LTS LTH-D311GY-WIFI User manual

Network Indoor Station
Configuration Guide

Network Indoor Station Configuration Guide
i
Legal Information
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the company website.
Please use this Manual with the guidance and assistance of professionals trained in supporting the
Product.
Trademarks
Trademarks and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND
"WITH ALL FAULTS AND ERRORS". OUR COMPANY MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL OUR COMPANY BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE),
PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF
OUR COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY WILL
PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATTER PREVAILS.

Network Indoor Station Configuration Guide
ii
Data Protection
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of our devices incorporates privacy by design principles. For example, for device
with facial recognition features, biometrics data is stored in your device with encryption method;
for fingerprint device, only fingerprint template will be saved, which is impossible to reconstruct a
fingerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protection laws and regulations, including without limitation, conducting
security controls to safeguard personal data, such as, implementing reasonable administrative and
physical security controls, conduct periodic reviews and assessments of the effectiveness of your
security controls.

Network Indoor Station Configuration Guide
iii
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.

Network Indoor Station Configuration Guide
iv
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
1. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device.
1. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes : l'appareil
ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.

Network Indoor Station Configuration Guide
v
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
Power Source Detail
The power source should be qualified and meet limited power source or PS2 requirements
according to IEC 60950-1 or IEC 62368-1 standard.

Network Indoor Station Configuration Guide
vi
Contents
Chapter 1 Activation...................................................................................................................8
1.1 Activate via NVMS V3............................................................................................................8
Chapter 2 Local Operation..........................................................................................................9
2.1 Quick Operation ....................................................................................................................9
2.2 Basic Settings.......................................................................................................................14
2.2.1 Set Indoor Station Network Parameters.................................................................14
2.2.2 Set Linked Device IP .................................................................................................15
2.2.3 Set Wi-Fi....................................................................................................................17
2.2.4 Set Indoor Station No...............................................................................................18
2.2.5 SIP Settings ...............................................................................................................20
2.2.6 Add Camera ..............................................................................................................21
2.3 Password Settings ...............................................................................................................21
2.3.1 Change Admin Password .........................................................................................21
2.3.2 Security Settings.......................................................................................................22
2.3.3 Modify Unlock/Duress Code....................................................................................22
2.4 Synchronize Time ................................................................................................................23
2.5 Sound Settings.....................................................................................................................24
2.5.1 Call Settings ..............................................................................................................24
2.5.2 Volume Settings .......................................................................................................27
2.6 Via the mobile client ...........................................................................................................27
2.6.1 Link to the Mobile Client..........................................................................................27
2.6.2 Unlink the Account...................................................................................................28
2.7 System Settings ...................................................................................................................28
2.8 Output Settings ...................................................................................................................31
2.9 Device Information..............................................................................................................31
Chapter 3 Remote Operation via the Client Software................................................................32
3.1 Device Management ...........................................................................................................32
3.1.1 Add Video Intercom Devices....................................................................................32
3.1.2 Modify Network Information ..................................................................................34

Network Indoor Station Configuration Guide
vii
3.2 System Configuration..........................................................................................................35
3.3 Remote Configuration.........................................................................................................35
3.3.1 System ......................................................................................................................35
3.3.2 Video Intercom.........................................................................................................41
3.3.3 Network....................................................................................................................47
3.4 Person Management...........................................................................................................52
3.4.1 Organization Management......................................................................................52
3.4.2 Person Management................................................................................................53

Chapter 1 Activation
1.1 Activate via NVMS V3
You can only configure and operate the indoor station after creating a password for the device
activation.
You can also activate the device from the intercom touch screen if needed.
Before You Start
Default parameters of indoor station are as follows:
●Default IP Address: 192.0.0.64.
●Default Port No.: 8000.
●Default User Name: admin.
Steps
1. Run the client software, enter Device Management, check the Online Device area.
2. Select an inactivated device and click the Activate.
3. Create a password and confirm the password.
Note
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three kinds of following categories: upper case letters, lower
case letters, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can better protect your product.
4. Click OK to activate the device.

Chapter 2 Local Operation
2.1 Quick Operation
After device activation, the wizard page will pop up.
Steps
1. Choose language and tap Next.
Figure 2-7 Language Settings
2. Set password reset methods and tap Next.
–Bind an email address. If you forget your admin password, you can reset the password via the
reserved email address.
–Tap Change to Security Question to select security questions and enter the answers. If you
forget your admin password, you can reset the password via answering the questions.

Figure 2-8 Password Reset Methods
3. Set network parameters and tap Next.
–Edit Local IP, Subnet Mask and Gateway parameters manually.
–Enable Auto Get IP address, the device will get network parameters automatically.
Figure 2-9 Network Parameters
4. Configure the indoor station.
1) Select Device Type as Indoor Station or Indoor Extension.
2) Set Floor No..

3) Set Room No..
4) Configure advanced settings. Set Community No., Building No. and Unit No.
5) Set Registration Password.
6) Tap Next.
Figure 2-10 Indoor Station Settings
5. Enable the Wi-Fi function. Select a Wi-Fi from the list and enter the Wi-Fi's password to get
connected. Tap Next.
Note
The device can communicate via Wi-Fi or LAN. We suggest using PoE whenever possible.

Figure 2-11 Wi-Fi
6. Set time and tap Next.
1) Select the Time Zone.
2) Tap Date Format and Time Format to set the time format.
3) Tap Time to set time manually.
4) Enable DST. Set the DST start time, end time and bias time.
Figure 2-12 Time Settings
7. Configure the Mobile APP service settings.

1) Enable Mobile APP service.
2) Edit verification code or use the activation password by default.
3) View Server Status.
4) Scan the first QR Code to download the APP of LTS Connect. Scan the second QR Code to add
your device to the APP. After adding the device to the APP, you can configure the device
remotely.
5) Tap Next.
8. Link related devices and tap Next. If the device and the indoor station are in the same LAN, the
device will be displayed in the list. Tap the device or enter the serial No. to link.
Figure 2-13 Related Device
1) Tap the door station in the list to link.
Note
If the door station is inactive, the system will pop up the dialog to activate the door station.
2) Edit the network parameters of the door station manually.
3) Tap Next.
9. Optional: Enable Indoor Station and link related indoor extension devices. Tap Finish. If the
indoor extension and the indoor station are in the same LAN, the device will be displayed in the
list. Tap the device or enter serial No. to link.

Figure 2-14 Related Device
1) Tap the indoor extension in the list to link.
Note
If the indoor extension is inactive, the system will pop up the dialog to activate the device.
2) Edit the network parameters of the indoor extension manually.
10. Tap Finish to save the settings.
2.2 Basic Settings
Basic settings are required before starting using the indoor station. It is necessary to set the indoor
station network, room No., linked devices, device time display, and so on.
2.2.1 Set Indoor Station Network Parameters
Network connection is mandatory for the use of the indoor station. Set the network parameters
after activating the indoor station. Only when the IP address of the indoor station is in the same
network segment as other devices, it can work properly in the same system.
Steps
Note
The default IP address of the indoor station is 192.0.0.64.

Two ways are available for you to set IP address: DHCP and set IP address manually.
1. Tap Settings → → Configuration and enter admin (activation) password.
2. Tap to enter the network settings page.
Figure 2-15 Network Settings
3. Set the network parameters.
–Enable DHCP, and the system can assign an IP address of the indoor station automatically.
–Disable the DHCP function, and set the IP address manually. You should set the device IP
address, the gateway, the DNS address.
2.2.2 Set Linked Device IP
Linked network parameters refers to the network parameters of devices (like door station,
doorphone, main station, center, etc.), to which the indoor station is linked. Linked devices for the
indoor station refers to door station, center, main station, and doorphone.
With the private SIP protocol, intercom can be realized only when all these devices are in the same
network segment with the indoor station.
With the standard SIP protocol, intercom can be realized when all these devices support the
standard SIP protocol.
Steps
Note
●The doorphone does not support adding with the standard SIP protocol.
●Here take main door station network settings as example.

1. Tap Settings → → Configuration → to enter the device management page.
Note
Default admin password is the activation password.
Figure 2-16 Device Management
2. Tap Main Door Station to pop up the device information dialog.
Figure 2-17 Device Information
Set the parameters
of the linked door
station.
Tap to set parameters of the door station.
3. Select a device to link. Edit the following parameters.
Name
You can edit the name of the device.
Language
Select a language from the drop-down list for the device.
Network
Enable Auto Get IP Address and the system will assign IP address, subnet mask, and gateway

automatically. Or edit the IP address, subnet mask, and gateway manually.
Door Lock Parameters
After wire the lock with the door station, you can set name and door opening duration
according to your needs.
Note
Up to 2 locks can be configured.
Volume Settings
Set microphone volume and output volume.
Call Number Settings
The call No. should be the same as the indoor station's room No. If press the call button of
the door station, you can call the indoor station directly.
Public Password
You can use the public password to open the door station related door lock. Select the public
password type. Enter the old password and new password and then confirm the new
password. Tap OK to save the settings.
Restore to Default Settings
Restore All
All parameters will be restored to the factory settings. The system will reboot to take
effect.
Device Reboot
Reboot the device.
2.2.3 Set Wi-Fi
Tap Settings → to enter the Wi-Fi Settings page. Enable Wi-Fi. Select Wi-Fi from the list and
enter the password of the Wi-Fi, and the indoor station can connect to the Wi-Fi.

Figure 2-18 Wi-Fi Settings
2.2.4 Set Indoor Station No.
Indoor station No. and the indoor extension No. are numbers, which can be dialed by other
devices to call the indoor station and the indoor extension in an intercom system. The indoor
station No., is composed of the floor No., room No., community No., building No. and unit No.
The indoor extension No. Should be a numeric from 1 to 5.
Up to 5 indoor extensions can be set for 1 indoor station.
Steps
1. Tap Settings → → Configuration → to enter the indoor station No. settings page.
Note
Default admin password is the activation password.

Figure 2-19 Set Indoor Station No.
2. Select Indoor Station to set the room information, live view duration, SIP parameters and
password.
Room Information
You can set room name, floor No., and room No. Tap Advanced Settings to set community
No., building No. and unit No. if you need.
Note
●Community No., building No., and unit No. can be omitted if there is no such information.
●If there are two indoor stations that are in the same building, and should call each other,
enter the room No. directly to call.
●If there are two indoor stations that are in two buildings, and should call each other, enter
the building No. and the room No. to call. For example, call 1-405 to call room 405 in
building 1.
Live View Duration
You can set the duration of live view.
SIP Settings
You can set SIP parameters. For more details, please refer to: SIP Settings
Password Settings
You can set unlock password and duress code.
3. Select Indoor Extension to set the room information, live view duration, registration password
and enable SIP 1.0 according to your needs.
