:
- Take o the doors.
- Leave the shelves in place so that children may not easily
climb inside.
• Therefrigeratormustbedisconnectedfromthesourceof
electrical supply before attempting the installation of accessory.
• Refrigerantandcyclopentanefoamingmaterialusedforthe
appliance are ammable. Therefore, when the appliance Is
scrapped, It shall be kept away from any re source and be
recovered by a special recovering company with corresponding
qualication other than be disposed by combustion, so as to
prevent damage to the environment or any other harm.
• ForENstandard:Thisappliancecanbeusedbychildrenaged
from 8 years and above and persons with reduce physical
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved.

6
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• Thenecessitythat,fordoorsorlidsttedwithlocksandkeys,
the keys be kept out of the reach of children and not in the
vicinity of the refrigerating appliance, in order to prevent
children from being locked inside.
• Toavoidcontaminationoffood,pleaserespectthefollowing
instructions:
- Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
- Clean regularly surfaces that can come in contact with food
and accessible drainage systems.
- Clean water tanks if they have not been used for 48 h; ush
the water system connected to a water supply if water has not
beendrawnfor5days,(note1)
- Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
- Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making ice-cream and making ice
cubes.(note2)
- One-, two- and three-star compartments are not suitable for
thefreezingoffreshfood,(note3)
- For appliances without a 4-star compartment: this
refrigerating appliance is not suitable for freezing foodstus,
(note4)
- If the refrigerating appliance is left empty for long periods,
switch o, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.
Note 1,2,3,4: Please conrm whether it is applicable according
to your product compartment type.

7
• Forafreestandingappliance:thisrefrigeratingapplianceisnot
intended to be used as a built-in appliance.
• Forappliancewithchillcompartment:sometypesoffresh
vegetables and fruits are sensitive to cold, and that therefore
they are not suitable for storage in this kind of compartment
• AnyreplacementormaintenanceoftheLEDlampsisintended
to be made by the manufacturer, its service agent or similar
qualied person.
This product contains a light source of energy eciency class
(G).
Meaning of safety warning symbols
Prohibition symbol
This is a prohibition symbol.
Any incompliance with instructions marked
with this symbol may result in damage
to the product or endanger the personal
safety of the user.
Warning symbol
This is a warning symbol.
It is required to operate in strict observance
of instructions marked with this symbol;
or otherwise damage to the product or
personal injury may be caused.
Note symbol
This is a cautioning symbol.
Instructions marked with this symbol
require special caution. Insucient caution
may result in slight or moderate injury, or
damage to the product.
This manual contains lots of important safety information which
shall be observed by the users.

8
Electricity related warnings
• Donotpullthepowercordwhenpullingthepowerplugof
the refrigerator. Please rmly grasp the plug and pull out it
from the socket directly.
• Toensuresafeuse,donotdamagethepowercordoruse
the power cord when it is damaged or worn.
• Pleaseuseadedicatedpowersocketandthepowersocket
shall not be shared with other electrical appliances. The
power plug should be rmly contacted with the socket or
else res might be caused. Please ensure that the grounding
electrode of the power socket is equipped with a reliable
grounding line.
• Pleaseturnothevalveoftheleakinggasandthenopen
the doors and windows in case of leakage of gas and other
ammable gases. Do not unplug the refrigerator and other
electrical appliances considering that spark may cause a re.
• Donotuseelectricalappliancesonthetopofthe
appliance, unless they are of the type recommended by the
manufacturer.
• Donotarbitrarilydisassembleorreconstructtherefrigerator,
nor damage the refrigerant circuit; maintenance of the
appliance must be conducted by a specialist.
• Damagedpowercordmustbereplacedbythe
manufacturer, its maintenance department or related
professionals in order to avoid danger.
• Thegapsbetweenrefrigeratordoorsandbetweendoors
and refrigerator body are small, be noted not to put your
hand in these areas to prevent from squeezing the nger.
Please be gentle when close the refrigerator door to avoid
falling articles.
• Donotpickfoodsorcontainerswithwethandsinthe
freezing chamber when the refrigerator is running,
especially metal containers in order to avoid frostbite.
Warnings for using

9
• Donotallowanychildtogetintoorclimbtherefrigerator;
otherwise suocation or falling injury of the child may be
caused.
• Donotplaceheavyobjectsonthetopoftherefrigerator
considering that objects may fall when close or open the
door, and accidental injuries might be caused.
• Pleasepullouttheplugincaseofpowerfailureorcleaning.
Do not connect the refrigerator to power supply within
ve minutes to prevent damages to the compressor due to
successive starts.
• Donotputammable,explosive,volatileandhighly
corrosive items in the refrigerator to prevent damages to the
product or re accidents.
• Donotplaceammableitemsneartherefrigeratortoavoid
res.
• Therefrigeratorisintendedforhouseholduse,suchas
storage of foods; it shall not be used for other purposes,
such as storage of blood, drugs or biological products, etc.
• Donotstorebeer,beverageorotheruidcontainedin
bottles or enclosed containers in the freezing chamber
of the refrigerator; or otherwise the bottles or enclosed
containers may crack due to freezing to cause damages.
Warnings for placement
Freezing chamber

10
Warnings for energy
1) Refrigerating appliances might not operate consistently
(possibilityofdefrostingofcontentsortemperaturebecoming
too warm in the frozen food compartment) when sited for an
extended period of time below the cold end of the range of
temperatures for which the refrigerating appliance is designed.
2) The fact that eervescent drinks should not be stored in food
freezer compartments or cabinets or in low-temperature
compartments or cabinets, and that some products such as
water ices should not be consumed too cold;
3)Theneedtonotexceedthestoragetime(s)recommendedby
the food manufacturers for any kind of food and particularly for
commercially quick-frozen food in food-freezer and frozen-food
storage compartments or cabinets;
4) The precautions necessary to prevent an undue rise in
the temperature of the frozen food while defrosting the
refrigerating appliance, such as wrapping the frozen food in
several layers of newspaper.
5) The fact that a rise in temperature of the frozen food during
manual defrosting, maintenance or cleaning could shorten the
storage life.
Warnings for disposal
Refrigerant and cyclopentane foaming material used for the
refrigerator are ammable. Therefore, when the refrigerator is
scrapped, it shall be kept away from any re source and be
recovered by a special recovering company with corresponding
qualication other than be disposed by combustion, so as to
prevent damage to the environment or any other harm.

11
When the refrigerator is scrapped, disassemble the doors, and
remove gasket of door and shelves; put the doors and shelves in a
proper place, so as to prevent trapping of any child.
Correct Disposal of this product:
This marking indicates that this product should not
be disposed with other household wastes. To prevent
possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources.
To return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product for
environmental safe recycling.

12
PROPER USE OF REFRIGERATORS
Placement
• Beforeuse,removeallpackingmaterials,Includingbottom
cushions, foam pads and tapes inside of the refrigerator;
tear o the protective lm on the doors and the refrigerator
body.
• Keepawayfromheatandavoiddirectsunlight.Donot
place the freezer in moist or watery places to prevent rust or
reduction of insulating eect.
• Donotsprayorwashtherefrigerator;donotputthe
refrigerator in moist places easy to be splashed with water
so as not to aect the electrical insulation properties of the
refrigerator.
• Therefrigeratorisplacedinawell-ventilatedindoorplace;
thegroundshallbeat,andsturdy(rotateleftorrightto
adjust the wheel for levelling if unstable).
• Thetopspaceoftherefrigeratorshallbegreaterthan30cm,
and the refrigerator should be placed against a wall with a
free distance more than 10cm to facilitate heat dissipation.
Precautions before installation:
Before installation or adjusting of accessories, it shall be ensured that the refrigerator is
disconnected from power.
Precautions shall be taken to prevent fall of the handle from causing any personal injury.

13
Leveling feet
Schematic diagram of the leveling feet
LH
(Thepictureaboveisonlyforreference.Theactualcongurationwilldependonthe
physical product or statement by the distributor)
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
Door right-left change
List of tools to be provided by the user
Cross screwdriver Putty knife thin-blade
screwdriver
5/16“
socket and ratchet Masking tape
1. Please power o this appliance before conduct this operation. Remove all food from
door shelves.

14
2. Remove the upper left hinge cover decorative cover, upper right hinge cover and
upperrighthinge,anddisconnecttherightsignalline(signallineterminal1,2)atthe
top of the box body.
3. Removetherefrigerateddoorbody(becarefulnottolosesmallpartssuchasthe
shaft sleeve and stop on the door);
Remove the middle hinge and remove the decorative cover of hinge hole on the
other side.
4. Removethefreezingdoorbody(becarefulnottolosesmallpartssuchastheshaft
sleeve and stop on the door);
Remove the hinge and adjust the angle. Remove and install the lower hinge shaft to
the other side of the hinge, and install the modied lower hinge to the other side of
the box.
upper hinge cover
decorative cover
decorative cover
upper hinge
middle hinge

15
5. Change the refrigerator door:
1) Remove the cover plate of the upper end cover of the refrigeration door and the
left decorative cover.
Install the upper shaft sleeve and the signal line of the door body to the other side
and cover the upper end cover plate. Take out the right decorative cover from the
accessory bag and install it to the other side of the upper end cover.
2) Remove the door self-locking, door stop and shaft sleeve of the refrigeration door,
take out the left door self-locking from the accessory bag, install it on the left side
of the lower end cover of the refrigeration door, change the door stop and shaft
sleeve to the left side of the lower end cover of the refrigeration door.
6. Change the freezing door:
1) Remove the shaft sleeve and cap of the upper end cover of the freezing doorand
install them at the left and right swap positions.
2) Remove the door self-locking, doorstop and shaft sleeve of the freezing door, take
out the left door self-locking from the accessory bag, install it on the left side of
the lower end cover of the freezing door, change the door stop and shaft sleeve to
the left side of the lower end cover of the freezing door.

16
7. Install the replaced freezing door on the lower hinge, then install the middle hinge
and cover the hinge hole decorative cover.
decorative cover
middle
hinge
8. Remove the upper left hinge cover and upper left hinge from the accessory bag.
Place the refrigerated door body on the middle hinge and install the upper left
hinge. Connect the refrigerator top signal line 4 to the door body signal line 1, and
connect the signal line 2 to the signal line 3.
 Finally,replacethehingedecorativecovertotherightsideoftheboxbody(note:
when replacing the hinge decorative cover to the right side of the box body, the two
insertsonthehingedecorativecover(asshowninthegure)shallbecuto).
decorative cover
upper hinge
upper hinge cover
inserts
(Thepictureaboveisonlyforreference.Theactualcongurationwilldependonthe
physical product or statement by the distributor)

17
Changing the Light
Any replacement or maintenance of the LED lamps is intended to be made by the
manufacturer, its service agent or similar qualied person.
Starting
• Beforeinitialstart,keeptherefrigeratorstillfortwohoursbefore
connecting it to power supply.
• Beforeputtinganyfreshorfrozenfoods,therefrigeratorshall
have run for 2-3 hours, or for above 4 hours in summer when the
ambient temperature is high.
• Spareenoughspaceforconvenientopeningofthedoorsand
drawers or statement by the distributor.
Energy saving tips
• Theapplianceshouldbelocatedinthecoolestareaoftheroom,awayfromheat
producing appliances or heating ducts, and out of the direct sunlight.
• Lethotfoodscooltoroomtemperaturebeforeplacingintheappliance.Overloading
the appliance forces the compressor to run longer. Foods that freeze too slowly may
lose quality, or spoil.
• Besuretowrapfoodsproperly,andwipecontainersdrybeforeplacingtheminthe
appliance. This cuts down on frost build-up inside the appliance.
• Appliancestoragebinshouldnotbelinedwithaluminiumfoil,waxpaper,or
paper toweling. Liners interfere with cold air circulation, making the appliance less
ecient.
• Organizeandlabelfoodtoreducedooropeningsandextendedsearches.Remove
as many items as needed at one time, and close the door as soon as possible.

18
STRUCTURE AND FUNCTIONS
Key components
(Thepictureaboveisonlyforreference.Theactualcongurationwilldependonthe
physical product or statement by the distributor)
Refrigerating chamber
• TheRefrigeratingChamberissuitableforstorageofavarietyoffruits,vegetables,
beverages and other food consumed in the short term,suggested storage time
3days to 5days.
• Cookingfoodsshallnotbeputintherefrigeratingchamberuntilcooledtoroom
temperature.
• Foodsarerecommendedtobesealedupbeforeputtingintotherefrigerator.
• Theglassshelvescanbeadjustedupordownforareasonableamountofstorage
space and easy use.
Door switch
LED light
Shelf
Fruits & vegetables box
Meat & sh box
Drawer
LED light
(for some models)Door tray

19
Freezing chamber
• Thelowtemperaturefreezingchambermaykeepfoodfreshforalongtimeanditis
mainly used to store frozen foods and making ice.
• Thefreezingchamberissuitableforstorageofmeat,sh,riceballsandotherfoods
not to be consumed in short term.
• Chunksofmeatarepreferablytobedividedintosmallpiecesforeasyaccess.Please
be noted food shall be consumed within the shelf time.
Drawers, food boxes, shelves, etc. placed according to the position in the picture
above are the most energy ecient.
Functions
(Thepictureaboveisonlyforreference.Theactualcongurationwilldependonthe
physical product or statement by the distributor)
Display screen
1Refrigerating chamber temperature display area 2Freezing chamber temperature
display area 3Quick cool icon 4Quick freeze icon 5Vacation icon 6Lock icon
Operation button
A. Temperature setting button of refrigerating chamber
B. Temperature setting button of freezing chamber
C. Vacation/lock button

20
Display
When power on the refrigerator for the 1st time, the whole display panel will shine for
3 seconds. Then the display panel enters the normal display. The rst time for using the
refrigerator,the default set temperatures of refrigerating chamber, freezing chamber is
5° C/-18 °C respectively.
Whentheerroroccurs,thedisplaypanelshowstheerrorcode(seenextpage);during
normal running, the display panel shows the set temperature of refrigerating chamber,
freezing chamber.
Under normal running, if there is no operation or opening door action within 30s, the
display panel will be locked,the light of display panel will go out after the locked state
continued for 30s.
Lock/unlock
In the unlock state, long press the lock button for 3 seconds, enter the lock state,
the icon lights up and buzzer sounds, it means the display panel is locked, at this
time, button operation cannot be implemented;
In the lock state, long press the lock button for 3 seconds, enter the unlock state,
the icon goes out and buzzer sounds, it means the display panel is unlocked, at this
time, button operation can be implemented.
Temperature setting of refrigerating chamber
Click the button to change the set temperature of refrigerating chamber, each
click of temperature adjusting button of the refrigerating chamber, the set temperature
will be reduced 1 °C. The temperature setting range of refrigerating chamber is 2~8 °C.
When the set temperature is 2 °C,
Temperature setting of freezing chamber
Click the button to change the set temperature of freezing chamber, each click
of temperature adjusting button of the freezing chamber, the set temperature will
be reduced 1 °C. The temperature setting range for freezing chamber is -24- -16 °C.
When the temperature is -24 °C, click the button again, the set temperature of freezing
chamber will switch to -16 °C.
Mode setting
Quick cool mode
Long press the button for 3s to set Quick cool mode, the icon lights up. The
refrigerating chamber temperature displays 2 °C, it enters the Quick cool mode.
Under Quick cool mode, press and hold button for 3 seconds or press briey,
the icon goes out, it exits Quick cool mode. The set temperature of refrigerating
chamber will automatically switch back to set temperature before.
