Lotim Cloud LCV05 Owner's manual

User Manual Book
Battery-powered Vehicle GPS Tracker
Model: LCV05

2/ 11
2/ 11
We’re appreciated that you choose on LCV05, a Battery-powered Vehicle
GPS Tracker as a tracking guard of your vehicles. Please read this user
manual book carefully and follow the instruction. It is suggested that you
keep this user manual book for future use.
CATALOG
1. Product description..................................................................................3
2. Warning ....................................................................................................3
3. Precautions...............................................................................................3
4. Production composition..........................................................................4
5. Hardware operation ................................................................................4
5.1 Insert SIM Card................................................................................4
5.2 Wiring...............................................................................................5
5.3 Place on Car/Vehicle.......................................................................5
6. Operation of indicator light.....................................................................6
7. Common command list............................................................................6
7.1 Query................................................................................................7
7.2 Setting ..............................................................................................7
8. Data sheet.................................................................................................7
9. Troubleshooting .......................................................................................8
10. Repair and disposal................................................................................9
11. Warranty card ......................................................................................11

3/ 11
3/ 11
1. Product description
The future will be battery-powered. It has to be. From electric cars to
industrial-scale solar farms, batteries are the key to a cleaner, more
efficient energy system — and the sooner we get there, the sooner we can
stop contributing to potentially catastrophic climate change. LCV05
designed with wide range power input and low power consumption, small
size, simple positive and negative power wiring, effective GNSS location,
choosing it as battery-powered vehicles tracking solution, we earn a low
cost but useful guard!
2. Warning
1) This device is suitable for adults. People with physical disability and
cognitive impairment must use it under the supervision of guardian.
2) Keep the product accessories and packaging materials away from
children, otherwise there may be accidents or choking hazard.
3) Do not use if it is damaged obviously.
4) The device is only used for its designed purpose and must be used in the
manner indicated. The manufacturer shall not be responsible for any
damage caused by any improper or reckless act.
5) It is strictly forbidden to use the equipment in violation of the operating
instructions, disassemble it without permission, collide, charge, soak in
water, exceed 80℃, man-made failure, force majeure damage, etc.,
otherwise it may cause short circuit, insufficient working time, battery
deformation, night leakage, explosion, etc. Loss, no warranty and
compensation will be made.
6) Clean the equipment in the prescribed way. Do not use any solvents and
disconnect the power supply in advance when cleaning.
3. Precautions
1) Do not exposed this device to rain and high temperature during
installation and use.
2) This product uses GPS and BeiDou satellite positioning, and there are
irresistible factors that cause positioning failure or abnormal

4/ 11
4/ 11
communication, such as bad weather, artificial shielding of wireless
signals, blind areas of wireless signal coverage, etc.
3) This device supports GSM/GPRS wireless communication network. To
achieve better communication and positioning performance, please be
sure not to place it in metal shielding boxes or under place with metal
surface.
4) This device requires the cooperation of the monitoring platform to
implement all its features. For details, please refer to the relevant
monitoring platform usage specifications.
5) The contents of this manual may be subject to change without notice.
Please refer to the actual product.
4. Production composition
5. Hardware operation
5.1 Insert SIM Card
Open the waterproof cover of the SIM card, insert a Micro SIM card in the
direction shown as below image, and the device will automatically turn on
after inserting the SIM card. After inserting the card, assemble the SIM
card cover, log in through the APP or platform to check its location.

5/ 11
5/ 11
Precautions:
1) If no SIM card is installed, the communication part of the terminal will
not be turned on; when a SIM card is installed, the device will be
powered on; when the SIM card is removed, the communication
terminal will automatically shut down.
2) The terminal SIM card needs to activate SMS and network
communication function.
3) Please ensure that the terminal SIM card has balance.
4) If your SIM card is turned on and you are required to enter the SIM PIN,
please refer to your mobile phone user manual to turn off the SIM PIN
input function.
5.2 Wiring
The device supports power input from 9~90V, red cable for positive and
black for negative, to avoid the short cut, please correctly handle the wire
metal connections by electric tape. The side with LED is with GPS antenna,
please keep it face toward sky during installation.
5.3 Place on Car/Vehicle

6/ 11
6/ 11
To gain higher location accuracy, it is recommended to install the device in
car or vehicle as images shown.
6. Operation of indicator light
By checking the status indicator, you can understand the working status of
the device. The status of the indicator is described as follows:
LED Color
LED Status
Meaning
Red
Solid bright
GSM network connected
Flashing
No GSM signal detected
Green
Solid bright
G
PRS internet well connected
Flashing
Failed to connect to server
Blue
Solid bright
Succeed to
GPS locate
Flashing
G
PS satellites searching
7. Common command list

7/ 11
7/ 11
7.1 Query
1 PARAM# Check the parameters
including IMEI number, APN, Server, Center,
Timer, Time Zone, Language, working mode, protocol mode.
2 STATUS#
Ch eck the device status, including external battery voltage,
internal battery percentage, GPRS status, GSM signal, GPS status,
GPS signal, ACC status.
3
WHERE#
or URL#
Check the Latitude and longitude
#URLSMS#<LOCALTime:2017-01-12,15:12:13>
http://map.google.com/maps?q=23.058233,113.380522
4 VERSION# Check the firmware version
7.2 Setting
Command Format
Description
Reply
1
SERVER,1,<domain>
o r IP,<port>#
Setting Domain name or
IP and Port
2
APN,
apn’s_name#
A
PN,apn’s_name,user,password#
APN setting
S
et APN OK!
3
RESET#
Restart device
System reboot OK
4
TIMER,
n#
n=3~300. means
every n
seconds update one
position to server
O
K!
8. Data sheet
HARDWARE
Location technology
GPS/Beidou/Galileo/Glonass/AGPS
Receiver
18*18*4mm, 66channels
Tracking sensitivity
-163dBm
Accuracy
3m
Hot/Warm/Cold start
<2s/<8s/<15s
Cellular technology
GSM/GPRS network, Quad-band, 850/900/1800/1900
SIM slot
Micro-SIM Card
Battery
N/A
Using environment
Workin g Temperature: -20
℃
~70
℃
Storage Temperature: -40℃~80℃

8/ 11
8/ 11
Humidity: 20%~80%
Power input
9~90V (suitable for electricity input 12V, 24V, 36V, 48V,
72V)
Wires
2 Cables (Power +, -)
Working Current
Engine off: <3mA@12V
Engine on: <25mA@12V
Auto Sleep Mode: <1.1mA@12V
Power anti-reversing
connection Supported
Surge protection
Supported, up to 1500W
INTERFACE
Antenna
GNSS/GSM
Sensors
3D G-Sensor
Indication
3 LEDs(Red, Green, Blue)
SOFTWARE
Firmware update
OTA
Protocols
ZTinfo Protocol, SMS/GPRS
More features
Soft ACC detection, hardware watchdog, 1000 location
packets storage, vibration alarm, external battery voltage
detection, vehicle battery low alarm etc.
PHYSICAL SPECIFICATIONS
Dimensions
50*20*7.5mm
Net weight
22g
CERTIFICATIONS & APPROVALS
Regulatory (Pending)
CE, FCC
9. Troubleshooting
FAQ
Reason
Solution
Bad Signal
When using terminals in areas with
poor signal reception, such as near tall
buildings or
in
basements, radio waves
cannot be effectively transmitted.
Use the terminal in a
n open air
area
Can't co nnect to the
network
The SIM card is not installed
Check the SIM card
Dirt on the metal surface of the SIM
card
slot
Wipe with a clean cloth

9/ 11
9/ 11
SIM card is invalid
Contact your network service
provider
Out of GSM service area
Please move to the network
service provider
service area
Weak signal
Please move to a place with
strong signal and try again
Unable to charge
The voltage is inconsistent with th e
range marked by the charger
Please use the same voltage as
the charger
Use a non
-standard charger
Please use the charger provided
by the factory
Bad Signal
Poor contact
Check if the plug is connected
When using terminals in areas with
poor signal reception, such as near tall
buildings or basements, radio waves
cannot be effectively transmitted
Use the
terminal in a location
with good signal
Can’t turn on device
Battery Dead
Use after charging
Can't co nnect to the
network
The SIM card is not installed
Check the SIM card
Dirt on the metal surface of the SIM
card
Wipe with a clean cloth
SIM card is
invalid
Contact your network service
provider
Out of GSM service area
Please move to the network
service provider service area
Weak signal
Please move to a place with
strong signal and try again
Unable to charge
The voltage is inconsistent with th e
ra
nge marked by the charger
Please use the same voltage as
the charger
Use a non
-standard charger
Please use the charger provided
by the factory
Poor contact
Check if the plug is connected
10. Repair and disposal
1) Never attempt to repair the instrument or adjust it yourself. We can no
longer guarantee perfect functioning if you do it.
2) Repairs may only be performed by Customer Service or authorized
dealers.
3) For environmental reasons, do not dispose of the device in the
household waste at the end of its useful life. Dispose of the unit at a
suitable local collection or recycling point. Dispose of the device in
accordance with EC Directive ‒ WEEE (Waste Electrical and Electronic

10 / 11
10 / 11
Equipment).
4) If you have any questions, please contact the local department
responsible for waste disposal.

11 / 11
11 / 11
11. Warranty card
Maintenance Card
Maintenance
shop
Delivery information
Fault
description
Maintenance result
IMEI
number
O
perator
