LP ESS R050096 User manual

User Manual
Home Energy Storage System
Model: ESS R050096

- Instruction Manual for ESS R050096 - 2
Catalogue
1. safety instructions .......................................................................... 4
1.1 Safety precautions..................................................................... 4
1.2 Symbol interpretation................................................................... 4
2. Product description ......................................................................... 5
2.1 Product Overview ..................................................................... 5
2.1.1 Battery......................................................................... 5
2.1.2 Inverter ........................................................................ 5
2.2 Structure and composition............................................................... 5
3. Product installation ......................................................................... 9
3.1 Installation precautions ................................................................. 9
3.2 Equipment list......................................................................... 9
3.3 Installation Instructions ................................................................ 12
3.3.1Battery cabinet Installation Guide ................................................... 12
3.3.2 Hybrid inverter Installation Guide ................................................... 15
3.4 Battery system cable connection ........................................................ 17
3.4.1Battery modules grounding ........................................................ 17
3.4.2Battery modules positive/negative connection ......................................... 18
3.4.3 Battery Modules Communication Line Connection ...................................... 19
3.4.4 Power on button connection ....................................................... 20
3.4.5 DIP Switch Setting .............................................................. 21
3.4.7 Termination Resistor Installation .................................................... 22
3.4.8 Cabinet door grounding........................................................... 22
3.5 Battery External Cable Connection ....................................................... 23
3.5.1 Battery Equipment Grounding ...................................................... 23
3.5.2 Single cabinet wiring............................................................. 23
3.6 Hybrid Inverter Cable Connection ........................................................ 25
3.6.1 Inverter Ground Connection ....................................................... 25
3.6.2 Battery connection .............................................................. 25
3.6.3 AC input/output ................................................................. 26
3.6.4 PV connection.................................................................. 27
3.6.5 CT connection .................................................................. 28
3.7 System wiring diagram ................................................................ 29
4. Operation guide ........................................................................... 29
4.1 Operating Instructions ................................................................. 29
4.1.1 Power on...................................................................... 29
4.1.2 Power off...................................................................... 30
4.2 LCD display icons..................................................................... 30
4.2.1 Main screen ................................................................... 31
4.2.2 LCD operation flow chart.......................................................... 32
4.2.3 Solar power curve............................................................... 33
4.2.4 Curve page-solar & load & grid..................................................... 34
4.2.5 System setup menu .............................................................. 35

- Instruction Manual for ESS R050096 - 3
4.2.6 Basic setup menu ............................................................... 35
4.2.7 Battery setup menu .............................................................. 35
4.2.8 System work mode setup menu .................................................... 37
4.2.9 Grid setup menu ................................................................ 37
4.2.10 Device info setup menu .......................................................... 38
4.3 Battery status display ................................................................. 38
5. Maintenance and troubleshooting............................................................. 41
5.1 Daily maintenance .................................................................... 41
5.2 Battery troubleshooting ................................................................ 41
5.3 Inverter troubleshooting ............................................................... 43
6. Packaging, transportation, storage ............................................................ 45
Appendix A Technical Parameter Table .......................................................... 46

- Instruction Manual for ESS R050096 - 4
1. safety instructions
Before installing, using and servicing the product, users must read the manual carefully and
follow the safety precautions required in the manual. The safety precautions mentioned in this
manual are only to supplement the local safety regulations.
1.1 Safety precautions
◼The product must be installed and maintained by professionals in accordance with local
standards and regulations, and in strict accordance with the manual installation steps.
◼Before installation and maintenance, make sure that the power supply is off to prevent electric
shock or fire.
◼During normal operation, it is strictly prohibited to directly touch the output and input terminals
to avoid the risk of electric shock.
◼During normal operation, do not directly open the machine casing, otherwise it may cause electric
shock.
◼Keep the equipment away from flammable and explosive materials, and away from heat sources.
◼It is forbidden to modify the equipment by yourself to avoid serious accidents.
1.2 Symbol interpretation
Note! Failure to operate as required
may result in moderate or minor
injury to the person and damage to
the product!
DO NOT dispose of the
battery in normal waste.
DO NOT include battery with
Lead Acid battery recycling
Danger: Risk of high voltage, be
careful of electric shock!
Recyclable!
No smoking!
This face should not be tilted
upside down!
Do not step on!
Please read the manual
carefully before use!
The air outlet of the device is hot and
carefully touched!
Protective grounding!
Wait 5 minutes after power off to
ensure the machine is fully
discharged!
Grounding general
identification!
5 m in

- Instruction Manual for ESS R050096 - 5
2. Product description
2.1 Product Overview
ESS R050096 home energy storage system products are composed of lithium batteries and
bidirectional energy storage inverters (hereinafter referred to as PCS), providing renewable energy
applications and uninterruptible power supply support services. The system can be used in
scenarios where photovoltaics are used spontaneously and the excess is connected to the Internet:
during the day, photovoltaic power generation first meets the power demand of the load, and the
excess electricity charges the battery or the grid; when there is no photovoltaic at night, the load
can choose to use the grid or battery power supply.
2.1.1 Battery
The battery system is based on a lithium iron phosphate battery and adopts a modular parallel
design lithium battery system.
◼Mainly consists of one cabinet and multiple battery modules.
◼The nominal capacity of the battery is 2.4kWh, and the nominal voltage of the battery is 48V.
◼The single cabinet supports up to four 48V/50Ah battery modules in parallel.
◼Supports up to two cabinets in parallel and can be expanded to 19.2KWh.
◼Customized battery management system (BMS), real-time data acquisition, status monitoring
and control to ensure safe and reliable operation of the system.
The system has flexible configuration and high reliability, which can be widely applied to
household energy storage scenarios.
2.1.2 Inverter
◼220V Single-phase Pure sine wave inverter.
◼Self-consumption and feed-in to the grid.
◼Auto restart while AC is recovering.
◼Programmable supply priority for battery or grid.
◼Programmable multiple operation modes: On grid, off grid and UPS.
◼Configurable battery charging current/voltage based on applications by LCD setting.
◼Configurable AC/Solar/Generator Charger priority by LCD setting.
◼Compatible with mains voltage or generator power.
◼Overload/over temperature/short circuit protection.
◼Smart battery charger design for optimized battery performance
◼With limit function, prevent excess power overflow to the grid.
◼Supporting WIFI monitoring and build-in 2 strings of MPP trackers
◼Smart settable three stages MPPT charging for optimized battery performance.
◼Time of use function.
2.2 Structure and composition
The product adopts a modular design framework. The battery box, energy storage inverter and
power distribution box are installed in the form of components for easy replacement.
The product adopts a modular design framework, and the four battery modules are assembled
in components for easy replacement.

- Instruction Manual for ESS R050096 - 6
Picture 2-2 Appearance of the Battery Cabinet
（1）Positive and negative terminal
（2）Communication terminal
（3）Battery display window
（4）Right side door
（5）Battery cabinet
（6）Cabinet foot
（7）POWER button
（8）Battery box
（9）Earth point
（10）Back bracket
（11 ）Left side door
Picture 2-3 Appearance of the inverter
（1）Inverter indicators
（2）LCD display
（3）Function buttons
（4）Battery input connectors
（5）Rs485 port
（6）CAN port
（7）DRMs port
（8）Parallel port
（9）Function port
（10）Generator input
（11 ）Load
（12）Grid
（13）Power on/off button
（14）DC Switch
（15）PV input with 2 MPPT
（16）WIFI interface

- Instruction Manual for ESS R050096 - 7
Picture 2-4 Appearance of the battery box
Item
Features & Indicators
Description
1
Mounting slot
To mount onto the rack with screws
2
Handles
3
RS485 communication port
RS485 communication interface (RJ45-6P)
4
CAN communication port
CAN communication interface (RJ45-8P)
5
ADD switcher
DIP Switch
6
Dry node
Dry node interface for battery pack output
(Reserve)
7
On/off button
Press to switch Battery pack on/off mode
8
Brand logo
Logo of manufacturer
9
State indicator
Indicating capacity and error status
10
Output Interface (Positive +)
Positive interface for power output
11
Output Interface (Negative -)
Negative interface for power output
12
Grounding hole
To battery pack

- Instruction Manual for ESS R050096 - 8
Name
Port
SN
Description
CAN Bus
Terminator
RJ45-8P8C
2-3
A 1 20 ohmresistorin1- 2 pin for parallel CAN
communication is needed to terminate the li n e .
When multiple battery boxes are combined for
CAN communication, an 8- PIN terminator with an
120 ohm resistor is inserted in the last CAN
communication interfaces for parallel CAN
communication termination resistors.
DIP switch
1-4
The dipswitch sets the module address and the
operating mode. The "ON" side indicates "1" and
the other side indicates "0"
For detailed description of the DIP switch settings,
refer to Section 4.1.
Dry contact
1-4
For connection of the cabinet start button boot line
cable.
Name
Port
Pin
Function
Description
RS485 Port
1
RS485B
RS485 communication line B
2
RS485A
RS485 communication line A
3
NC
4-5
NC
6
GND
RS485 communication signal ground
CAN Bus Port
1
CANL
CAN communication line L
2
CANH
CAN communication line H
3
CANLR
Communication Cable L
(Built-in 120Ω termination resistor)
4-5
NC
6
GND
CAN communication signal ground
7
NC
8
NC
78
123456
RJ45
123456
RJ11

- Instruction Manual for ESS R050096 - 9
3. Product installation
3.1 Installation precautions
Please follow the instructions below before starting the installation:
◼Whether the ambient temperature of the installation site is within the specified range of
◼-20℃～+55℃ (recommended at 0℃～40℃).
◼The installation location is well ventilated, away from inflammable and explosive materials, and
it is forbidden to install and operate in salt spray environment.
◼The product is prohibited from tilting or sideways.
◼The product should be installed in a location that avoids sun, rain, snow, etc.
3.2 Equipment list
Before installation, please check whether the appearance of the machine is intact, and check
whether the parts of the accessory package are consistent with the list.
Table 3-1 Battery Cabinet list
NO.
Material Name
Specification Model
QTY.
1
Battery Cabinet
ESS R050096
1
2
Hexagonal
expansion bolt
M10X70
8
4
Positive wiring
harness
UL10269 3AWG(27mm2) 600V
1
5
Negative Power
wiring harness
UL10269 3AWG(27mm2) 600V
1
6
PCS-CAN wiring
harness
24AWG(0.2mm2) 8-core cable gray
2000mm, one end with RJ45
crystal head ,one end with LP-24-
RJ45-PO1 connector
1

- Instruction Manual for ESS R050096 - 10
7
Cable tie
YJ-120 2.5*120mm Nylon; white
30
8
Terminals
RNYD5-6 Yellow
2
9
General
certificate
General certificate
1
10
User Manual
English language
1
11
Drier
20g
4

- Instruction Manual for ESS R050096 - 11
Table 3-2Hybrid Inverter list
NO.
Material Name
Specification Model
QTY.
1
Hybrid Inverter
SUN-5K-SG03LP1-EU
1
2
Stainless steel expansion
bolts
M8X80
4
3
Stainless steel mounting
screws
M6X12
2
4
Current transformer
100A/50mA
1
5
L-type Hexagon wrench
4mm
1
6
Internet Cable
Category 5 network
cable 2 meters
1
7
WiFi plug
-
1
8
Wall mounting bracket
-
1

- Instruction Manual for ESS R050096 - 12
3.3 Installation Instructions
The battery system cabinet can be installed on the floor and wall mount. The system adopts
the natural heat dissipation method. When installing, 300mm of heat dissipation space is required
on the left and right sides of the cabinet.
Picture 3-1 Installation Diagram
3.3.1 Battery cabinet Installation Guide
(1) Detach the mounting bracket: Use a screwdriver to unscrew the 4 fixing screws on the mounting
bracket and remove the bracket.
Picture 3-2 Disassembly and Assembly Bracket Diagram

- Instruction Manual for ESS R050096 - 13
(2) Adjust the mounting bracket.
Picture 3-3 Adjust the mounting bracket
The original mounting bracket is suitable for 12, 16-inch installation space. If it is suitable for
installation of 20 and 24 inches, remove the screws in the red circle in the figure above, and move
the removed parts to the left and right by a screw hole position according to the direction of the
arrow to fix the screws. The adjusted bracket is suitable for installation space of 20 or 24 inches.
(3) Fixed installation bracket:
Place the mounting bracket on a suitable position on the wall, draw a mark on the mounting
hole with a pen, and drill a hole with a diameter of φ12 at a depth of 70mm; insert the expansion
screw seat into the hole and knock to the end; after unscrewing the screw, the mounting bracket is
fixed to the wall, Tighten the screws with a wrench.
Picture 3-4 Intent of the fixed mounting bracket

- Instruction Manual for ESS R050096 - 14
(4) Installing the cabinet: Hang the cabinet to the mounting bracket, fix the 4 screws removed in the
first step, and complete the installation.
Picture 3-5Install the battery cabinet
Note: When installing on the ground, the height of the wall drillhole positions must ensure that the
cabinet feet can touch the ground, and then adjust the feet locking nuts with a wrench.
Picture 3-6 Adjusting the feet
Note: If the battery packs have been installed in the cabinet, you can skip the following steps.

- Instruction Manual for ESS R050096 - 15
(5) Unscrew the fixing screws on the right door with a screwdriver, and remove the left and right
doors.
Picture 3-7 Open the side door
(6) Push the battery box into the cabinet one by one along the card slot, and fix the battery pack
with M6×12 screws.
Picture 3-8assemble the battery box
3.3.2 Hybrid inverter Installation Guide
This Hybrid inverter is designed for outdoor use (IP65), Please make sure the installation site
meets below conditions:
◼Not in direct sunlight.
◼Not in areas where highly flammable materials are stored.
◼Not in potential explosive areas.
◼Not in the cool air directly.
◼Not near the television Antenna or antenna cable.
◼Not higher than altitude of about 2000 meters above sea level.
◼Not in environment of precipitation or humidity (>95%).
Please AVOID direct sunlight, rain exposure, snow laying up during installation and operation.
Before connecting all wires, please take off the metal cover by removing screws as shown below:
Positive and negative terminal

- Instruction Manual for ESS R050096 - 16
Considering the following points before selecting where to install:
◼Please select a vertical wall with load-bearing capacity for installation, suitable for
◼installation on concrete or other non-flammable surfaces, installation is shown below.
◼Install this inverter at eye level in order to allow the LCD display to be read at all times.
◼The ambient temperature should be between -25~60℃ to ensure optimal operation.
◼Be sure to keep other objects and surfaces as shown in the diagram to guarantee sufficient heat
dissipation and have enough space for removing wires.
For proper air circulation to dissipate heat, allow a clearance of approx. 500mm to the side.
And approx.500mm above and below the unit. And 1000mm to the front.
◼Mounting the inverter
Remember that this inverter is heavy! Please be careful when lifting out from the package.
Choose the recommend drill head (as shown in below pic) to drill 4 holes on the wall, 52-60mm
deep.
(1) Use a proper hammer to fit the expansion bolt into the holes.

- Instruction Manual for ESS R050096 - 17
(2) Carry the inverter and holding it, make sure the hanger aim at the expansion bolt, and fix the
inverter on the wall.
(3) Fasten the screw head of the expansion bolt to finish the mounting.
3.4 Battery system cable connection
Note: This section mainly describes the battery module assembly instructions. If the battery
packs have been installed in the cabinet, you can skip this section.
Note: Before wiring, make sure each battery module is turned off.
3.4.1 Battery modules grounding
Screw one end of the yellow green ground wire (labeled bat / GND) to the ground point of the
battery box panel, and the other end to the frame ground point. Tighten the screw with a
screwdriver.
Picture 3-9 Grounding diagram of battery module

- Instruction Manual for ESS R050096 - 18
3.4.2 Battery modules positive/negative connection
Connect the B + /B- terminal to jonction bus-bar of the battery module as shown in the figure,
where the BAT+ /BAT- is connected to the positive terminal on the top of the cabinet.
Picture 3-10 Battery modules positive/ negative connection
No.
Name
Line mark
(1)
Battery power wire harness black 750mm
BAT-、Busbar-
(2)
Battery power wire harness red 780mm
BAT+、Busbar+
（1）
（2）

- Instruction Manual for ESS R050096 - 19
3.4.3 Battery Modules Communication Line Connection
Connect the communication line of the battery module as shown in the figure, where the RS485
port and CAN1 port of BAT1 are respectively connected to the RS485 port and CAN1 port on the top
of the cabinet, the CAN2 port of bat1 / 2 / 3 is connected to the CAN1 port of BAT2 / 3 / 4.
Picture 3-11Battery modules communication line connection
No.
Name
Line mark
（3）
CAN1 communication cable 500mm
CAN1
（4）
RS485 communication cable 500mm
RS485
（5）（7）
CAN communication cable 150mm
CAN1,CAN2
（6）
CAN2 communication cable 950mm
CAN1,CAN2
（7）
（3）
（5）
（4）
（6）

- Instruction Manual for ESS R050096 - 20
3.4.4 Power on button connection
Connect the power on button power on line of the battery module as shown in the figure, and
plug the line terminals into the dry contact interface of BAT1 / 2 / 3 / 4 according to the direction of
the gap.
Picture 3-12Power on button connection
No.
Name
Line mark
(8)
Power on button cable
DRY1/ DRY2/ DRY3/ DRY4
(8)
