KB –LTH-301m-WIFI Quick Guide
LTH-301m-WIFI is a modern stylish intercom device with a compact design. The size
is slightly larger than a computer mouse. It is sleek and professional looking when
installed.
The LTH-301m-WIFI is developed based on technology from the LTH-M201-C. In theory, it can replace the LTK3500S in a few ways.
LTH-M001
LTH-M201-C
LTH-301M-WIFI
LTK3500S(F)
LTK3410MF
LTK3607FM
Product Line
Intercom
Intercom
Intercom
Access Control
Access Control
Access Control
Call Intercom Indoor Station
Yes
Yes
Yes
No
Yes
Yes
Max # of Apartments / Offices
1
500
1
1
500
500
Call NVMS V3
Yes
Yes
Yes
Yes
Yes
Yes
Call LTS Connect APP without Indoor
Station
Yes
No
Yes
Yes
Yes
No
Build-in Card Reader
No
Add MCR module
Yes
Yes
Yes
Yes
Max # of Cards (and Faces for 3410
and 3607)
N/A
10,000
256
50,000
1,500
6,000
Code Entry
No
Add KP module
No
Add Wiegand
Keypad Reader
Yes
Yes*
Scheduled Unlock/Remain Lock
No
No
No
Yes
Yes
Yes
PC Software (NVMS V3) Unlock **
No
Yes
Yes
Yes
Yes
Yes
Facial Recognition
No
No
No
No
Yes
Yes
Dimension L x W x H
6.4"x 2.9"x 2.1"
4.6"x 4.2"x 1.3"
4.7"x 2.2"x 0.8"
8.6"x 3.1"x 1.6"
6.8"x 3.3"x 0.9"
9.4”x 4.6”x 1.3"
S=Surface Mount, F=Flush Mount
S
S or F
S
S
S
S
Power Supply
PoE/DC12V 1A
PoE/DC12V 1A
PoE/DC12V 1A
DC12V 1A
DC12V 2A
DC 12V 3A
Hardware Description:
Terminal Wire Diagram:
1 Microphone
2 Camera
3 Indicator Unlock (Green; unlock)
4 Button (White Color; show at night)
5 Card Reading Area
6 Loudspeaker
7 Terminals
8 Debugging Port (no use)
9 TAMPER Sensor
10 Set Screw

pg. 2
Activation is Required: LTH-301m-WIFI requires WEB / IP Portal / NVMSv3 to activate and create the password first.
The default IP address is 192.0.0.65
1. Create admin Password & Activate.
2. Change the device IP address to connect the Internet.
Mobile App: LTS Connect
Once you are connected to the internet, you can use the Mobile
app to connect and call. To use the LTS Connect App, you need
to finish the following first.
1. Connect the Intercom Device to the Internet
2. Download LTS Connect and Register an account by
using Phone# or Email. Get the Confirmation code
from Text / Email, create LTS Account Login
Password.
3. Add the QR code to this account.
The QR code is located on the back of your
device. A Verification Code is also printed there.
After you connect the intercom successfully, you can watch
the Live View stream. The Microphone icon below the video
steam allows you to talk 2-way with the camera without being
on the call.
Use the Snapshot / Record icon to save footage onto your
mobile device.
Calling Mobile App - Press the Call button
After setting up the Mobile App and connecting the intercom correctly,
when you press the Call button, it will call the mobile app by default.
If the intercom is not setup, you will get a ‘Calling Failed’ error
message.

pg. 3
Install NVMSv3
After the NVMSv3 is installed, run the software. Go to Device Management, and
click ‘Online Device’. You should able to see it from the local network section at
the bottom of the page.
(NOTE: Set the IP address correctly for your network before adding it)
Remote Configuration
Make sure the device is Online.
Scroll to the right on the Device line item and you
should see the configuration (operation) section.
(NOTE: If your screen is small and you do not want to scroll to the
right side every time to access the Config button, you could
customize the column (right click the header) to reduce the
display column length. ie: remove the ‘Firmware Upgrade’
column.)
Click the Configure button.

pg. 4
Main View & Unlock Door
After you have added the Intercom to the software, go to the
Main View. Double-tap the device from the left panel to start
the Live View.Hover the mouse on top of the video, you should
see the function bar on the bottom of the stream (black area).
Unlock door button is on the left side of the function bar. (see
the orange arrow)
Click the Microphone icon to perform 2 way communication
with the intercom.
Change Calling to NVMSv3 Software
By default, the Intercom device is setup to call your Mobile App. This
can be changed to call the NVMSv3 software if needed. Please note
that the NVMSv3 software needs to be running to receive the call when
the button is pressed.
To change the setting, go to the NVMSv3 Remote Configuration for the
device or go to the Main Screen, click the Config button on the function
(see top of right picture)
Go to Intercom > Dial.
Enable ‘Quick Press for Calling Center’Click Save.
When you press the call button on the intercom it will call the NVMSv3
Call Center software instead.
NOTE: If you change this function, the mobile app will no longer receive
the calls until you revert this function back. The device cannot ring
both the LTS Connect App and NVMSv3 software simultaneously.
Connecting the Indoor Station Intercom
There are two ways to point the Indoor Station to the LTH-301m-WIFI
Intercom. This requires setting the Door station Master Address
1. NVMSv3
2. Indoor Station
In NVMSv3:
Remote Configuration of Indoor Station > Network > Linked Network
Configuration.
Set the ‘Door Station IP Address’
to the LTH-301m-WIFI IP address.
On Indoor Station:
Click Settings > More (wrench icon on the right) > Configuration (log into the Indoor station with the password used to activate the device) >
Device management (3rd icon on the right) and set the Door station IP address here.

pg. 5
Program Card Access –Add Person
Go to NVMSv3. Click the Menu Icon > Access Control > Person
Click +Add to add a person… (Follow the steps 1,2,3, etc.)
On step #5, select your LTH-301m Reader to read in the card from the device. You can also manually type in the card number. A manually
entered card number must match the physical card number itself.
Program Card Access –Add Permission
Go to the Access Control section
1. Go to Authorization > Access Group
2. Click +Add
3. Give an appropriate permission name.
4. Select the Time Template (All-Day
Authorized by default).
5. Select Person to add.
6. Select the door.
7. Click Save.
8. Select the Permission.
9. Apply changes.

pg. 6
Event Logs
Event Logs are saved in the NVMSv3 PC system, it is not saved in the device itself. To retrieve it, you can go to the Event Center.
Then follow the Steps 1-5 to search. Make sure to select the Video Intercom in Step 3.
Video Recording
You can record or snapshot the video while you watch and save to your
PC (see Pg4 Main View Picture)
The LTH-301m-WIFI device does not come with a self-record storage
function. (Note: The LTH-301m TF/SD card slot is disabled, and not used for recording
purposes.)
If you want to do Motion Detection Recording, you need a DVR/NVR to
record it. Make sure to turn on the Motion Detection in the 301m setting through NVMSv3 or through the Web Interface.
Or, if you want to use your PC to record automatically, you need setup the
NVMSv3 Storage Server. If you are interested in storage server setup,
please check the knowledgebase page from the link below.
https://ltsecurityinc.zendesk.com/hc/en-us/articles/360051972713--PC-NVMSv3-Storage-Server-Settings

pg. 7
FAQ
1. Q: Where can I find the user manual?
A: The LTS website or the knowledgebase page area.
https://ltsecurityinc.zendesk.com/hc/en-us/categories/360004343213-Official-User-Manual
2. Q: How do I factory default the device?
A: There is no physical default button for the LTH-301m device.
You may go to the Web interface or go to the NVMSv3 Remote configuration,
under Maintenance > Default.
3. Q: Why does the LED button not light up?
A: The LED only lights up when the device detects it is dark out.
4. Q: Why is there an alarm sound when the device is powered on?
A: It is a Tamper Alarm. The LTH-301m requires the metal Tamper Plate to be installed. If it installed correctly, the alarm will not
sound when powered up.
5. Q: How do I change the Microphone / Speaker Volume?
A: Through the Web Interface (see picture)
6. Q: How do I change the max call duration?
A: Through the Web Interface (see picture)
7. Q: Can you push the call button to call the Mobile App and
NVMSv3 software at the same time?
A: The call button can only be pointing to one device at a time.
Either the Mobile App or the NVMSv3 software (PC).
8. Q: Does the device support Push Notification for the Mobile App?
A: Currently, this is not available.
9. Q: Why can I see the stream and talk back but I can’t unlock the
door?
A: Network issue. Either not enough bandwidth or IP conflicted.
10. Q: Can I program the device to open the door based on a schedule?
A: No. The Intercom does not support this feature. If you want to open a door based on a schedule, you will need an access control
device. Intercom and access control are different products.
11. Is the camera ONVIF compatible?
A: No.
12. What is the TF/SD card slot (memory card slot) for?
A: It is a reserved slot that currently does not have a function.
Technical Post Note: Master Issue Card:
The package comes with a white card. It is the master issue card. The master issue is designed for No Network environment.
However, you still need to use a PC to activate the device for the first time. The issued card is helping to program the access card without PC. Just simply Tap Master issue card –Programming. Tap –New Card. And end the Tap
Master issue card to finish it. The master issue card is unique per device and binds to the 301m device. It is not compatible with any other device. LTS is not provided any support or warranty when you lost the card.
