Lotim Cloud LCV07 Owner's manual

User Manual Book
4G+2G Vehicle GPS Tracker
Model: LCV07

2/ 12
We’re appreciated that you choose on LCV07, an affordable 4G+2G Vehicle
GPS Tracker as a tracking guard of your vehicles. Please read this user
manual book carefully and follow the instruction. It is suggested that you
keep this user manual book for future use.
CATALOG
1. Product description..................................................................................3
2. Warning ....................................................................................................3
3. Precautions...............................................................................................3
4. Production composition ..........................................................................4
5. Hardware operation ................................................................................4
5.1 Insert SIM Card................................................................................4
5.2 Wiring...............................................................................................5
5.3 Place on Car/Vehicle.......................................................................6
6. Operation of indicator light.....................................................................7
7. Common command list............................................................................7
7.1 Query................................................................................................7
7.2 Setting..............................................................................................8
8. Data sheet.................................................................................................9
9. Troubleshooting.....................................................................................10
10. Repair and disposal..............................................................................11
11. Warranty card ......................................................................................12

3/ 12
1. Product description
LCV07 4G Vehicle GPS Tracker is a mini, easy-installation, 4G LTE +2GGPRS
network supported vehicle GPS Tracker, it supports 9-90V wide range
power input. It could widely applied in monitoring the trucks, cars,
motorcycle, electric scooters, etc. It has powerful and accurate satellite
location feature with 25*25mm GPS antenna. Optionally, it supports SOS
button and Microphone features.
2. Warning
1) This device is suitable for adults. People with physical disability and
cognitive impairment must use it under the supervision of guardian.
2) Keep the product accessories and packaging materials away from
children, otherwise there may be accidents or choking hazard.
3) Do not use if it is damaged obviously.
4) The device is only used for its designed purpose and must be used in the
manner indicated. The manufacturer shall not be responsible for any
damage caused by any improper or reckless act.
5) It is strictly forbidden to use the equipment in violation of the operating
instructions, disassemble it without permission, collide, charge, soak in
water, exceed 80℃, man-made failure, force majeure damage, etc.,
otherwise it may cause short circuit, insufficient working time, battery
deformation, night leakage, explosion, etc. Loss, no warranty and
compensation will be made.
6) Clean the equipment in the prescribed way. Do not use any solvents and
disconnect the power supply in advance when cleaning.
3. Precautions
1) Do not exposed this device to rain and high temperature during
installation and use.
2) This product uses GPS and BeiDou satellite positioning, and there are
irresistible factors that cause positioning failure or abnormal
communication, such as bad weather, artificial shielding of wireless
signals, blind areas of wireless signal coverage, etc.

4/ 12
3) This device supports 4G CAT1 +2G GPRS wireless communication
network. To achieve better communication and positioning
performance, please be sure not to place it in metal shielding boxes or
under place with metal surface.
4) This device requires the cooperation of the monitoring platform to
implement all its features. For details, please refer to the relevant
monitoring platform usage specifications.
5) The contents of this manual may be subject to change without notice.
Please refer to the actual product.
4. Production composition
No.
Item
Quantity
Note
1
Main Unit
1PCS
2
Power Cable
1PCS
Length=1 meter
3
Relay Set 12V or 24V
2SET
Optional
No.
Feature
Instruction
1
Power Positive
Red, input range from 9V to 90V
2
Power Negative
Black cable
3
ACC Input
Orange, connect to ACC signal
4
Relay Output
Yellow, connect to external relay
5. Hardware operation
5.1 Insert SIM Card
Please purchase the right SIM card instructed as below. And confirm with
the carrier if these SIM cards have 4G CAT-1 network well supported.
Normal Micro Nano

5/ 12
Inset the SIM card as guide below. Please make sure the device is power
off before insert or remove the SIM card.
;
Precautions:
1) The terminal SIM card needs to activate SMS and network
communication function.
2) SIM must not be insert reversely; SIM should be 4G CAT 1 +2G GPRS
network supported; Make sure the SIM with enough balance.
3) If your SIM card is turned on and you are required to enter the SIM PIN,
please refer to your mobile phone user manual to turn off the SIM PIN
input function.
5.2 Wiring
The device supports power input from 9~90V, red cable for positive and
black for negative, to avoid the short cut, please correctly handle the wire
metal connections by electric tape. The side with LED is with GPS antenna,
please keep it face toward sky during installation.
Step 1: Uncover the case
Step 4: Switch to Power on and install case
Step 3: Insert the SIM card
Step 2: Open the SIM slot

6/ 12
5.3 Place on Car/Vehicle
To gain higher location accuracy, it is recommended to install the device in
car or vehicle as images shown.
Under the rear windshield
Near the dashboard
Under the front
windshield
Under the seat
Under the
front cover
Under the seat
Inside the LED
(near Dashboard)
Inside the front cover

7/ 12
6. Operation of indicator light
By checking the status indicator, you can understand the working status of
the device. The status of the indicator is described as follows:
LED Color
LED Status
Meaning
Red --- Power
Solid bright
External power connecting
Quick Flashing (0.3S on, 0.3s off)
No external power connected;
internal battery low
Slow Flashing 1 (1s on, 3s off)
Battery fully recharged
Slow Flashing 2(0.1 on, 3s off)
Device working normally
Off
Power off / problem device
Green --- Network
Quick Flashing (0.3S on, 0.3s off)
GSM network initializing
Slow Flashing 1 (1S on, 3s off)
4G signals normally
Slow Flashing 2(0.1 on, 3s off)
Online connection successfully
Solid bright
Phone calling
Blue --- Satellite
Solid bright
GNSS positioning successfully
Quick Flashing (0.3S on, 0.3s off)
GNSS signal searching (It locates
faster if in open air)
Off
GNSS sleeping or not working
7. Common command list
7.1 Query
Command
Description
VERSION#
Firmware version
REBOOT#
Restart the device
SIMINFO#
SIM working status, ICCID
MILEAGE#
Total mileage
VOLT#
Charging status, internal battery voltage, external battery
voltage
POSITION#
Position time, Google link
CHECK#
IMEI number, SOS number, SERVER setting, APN, timer, ACC
status, GPS status, working mode, firmware version, internal
battery voltage, external battery voltage

8/ 12
7.2 Setting
Parameter
Format
Description
SERVER
SET-
server,0/1,Domain/I
P,Port#
GET-SERVER#
Set up the server for receiving GPS data
0 means by IP, 1 means by domain
TIMER
SET-TIMER,T1,T2#
T1 is ACC ON upload interval, T2 is ACC OFF upload
interval
T1/T2 range from 0/3-18000 seconds. 0 means no
uploads
In default, T1=10s, T2=0s
HBT
SET-HBT,T#
Set up the Heartbeat upload interval
T ranges from 1-600 minutes, in default, T=3
IGNITIONCHG
SET-
IGNITIONCHG,ON/OF
F#
GET-IGNITIONCHG#
Set up alarm if ACC status changed
In default, it is OFF
APN
SET-APN,apn's
name#
SET-APN,apn's
name,username,pass
word#
GET-APN#
Set up the internet access point name
PHONE NUMBER
SET-
PHONE,A,NUMBER#
SET-
PHONE,D,NUMBER#
GET-PHONE#
Set up admin phone number, A is add the number, D is
delete the number, allow adding three number
RELAY Control
Relay,M#
M=0/1, 0 means to restore, 1 means to cut off, default
M=0
Support on new firmware
CUT-OIL,Y#
CUT-OIL,N#
CUT-OIL#
Same function as RELAY,M#
Set up Relay status to cut-off or restore fuel supply
N means to restore, Y means to cut off, in default =N
TIMEZONE
SET-
TIMEZONE,A,B,C#
GET-TIMEZONE#
Set up time zone, if manually set up Timezone,
ADAPTGMT will be off automatically
A means time zone range, A=E/W, E means east, W
means West
B means time zone number, range 0-12
C is semi time zone, range 0/15/30/45
SPEEDALM
SET-
SPEEDALM,SW,M,V,T
#
GET-SPEEDALM#
Set up overspeed alarm
SW means the switch, SW=on/off, in default SW=OFF
M is the alarm mode, M=0/1, 0 is only platform alarm,
1 is platform + SMS alarm, in default M=0,
V is the speed threshold, range 1-255km/h, in default
V=50,
T is overspeed duration, range 5-600s, in default T=20

9/ 12
ODOMETER
SET-
ODOMETER,SW,L,k#
GET-ODOMETER#
Set up mileage function
SW means the switch, SW=on/off, in default SW=OFF,
L is the mileage original data on vehicle dashboard,
range 0-999999km, in default L=0,
K is the coefficient of variable vehicle dashboard to
variable GPS tracker, in default K=1000.
8. Data sheet
HARDWARE
Location technology
GPS/Beidou
Receiver
25*25*2mm, 66channels
GNSS sensitivity
Tracking: -165dBm
Acquisition: -148dBm
Accuracy
10m
Hot/ Cold start
<5s/<32s (open sky)
Cellular technology
4G CAT-1 network FDD: B1/B3/B5/B7/B8/B20,
TDD: B34/B38/B39/B40/B41
2G GSM: 900/1800Mhz
SIM slot
Nano SIM Card
Battery
55mAh/3.7V Lithium-polymer battery
Internal memory
8MB
Using environment
Working Temperature: -20℃~70℃
Storage Temperature: -40℃~80℃
Humidity: 20%~80%
Power input
9~90V (suitable for electricity input 12V, 24V, 36V, 48V,
72V)
Wires
4 Cables (power +, power -, relay, ACC)
Working Current
<5mA (built-in battery)
Power anti-reversing
connection
Supported
Surge protection
Supported, up to 1500W
INTERFACE
Antenna
GNSS/GSM
Sensors
3D G-Sensor
Indication
3 LEDs (Red, Green, Blue)
SOFTWARE
Firmware update
OTA
Protocols
JT/T 808 Protocol
More features
Geo-fence, GNSS location, tow alarm, overspeed alarm,
UBI, auto-defensing, vibration alarm, external battery

10 / 12
voltage detection, vehicle battery low alarm, remote cut-
off engine, etc.
UART Port
Optional
SOS button
Optional
PHYSICAL SPECIFICATIONS
Dimensions
75*30*13mm
Net weight
30g
CERTIFICATIONS & APPROVALS
Regulatory (Pending)
CE, FCC
9. Troubleshooting
FAQ
Reason
Solution
Bad Signal
When using terminals in areas with
poor signal reception, such as near tall
buildings or in basements, radio waves
cannot be effectively transmitted.
Use the terminal in an open air
area
Can't connect to the
network
The SIM card is not installed
Check the SIM card
Dirt on the metal surface of the SIM
card slot
Wipe with a clean cloth
SIM card is invalid
Contact your network service
provider
Out of GSM service area
Please move to the network
service provider service area
Weak signal
Please move to a place with
strong signal and try again
Unable to charge
The voltage is inconsistent with the
range marked by the charger
Please use the same voltage as
the charger
Use a non-standard charger
Please use the charger provided
by the factory
Bad Signal
Poor contact
Check if the plug is connected
When using terminals in areas with
poor signal reception, such as near tall
buildings or basements, radio waves
cannot be effectively transmitted
Use the terminal in a location
with good signal
Can’t turn on device
Battery Dead
Use after charging
Can't connect to the
network
The SIM card is not installed
Check the SIM card
Dirt on the metal surface of the SIM
card
Wipe with a clean cloth
SIM card is invalid
Contact your network service
provider

11 / 12
Out of GSM service area
Please move to the network
service provider service area
Weak signal
Please move to a place with
strong signal and try again
Unable to charge
The voltage is inconsistent with the
range marked by the charger
Please use the same voltage as
the charger
Use a non-standard charger
Please use the charger provided
by the factory
Poor contact
Check if the plug is connected
10. Repair and disposal
1) Never attempt to repair the instrument or adjust it yourself. We can no
longer guarantee perfect functioning if you do it.
2) Repairs may only be performed by Customer Service or authorized
dealers.
3) For environmental reasons, do not dispose of the device in the
household waste at the end of its useful life. Dispose of the unit at a
suitable local collection or recycling point. Dispose of the device in
accordance with EC Directive ‒ WEEE (Waste Electrical and Electronic
Equipment).
4) If you have any questions, please contact the local department
responsible for waste disposal.

12 / 12
11. Warranty card
Maintenance Card
Maintenance shop
Delivery information
Fault description
Maintenance result
IMEI number
Operator
