Loxit ChargeConnect 16 User manual
Loxit Limited
First Avenue
Poynton Industrial Estate
Poynton
Company Registration Number: 3162472 SK12 1YJ
Operating Instructions
6125 ChargeConnect 16
Universal USB Sync with Intelligent Charge
Loxit’s ChargeConnect 16 Universal USB with Intelligent Charge device is a
professional quality sync/charge device which is designed to perform two functions.
Charge
Firstly it is a professional grade universal USB charger which is able to output max 2.1A
per port continuously. When a device is plugged into one of the ports, the processor
profiles the device and ascertains the correct amount of charge to deliver to the
individual device. This profiling takes place on each port.
This means that you are ale to mix and match devices from different manufacturers and
charge all at the same time. This could include tablets, mobile phones, e-readers, 3-D
glasses, GPS devices, cameras etc, anything that is able to be charged by USB.
The Intelligent Charge then analyzes the charging profiles and when the devices are
fully charged, it cuts the power off to the devices and indicates via a blue flashing light
that all devices are now fully charged and ready to be used.
Sync
The second function is to synchronize.
The ability for a device to synchronise depends on the manufacturer or third party
support for this.
If the tablet’s manufacturer or a third party has produced software allowing the devices
to be synchronised in large numbers, then the ChargeConnect 16 will perform this.
For example, Apple’s Configurator software allows up to 30 Apple devices to sync
simultaneously when using a Mac computer. When using a Windows based PC, this is
restricted to 7 at a time.
Loxit Limited
First Avenue
Poynton Industrial Estate
Poynton
Company Registration Number: 3162472 SK12 1YJ
Therefore, dependent upon the manufacturer’s software, the ChargeConnect 16 is able
to charge and sync up to 16 devices at once and provides a professional quality solution
for the management of multiple devices.
Checks
Before commencing, ensure that all devices are connected to the USB Sync/Charge
device via the USB cables.
Press the Reset button on the RCD at the mains plug socket if applicable.
Press the rocker (ON/OFF) switch, found on top of the Sync/Charge device, to ON. The
switch will illuminate red.
The circular switch will also illuminate solid red notifying it is in on and in Standby Mode.
Syncing
If the devices require syncing, connect the USB A to B cable from the Sync/Charge
Device to a host computer where the devices are registered on iTunes.
Press the circular switch which is illuminated solid red. The button will begin flashing
red and iTunes will open automatically and list the devices registered to the account.
Sync will begin automatically if this iTunes option is selected.
Once Sync has completed, eject the devices through iTunes and disconnect the USB
cable.
Commence Charging
If Sync has already completed, simply remove the USB cable and charging will
commence. This will be indicated on each device displaying the charging icon.
If the button has not already been pressed to commence Sync, press the button now
and it will flash red. Charging has now started. This will continue to flash until the
charging is either interrupted or completed.
Charging Completed
Once the iPads/Laptops are fully charged, the power will automatically be switched off
to the iPads/Laptops and the button will illuminate in a flashing blue, indicating the
laptops are charged.
Interrupt Charging
Should the trolley be required to be taken out of charge mode before charging is
completed (for example to use a partially charged iPad/Laptops), hold down the button
for 5 seconds until the colour returns to solid red. This indicates that the charging circuit
is now in standby mode.
Resume Charging
To resume charging, press the red button and it will flash red, indicating that the
iPads/Laptops are charging once more.
Loxit Limited
First Avenue
Poynton Industrial Estate
Poynton
Company Registration Number: 3162472 SK12 1YJ
Reset After Laptops Are Fully Charged
To start charging after a full charge cycle has been completed, switch off the power at
the rocker switch and switch on again to reset the process.
NOTE:
As a safety feature, the timer is set to automatically turn off the charging after 12 hours
or when the iPads/Laptops are fully charged, whichever is soonest.
Do not forget to eject the iPads via iTunes before disconnecting the USB cable.
WARNING
Do not open the casing of the Sync/Intelligent Charge Device. It contains live
electrical elements.
Operating temperature 5 - 45 degrees Celsius.
Adequate ventilation must be provided to allow intake and output of air flow.
Do not cover ventilation holes.
Do not touch USB ports directly.
TECHNICAL SPECIFICATIONS
Input: 85-264 VAC/ 3,5A/ 47-63Hz.
Out: 5.25VDC/ 30A
Max operating temperature: 70 degrees Celsius (derating above 50 degrees Celsius).
