LTH SquareLED Clou3 User manual

SquareLED Clou³ Multifunction 3in1 LED Display Video + lighting + movement

Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement
Declaration
• The material in the manual is for standard Squareled Clou³ design. Other specic or special system or
function depends on the user’s order.
• This products is for professional installation and the user should keep clear of danger.
• If you have questions about how to operate them safely, please contact your manufacturer.
• In daily use, this product may cause radio interference. In this case, the user needs to take adequate
action.
• Copyright Reserved By Huasuny. No reprint or modify without permission.
This product is for professional use only. It is not for household use.
This product presents risks of severe injury or death due to re hazards, electric shock and falls.
Read this manual before installing, powering or servicing this product, follow the safety precau-
tions listed below and observe all warnings in this manual and printed on the product.If you have
questions about how to operate the LED display safely, please contact manufacturer.
PROTECTION FROM ELECTRIC SHOCK
• Connect the product to AC mains power within the range 105 - 240V nominal at 50 or 60 Hz only.
• Disconnect the entire installation from powered ensure that power cannot be reconnected, even acciden-
tally, before carrying out any installation or maintenance work.
• Disconnect the product from power when not in use.
• Always ground (earth) the product electrically.

Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement
• Use only a source of power that complies with local building and electrical codes and has both overload and
ground-fault (earth-fault) protection.
• Connect the LED display to power using only the cables supplied by attached with the product.
• Protect power cables from water and rain.
• Do not connect any other device than other LED display to the power throughput connector in the base of
the product.
• The number of LED display which are cascaded by one unit AC power cable is not allowed to exceed the
regular number.
• Before using the product, check that all power distribution equipment and cables are in perfect condition
and rated for the current requirements of all connected devices.
• Do not use the product if the power cable or a power plug is in any way damaged, defective or showing signs
of overheating.
• Refer any service operation not described in this manual to qualied technicians.
PROTECTION FROM FIRE
• Provide a minimum clearance of 40 cm around the cover at the back of the LED display base.
• Do not stick lters, masks or other materials directly on to LED modules.
• Do not modify the product in any way not described in this manual.
• Install only genuine parts in or on the product unless an alternative is described in this manual.
• Do not operate the product if the ambient temperature (Ta) exceeds 40°C (104°F).
PROTECTION FROM INJURY
• Ensure that any structure used for support as well as all fastening and connecting hardware can hold at least
10 times the weight of all supported devices and equipment.
• Do not suspend LED display using any other method of attachment than those described in this manual.
Check that all external covers and rigging hardware are securely fastened.
• Block access below the work area and work from a stable platform whenever installing, servicing or moving
the product.
• Do not look at lit LEDs from a distance of less than 40cm(1 ft.4in.)
without suitable protective eye wear.
• Do not view lit LEDs with optical instruments that may concentrate
the light output.

Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement
1. Squareled Clou³- Module Feature
2. Squareled Clou³- Main Data
Power input 110VAC/50~60Hz
Power consumption 380W(Max)
Head movement X:540°/Y:120°
Control model DMX512 Signal/Sound/Auto
DMX channel 64
Net weight ≈31kg
Dimension 498(L)*498(W)*595(H)mm
3. Squareled Clou³ - Connector

Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement
4. Squareled Clou³- Connection between Module
Please use the DMX512 shielded twisted pair signal line.The signal line connecting distance is 150 meters.When
used for long distance signal transmission, signal amplier should be added to the DMX512.
Since each DMX signal can only control 512 channels, each signal can control no more than 8 pcs of Squareled
Clou³.

4.1 Major Function
Turn on the machine, press the “MENU” button to enter the menu mode, use the “UP
“and “DOWN “buttons to look up the menu. When the preset menu is displayed on the
screen, press the “ENTER” button to confirm, use the “UP” and “DOWN” button to
select the sub-menu, and press the ENTER button to save the settings. Return to the
“BACK” button, or wait to exit menu mode automatically .
When there is no power connection, press to the “MENU “ button with about 7 seconds
to enter the menu mode with battery power. After setting up, press the “BACK” button
to return or wait to exit menu mode automatically. The LCD display screen will be off in
30 seconds if there is no touch or operations .
The main functions are shown as follows :
Main Functions
Class 1 menu Class 2 menu Class 3 menu Class 4 menu
DMX Settings
DMX Address 001 ρ 512
DMX lost.
Black Out
Hold Last
Vies DMX Value
Rest Pan/Tilt Rest
Sett
Master Slave
Master
Slave
Display Mode On Always
Off Delay
Lcd Dimmer 1ρ10
Menu
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement

Class 1 menu Class 2 menu Class 3 menu Class 4 menu
Sett
Display Invert
Normal
Inverted
Language
English
Chinese
Calibrate
Factory Setting
Clean Program
Option
Pan Invert OFF
ON
Tilt Invert OFF
ON
Offset
(Motor
Colors)
(Passcode
012)
Pan Offset -127 ~ 127
Tilt Offset -127 ~ 127
Red Offset 128—255
Green Offset 128—255
Blue Offset 128—255
Time Offset （Passcode 88
Passcode
015 Machine Mode
X Rover
X Rover Pro
X Rover Plus
Defaults
Information
Total Hours
Software Vers
Lcd Drv CPU
XY Drv CPU
Led Drv CPU
Status Inform
Pan Ecnoder
Pan Sensor
Tilt Encoder
Tilt Sensor
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement

Class 1 menu Class 2 menu Class 3 menu Class 4 menu
Test Mode
Auto Test
Manual Test
Pan
000-255
Tilt
XY Speed
Shutter
Dimmer
LED1 color macro
LED2 color macro
LED3 color macro
LED4 color macro
LED5 color macro
LED6 color macro
Mode
DMX Mode
User Memory
Preset Memory
Static Scene1-9
Pan
000-255
Tilt
XY Speed
Shutter
Dimmer
LED1 color macro
LED2 color macro
LED3 color macro
LED4 color macro
LED5 color macro
LED6 color macro
Keep Time 000-2550-20S
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement

X R o v er
P ro C o n t en t D M X f ig u re F u n c tio n
1 X a x is
0 00 -2 55
X r ota t e 5 4 0 d eg ree s
2 16 bit X a xis X a xis 1 6 b it r otate
3 Y a x is Y a xis ro tate 12 0 d e g r e e s
4 16 bit Y ax is Y a xis 1 6 b it r otate
5 X Y a xis sp ee d X Y a x is s p e e d s low d o w n
6 S hu tte r
0 00 -0 07 lig ht o f f
0 08 -1 31 S tro be s pe ed up
1 32 -1 39 L igh t on
1 40 -1 81 F a s t o f f s lo w o n
1 82 -1 89 L igh t on
1 90 -2 31 F a s t o n s lo w off
2 32 -2 39 L igh t on
2 40 -2 47
Sh u t ter a t r and om
2 48 -2 55 L igh t on
7
D im m e r
0 00 -2 55
lin ea r dim m in g F ro m da rk to b rig h t
8 M od es Ma c ro
0 00 -0 07 N / A
0 08 -2 55
16 M o de s
(W he n op era t e s th is m od e,dim m in g
m od es f ro m 1~ 6 pa rt ab ov e ar e n o t
av a ila ble bu t a va ila ble for d im m ing all
lig hts)
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement
DMX Channels

X R ove r
Pr o C on tent D M X figu re Fu nctio n
9 ru nni ng s tyle
m a cr o S pee d
00 0- 255
S low to fas t
1 0 ru nni ng sty le
m ac ro C o lo r 1
2 55 c o lors
1 1 ru nni ng sty le
m ac ro C o lo r 2
1 2 Re d all
line ar d im m in g from da rk to b rig ht
1 3 G re en a ll
1 4 B lue a ll
1 5 W hite all
1 6 Re d 1
1 7 G re en 1
1 8 B lu e 1
1 9 W hite 1
2 0 Re d 2
2 1 G re en 2
2 2 B lu e 2
2 3 W hite 2
2 4 Re d3
2 5 G re en 3
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement

X R o v e r
P r o C o n t e n t D M X fi g u re F u n c t io n
2 6 B lu e 3
0 0 0 - 2 5 5
lin e a r d im m in g fr o m d a rk to b rig h t
2 7 W h it e 3
2 8 R e d 4
2 9 G re e n 4
3 0 B lu e 4
3 1 W h it e 4
3 2 R e d 5
3 3 G re e n 5
3 4 B lu e 5
3 5 W h it e 5
3 6 R e d 6
3 7 G re e n 6
3 8 B lu e 6
3 9 W h it e 6
4 0 R e d 7
4 1 G re e n 7
4 2 B lu e 7
4 3 W h it e 7
4 4 R e d 8
4 5 G re e n 8
4 6 B lu e 8
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement

X R o v e r
P r o C o n t e n t D M X fi g u re F u n c t io n
4 7 W h it e 8
0 0 0 - 2 5 5
lin e ar d im m in g fr o m d a rk to b rig ht
4 8 R e d 9
4 9 G re e n 9
5 0 B lu e 9
5 1 W h it e 9
5 2 R e d 1 0
5 3 G re en 1 0
5 4 B lu e 1 0
5 5 W h ite 1 0
5 6 R e d 1 1
5 7 G re en 1 1
5 8 B lu e 1 1
5 9 W h ite 1 1
6 0 R e d 1 2
6 1 G re en 1 2
6 2 B lu e 1 2
6 3 W h ite 1 2
6 4 C o n t r o l
f u n ct io n
0 0 0 -9 9 N /A
1 0 0 - 1 0 9 X Y R e s e t (s t a y 3 s e c o n d s t o b e
r e s e t )
1 1 0 - 2 5 5 N /A
Manual | Clou³ Multifunction 3in1 LED Display
Video + lighting + movement
