Lowry LDH2002 User manual

20L Dehumidifier
For Customer Services & Spare Parts please call0345 2097461
Opening times: Monday -Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE
Model Number: LDH2002
220-240V AC 50/60Hz 440W

Page(s)
Safety
Instructions and Electrical Safety 3 - 4
Feature
Diagram 5
Control Panel
Diagram 6
Positioning your Dehumidifier
7
Using your
Dehumidifier 8 -12
Emptying
your Dehumidifier 13
Cleaning and Care
14 -15
Troubleshooting
16
Guarantee and Customer
Services 17
Spare
Parts 18
Connection to the Mains Supply
19
Notes
20
Specification
21
CONTENTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Page 2

Safety Instructions
Important note: Please read this booklet before installing and switching on this
appliance. The manufacturer assumes no responsibility for incorrect installation and
usage as described in this booklet.
•This model uses natural refrigerant gas as part of its cooling system. This gas
is known as R134a (tetrafluoroethane) and is environmentally friendly but can
be combustible. Care should therefore be taken when handling or transporting
the product to ensure that none of the refrigeration circuit components are
damaged,
•Do not obstruct ventilation openings in the appliance.
•Do not cover the appliance or place any object on the control panel
•The appliance must not be placed or rested on its power cord.
•Do not use adaptors or extension leads when connecting the appliance to the
electrical power supply
•Do not plug in if the plug is damaged.
•Do not pull, twist or damage the power cable.
•Do not plug-in or un-plug the appliance with wet hands to prevent electrical
shock.
•Always store the unit in an upright position in order to maintain the compressor
working in a proper condition.
•Never insert your finger or any other object into the air outlet
•This appliance can be used by childrenaged from 8 years and above and
persons with reduced physical, sensoryor mental capabilitiesor lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance.
•This appliance is designed to be used by adults, do not allow childrento play
with the appliance.
•The appliance is intended for residential use only.
Page 3

Safety Instructions
•Do not use in the following locations:-
Next to a source of fire.
An area where oil is likely to splash.
An area exposed to direct sunlight.
An area where water is likely to splash.
Near a bath, shower or a swimming pool.
In a greenhouse.
An area where flammable gasses or liquids are present.
Electrical Safety
THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET
•Before switching on, make sure that the voltage of your electricity supply is the
same as that indicated on the rating plate. This product is designed to operate
on 220 –240V AC; 50Hz. Connection to any other power source may damage the
unit.
•This product may be fitted with a non re-wireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.
•If the plug has to be changed because it is not suitable for your socket, or
becomes damaged in any way, it should be cut off and an appropriate plug fitted
following the wiring instructions below. This should be carried out by a qualified
electrician. The plug removed must be disposed of safely, as insertion into a 13
Amp socket is likely to cause an electrical hazard.
Page 4

FEATURE DIAGRAM
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
x
1. Control panel
2. Air outlet grille
3. Water drawer
4. Handles
1.
2.
3.
4. 5.
7.
6.
5. Air inlet grille/filter
6. Power cord storage
7. Drain hose outlet
Page 5

CONTROL PANEL DIAGRAM
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
1. Power
2. Mode Selection
3. Up Control Pad
4. Display
5. Down Control Pad
6. Timer
7. Turbo
8. Ioniser Function
1.
2.
3.
4.
5.
6.
7.
8.
Page 6
Ioniser
Indicator
Turbo Indicator
Timer On/Off
Indicator
Water drawer
full Indicator
Dryer Operation
Indicator
Continuous Operation
Indicator Smart
Dehumidifying
Operation Indicator
Power Indicator

•This dehumidifier is intended for indoor residential applications
only. This dehumidifier should not be used for commercial or
industrial applications.
•Place the dehumidifier on a smooth, level floor strong enough to
support the unit with a full drawer of water.
•Allow at least 20cm of air space on all sides of the unit for good air
circulation.
•Allow at least 40cm of air space above the unit for good air
circulation.
•Place the unit in an area where the temperature will not fall below
5⁰C (41 ⁰ F). The coils can become covered with frost at
temperatures below 5⁰C (41 ⁰ F), which may reduce performance.
•Place the unit away from clothes dryers, heaters or radiators.
•The dehumidifier must be operated in an enclosed area to be most
effective.
•Close all doors, windows and other outside openings
•Do not use outdoors.
POSITIONING YOUR
DEHUMIDIFIER
Page 7

When using the dehumidifier for the first time, run the unit in
continuous mode for 24 hours
Turning the Unit On
Remove all packaging and plug the unit into a socket.
Ensure the water drawer is correctly positioned and the drain plug is
fully inserted into the drain hose outlet on the back of the unit.
Press the Power button to turn the dehumidifier on and off. The light
next to the Power button will display green when the unit is turned on.
When the unit is first switched on, the display shows the actual room
% humidity level (within 5% accuracy).
The humidity level can be set using the instructions for “Setting the
Humidity”.
Continuous Extraction Mode
In Continuous Extraction Mode, the unit will run at a high extraction
rate until the water drawer reaches the max fill level.
Press the Mode button until the light next to “Cont.” (Continuous
Extraction) is illuminated green.
Press the Mode button again twice to cancel the continuous extraction.
Note: The humidity cannot be set when the unit is operating in
Continuous Mode.
Smart Dehumidifying Mode
In the smart dehumidifying mode, the unit will automatically control
room humidity in a comfortable range 45%~55% according to the room
temperature.
Press the Mode button until the light next to “SMD.” (Smart
Dehumidifying Mode) is illuminated green.
Press the Mode button again once to cancel the Smart
Dehumidification Mode.
Note: The humidity cannot be set when the unit is operating in
Continuous Mode.
USING YOUR DEHUMIDIFIER
Page 8

Dryer Mode
For maximum extraction rate when drying clothing, use the Dryer
Mode.
The dryer mode functions like the Continuous Extraction mode but
with the additional boost of the Turbo Function. The humidity level is
automatically controlled according to the actual room humidity. The
unit will run in Drying mode for a maximum of 10 hours, or until the
water drawer is full.
Press the Mode button until the light next to “Dryer.” is illuminated
green.
Press the Mode button three times to cancel the dryer function.
Note:
The humidity cannot be set when the unit is operating in Dryer Mode.
The dryer mode must be operated in a closed room. Do not operate
with a door or window open.
Place clothes 30-50cm from the unit for best drying results.
Caution:
Do not cover the ait outlet with wet clothing, or do not place wet
clothing above the unit.
Setting the Humidity
The desired humidity level can be set within a range of 35% to 85%
Relative Humidity in 5% increments by pressing the + and –keys.
To select the desired humidity level ensure the unit is not on Dryer,
Smart Dehumidification or Continuous Extraction mode.
None of the Mode indicator lights should be green. Press the Mode
button until none of the lights are illuminated.
Use the Up and Down control pads to select the desired humidity. The
display will flash while the humidity is being set.
For drier air, press the pad and set to a lower percent value(%).
For damper air, press the pad and set a higher percent value(%).
USING YOUR DEHUMIDIFIER
Page 9

USING YOUR DEHUMIDIFIER
Page 10
Setting the Timer
Delayed Start
The unit must be switched OFF for the Auto Start function to be
programmed.
With the unit switched off, press the Timer button until the Timer On
indicator is illuminated. “0.0” will be displayed.
Use the up and down controls to select the desired delayed start time.
The delayed start time can be adjusted in 0.5 hour increments up to 10
hours, and then in 1 hour increments up to 25 hours.
The selected time will stay on the display for 5 seconds, and will then
disappear. The countdown to the start time can be viewed by pressing the
Timer button again.
Auto Stop
The Auto Stop function can be set when the unit is either switched On or
Off.
Press the Timer button until the Timer Off indicator is illuminated.
Use the up and down controls to select the desired end time.
The stop time can be adjusted in 0.5 hour increments up to 10 hours, and
then in 1 hour increments up to 25 hours.
The selected time will stay on the display for 5 seconds, and will then
disappear. The Auto Stop time can be viewed by pressing the Timer button
again.
Both the Delayed Start and Auto Stop functions can be initiated in the
same sequence. In this instance, both Timer On and Off indicators will be
illuminated.
Note: Turning the unit On or Off at any time will cancel the Delayed Start
or Auto Stop functions and the unit can take 2 minutes to restart.
If the time is adjusted to “0.0” this will also cancel the Timer function.
If the water drawer is full or “P2” is displayed, the Delayed Start and Auto
Stop functions will be cancelled.

Other features
Auto Shut Off
The dehumidifier will shut off automatically under the following
conditions:
•When the water drawer is full
•When the water drawer is removed
•When the water drawer is not replaced in the proper position
•When the selected humidity level is reached
Water Drawer Full Indicator light
•The indicator light will illuminate red under the following conditions:
•When the water drawer is full
•When the water drawer is removed
•When the water drawer is not replaced in the proper position
3 Minute Restart
After the unit has stopped, it cannot be restarted for 3 minutes. This is
to protect the unit. Operation will automatically start after 3 minutes.
Auto Defrost
When frost builds up on the evaporator coils, the compressor will cycle
off and the fan will continue to run until the frost disappears.
Auto-Restart
If the unit turns off unexpectedly due to a power cut, it will restart with
the previous function setting automatically when the power resumes.
USING YOUR DEHUMIDIFIER
Page 11

Error Codes
AS –Humidity Sensor Error. Unplug the unit and plug it back in. if the
error continues, call customer service.
ES –Temperature Sensor Error –Unplug the unit and plug it back in. If
error continues, call customer service.
P1 –Unit is defrosting. Allow the unit time to automatically defrost. The
error code will disappear once the unit has defrosted.
P2 –Water drawer is full or drawer is not in the right position. Empty
the drawer and replace in the correct position.
E3 –Unit malfunction –unplug the unit and plug back in. If the error
repeats, call customer service.
EC -Refrigerant leakage detection. With this new technology, the display
area will appear EC when the unit detects refrigerant leakage, call
customer service.
USING YOUR DEHUMIDIFIER
Page 12

There are two ways to remove collected water:
Collection in the Water Drawer
When the water drawer is full, the unit will beep 8 times and will
automatically stop running. The Full indicator light will flash and the
display will show “P2”.
Slowly pull out the drawer. Grip the left and right handles securely,
and carefully pull out straight so water does not spill. Do not put the
drawer down because the bottom of the drawer is uneven.
Empty the water and replace the drawer. The drawer must be
correctly inserted for the dehumidifier to restart operation.
Continuous Draining
Water can be automatically emptied into a floor drain by attaching the
unit with a 13.5mm hose (not supplied).
Remove the rubber bung from the Drain Hose Outlet on the back of
the unit.
Insert the hose into the Drain Hose Outlet in the back of the unit as
shown below.
EMPTYING YOUR DEHUMIDIFIER
Lead the water hose to a suitable drainage
facility. The drainage facility should be lower
than the drain outlet of the unit.
Be sure to run the water hose sloping
downward and let the water to flow out
smoothly.
NOTE: When the continuous drain feature is
not being used, remove the drain hose from
the outlet and attach the rubber plug back to
the drain outlet.
Page 13

Cleaning the Air Filter
The air filter is located behind the back of the unit. The Air Inlet
Grille/Filter should be checked and cleaned at least every 30 days or
more often if necessary.
NOTE: DO NOT PUT THE FILTER IN AN AUTOMATIC DISHWASHER
To Remove the Air Filter:
Push both tabs on the Air Inlet Grille/Filter upwards.
Clean the filter with warm, soapy water. Rinse and let the filter dry
before replacing it. Do not clean the filter in a dishwasher.
To Replace the Air Filter
Insert the top of the Air Inlet Grille/Filter into the unit, then click the
bottom tabs into place.
CAUTION:
DO NOT operate the dehumidifier without a filter. This will cause dirt
and lint to build up and clog the unit and will reduce performance.
CLEANING AND CARE
Air Filter
Tabs
Page 14

Turn the dehumidifier off and remove the plug from the wall outlet
before cleaning.
Cleaning the Grille and Case
Use water and a mild detergent. Do not use bleach or abrasives.
Do not splash water directly onto the main unit. Doing so may cause
an electrical shock, cause the insulation to deteriorate, or cause the
unit to rust.
The air intake and outlet grilles get soiled easily, so use a vacuum
attachment or brush to clean.
Cleaning the Water Drawer
Every few weeks, clean the drawer to prevent growth of mould,
mildew and bacteria. Partially fill the drawer with clean water and
add a little mild detergent. Swish it around in the drawer, empty and
rinse.
NOTE: Do not use a dishwasher to clean the drawer. After clean, the
drawer must be in place and securely seated for the dehumidifier to
operate.
When not using the unit for long time periods
After turning off the unit, wait 24 hours before emptying the drawer.
Clean the main unit, drawer and air filter.
Wrap the cord and bundle it with the band and cover the unit with a
plastic bag.
Store the unit upright in a dry, well-ventilated place.
CLEANING AND CARE
Page 15

TROUBLE SHOOTING
Problem
What to check
Unit does
not start
•
Make sure the dehumidifier’s plug is pushed
completely into the socket outlet.
•
Check the house fuse/circuit breaker box.
•
Dehumidifier has reached its preset level or
drawer is full.
•
Drawer is not in the proper position.
Dehumidifier does not dry
the air as it should
•
Did not allow enough time to remove the
moisture.
•
Make sure there are no curtains, blinds or
furniture blocking the front or back of the
dehumidifier.
•
The humidity selector may not be set low
enough.
•
Check that all doors, windows and other
openings are securely closed.
•
Room temperature is too low, below 5 C(41 F).
•There is a kerosene heater or something giving
off water vapour in the room.
The unit makes a loud
sound when operating
•
The air filter is clogged.
•The unit is tilted instead of upright as it should
be.
•
The floor surface is not level.
Frost
appears on the coils
•
This is normal. The unit has Auto defrost
feature.
Water on the floor
•
Hose to connector or hose connection may be
loose.
•
Intend to use the drawer to collect water, but
the back drain plug is removed.
ES, AS, P1
or P2 appear on
the display
•
These are Error/Protection codes. Refer to
page 12 of the instruction manual.
Page 16

GUARANTEE AND CUSTOMER SERVICES
At Lowry, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday –Friday: 8am-8pm & Saturday: 9am –1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
•The product must be returned to the retailer with the original
proof of purchase.
•The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
•It must be used for domestic purposes only and for its intended
use.
•This warranty does not cover wear and tear, damage, misuse
or consumable parts.
This does not affect your statutory rights.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Page 17

SPARE PARTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
To check the availability of the following spare parts, simply contact
our friendly Customer Services team using the details provided at the
bottom of this page.
Air Filter
Drain Hose Bung
Page 18

CONNECTION TOTHEMAINSSUPPLY
This appliance is designed to operate from a mains supply of
220-240V~50/60Hz.
Check that the voltage marked on the product corresponds
with your supply voltage.
How to change the fuse
1. Slot the end of a screwdriver into the
recess in the fuse holder of the plug.
2. Pull the fuse holder upwards until free
of the plug and slide the fuse out.
3. Replace the fuse and replace fuse
holder, pushing down until locked into
place.
Important: Only ever use a 13 amp fuse.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Page 19

NOTES
Page 20
