LTV LTV-8N12082AD-K User manual

Quick Installation Guide
8x Multi Power Supply
LTV Europe Sicherheitstechnik GmbH
Am Wall 113
28195 Bremen
Germany
www.ltv-cctv.eu
LTV-8N12082AD-K

Front Panel
(1) Adjustable output voltage (ADJ):
This button is for adjusting the output voltage from 10.5V to 13.8V.
(2) Power indicator:
The power indicator turns on, when the power supply is activated. If the indicator
turns red, the device continues normal operation.
(3) Output voltage reader:
This indicator shows the output voltage, which you can adjust with the correspon-
ding button (1) on the front panel.
Details
(4) Power supply connector:
Input 96 - 264V, 47 - 63 Hz.
(5) Power supply safety unit:
Integrated glass fuse 5A.
(6) Power supply switch:
„I“ stands for„switched on“;„O“ stands for„switched o“
(7), (8) Output DC:
During the connection, you should note the„+“ and„-“ poles.
Rear panel
2
1
3
5
4
6
78

Installation
Step 1. Connect the power supply connector (4).
Step 2. Switch on the power supply switch (6).
Step 3. Check the LED-power indicator (2) and make sure that it turns solid red,
check the output voltage reader (3) and make sure that it indicates the output vol-
tage, check the LEDs of the channel and make sure that they turn solid green.
Step 4. Once you have checked all details of operation, you can switch o the de-
vice and remove the power adaptor.
Step 5. Connect the DC connectors as you require and repeat the steps 1-3.
Accessories
Dimensions
44
44
276
430,7
R3
210,1 175

LTV Europe Sicherheitstechnik GmbH
Am Wall 113
28195 Bremen
www.ltv-cctv.eu
[e-mail]
The LTV Europe Sicherheitstechnik GmbH as the publisher of this document, provi-
des no warranties related to the accuracy, completeness and topicality of the cont-
ent. The LTV Europe Sicherheitstechnik GmbH furthermore reserves the right to pub-
lish updated and revised versions of this document without prior notice. The names,
tradenames, trademarks etc. described in this work are used without guarantee of
free usability, and may be registered trademarks or brands without specic labelling,
and as such may be subject to legal regulations. This work is protected by copyright.
All rights, including the right to reproduce, reprint and the distribution and transla-
tion of this document, or parts thereof, are reserved. No part of this document may
be in any way reproduced, or electronically stored, processed, copied or distributed,
without written permission of the publisher or author, not even for the purpose of
teaching. All rights reserved.
© 2016 Version 01/2016
