CIB 2863
2-Line Adapter
CIB 2863
Comcode 103-974-572
Issue 2

CIB 2863
2-Line Adapter
The (267C) 2-Line Adapter is used to connect two (D2R-29) line cords to
an (RJ14C) single network interface where two outside telephone lines
enter the premises. If you do not know whether you have two outside
telephone lines entering at a single network interface, contact your local
telephone exchange service company.
Installation
1 Position the 2-Line Adapter so that its plug matches the jack of the
network interface. Insert the adapter plug firmly; it should lock with a
slight “click” (Figure 1).
iss 2, cib2863-1

Locking Tab
Release
Jacks
Locking Tab
Network
Interface
(RJ14C)
Plug
To Local
Telephone Exchange
Service Company
Lines
To the
Control Unit D2R-29 267C
Adapter
FIGURE 1 (267C) 2-Line Adapter
iss 2, cib2863-2

2 The two jacks on the adapter now provide connecting points for two
individual (D2R-29) modular line cords.
Removal
1 Push down the locking tab release and pull the adapter out of the
network interface jack.
iss 2, cib2863-3
