Lumag BSF15 User manual

Distribution Limited
Petrol Stump Grinder
Operator’s Manual
BSF15
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
BEFORE OPERATING THIS MACHINE

Warranty Registration Form
For the warranty to be valid the Warranty Registration Form must be completed and
returned to Lumag Distribution Limited within 14 days of the purchase, together
with a copy of the purchase invoice.
We will use your email to confirm that we have received the completed Warranty
Registration Form and contact you about any errors or omissions on the form. We
may occasionally use this email address to make you aware of news, technical advice
and special offers. If you do not wish to receive such emails please tick this box.
Unit 10, Hatchmoor Industrial Estate, Hatherleigh, Okehampton, Devon EX20 3LP
www.lumag-gb.co.uk 01837 811741
Lumag Distribution Limited Company Number: 09267547 VAT Number: GB154566788 Hatherleigh
Plant and Tool Hire is a trading name of Lumag Distribution LTD
Model:
Serial Number:
Type of Use: Business / Domesc
Name:
Business Name:
Address:
Email Address:
Phone Number:
Date of Purchase:
Place of Purchase:
Proof of Purchase
enclosed:

Lumag Servicing and
Maintenance Schedules
Engine Service & Maintenance Schedule
Machine Service & Maintenance Schedule
Item Checks/Work Each Use 20hrs
(1st Month)
50hrs
(2nd Month)
100hrs
(6th Month)
300hrs
(Yearly)
Engine Oil Check Level X
Change X (1) X
Air Filter Check X
Clean X (3)
Replace X (4)
Sediment Cup Clean X
Spark Plug Check/Clean X
Replace X
Idle Speed Check/Adjust X (2)
Valve Clearance Check/Adjust X (2)
Fuel Tank Strainer Check/Clean X (2)
Combuster Chamber Inspect/Clean X (2)
Fuel Lines Check X (2)
Item Checks/Work Each Use Weekly 20hrs
(1st Month)
50hrs
(2nd Month)
100hrs
(6th Month)
300hrs
(Yearly)
Grease Main Bearing Check Level X
Fasteners Tension Check Check X
Clean Machine Check X
Inspect Clutch Check/Adjust X (2)
Drive Belt Check/Adjust X
Replace X (2)
All Other Moving Parts &
Cables
Lubricate X X (2)
Engine Oil 1000ml Lumag Engine 1
1 – First service only, 2 = Should be carried out by your Lumag Dealer, 3 = May need to be done more oen in dusty areas &
4 = Replace paper element only
To maximise the life of your Lumag machine it needs to be serviced and maintained at every indicated month or
operang hour interval, whichever comes rst, in accordance with the below Schedules. Please note that failure to
service your machine on schedule or use genuine Lumag parts and consumables will result in your warranty being void.

Distribution Limited
Service & Maintenance Record
Product Details: Model: __________________________________
Serial number: ____________________________ Purchase Date: ____________________________
Date: Description of checks/work carried out: Parts Used?
Y/N
Parts Invoice Number:
Dealers Name:
Engineers Name:
Engineers Signature:
Please note that failure to service your machine on schedule or use genuine Lumag parts and consumables will result in your warranty being void

........................................................................ pg 3
............................................................................ pg 4
........................................... pg 5
................................................................ pg 7
............................................................ pg 11
......................................................... pg 12

3
Stump Grinder
anks for buying the Stump Grinder, another high-quality machine from our
company.
To get the most out of your purchase, please read the manual before using the stump
grinder.
We ask you to please read this manual carefully beforehand in order to familiarise
yourself with this product and aer reading, please store this instructional manual
for future reference. Failure to follow the proper protocols listed in the manual may
cause personal injury to the operator or damage to equipment.

4
Stump Grinder
1Handle Bar
2 Emergency Stop Switch (On/O)
3 rottle
4Wheel
5 Brake Lever
6 Engine
7 Pull Start (behind)
8Cutting Wheel
9Kill Switch
12
3
4
6
7
8
5
9

5
Stump Grinder
• Keep the working area clean and well lit.
• Do not operate the stump grinder in the presence of ammable liquids, gases
or dust.
• Keep children and bystanders away while operating the stump grinder. Keep the
area free of all distractions.
• Only responsible, properly instructed indivuals should operate this machine.
• Inexperienced operators must always be carefully supervised.
• Do not expose stump grinders to rain or wet conditions.
• Stay alert, watch what you are doing and use common sense when operating
a stump grinder. Do not use a stump grinder while you are tired or under the
inuence of drugs, alcohol or medication. A moment of inattention while
operating any stump grinders may result in serious personal injury.
• Use safety equipment. Always wear eye protection. Safety equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
• Always wear earplugs to protect your ears.
• Do not start the engine until the machine is in the cutting position next to
the stump.
• Do not overreach. Keep proper footing and balance at all times. is enables
better control of the stump grinder in unexpected situations.
• If devices are provided for the collection of dust extraction, ensure these are
connected and properly used.Use of these devices can reduce dust related
hazards.
• Check stumps to be removed for embedded nails, wire, metal fence posts and
other metallic objects and for rocks or other buried impediments which may
become dangerously thrown or cause unexpected machine movements when hit
by the cutting wheel.
• Make sure that all shields and guards are in place and are in good condition prior
to operating the machine. Check cutting wheel for damage or missing teeth and
replace as necessary.

6
Stump Grinder
• Ensure that everyone is in the vicinty is aware of the danger zone associated
with this machine(see diagram). You must avoid the danger zone at all times
when the machine is in operation.
• Make sure that no-one is working on underneath or close to the machine before
starting the engine or beginning to move the machine. Make sure that the area is
free of personnel.
• Don’t make any alterations or modications to your stump grinder.
• Check with your local council and utility providers for the locations of buried
pipes and cables where applicable, before operating the machine.
• Pay attention while handling fuel. ey are ammable and the vapours are highly
explosive.
• Never remove the fuel cap or add fuel with the power running. Stop the engine
and allow engine and exhaust components to cool before refueling.
• Do not smoke while adding fuel.
• Fill your engine with 10w-30/ 10w-40/ 15w-30/ 15w-40 non-synthetic engine oil
before use or serious damage will occur.
• Use extreme care when handling fuel. Fuel is extremely ammable and the
vapors are explosive. Never fuel machine indoors or while the engine is hot or
running.
• Never refuel or store the machine in a place where there is open ame, spark or
other ignition objects.
• Do not attempt to start the engine if fuel is spilled. Wipe away the spillage and
ensure all fuel has dried before starting the machine.
• Always make sure the fuel cap is securely tightened and replace before starting.
• If the fuel tank needs to be drained, it should be done outdoors.

7
Stump Grinder
1. Only ll the fuel tank to a level 15mm lower than the top of the fuel tank. Do
not overll.
2. Use the dipstick to check the oil level. Use 10w-30/ 10w-40/ 15w-30/ 15w-40
non-synthetic engine oil. Fill to the correct level before use.
e engine is shipped without oil. Fill to the correct level before use. Operating the
engine with no oil or oil at a low level will destroy the engine- this is not covered
under warranty.
1. Lock travel wheel by pulling brake lever fully back.
2. Make sure throttle is in slow position.
Do not allow the rope to snap back, return it by hand to prevent damage to the
starter.
3. If the engine is cold, move the choke lever to the closed position.
4. Raise the cutter wheel 4 to 5 inches o the ground by pushing downwards on the
handle bar, hold it in that position.
e next step may cause the cutter wheel to rotate, keep everyone away.
5. Pull the starter rope lightly until resistance is felt then pull briskly.
6. Move the choke lever to the open position.
e next step causes the cutter wheel to rotate, keep everyone away.
7. Move the throttle to fast. if the engine is cold, allow the engine to idle(throttle set
to slow) for a few minutes before cutting.
Dipstick Cover

8
Stump Grinder
• Remove all loose pieces of wood, stones, wire and other debris from the area
before beginning stump removal.
• Wind direction should be considered, as it inuences the direction in which dust
and wood chips are directed.
• Never operate the grinder aer dark.ere will be no adequate light for the
operator to use the grinder safely.
• Always allow a cold engine time to warm up before cutting a stump.
• Only the portion of cutting wheel within the 80 degree area shown above should
engage the stump. Never undercut the stump or use the bottom of the cutting
wheel for cutting purposes.
• Never leave controls when the cutting wheel is rotating.
Operating Tips!
• Use smooth, comfortable side to side movements while operating.
• When it is desired to cut smaller roots, it may be more eective to do so before
rather than aer cutting the stump.
• Should the chip build-up become excessive when cutting, shut o the machine,
wait for the cutting wheel to stop rotating, retract the machine from the stump
and rake away the chips. It is also possible to use the cutter wheel to push chips
o to the side.
• In order to prevent any of the wheels becoming stuck in the hole. Move the
grinder to the other side of the stump to continue removal or by lling the
hole with chips before continuing.
80

9
Stump Grinder
Prepare the grinder at the stump.
Place it into position with the cutting wheel near the top edge of the stump.
Removing roots
1. Make sure the throttle is set to fast, the cutter wheel will accelerate to
cutting speed.
2. Swing the cutting wheel to one side, then lower it into the nearest roots that are
buried at the foot of the stump.
3. Swing the cutting wheel before each sweep, until the roots are
suciently removed.
4. Raise the cutting wheel until the centre of the cutting wheel is just above the top
of the stump.
5. Allow the cutter wheel to stop, release the brake and reposition the machine.
6. Lock the brake again.
Cutting the full stump
1. Make sure the throttle is set to fast. e cutter wheel will accelerate to
cutting speed.
2. Direct the cutter wheel against the stump, beginning with the nearest top corner
of the stump, and steadily sweep it across the stump le and right, cutting away
1/2 inch of wood with each sweep.
3. Raise and lower the cutter wheel between sweeps by lowering and raising the
control handle.
4. Roll the machine forward and back, by pushing and pulling on the control
handle. To do this, release the brake. Relock it when the machine has been
repositioned and continue cutting.

10
Stump Grinder
Continue with nal roots removal
Cut the remaining roots as described in STEP 2 until satisfactorily removed
1. When stopping the machine aer normal operation, lower engine speed to slow,
and push the emergency switch.
2. Set park brake before leaving the controls.
3. Shut o the engine by pushing the on/o switch.
In consideration of your own safety and that of others, you should always use the
following normal shutdown procedures before departing from the controls for any
reason including cleaning, servicing, tranporting or inspecting the stump grinder.
Never deviate from this procedure unless so instructed in this manual or in an
emergency that requires it.
A rotating cutting wheel is very dangerous. Stand at controls and ensure that the
cutting wheel comes to a complete stop before doing anything else.
1. Move the engine throttle to the slow position.
2. Push the emergency (on/o) switch to stop the engine.
3. Set park brake before leaving controls.
1. Immediately push the emergency (on/o ) switch for the engine will be shut o.
2. Be sure to allow all moving parts to come to a complete stop.
3. Pull the brake lever to engage the brake.
4. Rectify the emergency situation and return to normal operation.

11
Stump Grinder
• Make sure all nuts, bolts and screws are tightened.
• Never store the equipment with petrol in the tank inside a building where
fumes can reach an open ame or spark. Allow the engine to cool before
moving the grinder.
• To reduce re hazards, keep the engine and petrol storage area free of
grass, dirt and excessive grease.
• Replace worn or damaged parts for safety. If the fuel tank has to be
drained, this should be done outdoors.
• Regularly check the oil level and add some oil or replace it if necessary.
• Frequently check the grinder and ensure that all bark and dirt deposits
are removed from beneath the deck.
• Lubricate the wheel axle and the bearings with grease regularly.
• Check the cutting wheel oen. In order to achieve clean work the blade
should always be sharp and well balanced.
• Check the tightening of all bolts and screws at regularly intervals. Nuts
and bolts that are worn out or badly tightened can damage the engine or
the frame.
• If the grinder hits an obstacle violently, stop the grinder and take it to a
specialist for inspection.
e stump grinder is designed to be transported via a van or small trailer. e
machine is equipped with grab bars that are to be used for both liing the
machine, and strapping it down.is machine weighs approximately 110kg
and should only be lied using correct apparatus or an adequate number of
people working as a team.
e are legal road requirements for towing equipment and trailers(such as
lighting and licensing).It is the owner’s responsibility to be aware of these laws
and to adhere to them.

12
Stump Grinder
Engine 15HP Four Strokes
Brake Drum Brake
Belt 2PCS v Belt
Clutch Centrifugal Clutch
Blades 12 Blades w Tungsten (4x le, 4x right, 4x middle)
Cutting Depth 12inch
Packing Size 1040*780*580mm
Gross Weight 130kgs
Net Weight 110kgs

Distribution Limited
PART DRAWINGS
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
BEFORE OPERATING THIS MACHINE

Unit 10, Hatchmoor Industrial Estate, Hatherleigh, Okehampton, Devon EX20 3LP
www.lumag-gb.co.uk 01837 811741
Lumag Distribution Limited Company Number: 09267547 VAT Number: GB154566788 Hatherleigh
Plant and Tool Hire is a trading name of Lumag Distribution LTD
