iS7 220V Auxiliary Power Option Card User Manual
1
Safety Precaution
First thank you for using our iS7 Auxiliary Power Option Board!
Please follow the following safety attentions since they are intended to
prevent any possible accident and danger so that you can use this
product safely and correctly.
Safety attentions may classify into „Warning‟ and „Caution‟ and their
meaning is as following:
Symbol
Meaning
WARNING
This symbol indicates the possibility of death or
serious injury.
CAUTION
This symbol indicates the possibility of injury or
damage to property.
The meaning of each symbol in this manual and on your equipment is
as follows.
Symbol
Meaning
This is the safety alert symbol.
Read and follow instructions carefully to avoid
dangerous situation.
This symbol alerts the user to the presence of
“dangerous voltage” inside the product that might
cause harm or electric shock.
After reading this manual, keep it in the place that the user always can
contact. This manual should be given to the person who actually uses
the products and is responsible for their maintenance.
WARNING
Do not remove the cover while power is applied or the unit is in
operation.
Otherwise, electric shock could occur.
Do not run the inverter with the front cover removed.
Otherwise, you may get an electric shock due to high voltage terminals or
charged capacitor exposure.

iS7 220V Auxiliary Power Option Card User Manual
2
WARNING
Do not remove the cover except for periodic inspections or wiring,
even if the input power is not applied.
Otherwise, you may access the charged circuits and get an electric shock.
Wiring and periodic inspections should be performed at least 10
minutes after disconnecting the input power and after checking the
DC link voltage is discharged with a meter (below DC 30V).
Otherwise, you may get an electric shock.
Operate the switches with dry hands.
Otherwise, you may get an electric shock.
Do not use the cable when its insulating tube is damaged.
Otherwise, you may get an electric shock.
Do not subject the cables to scratches, excessive stress, heavy
loads or pinching.
Otherwise, you may get an electric shock.
CAUTION
Be cautious when handling CMOS elements on the option board.
It may cause a failure due to static electricity.
When changing and connecting communication signal lines,
proceed the work while the inverter is turned off.
It may cause a communication error or failure.
Make sure to connect the inverter body to the option board
connector accurately coincided each other.
It may cause a communication error or failure.
Make sure to check the parameter unit when setting parameters.
It may cause a communication error.

iS7 220V Auxiliary Power Option Card User Manual
3
Table of Contents
Table of Contents.......................................................................................... 3
1. Introduction ........................................................................................... 4
2. Components .......................................................................................... 4
3. Installation and Wiring ............................................................................. 5
4. Option Card Standard ............................................................................10
5. Parameter .............................................................................................12
6. Function offer .......................................................................................12
6.1 Option Card Recognition ..................................................................12
6.2 Option Card Power Status LED Display...............................................13
6.3 Check Operation in Drive according to the Power Supply Status and
Communication.......................................................................................13
6.4 Jumper Use according to Communication Option ................................15
7. Troubleshooting ....................................................................................17

iS7 220V Auxiliary Power Option Card User Manual
4
1. Introduction
This user manual is standard for 220V auxiliary power option card supplying
power(5V) to the CPU in controller of IS7 to continue communication with PLC or
host controller through communication option card even if input power of IS7 is
blocked by external factors. Auxiliary power option card is designed to supply 5V
to the control board of IS7 through receiving 220V commercial power.
2. Components
-220V Auxiliary Power Option Card 1ea
-Fixed Screw 2ea
-Brass Bar 1ea
-User Manual 1ea
-
Option Card
Screw
Brass Bar
User Manual
Quantity
1
2
1
1
Item

iS7 220V Auxiliary Power Option Card User Manual
5
3. Installation and Wiring
(1) Option Module
①LED display feature
Item
220V AC Input power
Power On
Power Off
Status
220V Power input to the option card
LED On
LED off
Color
Green
Left LED only one used, the green LED lights up when 220V commercial power
is applied through terminal of this option card.
②220V AC input power
Terminal
Name
Function
L1,L2
220V Commercial Power
Supply 5V

iS7 220V Auxiliary Power Option Card User Manual
6
(2) Installation and Wiring
-Follow the procedures below for installation and wiring
①Installation
Mount a 220V auxiliary Power option card(Slot#2) dedicated to IS7.
②Wiring
Wire signal from commercial power(220V) to L1/L2 terminal block of
the option card.
220V
Commercial
Power

iS7 220V Auxiliary Power Option Card User Manual
7
-For details, see cable standard below.
<Cable Standard>
①Cable Standard : AWG20~12
②Recommended Cable Standard
Terminal
Type
Recommended Wire Size
[mm2] (AWG)
Terminal
Screw
Contact
Method
Crimp
Terminal
(Unused)
Crimp
Terminal
(used)
L1 / L2
0.75 (18)
0.5 (20)
M2
Elevator
Type
③Recommended Wire Size Crimp Terminal
④Cautions
- When you arrange control wiring by using a cable tie to work, you should
work in a place more than 15cm away from the inverter.(Otherwise, top
cover of drive may not be assembled)
- The standard of wire must be at least more than 300V and higher than 75℃
With copper wires
- When tightening the terminal block, the width of screwdriver’tip is less than
2.5mm and the thickness of screwdriver is less than 0.4mm in use.
Less than 0.4mm
Less than 2.5mm

iS7 220V Auxiliary Power Option Card User Manual
8
(3) Installation Check
- Please Proceed the following step to check whether the installation has been
done correctly.
①Shut down SV-iS7.
②Take off the upper cover of the SV-iS7 and install 220V auxiliary power
option board into the option slot.
③Connect 220V auxiliary power supply into the terminal of the option
board(L1, L2).
④Power up into SV-iS7 as well as the option.
⑤Check the option board whether the green LED light has turned on.
⑥Screw back the upper cover of the SV-iS7.
⑦Set DR30-Auxiliary Opt = ‘Yes’, using the LCD keypad.
⑧When the main power for SV-iS7 is on, the option board does not operate.
(The LED of the option board is on when the option power supply is
applied)
⑨When the main power shuts down, the relay of the auxiliary Power option
board will activate, supplying control power(5V) into the CPU.
- ‘Trip’message will show in the keypad.
- Normal operation of the motor is not possible and only communication
status through option Slot#1 will be possible.
⑩When the option board is connected and the main power of the SV-iS7
turns on the relay connection with the option board will shut down.
- Power through the option board will not be supplied and the ‘Trip’message
will automatically disappear.
- The inverter is at its ready state.
Remark
When the iS7 220V External Power option board is in operation the ‘Trip ’
message will show up in the keypad and regardless of its power rating ‘AUX
Power ON’Trip may occur. There are chances of other trips from being triggered
and the record showed up on the keypad does not necessarily show in an order in
time.

iS7 220V Auxiliary Power Option Card User Manual
9
(4) Other options mixed in use with precautions
1) The same slot op the option as shown in the table below can not be used
at the same time.
For example, Binary option card is to be used in slot#2. PLC, EXTENSION
I/O-1, EXTENSION I/O-2, Synchronization and Safety option can not be
used at the same time.
Option Slot#
Applicable Options
Option Card Slot #1
(Slot for
Communication)
RNET,
CANopen,
DEVICENET,
LONWORKS,
PROFIBUS-DP,
ETHERNET,
CC-Link
RAPIENET
Option Card Slot #2
(Slot for PLC,
Extension I/O and
so on)
PLC,
EXTENSION I/O-1,
EXTENSION I/O-2,
Synchronization,
Safety,
Binary
220V Auxiliary Power(this option)
Option Card Slot #3
(Slot for Encoder)
ENCORDER,
Position Control

iS7 220V Auxiliary Power Option Card User Manual
10
4. Option Card Standard
(1) Standard
Item
Description
Name
YA-S7M1
Auxiliary Power Option
Drive
SV-IS7 Series
Type
Option
Input Voltage
Rated Input Voltage : AC 200~230V±
10%(50/60Hz)
Output Voltage
Output to be supplied to control board of the
drive(not for external terminal)
Rated Output Voltage: DC 5V±5%
Rated Output Power: 5W±5%
External Adaptor
Not required
Cable shield ground
Terminal
Not provided
(If necessary, use F/G of drive)
Applicable Terminal
5mm Pitch, Elevator Type
LED
Only one LED shows status of auxiliary power
option.
Item
LED Power
Status
status of auxiliary power option
Color
Green(On)

iS7 220V Auxiliary Power Option Card User Manual
11
Basic Function
220V auxiliary power option card supplying
power(5V) to the CPU in controller of IS7 to
continue communication with PLC or host
controller through communication option card
even if input power of IS7 is blocked by external
factors
<Applicable Communication Option>
-RNET
-CANopen
-DEVICENET
-LONWORKS
-PROFIBUS-DP
-ETHERNET
- CC-Link
- RAPIEnet
(2) Use Environment
Ambient Temperature
-10℃~ 50℃
Storage Temperature
-20℃~ 65℃
Surrounding Humidity
Below 90% RH of relative humidity (with no dew
formation)
Altitude, Vibration
Below 1,000m, Below 5.9m/sec2 (=0.6g)
Environment
There should be no corrosive gas, flammable gas,
oil mist or dust
Protection Degree
According to drive protection rating
Remark
When using Ethernet Option, because of Ethernet communication characteristics,
be sure to reset the host controller for Ethernet communication when the power of
drive is shut off and auxiliary power option is operating for supply.

iS7 220V Auxiliary Power Option Card User Manual
12
5. Parameter
(1) Parameter
No.
Function
Display
Name
Setting
Range
Initial
Value
Unit
Shift in
Operation
DRV-30
Auxiliary OPT
Enable 220V
Auxiliary Power
Option
YES/NO
NO
-
X
Set the parameter to use auxiliary power option.
If you have not set up the parameter, you can not use the option properly.
6. Function offer
Description of SV-iS7’s functionality provided by 220V Auxiliary power option.
6.1 Option Card Recognition
(1) Purpose
Verify whether the recognition of the option mounted on the slot#2 of iS7
drive.
(2) Way of offering
Code
Name of Functionality
Display
CNF-31
Option-2 Type
Auxiliary
After mounting the option in slot#2, make sure that the option-2(CNF-31)
parameter represented by ‘Auxiliary’.
Please cut off the drive when mounting options.

iS7 220V Auxiliary Power Option Card User Manual
13
6.2 Option Card Power Status LED Display
(1) Purpose
Check the input power of the option through LED display.
(2) Way of offering
The status of LED(Green) means that LED is on when (AC 200~230V) is
applied to the option.
Item
LED Power
Status
status of auxiliary power option
Power
Supplied
Power not
Supplied
Color
Green
On
Off
6.3 Check Operation in Drive according to the Power Supply
Status and Communication
(1) Operating Status according to the Drive and the Option
Power Input Condition
No.
Drive
Power
Option
Power
Option in
Operation
(5V Supplied)
Driving of
Inverter
Communication
1
ON
ON
X
Available
Available
2
OFF
X
Available
Available
3
OFF
ON
O
Not Available
(Trip)
Available
4
OFF
X
Not Available
(OFF)
Not Available
While the option is on, the main power is off and the inverter displays the
trip state, but the communication function is still working. If the above table
3 condition : the inverter power off & the option power on, only the

iS7 220V Auxiliary Power Option Card User Manual
14
condition is ready to supply power to the inverter.
Remark
When the inverter power is turned off and the option power is on, the normal
inverter driving operation is not available by supplying only the option power. The
option supplying power is only for communication with other communication
option.

iS7 220V Auxiliary Power Option Card User Manual
15
6.4 Jumper Use according to Communication Option
(1) Purpose
Some options must be used to set the jumper for the IS7 product more than
90kW capacity according to communication option card type.
(2) Condition
Jumper used as shown the table below according to communication option
and inverter capacity
Option Slot#1
The Option Type
Applicable Capacity
Jumper Whether to
use or not
(J1)
Communication
Option Slot#1
ETHERNET/ CC-Link
IS7 0.75~375kW-2/4
X(Not Used)
PROFIBUS-DP/
RAPIENET/ RNET/
CANopen/
DEVICENET/
LONWORKS
IS7 0.75~75kW-2/4
X(Not Used)
IS7 90~375kW-4
O(Used)

iS7 220V Auxiliary Power Option Card User Manual
16
(3) Set up Method
<Used>
<Default Value and Not used>
Caution
Do not use jumper at Ethernet/CC-Link Communication Option.
Check if the capacity of IS7 is more than 90kW. If so use the jumper at
Profibus/RAPIENET/PROFIBUS-DP/RNET/CANopen/DEVICENET/
Lonworks.
When using auxiliary power option, the allowable maximum input
voltage of the IS7 product is 480V.(However, the capacity of inverter is
90kW or more product)

iS7 220V Auxiliary Power Option Card User Manual
17
7. Troubleshooting
This page is to explain faults or abnormal symptoms that may arise while using
the auxiliary power option board. If the below process do not solve the issue
please contact your supplier or your regional sales manager of LSIS.
Type
Diagnosis
resolution
“AUX Power
ON ”message
on the keypad
220V auxiliary power
option board is active
Check whether the main power of
the inverter is on
- If the main power is not on, it is
normal for such message to show
on the keypad.
LED is OFF
220V power supply is
not live
Check whether the connection to
the terminal of the option
board(L1,L2) is properly
connected.
Control board
of the inverter
is not ON
The LED of the option
board is ON but the
power supply into the
control board is not
active.
Check whether the option board is
connected in option Slot#2.
Keypad blinks
when the main
power of the
inverter is ON
For few
communication
option board,
a jumper needs to be
used.
1) Check on the inverter rating.
- For 90kW and above jumper is
needed for each option boards.
2) Turn OFF the power supply for
the 220V auxiliary power option
board and power up the inverter.
- If this symptom constantly
occurs, please contact your
supplier or your regional sales
manager of LSIS.

iS7 220V 외부전원 옵션 사용설명서
1
제품을 사용하기 전에 먼저 저희 IS7 220V 외부전원 옵션을 사용하여 주셔서 감사
합니다.
안전상의 주의사항
안전상의 주의사항은 사고나 위험을 사전에 예방하여 제품을 안전하고 올바르게
사용하기 위한 것이므로 반드시 지켜주십시오.
주의사항은 ‘경고’와 ‘주의’의 두가지로 구분되어 있으며 ‘경고’와 ‘주의’의 의미
는다음과 같습니다.
경고
주의
제품과 사용설명서에 표시된 그림기호의 의미는 다음과 같습니다.
는위험이 발생할 우려가 있으므로 주의하라는 기호 입니다.
는감전의 가능성이 있으므로 주의하라는 기호 입니다.
사용설명서를 읽고 난후사용하는 사람이 언제라도 볼수있는 장소에 보관 하
십시오.
SV-iS7 220V 외부전원 옵션의 기능을 충분하고 안전하게 사용하기 위하여 이
사용 설명서를 잘읽어 보십시오.
지시사항을 위반할 때심각한 상해나 사망이 발생할 가능성이
있는 경우
지시사항을 위반할 때경미한 상해나 제품손상이 발생할 가능성이
있는 경우

iS7 220V 외부전원 옵션 사용설명서
2
주의
옵션보드의 CMOS 소자들의 취급에 주의하십시오.
정전기에 의한 고장의 원인이 됩니다.
신호선 등의 변경 접속은 인버터 전원을 내린 상태에서 하십시오.
통신불량 및고장의 원인이 됩니다.
인버터 본체와 옵션보드 커넥터가 정확히 일치하게 접속되도록 하십시오.
통신불량 및고장의 원인이 됩니다.
파라미터를 설정할 때는 파라미터 unit 을확인하시기 바랍니다.
통신불량의 원인이 됩니다.

iS7 220V 외부전원 옵션 사용설명서
3
목 차
목 차 ..............................................................................................3
1. 220V 외부전원 옵션 카드 소개................................................................4
2. 제품 구성물...........................................................................................4
3. 외관 및배선 .........................................................................................5
4. 옵션 카드 규격 ....................................................................................10
5. 옵션 카드 관련 파라미터 ......................................................................12
6. 제공 기능............................................................................................12
6.1 옵션 카드 인식 ..............................................................................12
6.2 옵션 카드 전원 상태 LED 표시 기능 ................................................13
6.3 전원 공급 상태에 따른 인버터/통신 동작 확인...................................13
7. 문제 해결하기......................................................................................17
