LOXONE WEATHER STATION TREE User manual

www.loxone.com
GET IN TOUCH!
o[e-mail]
www.loxone.com/contact
Part No.: 100246
FIND MORE LOXONE PRODUCTS:
www.loxone.com
Loxone Miniserver
Dumb Home
Smart Home
SMART HOME
AUTOPILOT LIVING
WEATHER
STATION TREE
Power Supply 10...30VDC SELV
Power Consumption typ. 0.06W, max. 1.1W (when
rain-sensor heating is on)
Heating of Rain-
Sensor Surface Yes
Safety Rating IP44
Ambient Temperature -30...85°C / -22...185°F
Wind Detection Range 9...145km/h / 5.6...90mph
Brightness Detection
Range 0...188kLux
Temperature Detection
Range -40...125°C / -40...257°F
Maintenance & Cleaning
This device is free of
maintenance and may only be
cleaned with a dry cloth.
Technical Specifi cations
NEED HELP?
For further information and documentation please visit:
www.loxone.com/support

Status LED
Push on both side and
pull to open the top
About the product
The Weather Station Tree detects important weather conditions for
your Smart Home. Together with the Miniserver, you can measure
wind, rain, brightness and temperature data, and use this data for a
variety of functions throughout your home.
Features
• Wind sensor
• Wind alarm
• Rain sensor
• Brightness sensor
• Temperature sensor
Information
Please note that the temperature sensor may not always accurately
record the external temperature. This is due to direct sunlight warming
the housing, which can inuence the temperature reading. Always
select an installation place that’s suitable for the application.
Installation
We suggest you install the weather station in a place where wind,
rain and brightness can be detected without interference. Install and
connect the device as shown, either on a pole or directly on the wall,
with the provided accessories. Please note that buildings or objects
in close proximity to the Weather Station could cause air turbulence
which may inuence the accuracy of wind measurements.
Wire Diameter 0.14mm²...1mm²
AWG18...AWG25
Exposed Wire Length 7mm / 9/32”
Push-In-Technology
To make connection, insert the
wire; to remove the wire twist
and pull at the same time.
Connection
Push and pull
to unlock
GNDGW 24V
