Contractor Quick Start Guide for
Vive Integral Fixture Controls
Part of the Vive System
Customer Assistance | 1.844.LUTRON1 USA, Canada, and the Caribbean | +1.888.235.2910 Mexico | +1.610.282.3800 Others | www.lutron.com
Important Installation and Startup Notes
1. If access to the fixture is required in order to supply power:
A. Minimize the length of wires (incoming power) that can bundle up in close proximity to the Vive Integral
Fixture Control.
B. Keep incoming power wires separated from the wires that run between the driver and the fixture control.
2. Fixture will run through the self-test as described to the left.
A. If at the end of that self-test the fixture control LED turns green and the fixture is ON,
the fixture passes the test. Proceed with commissioning.
B. If at the end of that self-test the fixture control LED turns red and the fixture is OFF:
i. Adjust wiring as described in Step 1 above. Ensure incoming power wires and LED wires are
separated from the sensor wires. Wires may have shifted during shipping/installation or may have
been bundled together when closing up the driver channel.
ii. Repeat the self-test by doing one of the following:
a. Toggle power to the fixture (at the breaker or fixture quick connects).
b. With fixture powered, Reset Factory Defaults for fixture control. See the Reset Factory Defaults
section.
iii. If the self-test still results in a red LED the range of the fixture may be reduced in certain
installations. Work with whomever is doing the commissioning of the system to test performance
(i.e. still able to control the fixture with a Pico remote? Still able to properly associate the fixture to the
Vive System? etc.)
a. If the above yields satisfactory results, the evaluation is done.
b. If the above yields unsatisfactory results, consult the fixture manufacturer and/ or Lutron.
NOTE: Lutron recommends as best practice that this information
be provided with the fixture to the electrical contractor.
Status LED
Important Notes about Initial Fixture
Power-up:
When power is applied to the fixture, the fixture will run through
a 10-second self-test described below before normal operating
mode commences unless the fixture was previously powered for
an hour or more continuously, or is associated to a Vive hub.
1. While the self-test is in progress, the status LED alternates
between green and red. During the test, the Vive integral fixture
control will not respond to button presses or commands from
other Lutron Clear Connect devices.
2. Fixture will turn ON to full intensity for 5 seconds and then will turn
OFF for 5 seconds.
3. Once the self-test is complete:
A. If the fixture passes, the status LED blinks green twice,
repeating every 2 seconds, and the fixture will turn ON.
B. If the fixture fails, the status LED blinks red twice, repeating
every 2 seconds, and the fixture will remain OFF. See
Important Installation and Startup Notes section for
managing a self-test failure.
4. The LED and load state will continue to display the self-test result
(from #3 above) for 5 minutes unless the button is pressed or until
the unit is associated to a Vive hub.
Note: Do NOT disconnect power to the fixture until the pass/fail
determination has been made.
5. See video at https://youtu.be/LS6MmjqhH2M
Reset Factory Defaults
Note: In some instances, it may be necessary to reset
the Fixture Control back to factory default settings. Before
beginning, make sure the Fixture Control is connected and
powered.
A Rapidly tap the button on the Fixture Control three times and
hold on the fourth until the green LED begins to flash rapidly;
release button.
B Within 1 second of releasing the button, again rapidly tap the
button three times and the green LED will flash slowly indicating
that the unit has been reset to factory defaults.
Note: Any associations or programming previously set up
with the Fixture Control will be erased and will need to be
re-programmed. Upon successful completion of Reset Factory
Defaults, the fixture control will commence with the self-test as
described above in Important Notes about Initial Fixture
Power-up.
Programming without a Vive Hub
(Associating transmitters to Fixture Control)
1. Press and hold the button on the Integral Fixture Control for 6 seconds until the load attached to the Fixture
Control starts flashing (every 2 seconds).
Note: Multiple Fixture Controls can be placed into association mode by repeating Step 1 prior to moving to
Step 2.
2. Hold the indicated button on each transmitter for 6 seconds. The fixture will flash at a different rate than in
Step 1 to show that wireless transmitters have been associated. Alternatively, for Radio Powr Savr occupancy/
vacancy and daylight sensors, the green laser pointer can be used. See the Using a Green Laser to
Program Lutron Ceiling and Wall-Mounted Devices App Note #407 (048407) on www.lutron.com for more
information. To associate another transmitter, repeat Steps 1 and 2 above.
Test
Link
Step 1 Step 2
Default Sensor Settings for DFCSJ-OEM-OCC (adjustable ONLY via the
Vive hub user interface unless otherwise noted)
• Occupancy sensor timeout: 15 minutes
• Occupancy sensor sensitivity: Medium
• Mode: Occupancy detection (auto-ON, auto-OFF)
• Occupied light level: 100% (note this can also be changed with a Pico remote and Radio Powr Savr sensor. See
App Note #556 [048556] at www.lutron.com)
• Daylighting: Enabled
• Daylighting dims lights to OFF from low light level when sufficient ambient light is present for
15 minutes or more
Lutron Electronics Co., Inc. 7200 Suter Road
Coopersburg, PA 18036-1299 USA
Please read before installing fixture
041657
Rev. B
07/2018
DFCSJ-OEM-OCC Vive Integral Fixture Control with Sensor
DFCSJ-OEM-RF Vive Integral Fixture Control (RF only)
9.5– 20.5 V-
250 mA max
IEC SELV / NECRClass 2
UL2043 Plenum Rated
Programming with a Vive Hub
A Use an iOSRor AndroidR
compatible device.
B Download the Lutron
Vive app.
C Open the app and follow
the instructions.
Note: For further information on set up, programming, and troubleshooting with a Vive system, please
refer to the installation instructions included with the Vive hub or visit www.lutron.com/vive
Note: For programming the Vive Integral Fixture Control without a Vive Hub see section to the right.
vive.lutron.com
X
X
Vive

Troubleshooting www.lutron.com/support
Symptom Solution
Sensor does not respond to motion. • Fixture control is in self-test feedback mode (sensor will not respond to occupancy detection) for 5 minutes after power up unless button is
pressed or it gets associated to a Vive system.
• If self-test feedback mode has been exited by one of the two methods above, sensor will not respond to occupancy detection until
2 minutes after the power reset.
Lights do not dim or turn ON as expected.
Vive Integral Fixture control does not toggle the load.
Vive Integral Fixture Control LEDs do not respond.
• Ensure that control lines are wired properly.
• Verify that the driver with self-powered DALI link has the DALI power supply activated. See driver manufacturer for details.
Lights are unstable at low-end. • Adjust low-end trim. Refer to Vive documentation on www.lutron.com/vive
The “Raise” button on the Pico remote control does not increase the light
level.
• The lights cannot be raised above the daylighting light level using a Pico remote control. If it is critical to override the daylight level, disable
daylighting from the Vive application.
Fixture control self-test ends in blinking red LED. This means RF
performance of the product in this fixture may not meet Lutron’s
specifications.
• Review wiring and construction guidelines in the Vive Integral Fixture Controls App Note #642 (048642) at www.lutron.com. Modify as
necessary and repeat the fixture control self-test. See Important Installation and Startup Notes section on page 1.
Wireless transmitter(s) cannot be associated to Vive Integral
Fixture Control.
• The maximum number of wireless transmitters have been associated to the Vive Integral Fixture Control. To remove a previously set up wireless
transmitter, tap the button used for association on the wireless transmitter three times, on the fourth tap hold for three seconds and then tap three
more times.
Fixture does not appear to perform daylighting function. • Auto-calibration may not have completed successfully. Reset the device using 3x-tap and hold for 15 seconds, then let the sensor time out.
• Change the daylighting target brightness in the Vive application.
Sensor turns on and/or stays on when space is unoccupied. Possible sources: RF interference, flowing air (HVAC vent, blowing shades, fan, baseboard heat, etc.).
• Reduce the sensitivity (through the Vive User Interace app).
• Rotate the fixture 180 degrees to create more distance from the WiFi router, other source of RF interference, or HVAC diffuser / return.
• Cover the PIR lens on the Vive Integral Fixture Control with a PIR-opaque tape or label.
Contractor Quick Start Guide for
Vive Integral Fixture Controls
Part of the Vive System
Customer Assistance | 1.844.LUTRON1 USA, Canada, and the Caribbean | +1.888.235.2910 Mexico | +1.610.282.3800 Others | www.lutron.com
Lutron, Pico, Vive, and Clear Connect are trademarks of Lutron Electronics Co., Inc. registered in the U.S. and other countries. Radio Powr Savr is a trademark of Lutron Electronics Co., Inc. App Store is a service mark of Apple, Inc.
Android and Google Play are trademarks of Google LLC. NEC is a registered trademark of the National Fire Protection Association, Quincy, Massachusetts. PHILIPS is a trademark of Philips. OSRAM and DEXAL are trademarks of OSRAM Opto
Semiconductors GmbH. iOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. ©2018 Lutron Electronics Co., Inc.
Testing occupancy sensor functionality
(Occupancy Test Mode) (does not apply to
DFCSJ-OEM-RF):
1. Apply power to the fixture.
2. Wait for fixture control self-test to complete (10 seconds) and
press the button to exit the self-test.
3. Press and hold button for 3 seconds until red LED turns on solid
to enter occupancy test mode.
A. The sensor requires a 2 minute “warm up” period after
applying power. Red LED will blink during the “warm up”
period in occupancy test mode.
4. Provide motion in front of sensor - lights will turn ON.
5. Lights will not turn off automatically until 5 seconds after last
motion detection.
6. Test mode will automatically exit after 5 minutes of inactivity or by
tapping the button.
Testing daylight sensor functionality
(does not apply to DFCSJ-OEM-RF):
1. Apply power to the fixture.
2. Wait for fixture control self-test to complete (10 seconds) and
press the button to exit the self-test. Press the button until the
light is in the ON state.
3. Shine a light source (flashlight) directly into daylight sensor lens.
Fixture lights will dim down over 1 minute (hold flashlight steadily
in place).
4. Cover daylight sensor lens/button with an opaque material. Fixture
light will brighten over 1 minute (hold opaque material steadily in
place). Daylighting Auto-Calibration
The Vive Integral Fixture Control (DFCSJ-OEM-OCC) will run through an automatic calibration process for its daylighting feature, when the sensor first goes vacant after being occupied and when the ambient light level is low
(<5 ft-candles – typically at night).
The procedure executes as follows: Upon first vacancy and low ambient light level, the sensor first turns the fixture full ON for 85 seconds, then turns the fixture to OFF for 20 seconds. If the calibration was successful, the lights
will remain OFF. If it fails, the fixture will attempt to do this 5 times before aborting.
If the space is occupied during auto-calibration, it will exit and try again in the next vacant transition.
FCC information and IC information
This device complies with part 15 of the FCC Rules and Industry Canada
license-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) This device may not cause interference, and (2) this
device must accept any interference, including interference that may
cause undesired operation. Modifications not expressly approved by
Lutron Electronics Co., Inc. could void the user’s authority to operate this
equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
