LUMENWERX MEDIUS User manual

A
CONTINUOUS SYSTEM
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC. FILE NAME:MEDIUS-DIRECT-INDIRECT-WALL-MOUNT-INST November 12, 2019
LumenWerx ULC. reserves the right to change or modify product specifications without notification
WWW.LUMENWERX.COM
MEDIUS
NOTE: Wire dimming conductors as Class 1
1
4
23
6
5
Page: 1 / 2
Make electrical connection between fixture (B)
and wall power cable (C).
Insert fixture bracket (D) into wall bracket (A) and
secure it in place with supplied screw (E).
B
A
E
C
D
SIDE VIEW
AA
F
F
Remove the screws (H) on the joiner and put
them in a safe place.
G
SIDE VIEW
A
H
Locate wall bracket position using provided client
drawing. Install mounting brackets (A) to wall.
Align with structural stud (need double studs –
distance between screws is 1.250”) or use metal
anchors with min. length 1.250”. Flat head Philips
drive screw, nominal size #10, min. length 1.250”.
Locate wall bracket position using provided client
drawing. Install mounting brackets (A) to wall.
Align with structural stud (need double studs –
distance between screws is 1.250”) or use metal
anchors with min. length 1.250”. Flat head Philips
drive screw, nominal size #10, min. length 1.250”.
DIRECT/INDIRECT WALL MOUNT - INSTALLATION INSTRUCTIONS
Remove the top cartridges (F) by pulling them up
and disconnect the quick connectors (G). Keep the
cartridges (F) in a safe place.

Connect wires between joining fixtures (K) and
using wires connectors (I). Push the connectors
inside the second fixture (J). Number of wires
may vary.
J
K
I
E
D
A
Insert the first fixture brackets (D) into wall
brackets (A), and secure in place with supplied
screws (E).
F
L
H
WWW.LUMENWERX.COM
7
10
89
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC. FILE NAME:MEDIUS-DIRECT-INDIRECT-WALL-MOUNT-INST November 12, 2019
LumenWerx ULC. reserves the right to change or modify product specifications without notification
WWW.LUMENWERX.COM
MEDIUS DIRECT/INDIRECT WALL MOUNT - INSTALLATION INSTRUCTIONS
Page: 2 / 2
G
Join fixtures using align pins as guide. Put back in
place the provided screw (H) (using 3/16” Ball-
End Screwdiriver (L) provided). Make sure that
no wires are placed in between the extrusions,
preventing the fixtures to be joined. Tighten the
screw (L) to pull the extrusions together.
Put the top cartridges (L) back by connecting the
quick connectors (G)
