Stick Blender Set
What your 1 year warranty means
Great care has gone into the manufacture of this product and it should therefore provide you with years
of good service when used properly. In the event of product failure within its intended use over the
course of the first 1 year after the date of purchase, we will remedy the problem as quickly as possible
once it has been brought to our attention. In the unlikely event of such an occurrence, or if you require
any information about the product please contact us via our after sales support services, details of which
can be found in this manual and on the product itself.

Client: ALDI Australia
Project: Lumina STM32E 200+
Language: EN
Barcode: 930 5026 10 000 3 00151
3
Date: 27.09.2007
Version: 04
Page: 3 (of 8 pages)
INTRODUCTION
Thank you for purchasing this product from our LUMINA®range. We believe that we have provided you
with a product that is both reliable and value for money. We encourage you and your friends to choose
from our range of LUMINA®products again in future.
PACKAGE CONTENTS
1 Stick Blender Unit
1 Stainless Steel Leg Attachment (May be fixed to the Unit)
1 Whisk Attachment
1 500ml Chopper Attachment (with Removable Blade)
1 Mixing Cup
1 Skid-Proof Base for Mixing Cup
1 Wall Mount Bracket
2 Screws (for Wall Mount Bracket)
1 Instruction manual
Confirm all parts before disposing of carton.
SAFETY INSTRUCTIONS
Carefully read this manual before using this appliance.
Make sure that you know how the appliance functions and how to operate it.
Maintain the appliance in accordance with the instructions to ensure that it functions properly.
Keep this manual with the appliance. If the appliance is to be used by a third party, this instruction
manual must be supplied with it.
The safety instructions, by themselves, do not eliminate danger completely, and proper accident
prevention measures must always be used.
For any customer query or in the unlikely event of a product failure, please phone or email the helpline
contact details below for assistance, before attempting to return the product to the retailer.
Toll Free Help line: 1300 366 144
Email: info@telefixsales.com.au
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Client: ALDI Australia
Project: Lumina STM32E 200+
Language: EN
Barcode: 930 5026 10 000 3 00151
4
Date: 27.09.2007
Version: 04
Page: 4 (of 8 pages)
INTRODUCTION ................................................ 2
PACKAGE CONTENTS......................................... 2
SAFETY INSTRUCTIONS ................................... 2
SAFETY WARNINGS ......................................... 4
Electrical safety ................................................ 4
OPERATION GUIDE ........................................... 5
Parts Guide ..................................................... 5
Assembly Guide ................................................ 5
CARE AND CLEANING........................................ 7
TECHNICAL DATA ............................................... 7
TABLE OF CONTENTS

Client: ALDI Australia
Project: Lumina STM32E 200+
Language: EN
Barcode: 930 5026 10 000 3 00151
5
Date: 27.09.2007
Version: 04
Page: 5 (of 8 pages)
SAFETY WARNINGS
Electrical safety.
When using electric appliances always observe safety regulations where applicable
to reduce the risk of fire, electric shock and personal injury.
Always check that the power supply corresponds to the voltage on the rating plate
Supply cord and plug.
Always fully unwind any cord to avoid overheating.
Never allow the supply cord to come in contact with hot objects.
Do not carry the appliance by the cord or yank the cord to disconnect it from the
mains supply.
Disconnect by first switching off the outlet, grasping the plug and pulling it out
gently.
Do not let the supply cord hang over the edge of a table or counter.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or a similarly qualified person in order to avoid a hazard.
Children.
Caution. Keep out of reach of children.
This appliance is not intended for use by young children or infirm persons.
Young children must be supervised to ensure that they do not play with the
appliance.
This appliance is not suitable for use by young children or infirm persons unless
adequately supervised to ensure that they can use the appliance safely.
Water.
Do not immerse. Do not immerse any part of this appliance motor assembly or supply
cord in water or other liquid.
Do not use with wet hands or use in damp situations.
Handling.
Do not drop the appliance.
Do not use this appliance if it has been damaged in any way, immersed in water, the
supply cord is damaged or the operation is faulty.
Contact with any damaged appliance could result in electric shock.
Unattended.
Do not leave the appliance unattended while in use. Disconnect from the power
supply.
Sharp Objects and Moving Parts.
WARNING! Do not touch the cutting blades. The cutting blades have very sharp
edges.
Do not operate near any body parts. Ensure the blades have stopped rotation
completely before touching any area near the blades.
Store in a safe place.
When not in use store your appliance and all its accessories and instruction manual
in a safe and dry place.
Liability.
No liability can be accepted for any damage or personal injury caused by non-
compliance with these instructions or any other improper use or mishandling. This
appliance is intended for household use only.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Client: ALDI Australia
Project: Lumina STM32E 200+
Language: EN
Barcode: 930 5026 10 000 3 00151
6
Date: 27.09.2007
Version: 04
Page: 6 (of 8 pages)
OPERATION GUIDE
This appliance has been designed for general indoor household use only. Disconnect from the power
supply when not in use.
Parts Guide
A. Motor Housing
B. On /Off and Turbo Switch
C. Variable Speed Control
D. Stainless Steel Mixing Leg
E. Whisk Attachment
F. Whisk
G. Chopper Attachment
H. Detachable Chopper Blade
I. 500ml Chopper Bowl
J. Mixing Cup
K. Skid-Proof Base
L. Wall Mount Bracket
Assembly Guide
Important Note: Maximum Use
WARNING! This appliance has been designed for short-term use only. Refer below guide for usage
times.
Stick Blender Use – 30 seconds continuously, allow 1-minute rest between operations.
Whisk Attachment Use – 2 minutes continuously, allow 1-minute rest between operations.
Chopper Attachment Use – 30 seconds continuously, allow 1-minute rest between operations.
CAUTIONS!
Sharp Blades. Handle with care. Do not touch moving blades.
Unattended. Unplug when not in use or before assembly or disassembling.
Safety Warnings. Read all safety warnings before use.
•
•
•
•
•
•

Client: ALDI Australia
Project: Lumina STM32E 200+
Language: EN
Barcode: 930 5026 10 000 3 00151
7
Date: 27.09.2007
Version: 04
Page: 7 (of 8 pages)
OPERATION GUIDE
Stick Blender Operation
Attach the Stainless Steel Mixing Leg to the Motor Housing
as shown in the assembly diagram.
Ensure the Motor Housing and the Mixing Leg are
securely ‘locked’ together.
Plug the supply plug into a suitable 230-240Vpower outlet
and switch on.
Place the Stick Blender into the supplied Mixing Cup or
another sturdy container. If using the supplied Mixing
Cup, be sure to use the supplied Skid-Proof Base so that
the Mixing Cup does not slide around during use. Hold the
Mixing Cup and Motor Housing firmly and press the ON/
OFF switch to activate the Stick Blender motor. Carefully
mix the ingredients as required with a sideways action of
the Stick Blender.
Whisk Operation
Assemble the Whisk and the Whisk Attachment by
pushing the Whisk up into the hole at the base of the Whisk
Attachment. Ensure this is firmly locked into place.
Attach the completely assembled Whisk Attachment to the
Motor Housing as shown in the assembly diagram.
Ensure the Motor Housing and the Whisk Attachment are
securely ‘locked’ together.
Plug the supply plug into a suitable 230-240V power
outlet and switch on.
Place the whisk into a sturdy mixture bowl. Hold the
bowl and the Motor Housing firmly and press the ON/OFF
switch to activate the Stick Blender motor.
Carefully mix the ingredients as required with a sideways
action of the whisk.
Chopper Attachment
Assemble the 500ml Chopper Bowl and Detachable Blade
as shown in the assembly diagram. Place the Detachable
Chopper Blade onto the centre pin of the Chopper Bowl
and turn 90º to lock into place.
NOTE: Be careful when inserting the Chopper Blade, as it
has sharp edges.
Place food items into chopper bowl and attach to the
Chopper Attachment to the Chopper Bowl firmly.
Attach the Motor Housing to the Chopper Attachment
as shown in the assembly diagram. Ensure the Motor
Housing and the Chopper Attachment are securely ‘locked’
together
Firmly holding the Motor Housing, switch the ON/OFF
switch on to activate the Stick Blender motor.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Client: ALDI Australia
Project: Lumina STM32E 200+
Language: EN
Barcode: 930 5026 10 000 3 00151
8
Date: 27.09.2007
Version: 04
Page: 8 (of 8 pages)
CARE AND CLEANING
Before cleaning.
When not in use or before cleaning, always disconnect the appliance from the mains supply.
Cleaning guide.
Regularly clean the outside of the main Stick Mixer Unit Body with a soft damp cloth and dry it with
a dry towel.
WARNING! Do not immerse any part of the main Stick Blender Unit Body in water. Wash the Chopping
Bowl, Mixing Leg, Whisk and Mixing Cup in hot soapy water, dry with a dry towel. Do not use harsh
solvents to clean the plastic, as these will damage the plastic.
The Mixing Attachments may also be washed using a dishwasher.
Storage
When not in use store the appliance, accessories and these instructions in a dry place.
TECHNICAL DATA
Supply Voltage: 230-240 V ˜ AC 50 Hz
Wattage: 200 Watt
•
•
•
•
•
