lumz PIXA Series User manual

563 397
23
599 397
76
203
LUMINAIRE
POLE
ADAPTER
POLE
ADAPTER
POLE
SCREWS
PROVIDED
SPRING WASHER
PROVIDED
12
we brighten up your life
LUMZ PTE LTD
INSTALLATION MANUAL
PIXA
PRODUCT DESCRIPTION & DIMENSION
WIRING INSTALLATION
PIXA/INSTALLATION MANUAL/REV.2
1/2
Factory:
No.14, Jalan Anggerik Mokara 31/44, Kota Kemuning Seksyen 31,
40460 Shah Alam, Selangor, Malaysia.
Tel: [phone]
Fax: [phone]
Email: [email protected]
Singapore Office (HQ Sales & Marketing):
1 Coleman Street #10-06, The Adelphi,
179803, Singapore.
Tel: [phone]
Email: [email protected]
CLASS I WITH INTERGRAL DRIVER IP 65 IK 08
MODEL:
[email protected]
www.lumzlighting.com
Connect all wires from the luminaire to AC power using a connector.
Make sure all wiring connections are tight so that no bare wires are visible.Good connections may avoid tripping from happening.
For wiring, use a terminal complies with EN 60998-2-1 and EN 60998-2-2.
Consult your local authority regarding disposal or recycling procedures of removed ballast and lamps.
Read the Installation Manual instruction carefully before install the products to ensure that you obtain the best possible results.
SAFETY WARNINGS
!
Electronic equipment sensitive to voltage surges.
The installation of a protection device against overvoltages on the electrical
system attenuates the intensity of these phenomena protecting apparatus from
the risk of damage.
Use only flexible cables of suitable diameter according to the national
installation standards.
DO NOT USE HARD CABLES OR ARMOURED CABLES.
Use only supply cables with double case. Do not enter with single cables.
Connect wires from the luminaire to AC power as follows:
1. Connect BLUE / BLACK wire to the NEUTRAL wire.
2. Connect GREEN / YELLOW-GREEN wire to the GROUND or EARTH wire.
3. Connect BROWN / RED wire to the LIVE wire.
DESCRIPTION
Housing made of aluminium
Impact resistance clear extruded
polycarbonate UV stabilized additive
Operating temperature: -20°C~+40°C.
LED lifetime up to 50,000 hours
Voltage range: 200 - 240 VAC ~ 50 /60 Hz
Wattage: 43 W
NOTE:
MAKE SURE POWER IS DISCONNECTED UNTIL INSTALLATION OF PRODUCT IS COMPLETELY FINISHED.
FAILURE TO DO SO COULD RESULT IN ELECTRICAL SHOCK CAUSING SERIOUS INJURY OR DEATH.
INSTALLATION INSTRUCTION
Do not use water high pressure cleaners.
The LED module contained in this luminaire SHALL ONLY BE REPLACED by
the manufacturer.
For further informations, please contact your supplier.
The electronic equipment should not be disposed of in the normal waste.
Instead it should be recycled in accordance with the waste electronic &
electrical equipment (WEEE) directive.
Terminal block not included. Installation may require advice from a qualified
person.
The IP rating of the electrical connection must be equal to or greater than the
IP rating of the luminaire.
Fix pole adapter to pole by using
screws and spring washer provided.
Make sure all screws fix tightly.
Remove luminaire by slightly
spin to separate pole adapter
for installation.
# Pole sold separately
Pole is available upon request, please consult us for more details.
PIXA.B PIXA.A
CL-09A-J-W43-30-xx
CL-09A-J-W43-40-xx
CL-10A-J-W43-30-xx
CL-10A-J-W43-40-xx
PIXA.A

POLE
LUMINAIRE
10 deg
LUMINAIRE
SET SCREW
PROVIDED
CONNECTOR
!
LUMINAIRE
2
LUMINAIRE
POLE
CONNECTOR
SLOT
HOLES
10 deg
3
1
!
we brighten up your life
LUMZ PTE LTD
INSTALLATION MANUAL
PIXA
INSTALLATION INSTRUCTION
PIXA/INSTALLATION MANUAL/REV.2
2/2
Factory:
No.14, Jalan Anggerik Mokara 31/44, Kota Kemuning Seksyen 31,
40460 Shah Alam, Selangor, Malaysia.
Tel: [phone]
Fax: [phone]
Email: [email protected]
Singapore Office (HQ Sales & Marketing):
1 Coleman Street #10-06, The Adelphi,
179803, Singapore.
Tel: [phone]
Email: [email protected]
[email protected]
www.lumzlighting.com
NOTE:
Connect all wires from the luminaire to AC power using a connector.
Make sure all wiring connections are tight so that no bare wires are visible.Good connections may avoid tripping from happening.
For wiring, use a terminal complies with EN 60998-2-1 and EN 60998-2-2.
Consult your local authority regarding disposal or recycling procedures of removed ballast and lamps.
Read the Installation Manual instruction carefully before install the products to ensure that you obtain the best possible results.
Fix luminaire back to pole adapter by insert
and rotate according to slot on luminaire.
Make sure all screws fix tightly.
Connect wires with connector.
# Make sure power is disconnected before installation
Connect wires with connector.
Fix luminaire
back to pole
adapter with set
screws provided.
Make sure all
screws fix tightly.
# Make sure power is disconnected before
installation
Remove all three set screws
from luminaire for installation.
PIXA.B
OPTIONAL:
Rotate luminaire to change angle of luminaire.
Each holes provide 10 degree of rotation.
PIXA.A
