Lumens LC100 User manual

No.
Item
Function Descriptions
No.
Item
Function Descriptions
1. LCM Display Menu and
Information 16 DC IN 12V DC 12 V power connector
2. Knob LCM knob 17 Input1
¡HDMI Input 1
¡3G-SDI Input 1
¡HDMI Passthrough
3 Record Start/Stop recording
4 Stream On/Off image streaming 18 Input2 ¡HDMI Input 2
¡3G-SDI Input2
5 Scene Switch templates
19 Output
¡PGM: Main screen output,
display the recording or streaming
screen and layout
¡Multiview: Operation interface
output; display the settings menu
and image management
6 Power On/Off the device power
7 Single Channel Display a single channel screen
8 PIP Switch to PIP (picture in
picture)
9 PBP Switch to PBP (picture by
picture)
20 USB3.0 port
Supports the following
devices:
¡ USB video/audio devices
¡ External storage disk
¡ Keyboard/mouse
¡ LC-RC01 (optional)
controller
10 SWAP Switch signal channels
11 USB3.0 port for external storage disk
12 USB3.0 port for external storage disk
13 USB2.0 port Can connect to keyboard/mouse
device operation menu 21 Ethernet Connect to LAN
14 Factory
Reset
Reset all configurations to
factory default settings 22 RS-232/ RS-485
port
Connect to AV control
equipment
15 Restart Reboot the machine 23 XLR audio in Connect to a microphone or
audio mixer
24 Line In/ Out Audio In/Out
4.1 Remove the screws (5 pcs) on the top cover.
4.2 Loosen the following screws.
4.3 Attach your hard drive to the connection cable.
* Please make sure the port and the L-shaped slot of the cable are aligned
before insertion. Do not force the connection to avoid damage to the port.
4.4 Fasten the hard disk to the metal plate with the provided
screws (4 pcs).
* Do not over-tighten the screws to avoid damage to the hard drive. Only
use the screws provided.
A. 2.5" SATA Hard Drive holes
B. 3.5" SATA Hard Drive holes
4.5 Lock the hard drive mounting plate in place and insert the
connection cable.
4.6 Close the top cover to complete the installation.
4.7 Hard drive setting
After installation, you need to log in to the web page and click
Information to format the drive.Storage Setting > Hard Disk
1.1 Front View
1.2 Back View
1.3 Function Descriptions
13
15
14129 10 1187
654
3
21
External USB device
212019181716 22 23 24
3.1 Lumens strongly recommends the use of a hard drive (not
supplied) for recording video and audio.
3.2 LC100 supports 2.5"/3.5" SATA hard drives.
3.3 If no hard drive is installed, use a USB disk for external
storage.
XLR
Display
(Program)
Display
(MultiView)
Router
Power Cord
Power Audio Out
USB Control
RS-232/RS-485 Control
AV Control
Equipment
Computer
Box Camera
Document
Camera
IP Camera
Audio In
Video Out Connecting
to Internet
Video In 1/2
Speaker/ Amplifier
MIC/ Audio mixer Music Player
5100438-50 APR. 2022
4. Hard drive installation steps
2. Product connection diagram
1. Introduction of Product Functions
3. Precautions Prior to Use
LC100 Installation Guide www.MyLumens.com
Copyright © Lumens Digital Optics Inc. All rights reserved.
AB
*Formatting the drive will erase all existing data on the disk

Channel
The drop-down menu allows the
user to select the required input
HDMI sources, USB camera, IP
camera, IP streams.
REC
Start or stop recording; also
select the option to
synchronously stream.
Audio
Manage the input and output
audio sources; adjust the audio
recording volume.
Scenes
Select the required production
layout, or customize the
background and theme style.
Camera Control
Provide IP video camera/ PTZ
control.
Main Screen Output
Displays the program out
video.
Recording Progress Bar
Displays current streaming
/recording status and hard
disk capacity.
Follow these steps to access the Director Tab
■On the MultiView interface, select Director
■Log in to the web page by entering the online Director Casting Account /Password (default setting: director/director)
Video management
settings
Casting
Management Interface
LC100
LC100_Conference
No.
Item
Function Descriptions
1
Configuration
Configure the network settings and
recording/streaming quality
2
Director
Creative control of video and audio inputs,
audio feeds. Control recording and
streaming and network video cameras
3
File Management
Transfer, upload, download, delete, and
play back video files
4
About
Display the current LC100 firmware
version
5
Device IP
Displays the device’s network IP address.
Connect the HDMI1 MultiView output to a monitor to display
the real-time operation menu
5
4
3
21
6. Web Interface
www.MyLumens.com
5. Real-time operation menu
Copyright © Lumens Digital Optics Inc. All rights reserved.
7. Director Tab
6.1 Confirm the IP address of the device
Connect the LC100 to a router. Note the IP address of
the device (visible in the lower right corner of the HDMI
MultiView output screen) .
Account : admin
Password : admin
Web Interface
Thru the web interface users can access the File Manager, the MultiView
interface and system settings.
6.3 Please enter your account/password to log in.
6.2 Input the device,s IP address into the web browser,
.e.g. 192.168.100.100
