LSI DOUBLE-DECK CROSSOVER Series Guide

Nut
2 / 3 p/n 442652 Rev. 1/11
LSI Industries Inc. 10000 Alliance Road Cincinnati, Ohio 45242 [phone] Fax [phone] www.lsi-industries.com
©2011 LSI Industries Inc.
442652 Rev. 1/11 1 / 3
LSI Industries Inc. 10000 Alliance Road Cincinnati, Ohio 45242 [phone] Fax [phone] www.lsi-industries.com
Listed to UL1598
Canopy Luminaire,
Suitable for wet locations
1
Collar
Clamp
Bracket
DOUBLE-DECK CROSSOVER® SERIES LUMINAIRE, cont'd.
Install Mounting Bracket using outer most holes in flange
and (4) #10-24 x 1" screws. Tighten screws so Mounting
Bracket is flush and tight up against decking.
IMPORTANT: The following instructions are for
qualified electricians only!
Locate Driver Box. O pen Driver Box Cover from bottom by
loosening side screw and rotating top upward. Secure box
bottom to conduit stem. With (1) Stem Nut in hand -
locking teeth facing UP - feed both luminaire connectors
thru Nut, then thread nut onto Stem external threads; fully
thread Nut all the way down Stem until it stops. Feed
all luminaire wiring thru box bottom, then lower Box
onto Stem. With other Stem Nut in hand - locking teeth
facing DOWN - feed wiring thru nut, then thread
onto Stem and tighten. Make secondary wiring
connections per terminal block label inside Driver Box.
2
Nut
INSTALLATION AND ASSEMBLY INSTRUCTIONS
CRR/CRR3 DOUBLE-DECK CROSSOVER® SERIES LUMINAIRE
WARNING: Failure to follow instructions could result in
damage to product and void warranties!
For new installations ONLY! For retrofit of existing luminaires refer
to proper retrofit instructions!
Risk of fire or electrical shock. Disconnect power before installing
or servicing.
NOTE: For installation on Metal double-deck Canopies.
Driver for
128 LED Luminaire 104 LED Luminaire 84 LED Luminaire 64 LED Luminaire Focus Luminaire all Luminaires
Suggested Tools: Flat screwdriver, Philips screwdriver, caulk gun
Reference site layout for luminaire location and type. Ensure nothing is above decking before cutting. Cut
an 11" square hole in between canopy ribs. Apply 1/4" bead of Sealant/Adhesive (supplied) around hole.
Push Collar up through the hole and into the Sealant/Adhesive to create a water tight seal. Install (2) Clamp
Brackets by inserting them up through the hole and back down over the lip of the Collar. Secure Clamp
Brackets to Collar using outer most holes in flange and (4) #10-24 x 1" screws. Tighten screws so that Collar
flange is flush and tight up against decking. NOTE: For thin-material canopies, holes are provided at top of
Collar which allow wire hanging from interior canopy structure.
1/4" Bead Sealant
Adhesive (supplied)
#10-24 x 1"
Screw
Driver
Box
Stem
Mounting
Bracket
#10-24 x 1" Screw
Deck
Luminaire
3
Clamp
Bracket
Driver
Box Cover
Side
screw
Collar Holes
(for additional support
on thin canopy decks)

©2011 LSI Industries Inc.
442652 Rev. 1/11 3 / 3
LSI Industries Inc. 10000 Alliance Road Cincinnati, Ohio 45242 [phone] Fax [phone] www.lsi-industries.com
Installation Questions?
Call LSI Field Service Department at:
1-800-436-7800 Ext. 3300
Fax: [phone]
DOUBLE-DECK CROSSOVER®SERIES LUMINAIRE, cont'd.
Using Clasp on the end of the Tether, attach Luminaire to
Mounting Bracket through rectangular hole. Allow Luminaire
to hang by Tet her for wiring. Run supply wiring to box
bottom. NOTE: K.O.'s are 1/2" conduit size. Make all
primary wire connections. Flip Driver Box Cover top
closed. Ensure all wiring is inside box and that no wires are
pinched. Make sure wire tie keeps wires together to prevent
pinching! Secure cover to box bottom with side screw.
Leaving Tether attached, lift Luminaire up through the Collar.
Position Luminaire over Mounting Bracket. Secure Luminaire
with (4) #10-24 x 1" screws and tighten. (Note keyhole slots
on opposite corners).
NOTE: if installing Focus (CRR3 FO) model, ensure light
bars point towards pump!
If installing Focus (CRR3 FO) model, adjust each light strip
until satisfied. Use a 7/32" rounded Allen key. A 5.5 mm
Allen key will work as well.
Clasp
Luminaire
Mounting
Bracket
Tet her
4
5
#10-24 x 1"
Screw
Luminaire
Driver
Box
