Lucent Technologies IR II Series User manual

IR Series II Batteries
12IR125/12IR125LP
KS-23997
Product Manual
Select Code 157-622-025
Comcode 107251688
Issue 7
December 1999
© 1999 Lucent Technologies

Product Manual
Select Code 157-622-025
Comcode 107251688
Issue 7
December 1999
Lucent Technologies
IR Series II Batteries
12IR125/12IR125LP
KS-23997
Notice:
Every effort was made to ensure that the information in this
document was complete and accurate at the time of printing.
However, information is subject to change.
© 1999 Lucent Technologies
All Rights Reserved
Printed in U.S.A.

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 Table of Contents - 1
Table of Contents
1 Introduction
12IR125 Batteries 1 - 1
Customer Assistance Contacts 1 - 3
Customer Training 1 - 3
Customer Service 1 - 3
Technical Support 1 - 3
Product Repair and Return 1 - 3
Warranty Service 1 - 4
On-Line Power Systems Product Manuals 1 - 4
2 Product Description
Overview 2 - 1
Features 2 - 2
Specifications 2 - 3
3 Ordering Information
Batteries 3 - 1
Single Hole Lugs 3 - 2
4 Safety and Environmental
Safety Symbols 4 - 1
Safety Precautions 4 - 1
Poison 4 - 1
Electrical Hazard 4 - 3
Battery Gases 4 - 4
First Aid 4 - 6
Lifting Information 4 - 6
Transportation and Handling 4 - 6
Environmental 4 - 6
5 Battery Storage
State of New Battery 5 - 1
Storage Conditions 5 - 1

Lucent Technologies 12IR125 Series II Batteries
2 - Table of Contents Issue 7 December 1999
Storage Time 5 - 1
6 Installation
Introduction 6 - 1
Installation Tools, Materials, and Test Equipment 6 - 1
Accessory Kit 6 - 2
Product Manual 6 - 2
Connectors 6 - 2
Unpacking and Handling 6 - 2
Safe Handling 6 - 2
Specific Unpacking Instructions 6 - 3
Battery String Location 6 - 5
Environmental Requirements 6 - 5
Mixing Batteries in a String 6 - 6
Battery Installation 6 - 7
Battery Installation Procedure 6 - 9
Initial Charging 6 - 10
Placing a Battery String Into Service 6 - 12
Installation Records 6 - 12
Voltage Measurements 6 - 13
7 Operation
Lead-acid Battery Gassing Rate 7 - 1
Service Life 7 - 2
Charging 7 - 3
Battery String Float Voltage 7 - 3
Charging Voltage Ripple 7 - 3
Battery and Ambient Temperatures 7 - 4
Capacity 7 - 5
Temperature Correction for Capacity 7 - 5
Discharge Capacity Test 7 - 6
Recharge After Discharge 7 - 7
Boost Charge 7 - 7
8 Maintenance
Maintenance Schedule 8 - 1
Maintenance Routines 8 - 2
Individual Battery Voltages 8 - 2
Measuring Battery Temperatures 8 - 3
String Current Measurement 8 - 3
Inspection and Cleaning 8 - 3
Retorquing Inter-battery Connections 8 - 4
Flame Arrestor Vent Feature 8 - 4

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 Table of Contents - 3
Battery Replacement 8 - 4
9 Discharge and Power Data
Discharge Capacity 9 - 1
Discharge Cycle Life 9 - 1
10 Installation and Maintenance Record
11 Material Safety Data Sheet
12 Product Warranty

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 List of Figures - 1
List of Figures
Figure 1-1: 12IR125 Battery 1 - 2
Figure 1-2: 12IR125LP Battery 1 - 2
Figure 6-1: Typical Inter-battery Connection 6 - 7
Figure 6-2: Inter-battery Connections of 12IR125 6 - 8
Figure 6-3: Inter-battery Connections of 12IR125LP 6 - 8
Figure 7-1: Temperature Correction Chart 7 - 6
Figure 9-1: Characteristic Discharge Curve 9 - 2
Figure 9-2: Discharge Watts Versus Discharge Duration 9 - 2
Figure 9-3: Discharge Current versus Discharge Time 9 - 3

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 List of Tables - 1
List of Tables
Table 2-A: 12IR125 and 12IR125LP Specifications 2 - 3
Table 3-A: 12IR125 and 12IR125LP Ordering Information 3- 1
Table 3-B: Single Hole Connectors 3 - 2
Table 6-A: Initial Charging 6 - 11
Table 8-A: Required Maintenance Routines 8 - 1
Table 9-A: Battery Discharge Amperes for 12IR125
at 77°F 9 - 3
Table 9-B: Battery Discharge Watts for 12IR125
at 77°F 9 - 4
Table 12-A: New Battery Warranty Periods
and Conditions 12 - 1

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 Introduction 1 - 1
1 Introduction
12IR125
Batteries This product manual (Select Code 157-622-025) provides
information on Lucent Technologies’ 12IR125 and 12IR125LP
batteries.
Note: Except for specific references, the term “12IR125” refers
to both the 12IR125 and 12IR125LP batteries.
The 12IR125 battery is a 12-volt, stationary, valve-regulated,
rechargeable, lead-acid battery designed by Bell Laboratories,
an acknowledged leader in technology, research, and design of
power systems.
Lucent Technologies’ power products have proved their field
reliability by providing dependable standby reserve power for
the telecommunications industry for decades. All battery
components and manufacturing processes meet Lucent
Technologies’ strict specifications and quality standards.
Designed for applications where the loads are fairly large,
temperatures may vary, and long back-up time is desired,
12IR125 batteries are an excellent choice for Lucent
Technologies 60- and 80-Series cabinets, mini- and maxi-huts,
vaults, customer premises, and outdoor wireless communication
sites.

Lucent Technologies 12IR125 Series II Batteries
1 - 2 Introduction Issue 7 December 1999
Figure 1-1: 12IR125 Battery
10.10"
(25.7 cm)
6.97"
(17.7 cm)
16.82"
(42.7 cm)
Figure 1-2: 12IR125LP Battery
17.9"
(45.5 cm)
16.4"
(41.7 cm)
7.08"
(18 cm)
6.97"
(17.7 cm)
9.36"
(23.8 cm)

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 Introduction 1 - 3
Customer
Assistance
Contacts
Customer Training Lucent Technologies offers customer training on many Power
Systems products. For information call 1-972-284-2163. This
numberisansweredfrom8:00a.m.until4:30p.m.,CentralTime
Zone (Zone 6), Monday through Friday.
Customer Service For customers in the United States, Canada, Puerto Rico, andthe
US Virgin Islands, call 1-800-THE-1PWR (1-800-843-1797).
Services provided through this contact include initiating the
spare parts procurement process for out of service emergencies,
ordering Lucent Technologies documents, and providing other
product and service information.
For other customers worldwide, call 001-972-840-0382. This
numberisansweredfrom8:00a.m.until4:30p.m.,CentralTime
Zone (Zone 6), Monday through Friday.
Technical Support Technical support for Lucent Technologies customers is
available around the world during the normal product warranty
period and also while specific contractual agreements extend
this service.
For customers in the United States, Canada, Puerto Rico, andthe
US Virgin Islands, call 1-800-CAL-RTAC (1-800-225-7822) to
contact a product specialist to answer your technical questions
and assist in troubleshooting problems.
For other customers worldwide, contact your local field support
center or your sales representative to discuss your specific needs.
Product Repair and
Return Repair and return service is provided for Lucent Technologies
customers around the world.
For customers in the United States, Canada, Puerto Rico, andthe
US Virgin Islands, call 1-800-255-1402 for information on
returning of products for repair.
For other customers worldwide, contact your sales
representative to discuss your particular circumstances.

Lucent Technologies 12IR125 Series II Batteries
1 - 4 Introduction Issue 7 December 1999
Warranty Service For domestic warranty service, contact your Warranty Service
Manager (WSM). For international warranty service, contact
your sales representative.
On-Line Power
Systems Product
Manuals
For Lucent Technologies users logging in from inside the
corporate firewall, the address of the “Power Systems On-Line
Product Manuals” page is
http://www.cic.lucent.com/lineage.html.
Forcustomers logging infromoutsidethefirewall, theaddressis
http://www.lucent8.com/lineage.html. The annual subscription
fee for access to this site is $25.To obtain a password, follow the
instructions on-line or call 1-888-Lucent8 (1-888-582-3688).
When prompted for an order number, enter or say
“167-790-010.”

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 Product Description 2 - 1
2 Product Description
Overview The 12IR125 is a 12-volt, 125 ampere-hour (ten-hour rate)
battery that packs greater capacity in a reduced footprint. The
compact design allows additional room for air flow between the
batteries or for an additional battery string in many applications.
The valve-regulated design and construction of the 12IR125
batteries prevent electrolyte leakage and minimize water loss
and maintenance throughout the design life. During normal
operation, oxygen is generated at the positive electrode and
hydrogen is generated at the negative electrode. In conventional
(flooded) lead-acid cells, these electrochemical reactions result
in water loss from the electrolyte. The self-resealing pressure
release safety valves in 12IR125 batteries are designed to aid in
the electrochemical recombination of nearly all the oxygen
within the battery. In addition, the safety valves prevent the
build-up of excessive internal pressure.
Like other Lucent Technologies valve-regulated batteries, the
12IR125 battery’s pure lead positive grid is the key to its slow,
uniform growth rate, which promotes longer life. This slow
growth rate, combined with extremely low water loss, allowsthe
cell to maintain capacity over its 10-year life span (80% of
capacity @ 10 years) when operated at 77°F (25°C).
The 12IR125 battery is ideal for most operating environments
because of its leakproof seals, high-strength, flame-resistant
polypropylene (UL94 V-O) jar and cover, and low gassing rate
(compared to flooded design).
The 12IR125 battery complies with the requirement for sealed
battery/cell pressure release test of UL1989, Standard for
Standby Batteries.

Lucent Technologies 12IR125 Series II Batteries
2 - 2 Product Description Issue 7 December 1999
Features • Bell Laboratories’ patented lead/tin alloy post, leakproof
post seal, and valve-regulated design require minimal
maintenance.
• Post design:
– The 12IR125 has a dual-terminal post design (front and
side) that allows for flexible installation.
– The 12IR125LP has a front-terminal post design.
• Elongated slots on inter-battery bus bars allow for variable
spacing between batteries.
• Front-access terminals provide easy access to batteries in
cabinetized power applications.
• Cover:
– The 12IR125 has a top cover that protects from terminal
post shorting and includes a slot to hold a thermal probe.
– The 12IR125LP has a clear terminal shield that protects
the connections for the batteries, eliminating the need
for covers on the battery stand.
• Heat-sealed container and cover provide reliable seal.
• Flame-retardant, non-halogenated, polypropylene container
and cover meet UL 94 V-O and have an oxygen index
greater than 28.
• Permanent, patented V-O handle simplifies handling and
installation.
• Epoxy-coated jacket helps dissipate heat and provides
structural rigidity.

Lucent Technologies 12IR125 Series II Batteries
Issue 7 December 1999 Product Description 2 - 3
Specifications Table 2-A lists the specifications for the 12IR125 and
12IR125LP batteries.
Table 2-A: 12IR125 and 12IR125LP Specifications
Product
Code Nominal Voltage
Ampere
Hours @
8-hour
Rate
Ampere
Hours @
10-hour
Rate
Maximum Dimensions Total
Weight Acid Volume
Length Width Height
12IR125 12V 120 125 16.82 in.
42.72 cm 6.97 in. 17.7 cm 10.10 in. 25.65 cm 120 lbs. 54.55kg 2 gal. 7.57 L
12IR125LP 12V 120 125 17.90 in.
45.47 cm 6.97 in. 17.7 cm 9.36 in. 23.77 cm 120 lbs. 54.55kg 2 gal. 7.57 L
