Lumie Bodyclock Elite 300 User manual

ELITE 300
OPERATING INSTRUCTIONS
NOTICE D’UTILISATION
BEDIENUNGSANLEITUNG
BRUKSANVISNING
GEBRUIKSAANWIJZING

OPERATING INSTRUCTIONS
Bodyclock Elite 300
1Introduction
2Important
3Getting started
4Basic set-up
5Using Bodyclock Elite
Waking up with a sunrise alarm
When you don’t need an alarm
6Programming features
Alarm options
Sleep sound
Display auto-dim
Sunrise duration
Sunset duration
Nightlight
Security option
7-day alarms
Language
Snooze
7Audio features
FM and AM radio
Meditainment®
SD card or external analogue source
8Problem-solving
2|www.lumie.com
English
1Introduction
Lumie Bodyclock Elite wakes you with a sunrise that naturally helps
to regulate your sleep and wake patterns.You’ll wake up in a better
mood, find it easier to get up and feel more energetic during the
day. There’s also a fading sunset to help you unwind at the end of
the day and drift off to sleep.
In clinical trials,‘dawn simulators’such as Bodyclock Elite have been
shown to improve mood, energy, productivity and the quality of
sleep and awakening*.They can also help SAD (Seasonal Affective
Disorder) and winter blues sufferers cope with dark winter
mornings.
Lumie was the first to launch a dawn simulator range and began
selling an early version of Bodyclock in 1993.
Please read these instructions carefully to get the most out of your
Bodyclock Elite.
*Acta Psychiatr Scand 1993 Jul; 88 (1):67-71.
www.lumie.com | 3
English

3Getting started
The best position for Bodyclock Elite is by your bedside.
!Screw in the bulb firmly and fit the glass bulb cover.
!Hook one of the clips over the inside of the bulb cover. Make sure
the other clip is tucked inside as you lower the bulb cover onto the
base.
!Plug in, switch on at the mains and you’re ready for Basic set-up.
www.lumie.com | 5
English
2Important!
!Do not use Bodyclock Elite if the lamp cover is broken, damaged or
missing. If you need to remove the lamp cover, unplug the unit first
and let it cool down.
!The lamp cover gets warm when the light is on so keep the unit
clear of anything that may be damaged by heat.Take care that you
don’t accidentally cover the unit with your bedding!
!Do not open the base – there are no user-serviceable parts inside.
!For indoor use only. Keep away from water and damp.
!Clean only with a dry or lightly moistened cloth.
!Always use the correct bulb (maximum 42W E14 halogen bulb).
Replacements are available from Lumie.
!It’s possible there may be some interference between this product
and other electronic products close by, notably mobile phones.
Usually this is in the form of audible noise and all you need do is
move them apart.
!Keep the cable away from heated surfaces.
!At the end of its life, do not throw the unit out with normal
domestic waste. Please take it to an official recycling point
to be disposed of responsibly.
4|www.lumie.com
English
123
A
P
P
S
4
1234
A
LAMP
S
Speaker
Display
Clip
Bulb
Glass bulb cover
Speaker
Slot for SD card
Mains
FM aerial
Audio input
(e.g. MP3 player)
Audio output
(e.g. headphones)

!You’ve finished basic programming. The display will revert to
normal (after 12 seconds) and any changes will be saved.
Note: When you next access programs, the display will show your new
settings. All settings are saved if the unit is unplugged or if there’s a
power failure.
Once you’ve been using Bodyclock Elite for a few days, you might
like to change this basic set-up; for full details and additional
options see Programming features.
5Using Bodyclock Elite
Ideally, you should use Waking up with the sunrise alarm all year
round to help keep your sleep/wake cycle on track. But life’s not like
that. When you don’t need an alarm explains how to use Bodyclock
Elite and still enjoy a lie-in.
Waking up with a sunrise alarm
When you’re ready to sleep, turn on the alarm. This also activates
the sunset and auto-dim display* to help create a relaxing sleeping
environment.When you wake up with the sunrise, simply turn off
the alarm.
Note: *These are the basic sleep features but any others you have
programmed will also be activated. For more details see Sleep sound
and Nightlight.
!Use the Lamp +to turn on the light.
!When you’re ready to sleep, push A up to turn on the sunrise alarm
(display shows alarm time briefly and A).
!The display dims and the light starts to slowly fade (sunset).
!If you don’t want a sunset, simply use the Lamp –button to turn out
the light.
www.lumie.com | 7
English
4Basic set-up
Setting the clock and alarm time will provide you with basic
Bodyclock Elite functions: a 30-minute sunrise to wake you up,
including an audible alarm for added reassurance; an optional 30-
minute sunset to help you sleep; and auto-dimming display.
!You can only program Bodyclock Elite when the alarm is turned off
so make sure the Abutton is down (alarm time / Ais not showing).
!Press Pbutton to access programs. Display shows SET ALARM
TIME.
!Use Lamp –/+ buttons to set alarm time.
!Press Pto skip to the next program, SET ACTUAL TIME.
!Use Lamp –/+ buttons to set the clock.
!Press Pto skip to the next program, 24 HOUR.
!Use Lamp –/+ buttons to choose 12 or 24 hour clock display.
!Press Pto skip to the next program. Display shows e.g. MONDAY.
!Use Lamp –/+ buttons to set day of the week.
6|www.lumie.com
English
Day of the week
Sunrise alarm ON
Programming
AM/PM indicator
Actual time
Alarm time

6Programming features
Bodyclock Elite offers the following range of features to help you
sleep and wake better.
Please see the relevant section for more information and details of
how to change the settings used for Basic set-up.
www.lumie.com | 9
English
!When you wake up, push Adown to turn off the alarm and use
Lamp –to turn out the light.
!To‘snooze’, instead of turning off the alarm, use Lamp –to dim the
light.
!After 9 minutes the light reaches full brightness and the audible
alarm sounds again.
!When you’re ready to get up, push Adown to turn off the alarm and
use Lamp –to turn out the light.
Note: Both the light and the audible alarm will turn off after 20 minutes
if they are not turned off manually.
When you don’t need an alarm
If you’re looking forward to a lie-in, instead of turning on the alarm
when you’re ready to sleep, follow the sequence below. This activates
the sunset and auto-dim display features to help create a relaxing
sleeping environment but without a sunrise to wake you up.
!Use the Lamp +button to turn on the light.
!When you’re ready to sleep, press both Lamp –and +buttons at the
same time (display shows SUNSET).
!The display dims and the light starts to slowly fade (sunset).
!If you don’t want a sunset, use the Lamp –button to turn off the
light.
Note: If you don’t need to wake up with an alarm you could, of course,
simply leave it turned off! However, you won’t have the sunset option
and the display would remain at its usual brightness. Any other sleep
features you have programmed will also not be activated, for example
Sleep sound and Nightlight.
8|www.lumie.com
English
PROGRAM
Alarm options
Wake up to a simple sunrise or add other
alarm features.
Sleep sound
Controls the volume of any audio source,
fading down as you fall asleep or staying on
at low level to mask other noise.
Display auto-dim
Controls the brightness of the display when
you’re ready to sleep.
Sunrise duration
Choose a shorter or longer sunrise.
Sunset duration
Choose a shorter or longer sunset.
Nightlight
Set the light to stay on at low level.
Security option
Light automatically comes on in the evening
while you’re away.
7-day alarms
Set different alarm times for the whole week.
Language
Choose to display the program options in
another language.
BASIC SET-UP DEFAULTS
Sunrise with alarm beeps
Not set - volume controlled
manually
Automatically drops to low
level
30 minute sunrise
30 minute sunset
Not set
Not set
Not set - alarm time used for
Basic set-up is generic
English

Sleep sound
If you enjoy listening to audio before sleep, you might like to set the
volume to fade down as you fall asleep. Or maybe have low level
background sound until you wake up – great if you work shifts and
need to block out other noise!This feature is activated when you
turn on the alarm (see also When you don’t need an alarm).
Program options:
SLEEP SOUND OFF - no auto-fade, you control volume manually.
SLEEP SOUND PERM – plays at your chosen volume for 22
minutes then drops to permanent low volume. Display shows W.
SLEEP SOUND AUTO – plays at your chosen volume for 22
minutes volume then drops to low volume (or goes off if the light is
off at this point). Remains at low volume then goes off when the
light turns off (or reaches nightlight level if you’ve selected a
Nightlight option.) Display shows W.
!Make sure Ais down.
!Press Pto skip to the volume auto-fade options e.g. SLEEP
SOUND OFF.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
Note: When you choose SLEEP SOUND PERM or SLEEP SOUND
AUTO the default audio source is P4, Meditainment WHITE NOISE.
To fall asleep to a different Meditainment sound (see Meditainment
for more options), the radio (see FM and AM radio) or your own MP3
files (see SD card and external analogue source) you must save it to
P4 (see Audio features).
www.lumie.com | 11
English
Note: You can only program Bodyclock Elite when the alarm is turned
off so make sure the Abutton is down (alarm time / Ais not showing).
Then you can program these in much the same way as you set the
clock, alarm time etc. in Basic set-up.
Alarm options
Choose to wake with just a sunrise or add extra alarm features.
Program options:
WAKE BEEP - sunrise and alarm beep. Display shows B.
WAKE AUDIO - sunrise and audio, e.g. the radio or MP3 files.
Display shows Ror M.
WAKE FLASH - sunrise then light flashes quickly on/off.
WAKE LIGHT - sunrise only.
!Make sure Ais down.
!Press Pto skip to the alarm options e.g. WAKE BEEP.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
Note: When you choose WAKE AUDIO the default audio source is P1,
Meditainment DAWN CHORUS. To wake to a different Meditainment
sound (see Meditainment for more options), the radio (see FM and
AM radio) or your own MP3 tracks (see SD card and external
analogue source) you must save them to P1 (see Audio features).
10 |www.lumie.com
English

Program options:
SUNRISE 15 - the light takes 15 minutes to reach full brightness.
SUNRISE 30 - the light takes 30 minutes to reach full brightness.
SUNRISE 60 - the light takes 60 minutes to reach full brightness.
SUNRISE 90 - the light takes 90 minutes to reach full brightness.
!Make sure Ais down.
!Press Pto skip to the sunrise duration options e.g. SUNRISE 30.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
Sunset duration
Choose to fall asleep with a short or long sunset to suit you. Using
SUNSET 30 as an example, starting from full brightness, the light
will take 30 minutes to gradually fade and turn off.
Program options:
SUNSET 15 - the light takes 15 minutes to fade and turn off.
SUNSET 30 - the light takes 30 minutes to fade and turn off.
SUNSET 60 - the light takes 60 minutes to fade and turn off.
SUNSET 90 - the light takes 90 minutes to fade and turn off.
!Make sure Ais down.
!Press Pto skip to the sunset duration options e.g. SUNSET 30.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
www.lumie.com | 13
English
Display auto-dim
Controls the brightness of the display to minimise sleep
distractions.This feature is activated when you turn on the alarm
before going sleep (see also When you don’t need an alarm).
Program options:
DISPLAY AUTO – brightness drops to low level.
DISPLAY HIGH – no auto-dim; display remains at usual brightness.
DISPLAY AUTO OFF – brightness drops to low level. Remains at
low level then goes completely dark when the light turns off (or
reaches nightlight level if you’ve selected a Nightlight option.)
!Make sure Ais down.
!Press Pto skip to the display auto-dim options e.g. DISPLAY
AUTO.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
Note: If you choose DISPLAY AUTO OFF and need to check the
time whilst the display is dark, one quick press on any button (except A,
or you will turn off the alarm!) will illuminate the display for 12 seconds
only.
Sunrise duration
Choose to wake with a short or long sunrise to suit you. Using
SUNRISE 30 as an example, when the alarm time is set to 07:00,
the light will gently come on at 06:30 and gradually increase to full
brightness over 30 minutes.
12 |www.lumie.com
English

7-day alarms
You may find this useful if you regularly need different alarm times
for different days of the week. The default alarm time for all seven
days is 07:00.
!Make sure A is down.
!Press Pto search for e.g. MONDAY ALARM.
!Use Lamp –/+ to set the alarm time.
!Press Pto skip to TUESDAY ALARM or skip to next program;
otherwise the display will revert to normal after 12 seconds.
Note: Setting one or more alarm times using this program overrides the
basic alarm program. To revert to generic alarm time, press P to skip to
SET ALARM TIME and set new time.
Language
Choose to display the program options in another language.
Program options:
FRANCAIS;DEUTSCH;SVENSKA;DANSK;SUOMI;
ITALIANO;ESPANOL;PORTUGUES;NEDERLANDS;
PÇCCÉÑÑ
!Make sure Ais down.
!Press Pto search for e.g. ENGLISH.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
Display now shows day of the week in your chosen language; when
you next access programs they will also be in your chosen
language.
www.lumie.com | 15
English
Nightlight
Instead of fading to darkness, the sunset fades until reaching your
pre-selected level to provide a continuous soft nightlight.
Program options:
NIGHTLIGHT OFF;NIGHTLIGHT LOW;NIGHTLIGHT MED;
NIGHTLIGHT HIGH
!Make sure Ais down.
!Press Pto skip to the nightlight options e.g. NIGHTLIGHT OFF.
!Use Lamp –/+ to change setting.
!Press Pto skip to next program; otherwise the display will revert to
normal after 12 seconds.
Security option
Useful when you’re away.The light will switch on and off for random
periods between 16:00 and 23:00 to give the impression that there
is someone at home.
Program options:
SECURITY OFF;SECURITY ON
!Make sure Ais down.
!Press Pto skip to the security options e.g. SECURITY OFF.
!Use Lamp –/+ to change setting.
!Wait until the program display reads SECURITY.
Press any button to cancel and revert to SECURITY OFF.
14 |www.lumie.com
English

Please see the relevant section for more information and details of
how to change the settings used for Basic set-up.
Note: You can only program Bodyclock Elite audio when the alarm is
turned off so make sure the Abutton is down (alarm time / Ais not
showing).
www.lumie.com | 17
English
Snooze
For a few extra minutes in bed!
!Instead of turning off the alarm, use Lamp –to turn off the light.
!The light will gradually brighten again over 9 minutes.
!Any extra alarm or audio options will also repeat.
!OR press Lamp –just once to leave the light on.
!Any extra alarm or audio options will repeat in 9 minutes.
7Audio features
Bodyclock Elite comes with a range of sounds from Meditainment, a
leading creator of relaxation, sleep and well-being audio content. In
addition, you can listen to FM and AM radio and your own mp3
tracks, either via an SD card or by connecting an mp3 player.
There are four presets available for you to store your favourite audio
settings.
Note: When adjusting volume, the display shows volume indicator and
reverts to normal after 12 seconds. For ‘instant off’ volume press Aonce
(or twice).
16 |www.lumie.com
English
SOURCE
FM radio
Allows you to listen to an
FM radio station.
AM radio
Allows you to listen to an
AM radio station.
Meditainment
Library of 12 sounds to use with
the sunrise alarm and/or to help
you unwind for sleep.
SD card
Use the SD card reader to listen
to saved mp3 tracks.
External audio
Allows you to listen to mp3 tracks
via an external mp3 player.
Preset 1
Preset 2
Preset 3
Preset 4
Press and hold any preset button
to save any favourite audio
setting.
BASIC SET-UP DEFAULTS
89.1 MHz (BBC Radio 2)
909 KHz (BBC Radio 5)
DAWN CHORUS
Not applicable
Not applicable
P1 - Meditainment DAWN CHORUS
Note: If you choose to have an audible
alarm (see Alarm options) your wake up
audio selection must be saved to P1.
P2 - 89.1 MHz (BBC Radio 2)
P3 - 909 KHz (BBC Radio 5)
P4 - Meditainment WHITE NOISE
Note: If you choose to have the volume
fade when you go to sleep (see Sleep
sound) your bedtime audio selection must
be saved to P4.
Sleep sound*
Audible alarm*
*Only shows when this program option has been set.
Audio source
Volume indicator
4 x Presets

!Make sure Ais down.
!Press Sto skip to Meditainment source or use a preset with
Meditatinment option already saved e.g. DAWN CHORUS.
!Use Tuning </> to change the track.
!Press and hold a preset button if you would like to save (release
when sound is restored); otherwise the display will revert to normal
after 12 seconds.
Note: You can save Meditainment tracks to any preset. However, if you
want to wake up to a sunrise and a wake-up track you must use P1 (see
also Alarm options). Use Volume +/– to set the wake-up volume then
press P1 to save.
Sleep options:
WHITE NOISE;SLEEP TROPICAL*; SLEEP PASTORAL*;
RAIN;WAVES;SLEEP AMBIENT
*22 minutes of spoken guided meditation: also available in French
(SOMMEIL PASTORAL; SOMMEIL TROPICAL) and German
(SCHLAF PASTORAL; SCHLAF TROPISCH)
The guided meditation tracks use stories, natural sound effects and
music to help you relax and drift into a deep and natural sleep.You
don’t need to have any knowledge of relaxation techniques and
both options follow the same structure:
0 -5 mins. Easy-to-follow, calming routine to relax your body
and prepare you for sleep.
6 -12 mins. Storyline to capture your imagination and encourage
feelings of contentment and wellbeing e.g. walking
along a beach (SLEEP TROPICAL) or relaxing in a
field (SLEEP PASTORAL).
13 -18 mins. Period of deep relaxation with opportunities for you
to fall asleep.
18 -21 mins. Story ends as you are guided into a deep and natural
sleep.
www.lumie.com | 19
English
FM and AM radio
Listen to your favourite radio stations and save settings for next
time.
!Make sure Ais down.
!Press Sto skip to FM or AM audio source; or use a preset with radio
already saved.
!Use Tuning </> to change the frequency.
!Press and hold a preset button if you would like to save (release
when sound is restored); otherwise the display will revert to normal
after 12 seconds.
Note: You can save your favourite radio station to any preset. However,
if you want to wake up to a sunrise with radio you must use P1 (see also
Alarm options). Use Volume +/- to set the wake-up volume then press
P1 to save. If you want to fall asleep with the radio and have the volume
fade you must use P4 (see also Sleep sound).
Meditainment®
Bodyclock Elite comes with a range of tracks from Meditainment, a
leading creator of relaxation, sleep and wellbeing audio content.
Wake-up options can be used to complement the Bodyclock Elite
sunrise alarm; whilst the Sleep options (including two 20-minute
meditative stories) help you to wind down ready for sleep. For more
information visit www.meditainment.com.
Wake-up options:
DAWN CHORUS;GENERIC ALARM;WAKE UP ASSERTIVE*;
MUSICAL HARD;MUSICAL SOFT;WAKE UP GENTLE*;
RAIN;WAVES
*Spoken wake-up call; also available in French (REVEIL ACTIF;
REVEIL DOUX) and German (AUFWACHEN BESTIMMT;
AUFWACHEN SANFT)
18 |www.lumie.com
English
