Lucent Technologies I Series User manual

IR-30EC and IR-40EC
Series I Batteries
KS-23815
Product Manual
Select Code 157-622-020
Comcode 107078859
Issue 7
November 1998
© 1998 Lucent Technologies

Product Manual
KS-23815
Select Code 157-622-020
Comcode 107078859
Issue 7
November 1998
Lucent Technologies
IR-30EC and IR-40EC
Series I Batteries
Notice:
Every effort was made to ensure that the information in this
document was complete and accurate at the time of printing.
However, information is subject to change.
© 1998 Lucent Technologies
All Rights Reserved
Printed in U.S.A.

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 Table of Contents - 1
Table of Contents
1 Introduction
IR-30EC and IR-40EC Batteries 1 - 1
Customer Training 1 - 3
Customer Service 1 - 3
Technical Support 1 - 3
Product Repair and Return 1 - 3
Warranty Service 1 - 3
2 Product Description
Overview 2 - 1
Features 2 - 1
Specifications 2 - 2
3 Ordering Information
Batteries 3 - 1
4 Safety and Environmental
Safety Symbols 4 - 1
Safety Precautions 4 - 1
Poison 4 - 1
Electrical Hazard 4 - 3
Battery Gases 4 - 4
First Aid 4 - 6
Lifting Information 4 - 6
Transportation and Handling 4 - 6
Environmental 4 - 6
5 Battery Storage
State of New Battery 5 - 1
Storage Conditions 5 - 1
Storage Time 5 - 1

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
2 - Table of Contents Issue 7 November 1998
6 Installation
Introduction 6 - 1
Installation Tools, Materials, and Test Equipment 6 - 1
Product Manual 6 - 1
Unpacking and Handling 6 - 2
Specific Unpacking Instructions 6 - 2
Battery String Location 6 - 4
Environmental Requirements 6 - 4
Mixing Batteries in a String 6 - 5
Mixing Parallel Strings of Batteries 6 - 5
Constant Current, Separate Chargers 6 - 5
Constant Voltage Chargers 6 - 5
Battery Installation 6 - 5
Initial Charging 6 - 6
Placing a Battery String Into Service 6 - 8
Installation Records 6 - 8
Voltage Measurements 6 - 8
7 Operation
Lead-acid Battery Gassing Rate 7 - 1
Service Life 7 - 2
Charging 7 - 3
Battery String Float Voltage 7 - 3
Charging Voltage Ripple 7 - 3
Battery and Ambient Temperatures 7 - 4
Capacity 7 - 5
Discharge Capacity Test 7 - 5
Recharge After Discharge 7 - 6
Boost Charge 7 - 7
8 Maintenance
Maintenance Schedule 8 - 1
Maintenance Routines 8 - 2
Individual Battery Voltages 8 - 2
Measuring Battery Temperatures 8 - 3
String Current Measurement 8 - 3
Inspection and Cleaning 8 - 3
Retorquing Inter-battery Connections 8 - 3
Flame Arrestor Vent Feature 8 - 3
Battery Replacement 8 - 4

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 Table of Contents - 3
9 Discharge and Power Data
Discharge Capacity 9 - 1
Discharge Cycle Life 9 - 1
10 Installation and Maintenance Record
11 Material Safety Data Sheet
12 Product Warranty

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 List of Figures - 1
List of Figures
Figure 1-1: IR-30EC Battery 1 - 2
Figure 1-2: IR-40EC Battery 1 - 2
Figure 7-1: Temperature Versus Battery Capacity
(within 5%) for IR-30EC/40EC 7 - 5
Figure 9-1: Discharge Current (within 5%) vs.
Discharge Duration to 10.5V
(IR-30EC and IR-40EC) 9 - 2
Figure 9-2: Discharge Power (within 5%) vs.
Discharge Duration to 10.5V
(IR-30EC and IR-40EC) 9 - 3
Figure 9-3: Characteristic Discharge Curves
(within 5%) for IR-30EC 9 - 4
Figure 9-4: Constant Power Capacity for IR-30EC 9 - 4
Figure 9-5: Characteristic Discharge Curves
(within 5%) for IR-40EC 9 - 5
Figure 9-6: Constant Power Capacity for IR-40EC 9 - 5

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 List of Tables - 1
List of Tables
Table 2-A: IR-30EC and IR-40EC Battery Specifications 2 - 2
Table 3-A: IR-30EC and IR-40EC Batteries Ordering
Information 3 - 1
Table 3-B: Non-Standard Parts for IR-30EC and
IR-40EC Batteries 3 - 2
Table 6-A: Initial Charging 6 - 7
Table 8-A: Required Maintenance Routines 8 - 1
Table 9-A: Battery Discharge Amperes (within 5%)
for IR-30EC at 25°C (77°F) 9 - 6
Table 9-B: Battery Discharge Wattage (within 5%)
for IR-30EC at 25°C (77°F) 9 - 6
Table 9-C: Battery Discharge Amperes (within 5%)
for IR-40EC at 25°C (77°F) 9 - 7
Table 9-D: Battery Discharge Wattage (within 5%)
for IR-40EC at 25°C (77°F) 9 - 7
Table 12-A: New Battery Warranty Period and
Conditions 12 - 1

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 Introduction 1 - 1
1 Introduction
IR-30EC and
IR-40EC
Batteries
This product manual (Select Code 157-622-020) provides
information on Lucent Technologies IR-30EC and IR-40EC
Series I batteries. The IR-30EC and IR-40EC batteries are
12-volt, stationary, valve-regulated, rechargeable, lead-acid
batteries, which are backed by Bell Laboratories, an
acknowledged leader in technology, research, and design of
power systems.
Lucent Technologies’ power products have proved their field
reliability by providing dependable standby reserve power for
the telecommunications industry for decades. All battery
components and manufacturing processes meet Lucent
Technologies’ strict specifications and quality standards.
Designed for applications where the loads are fairly small,
temperatures may vary, and long back-up time is desired,
IR-30EC and IR-40EC Series I batteries are an excellent choice
for subscriber loop, customer premises, and distributed power
cabinets.
Figures 1-1 and 1-2 illustrate the IR-30EC and IR-40EC Series I
batteries.

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
1 - 2 Introduction Issue 7 November 1998
Figure 1-1: IR-30EC Battery
Lucent
6.75 in.
(17.5 cm)
5.13 in.
(13.02 cm)
7.00 in.
(17.78 cm)
Figure 1-2: IR-40EC Battery
5.13 in.
(13.02 cm)
8.31 in.
(21.1 cm)
Lucent
7.00 in.
(17.78 cm)

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 Introduction 1 - 3
Customer
Training Lucent Technologies offers customer training on many Power
Systems products. For information call 1-972-284-2163. This
numberisansweredfrom8:00a.m. until4:30p.m.,Central Time
Zone (Zone 6), Monday through Friday.
Customer
Service Forcustomers in the United States, Canada, Puerto Rico, and the
US Virgin Islands, call 1-800-THE-1PWR (1-800-843-1797).
Services provided through this contact include initiating the
spare parts procurement process for out of service emergencies,
ordering Lucent Technologies documents, and providing other
product and service information.
For other customers worldwide, call 001-972-840-0382. This
numberisansweredfrom8:00a.m. until4:30p.m.,Central Time
Zone (Zone 6), Monday through Friday.
Technical
Support Technical support for Lucent Technologies customers is
available around the world during the normal product warranty
period and also while specific contractual agreements extend
this service.
For customers in the United States, Canada, Puerto Rico, and the
US Virgin Islands, call 1-800-CAL-RTAC (1-800-225-7822) to
contact a product specialist to answer your technical questions
and assist in troubleshooting problems.
For other customers worldwide, contact your local field support
center or your salesrepresentative todiscuss your specific needs.
Product Repair
and Return Repair and return service is provided for Lucent Technologies
customers around the world. For customers in the United States,
Canada, Puerto Rico, and the US Virgin Islands, call
1-800-255-1402 for information on returning of products for
repair.
For other customers worldwide, contact your sales
representative to discuss your particular circumstances.
Warranty
Service For warranty service worldwide, contact your Warranty Service
Manager (WSM). The WSM serves specific customer-groups,
who have taken ownership of the product. For product

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
1 - 4 Introduction Issue 7 November 1998
conformance issues prior to customer ownership, contact your
local customer service.

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 Product Description 2 - 1
2 Product Description
Overview Lucent Technologies IR Series I batteries are configured in two
different ampere-hour capacities that are engineered to meet
specific and often unique application requirements: IR-30EC
and IR-40EC.
The valve-regulated design and constructionof the IR-30EC and
IR-40EC batteries prevents electrolyte leakage and minimizes
water loss and maintenance throughout the design life. During
normal operation, oxygen is generated at the positive electrode
and hydrogen is generated at the negative electrode. In
conventional (flooded) lead-acid cells, these electrochemical
reactions result in water loss from the electrolyte. The
self-resealing pressure release safety valves in IR-30EC and
IR-40EC batteries are designed to aid in the electrochemical
recombination of nearly all the oxygen within the battery. In
addition, the safety valves prevent the build-up of excessive
internal pressure.
The IR-30EC and IR-40EC batteries comply with the
requirement for sealed battery/cell pressure release test of
UL1989, Standard for Standby Batteries.
Features • High energy density
• Leak-resistant post seals
• Flame arrestor
• Flame-retardant 94-V0 polypropylene container and cover
• Metal sleeve

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
2 - 2 Product Description Issue 7 November 1998
Specifications
Table 2-A: IR-30EC and IR-40EC Battery Specifications
IR
Series I Nominal Voltage
Nominal
Ampere
Hours at
8-hour Rate
Charging
Method
Maximum
Dimensions
WxDxH Weight
IR-30EC 12 25 Constant Voltage/
Constant Current 6.75 x 5.13 x 7.0 in. 17.2 x 13.0 x 17.8 cm 24 lbs.
10.9 kg
IR-40EC 12 34 Constant Voltage/
Constant Current 8.31 x 5.13 x 7.0 in. 21.1 x 13.0 x 17.8 cm 32 lbs.
14.5 kg

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
Issue 7 November 1998 Ordering Information 3 - 1
3 Ordering Information
Batteries
Table 3-A: IR-30EC and IR-40EC Batteries Ordering Information
Comcode Model No. Description
407928761 IR-30EC Battery
12V, 25Ah battery with standard 14 AWG lead
assembly terminating with 350537-6 AMP
contacts and a 1-480698-0 AMP
2-terminal plug
407976182* IR-30EC Battery equipped with
heavy-duty cable
12V, 25Ah battery equipped with 847307436
heavy-duty 10 AWG cable and 4-terminal plug
407928753 IR-40EC Battery 12V, 34Ah battery with standard 14 AWG lead assembly terminating with 350537-6 AMP
contacts and a 1-480698-0 AMP 2-terminal plug
407976190* IR-40EC Battery equipped with
heavy-duty cable
12V, 34Ah battery equipped with 847307436
heavy-duty 10 AWG cable and 4-terminal plug
*Lucent Technologies IR-30EC and IR-40EC batteries are provided with a 14 AWG
lead assembly terminating with AMP #350537-6 contacts and an AMP #1-480698-0
plug as standard equipment. The standard lead assembly was designed to be
compatible with Lucent Technologies SLC 96 and SLC Series 5 applications where
reserve power of 5 hours or longer duration is required. The standard assembly may
not be suitable for applications where the battery load exceeds the 5-hour rate, and may
fail catastrophically at battery charge/discharge currents exceeding 18 amperes.

Lucent Technologies IR-30EC and IR-40EC Series I Batteries
3 - 2 Ordering Information Issue 7 November 1998
Table 3-B: Non-Standard Parts for IR-30EC and IR-40EC Batteries
Comcode/
J-Code Model No. Description
846861664 Interbattery bus bar Interbattery bus bar to connect IR-30EC and
IR-40EC batteries within a string
