Lumitec Poco 3 User manual

Poco 3 User Guide
This document covers the Poco 3 module only.
For information on all previous versions of Poco refer
to the Poco Legacy document on our website.
lumiteclighting.com
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

Table of Contents
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU
Specications: 04
Supported MFD Models 04
Features 05
Installation: 07
Mounting 07
Quick Tips 08
System Congurations (Wiring Diagrams) 09
Interface: 11
Overview 11
Widgets 12
Setup: 15
Interface Setup 15
Switches 18
Clans 17
Layout 22
Maintenance 27
Network Setup 28
Updates: 29
Firmware Updates 29
Quick Start: 02
Quick Start Guide 02
Resources: 34
Glossary 35
Scene Select 14
Automation 23
Troubleshooting: 31

QUICK START
Poco 3 Quick Start Guide
Quick Start continued...
BATTERY
12 or 24 vDC
CH1 IN
CH2 IN
CH3 IN
CH4 IN
ACC IN
Amp Draw at Lights
CALCULATE YOUR AMP DRAW
Total Amps Per/CH
Total amps per channel must be below 10 Amps
3A Fuse
10A Fuse Max
10A Fuse Max
10A Fuse Max
10A Fuse Max
PWR IN
POCO Replaces Physical Switches
Ethernet Connection
(optional)
MFD or Wireless DeviceTo Pico S8 Module
(optional)
Power Wire
Fuse size is based on number
of underwater lights
Amp draw information is available
on product packaging or at
lumiteclighting.com
Ground Wire
CH4 OUT
CH3 OUT
CH2 OUT
CH1 OUT 0.5A 0.5A 1.25A 1.25A = 3.5 Amps
= 3.5 Amps
= 5 Amps
= 0 Amps
0.5A 0.5A 1.25A 1.25A
1.25A 1.25A 1.25A 1.25A
Aft Hardtop Lights
Aft Spreader Lights
Fwd Spreader Lights
Under Gunwale Lights
Underwater Lights
Fwd Hardtop Lights
0A 0A 0A 0A
1. Install Poco Module: Install your Poco module using the wiring diagram below.
2. Connect to Poco:
A. Poco can be connected to a chart plotter (MFD) and/or a mobile device.
B. For an MFD connect the network cable to a compatible display. For a list of compatible displays visit:
http://lumiteclighting.com/poco-quick-start
C. For mobile devices connect using the Lumitec Poco App available on Apple or Google Play stores. You will be prompted to
connect to Poco on launching the app.
3. Create Light Groups:
Select conguration in the setting menu (top right of screen). Assign Channel and Clan for each light location on your boat
(underwater lights, spreaders lights etc.).
Examples:
Name: LG_aft_hardtop
Channel: 1
Clan: 1 - Down Lights
Output: Lumitec Spectrum
Name: LG_aft_spreader
Channel: 1
Clan: 2 – Flood Lights
Output: Blue / White
Name: LG_fwd_hardtop
Channel: 2
Clan: 1 - Down Lights
Output: Lumitec Spectrum
02
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

QUICK START
Poco Quick Start Guide
4. Create Switches (conguration menu). Assign a default intensity and color to each switch.
Example Simple Switch:
Name: Aft Hardtop
Target: LG_aft_hardtop Intensity: 50% Color: Red
You can create lighting scenes by assigning multiple light groups to more than one target.
Example Scene Switch:
Name: Night Fishing
1. Target: LG_aft_hardtop, Intensity: 20%, Color: Red
2. Target: LG_fwd_hardtop, Intensity: 20%, Color: Red
3. Target: LG_underwater Intensity: 100%, Color: Green
5. Add Switches to Layout Page:
A. Select a location screen for your switch.
B. Select the plus (+) button symbol.
C. Select desired switch from list.
Note: Visual order of switches will be arranged by the order of the switch placement on layout. Switches cannot be rearranged after
they have been added to a screen, only deleted. Go to http://lumiteclighting.com/poco-quick-start for more detailed information..
6. Check Status Indicators:
• POWER Indicator - Illuminates Green if POCO is powered on, PWR line must have supply voltage between 10-30vDC.
• CH1, CH2, CH3 or CH4 Indicator –
• Illuminates Red if power is supplied to channel from fuse/breaker panel.
• Illuminates Green if power is supplied to channel input and channel is turned on inside of POCO controller;
(PLI enabled lights may be OFF even if there is power on the wire).
• Flashes Orange if PLI data is transmitted.
• Illuminates Orange if channel is dimmed through a PWM signal.
STATUS Indicator -
• Green blinking light indicates WiFi connection status:
• 0 blinks: WiFi disabled.
• 1 blink: WiFi enabled but not connected to any peers.
• 2 blinks: WiFi is connected to one or more peers.
continued...
03
STATUS Indicator -
• Blue blinking light indicates Bluetooth connection status:
• 0 blinks: Bluetooth disabled.
• 1 blink: Bluetooth enabled but not connected to any peers.
• 2 blinks: Bluetooth is connected to one or more peers.
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SPECIFICATIONS
MANUFACTURE MODEL CONNECTION TYPE ADAPTER CABLES
Garmin 8400, 8600, GPSAMAP 7-9X3, GPSMAP 8X10-24 WiFi/Ethernet Not Required
Simrad NSO EVO3/S, NSO EVO2, NSS EVO3, IDS, GO Ethernet Only Required (Check MFD Manual)
B&G Zeus3/S Glass Helm, Zeus3/S, Vulcan Ethernet Only Required (Check MFD Manual)
Lowrance HDS Live, HDS Carbon, Elite FS Ethernet Only Required (Check MFD Manual)
Raymarine Axiom, Axiom Pro, Axiom XL Ethernet Only Required (Check MFD Manual)
Supported MFD Models
Dimensions
04
Specications continued...
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SPECIFICATIONS
FEATURES INDICATOR DESCRIPTIONS
PWR Red Wire Positive 10-30 VDC POCO logic supply power. Line must be fused prior to connecting to POCO with
3 Amp ATC blade fuse or equivalent.
GRND Black Wire Supply Power Ground (Battery negative terminal).
ACC Blue Wire Poco Accesory Bus blue wire to connect to Pico S8 modules.
RESET Button See “RESET MODES” chart on page 6.
1-4 IN Red Wires Channel Input power. Line must be fused prior to connecting to POCO with 10 Amp ATC blade fuse
or equivalent (14 AWG 300V 16 inch long cable).
1-4 OUT Orange Wires Channel Output power to lighting circuit. Maximum 10 Amp load per channel. Maximum total load
across all channels is limited to 40 Amps. Load on channel must be only one of the following:
(Lumitec PLI enabled lighting/lighting capable of dimming (through PWM) / device requiring a
standard ON-OFF circuit). (14 AWG 300V 16 inch long cable).
LAN Ethernet Cable Local Area Network connection. 10/100 Base-T data connection to POCO. Standard CAT-5 cable
with RJ45 connector required to plug into sealed network cable adapter. (18 inch long cable with
Link light).
POCO STATUS LIGHTS
POWER Green Solid POCO is powered on
CH1-4 Red Solid Red if power is supplied to Channel from fuse/breaker panel.
Green Solid Channel has power on output wire.
Orange Flash PLI data is being transmitted.
Orange Solid Channel dimmed through a PWM.
Not Illiminated None No power to channel input (Check fuse/breaker).
STATUS Green 1 Flash WiFi enabled but not connected.
2 Flash WiFi is enabled and connected.
Blue 1 Flash Bluetooth enabled but not connected.
2 Flash Bluetooth enabled and connected.
Not Illuminated WiFi and Bluetooth disabled within Poco.
Features
continued...
Specications continued... 05
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SPECIFICATIONS
RESET MODES
USER ACTION
Short-press while Poco is running.
Must release before 5s.
Press-hold for > 5s while Poco is running,
then release.
Press-hold while powering-on Poco.
Hold for > 5s.
FUNCTION
Reboot poco (no change to settings).
Restore WiFi/BLE/Eth settings.
Factory restore all. - Wipes ota data
partition; which disables booting to any
OTA partitions. - Wipes internal fs (FAT)
partition; which clears any user congu-
ration. - Wipes nvs partition; which clears
WiFi/BLE/Eth settings.
FEEDBACK
No indication while holding down button.
After release button, status LED turns solid
‘aqua’ color while rebooting. Then resumes
normal pattern.
No indication while holding down button
for the rst 5 seconds, then rapidly blink
Green/Blue until release button.
Status LED turns solid ‘aqua’ color while
waiting for user to keep holding button.
There is no indication that user has held
down button long-enough. After release
button, Status LED continues solid ‘aqua’
color while booting. Then resumes normal
pattern.
Features
continued...
06
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INSTALLATION
NOTICE
POCO should be mounted in a location that is not exposed to extreme temperature conditions. This device is rated for operation at
ambient temperatures between 0 F (-18 C) and 120 F (50 C) and is sealed against water ingress per IP65 standards. To prevent standing
water, it is recommended to mount the POCO device on a vertical surface protected from continuous water exposure.
• Using the included hardware, you can surface mount the device close to a breaker panel or fuse block.
• Pre-drill mounting holes with appropriately sized bit depending on the material. Typically a #32 (.116 inch) or 3mm bit can be
used for pre-drilling for the #6 self tapping screws.
• Ensure screw holes do not interfere with anything on the opposite side of the mounting surface.
• The location must allow room for routing, the connection of all cables, visibility of LED indicators and access to depress the
reset button.
SUPPLY
Poco must be powered with a 10-30 VDC supply independently fused with a 3 Amp ATC blade fuse or equivalent (Not Provided).
ACC - Poco Accessorty Bus Blue Wire
Connect to blue accessory bus wire to multiple expansion moudles from Lumitec. Works with up to 4 Pico S8 Modules for expansion.
INPUTS
Notice: POCO is designed to switch DC voltages between 10 and 30 volts. Switching any AC line voltages or DC voltages higher than 30V is
not permitted and failure to adhere to the input voltage requirement can cause serious injury and death.
Each channel is independently powered and switched inside the POCO device allowing for many different wiring methods depending
on system requirements. Each input line must be fuse protected prior to the POCO digital switch with a 10 Amp ATC or equivalent
protection device. Input voltage must be between 10 VDC and 30 VDC. Switching of AC or high voltage lines is not permitted without
properly rated relay and integral yback diode. Contact Lumitec for further information. POCO comes with 16 inches (400 mm) 14 AWG
wire for each channel input. Use appropriately sized and sealed crimp terminals to connect with channel supply.
Mounting
Connections
Installation continued... 07
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INSTALLATION
OUTPUTS
Each channel is capable of switching a 10 Amp load powered within 10 and 30 VDC. POCO comes with 16 inches (400 mm) 14 AWG
wire for each channel input. Use appropriately sized and sealed crimp terminals to connect with each channel load. See System Design
Considerations for further information on lighting system architecture.
WIRED NETWORK
10/100 Base-T network connection from POCO device with a standard Ethernet cable (not included) to a compatible display or MFD. If
all network ports are used for other system components, a network switch must be used to split the network trafc between two or more
networked devices.
In most cases, channels should be designated either a Lumitec PLI channel, standard PWM dimming channel or standard ON/OFF
channel. Lumitec PLI controlled lighting reaches its fullest potential when this rule is followed. Lumitec PLI lighting has the ability to
create “virtual circuits” where lighting on each PLI channel can be addressed with commands specic to each clan of lights. For
example, SeaBlazeX2 or Typhoon lights can be attached to the same channel as Lumitec Mirage lighting and Caprera2 lighting as well as
other clans of lights. Because each are digitally controlled over the two power wires you are able to communicate with light clans
independently as if they were setup on multiple circuits.
QUICK TIPS:
• Lighting that is not PLI enabled on a channel that also has PLI enabled lights will stay in the ON state without
dimming control, even when other lighting is sent PLI commands. This works well for situations where you want to
connect a non-PLI Aurora Dome Light to the same circuit as PLI enabled lights. This setup will only work if the
attached non-PLI lights have low internal capacitance or a series diode. Lumitec lights that will work in this
conguration include Courtesy and Accent lighting as well as the Touch Dome Light and Aurora Dome Light.
• If PWM dimming control is being used on a channel, PLI enabled lights on that channel will respond as standard
lights without digital color control.
• PWM dimming control is not compatible with some loads such as relays or inductive loads. For these situations,
ensure all commands sent to these commands are ON/OFF only commands (see UI setup for further information).
Connections
System Design Considerations
Installation continued...
continued...
08
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

10 to 30 VDC
Fig. 3
10 A 3 A10 A 10 A 10 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
INSTALLATION
These schematics are intended to be used as general guidelines. Wiring
requirements will vary from vessel to vessel.
Note: The Pico S8 module provides the easiest way to connect mechanical
switches to your Poco 3 device. See Fig. 4 for wiring diagram.
Fig. 1: Use of a single channel to control multiple light types within the lighting system
Fig. 2: Use of different channels to allow isolated control of a set of similar light types within the system
Fig. 3: Use of different channels to allow isolated control of PLI and PWM lighting
Various System Configurations
Installation continued...
continued...
10 to 30 VDC
Fig. 1
10 A 3 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
10 to 30 VDC
Fig. 2
10 A 3 A10 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
09
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INSTALLATION
10 to 30 VDC
Switches can be placed on input OR output (one side only)
Fig. 5
10 A 3 A10 A 10 A 10 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
Fig. 6: Use of an SPST switch on each channel to allow for standard Lumitec TTP control as well as digital PLI control (non-redundant)
Note: POCO will need to be congured with startup commands to turn on all 4 channels by default. Refer to “Startup Switch” under Automation section.
continued...
Fig. 5: Use of an SPST switch on a channel to allow for redundant mechanical control of a set of lights within the system allowing for
standard Lumitec TTP control or Poco digital PLI control
10 to 30 VDC
Fig. 4
10 A 3 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
Switch must be in open position for Poco operation
Manual Mode/TTP
Poco Mode/Digital
10 to 30 VDC
Fig. 6
10 A 3 A10 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
Poco
TTP
OFF X
Fig. 7: Use of an SPDT switch prior to all lighting circuits to allow for redundant mechanical control of entire lighting system with one switch
SWITCH
PANEL
10 to 30 VDC
Fig. 7
10 A 3 A
1-IN
1-OUT
2-IN
2-OUT
3-IN
3-OUT
4-IN
4-OUT
LAN
ACC GRND PWR
Fig. 4: Use of a Lumitec Pico S8 module to allow POCO to read the state of mechanical switches and send corresponding digital commands to lights.
10
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INTERFACE
Switch Panel:
1. Active switch page.
2. Customizable name of switch pages.
3. Gear Icon - Conguration and setup.
4. Hamburger menu icon - Drop down menu of options.
5. Switch that has been turned on (blue highlighted icon).
6. Switch that has the ability to be modied from default intensity and color with a press and hold of the button
(Notice ring around power logo). Switch has been congured as an Omnillume in switch setup.
7. Switch is either latching or momentary ON/OFF with no ability to modify (Notice NO ring around power logo).
User Interface Components
Interface continued...
Latching or momentary
ON/OFF switch with no
ability to modify.
Omnillume switch with the
ability to be modied from
default intensity and color.
11
1
2
4
6
7
5
3
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INTERFACE
Omnillume Widget:
1.Switch modication popup that appears when an Omnillume switch is pressed and held for greater than 1 second.
2. Light color modication rings, press for desired color.
3. Light intensity modication.
4. Play and Pause pattern (available for Spectrum and Dual-Color lights).
Omnillume Widget
continued...
Latching or momentary
ON/OFF switch with no
ability to modify.
Omnillume switch with the
ability to be modied from
default intensity and color.
12
Interface continued...
1
2
3
4
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INTERFACE
Switch Folder Widget:
- Switch Folder popup appears when a Switch Folder button is pressed and held.
- A quick press of a Switch Folder button will activate the rst button in the list.
- Highlighted switch showing that switch is activated.
Switch Folder Widget
continued...
Latching or momentary
ON/OFF switch with no
ability to modify.
Omnillume switch with the
ability to be modied from
default intensity and color.
13
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

INTERFACE
Scene Select:
1. The Scene Select feature allows you to group multiple scenes within one switch.
- Scene Select button contains multiple scenes.
- A quick press of a Scene Select button will activate the rst scene in the list
- Change scenes by pressing the button within 4 seconds to cycle to next scene.
- Pressing the button after 4 seconds will shut the switch off.
2. Press and hold the switch to bring up the list of scenes available under the switch.
Note: Only one scene grouped within Scene Select can be active (ON) at any given time.
Scene Select
continued...
Latching or momentary
ON/OFF switch with no
ability to modify.
Omnillume switch with the
ability to be modied from
default intensity and color.
14
1
2
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SETUP
List of congured Light Groups:
1. First step in system conguration is to dene the “Light Groups”.
2. Select a row to edit or select “+ Add New Item” to create a new “Light Group”.
Note: Light Groups must be congured rst before setting up switches.
The Poco setup menu is accessible through the gear wheel icon in the upper right of the user interface window.
User Interface SETUP
Setup continued... 15
1
2
Default Maintenance pin is set to “0000”. This can be changed but must be
done by manually editing the conguration le. See exporting and importing
conguration below.
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SETUP
Add/Edit a Light Group:
1. User Congurable “Light Group” Name, Using a prex like “LG” may help with future setup.
2. Hardware output channel on Poco. Gives the ability to send a command to all channels or each individual channel (1-4).
3. A PLI-level identier for one or more devices. Clans are roughly organized around product families. Allows commands to
be sent to all Clans or individual Clans in the list below.
4. Color capability of lights built into light group. This is the property that provides the correct color options for a light
when a switch is pressed and held to bring up the omnillume widget.
User Interface SETUP
Setup continued...
continued...
16
1
2
3
4
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SETUP
CLAN CLAN NAME FAMILY OF LIGHTS
0 All PLI Lights All Lights that are PLI Enabled.
1 Down Lights Mirage, Orbit, Shadow (1- color, 2-color, 4 color, Spectrum).
2 Spreader Utility Lights Spreader Lights and Utility Lights (Capri, Caprera, Nevis, Ibiza, Perimeter Light) .
3 Rail Lights 12” Spectrum Only.
4 Underwater Lights SeaBlaze X2 and Typhoon (Spectrum or Dual Color).
5 Mini Rail 6” Spectrum Only.
6 Flex Lighting Moray Flex Lights.
7 Pico C4 Control of Third-Party RGB(W) Lighting Accessories.
8 Pico P1 Solid State Relay (20A max. load).
9 Livewell Lights Lutra Spectrum.
10 Pathway Dock Lights Nautilus Pathway Lights (Spectrum and single color).
11 Piling Dock Lights Scallop Piling Lights (Spectrum and single color).
N/A Non PLI Dimming All non PLI dimming lights.
N/A Non PLI on/off Turns all non PLI lights on or off.
Clans
continued...
Setup continued... 17
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SETUP
List of congured Switches
1. Second step in system conguration is to dene the “Switches” and Scenes.
2. Select a row to edit or select “+ Add New Item” to create a new “Switch”.
Switches
Switches continued...
continued...
18
1
2
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU

SETUP
Add/Edit a Switch:
1. User Congurable “Switch” Name.
2. Type of Switch to dene button action. See switch types in the list below.
3. Push to test commands in list, push again to issue off command to targets in list.
4. Push to create a copy of current switch and begin editing.
5. Light Group or Switch Selection. Light Groups are allowed to have intensity and color properties, switches cannot have
any modication properties and are only activated in the order they appear in the list.
6. Light Intensity Selection 0% - 100%.
7. Color and Pattern Selection.
Switches
Switches continued...
continued...
19
1
3 4 2
5 6 7
Specications
Installation
Interface
Setup
TroubleShooting
Updates
Quick Start
NAVIGATION MENU
