Louroe Electronics DIGIFACT A User manual

The Digifact™ A is a networked audio monitoring and streaming device which streams audio over
several industry standard RTP protocols. The wide dynamic range microphone supports a wide
frequency response capable of picking up low and high frequency sounds. The device features a
robust quad-core microprocessor that has the capability of integrating signal processing
applications, audio enhancements and analytic applications. Analytic applications can be added to
the device to detect and report events such as:
- Aggression/Duress
- Gunshots/Explosions
- Breaking Glass
- Car/Panic Alarms
PAGE 1 OF 6
NOTE:
A Microphone is NOT recommended for
outdoor use or in areas with high moisture
content.
Digifact™
DESCRIPTION
DIGIFACT A
TM
AUDIO STREAMING AND ANALYTIC SYSTEM
DATASHEET AND QUICK START GUIDE
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: [phone] / FAX: [phone]
/ www.louroe.com[email protected]
®
Digifact _A_mic-inst_01/18™
WARRANTY
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
®
®
®
®
®
®
IMPORTANT NOTICE
When this equipment is used as part of an
audio monitoring system, the law requires
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
decal notice is included with each
microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.
AUDIO
MONITORING
On
These Premises
®
LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
M
A
N
U
F
A
C
T
U
R
E
D
I
N
T
H
E
Rear
Front

AUDIO
Audio Streaming: One-way
Audio Compression: PCM,16 bits linear
G.711 a-Law
G.711 mu-Law
G.726-40
AAC
Sensitivity: -45 dBV/Pa, 1 Pa = 94 dB SPL
Frequency Response: 50 Hz to 15 kHz
TECHNICAL SPECIFICATIONS
Page 2 of 6
LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
Digifact _A_mic-inst_01/18™
NETWORK
Security: Password protection, user level access (admin and operator)
Supported protocols: IPv4, HTTP, RTSP, RTP, TCP, SSH
SYSTEM INTEGRATION
Application programming: Open API for software integration, specifications at www.louroe.com
interface
Analytics: Louroe/SI audio analytics, audio level (dB) alarm
Event triggers: Analytics, audio level
Event actions: TCP notification, external output activation, pre and post-alarm audio recording
to Network Attached Storage (NAS)
GENERAL
Enclosure:
Power: Power over Ethernet IEEE802.3af
external 5V DC 2A (2-pin header)
Memory: 512 MB RAM
Event triggers: Audio analytics, decibel threshold
Event actions: TCP notification, external output activation, pre and post-alarm audio recording
to Network Attached Storage (NAS)
Connectors: Female RJ45 for 10BASE-T/100BASE-TX PoE; 5-pin header for four outputs
(5V DC), max load 100mA; 2-pin header for 5V DC 2A input
Operating Conditions: -20 C to 50 C Humidity 10-85% RH
Storage Conditions:
Dimensions: 4.7 in (119mm) diameter x 2.0 in (50.8mm) height
Weight: 9.0 oz
Packaged weight: 1.0 lb
Included accessories: User manual, 5-pin and 2-pin headers
optional
oo
High Impact Anti-Static ABS
-30 C to 60 C
oo

NETWORK AND POWER CONNECTION
INSTALLATION TIP: For instances where the CAT5/6 cable is to make a side entry to the rear of the unit, it is
recommended that the cable not be terminated using a molded strain relief, and instead the cable wound once
around the inner ring of the device to provide strain relief to the cable.
MOUNTING
The Digifact Model A is cylindrical, 4.7” dia. x 2” H, and has four mounting holes for surface mounting to a
ceiling or other flat surface. It should be positioned so that the microphone is 4’ to 8’ from the area of desired
coverage.
™
INSTALLATION AND CONNECTIONS
Page 3 of 6
LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
Digifact _A_mic-inst_01/18™
ALARM OUTPUT CONNECTIONS
AFemale Rj45 jack is located on the rear of the unit for 10BASE-T/100BASE-TX PoE connection using
CAT5/6 cable. If no PoE connection is available (network only) an optional two-pin header is available for
connection of a 5V DC 2A external power supply (not included), as depicted in the image below. Once
the device is powered on (PoE or ext power) the blue light on the front of the device should turn on.
Four digital alarm output ports are available for connection to external devices, the alarm
outputs can be set to trigger from analytic and volume threshold events. If used with an
inductive load, e.g. a relay, a diode must be connected in parallel with the load, for protection
against voltage transients.
FUNCTION PIN NOTES
5V DC 1 Max load 100mA
Output 1 2
Output 2 3
Output 3 4
Output 4 5
PIN 1 PIN 5
ALARM OUTPUT
+5VDC GND
EXT POWER
WIRE TERMINATIONS:
Alarm output and external power supply ports use a 5 and 2
position respectively 0.1” (2.54mm) pitch vertical header, the
mating connector needs to be terminated by the installer,
recommended mating connectors are:
5-pin: TE Conn 3-640441-5
2-pin: TE Conn 3-640441-2

DEVICE DISCOVERY
The Digifact A is by default set to obtain an IP address from the network it is connected to (DHCP), hence it
must be connected to a suitable DHCP server. To discover the device on a network, the following commands
need to be run through windows powershell to locate the device name;
dns-sd -B _simic._tcp
DEVICE DISCOVERY AND DEFAULT PASSWORD CHANGE
Page 4 of 6
LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
Digifact _A_mic-inst_01/18™
Once the device name has been located, the following script must be run:
to locate the device IP address:
dns-sd -G v4 .local<devicename>
The device IP address can them be typed into an internet browser (Chrome, Internet Explorer, Firefox etc.) to
access the device user interface page.
DEFAULT PASSWORD CHANGE
On first use the default password for the device is;
username: admin
password: admin
After entering the above information, the device will request the user to change the default password
Once the default password has been changed the device prompts to re-enter the new password to login
to the device.

The live view screen of the device contains information and controls such as;
Device firmware version, device name, acoustic monitoring settings, sound detector settings, audio activity
spectrogram, listen live control, ability to add analytic licenses as well as access to the other device parameter
pages.
LIVE VIEW PAGE
Page 5 of 6
LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
Digifact _A_mic-inst_01/18™
LIVE VIEW
Device firmware:
Acoustic Monitoring settings:
Sound Detector activity:
Live audio:
Add Analytics License:
System and firmware updates can be periodically updated from
Allows for enabling level triggering, setting level threshold, adjustment of
streaming volume level (dB), adjustment of time and volume over ambient threshold (for analytic applications).
Graphic representation of sound activity level and classification (for analytic
applications) of audio signals detected by the device.
Allows for enabling/disabling of live audio stream played from the speakers of the device from
where the device user interface is being accessed.
Used to add audio analytic detector application licenses to the device, note clicking
on the button displays a dialog page with the serial number of the device, using the serial number licenses can
be requested by either calling Louroe customer service at: 1-818-994-6498 and/or emailing the serial number
to with information regarding the type of application/s desired.
www.louroe.com
[email protected]

The icon on the top left hand side of the live view page, grants access to miscellaneous device parameters
such as;
Revert to default settings - sets device setting to factory default
Reboot - reboot’s the device
Device Name - character text box to rename the device (numeric and alpha-numeric only, no spaces)
Enable Live audio streaming - turns the audio stream on/off
Start/Stop/Change Analytics - starts/stops and modifies the type of analytic applications running on the device
Update to new firmware - updates device firmware; source file can be downloadeded from
System Control:
www.louroe.com
www.louroe.com
[email protected]
Storage configuration:
VMS configuration:
Network Settings:
Date and Time configuration:
Peer devices:
Status:
Log:
Used to configure parameters for network attached storage device (NAS)
Used to configure meta-data transmission to Video Management Systems (VMS), detailed application notes of
adding and configuring devices to VMS’s can be found at
Set the device to a static IP address and configure device IP settings.
Configure devices date/time settings
Used to detect and configure other Louroe devices on the same subnet.
Displays device status/health parameters such as; CPU usage and temperature, memory and network status.
Provides day/time stamped entries of system events, please note in the event of reported issues with the
device please send a detailed email to and attach the latest downloaded copy of the
log data for analysis and troubleshooting
MISCELLANEOUS DEVICE PARAMETERS
Page 6 of 6
LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
Digifact _A_mic-inst_01/18™
DEVICE PARAMETERS
